Pipishell PITUC1 User manual

Rolling Utility/Shopping Cart
V1.0
PITUC1
[email protected]

Supplies Parts List
Tools Needed for Assembly (Not Included)
Specification Parameter
Color: Black
Material: Iron tube
Product dimensions: 20"x 19"x 38.5"/41.5"(L x W x H)
Basket size: 15"x 13"x 20"(L x W x H)
Adjustable height: 38.5"~ 41.5"
Front wheel: 2.5"
Rear wheel: 7"
Net weight: 10.5 lbs
Max weight capacity: 66 lbs
Package includes: 1 x shopping cart 1 x user manual
1
BCD
E F
2 PCS
G
1 PC
H
1 PC
1 PC
A
4 PCS 6 PCS 2 PCS
Axle Cotter Pin Washer Spring
Hub Cap
Pliers Hammer
Back Wheel Adjustable Handle Shopping Cart
2 PCS

Introduction
Step 1 Step 2
Pipishell PITUC1 Rolling Utility/Shopping Cart
The handle can be adjusted from 38.5"to 41.5"to meet right height
2.5" rubber front wheels provide a sturdy and easy 360 degree rotation
7" rubber rear wheels let you handle any condition with ease
Assembly time: Less than 30 minutes
This products intended use is for carting groceries, sporting equipment, laundry items, etc.
Press the button on the handle (G) and lift
the shopping cart (H).
Unfold shopping cart (H) to expose the back
leg of cart. Slide axle (A) through hole in each
back leg. Center the axle and place two
cotter pins (B) in the two holes on the inside
of the back legs. Using pliers (not included)
bend cotter pins (B) to lock the axle into
place.
2
G
H
A

Attach the back wheels by placing a washer
(C), a spring (D), then another washer (C)
onto one end of the axle. Place one back
wheel (F) and one more washer (C) onto axle
and press against spring assembly until the
outer hole on axle is visible.
Center the axle and place two cotter pins (B)
in the two holes on the inside of the back
legs. Using pliers (not included) bend cotter
pins (B) to lock the axle into place.
3
Step 3 Step 4
B
×2
×2
CF
D
C
C

Insert another cotter pin (B). Using pliers (not
provided) bend cotter pin (B) to lock the
wheel into place on axle.
Using hammer (not provided) press the hub
cap (E) onto end of axle. Repeat step 4 to 6
for the other side.
4
Step 5 Step 6
B
×2
E×2

Adjustable Height- The handle of this
shopping cart can be adjusted from 38.5"to
41.5", which fits your different situational
needs. There are three gears that you can
adjust by yourself whenever you pull it or
push it, which is convenient for you to meet
the right height.
Assembly is complete. Enjoy using your
Pipishell rolling shopping cart.
