PJ Chonburi Parawood YZ8-16-079-048 User manual

YZ8-16-079-048
DO NOT RETURN TO THE STORE
Individual stores do not stock parts.
drop us an e-mail
For prompt, reliable service, please have your manual
ready.
THIS INSTRUCTION BOOKLET CONTAIN IMPORTANT
SAFETY INFORMATION. PLEASE READ IT CARFULLY
AND KEEP FOR FUTURE REFERENCE.
Visit our website: www.pjparawood.com
•Read each section carefully before starting. It is very
important that each step is performed in the correct
order. If these steps are not followed in sequence,
assembly difficulties will occur.
//
1-800-538-1489
Product Description: Activity Easel
Date of purchase:
If a part is missing or damaged, call our toll-free
customer service line. We will gladly ship your
replacement parts FREE of charge.
Need parts or assistance?
Lot number:
•Working spacious area, preferably on a carpet, near
the place the unit will be located.
[email protected]
• Do not use power tools to assemble your furniture.
Power tools may strip or damage the parts.
Manufactured by:
PJ Chonburi Parawood, Co., Ltd.
Physical address / Zip code:
928/1 Moo 1, T.Klong-kew, A. Bangbung,
Chonburi, 20220, Thailand
Contact number:
1-800-538-1489 / [email protected]om
Recommended no. of people needed for assembly : 2
Before Starting:
•Make sure all parts are included. Most board parts
are labeled or stamped on the raw edge.
Call us at: 1-800-538-1489
LIMITED WARRANTY
PJ Chonburi Parawood Co., Ltd. warrants its product to be free from defects in material and workmanship and agrees to
remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon
presentation of proof of purchase. This is solely limited to the repair or replacement of defective furniture components
and no assembly labor is included. This warranty does not apply to any product which has been improperly assembled,
subjected to misuse or abuse or which has been altered or repaired in any way. This warranty gives you specific legal
rights and you may have other rights which vary from State to State.
Page: 1 / 4

HELPFUL HINTS:
•Identify, sort and count the parts before beginning
assembly.
Easel
A
1 (Folding)
Easel's Leg
B
4
•Move your new furniture carefully. Two people are
needed to lift and carry the unit to its new location.
•Clean the product with your choice of furniture polish
and a soft cloth. DO NOT USE harsh chemicals or
abrasive cleaners.
PART LIST:
Tray
C
1
HARDWARE LIST:
Joint Connector Bolt (M6x20mm.) Allen Key
1
x 8
2
1
Page: 2 / 4

Repeat Step 2on another side of the Easel.
Extend the Easel (A) as the picture position.
Step 2
Step 3
Holding up the end side of the Easel (A), then, insert the Leg (B) into its position. Attach the Legs
(B) to the Easel (A) by using Joint Connector Bolt (1) with Allen Wrench (2).
Step 1
Assembly:
A
A
1
1
1
1
2
B
B
A1
1
1
1
2
M6x20mm.
A
B
B
M6x20mm.
Page: 3 / 4

Step 4
Step 6 Pull the Easel's legs (front & back) forward to move Dowel into lock position.
Step 5 Put the Tray (C) into its position.
Turn the Easel to up-right position
Finished Easel
Please make sure that all the objects are removed
before moving the assembled unit. The unit must be
lifted by more than one person, not dragged or
pushed. Failure to do will cause product damage,
instability, product collapse, and/or serious injury.
WARNING
Weight Limits:
This unit has been designed to support the maximum
loads shown. Exceeding these load limits could
cause sagging, instability, product collapse, and/or
serious injury.
C
C
C
8.8 lbs. (4 kg)
Page: 4 / 4
