Pl-audio Minipac 2004 dsp User manual

USER MANUAL

MiniPac 2004 DSP

FREE PROGRAMMABLE SYSTEM AMPLIFIER

✔powerful 4-channel amplifier „Handmade in Germany“

✔remarkable power (4 x 500W @ 4 Ohm or 2 x 1.000W @ 8Ohm)

✔front cooling system

✔free programmable DSP

✔audiophile Präsenz, small depth & light weight

USER MANUAL MiniPac 2004 DSP

Table of content

Chapter Page

Introduction 3

Safety instructions and intended usage 3

Transport and storage 4

Guarantee terms and conditions 4

Product short description 4

Technical data overview 5

Detailed product description 5

Technical data detailed 6

Scope of delivery 7

Construction and control interface 8

Signal flow DSP and connection panel 9

Mains connection 10

Usage on a mains power generator, XLR- and speaker connection 11

Bi-amp connection 12

Bridge Mode (BTL-Modus) 13

Netzwork communication, installation, limiter settings 14

Netzwork connection, LowCut-Function, possible usage 15

Connection examples 16

Loading of presets on the device, internal mixer 19

DSP control via Software PL-audio DSP Control, Firmware update process 20

Restore firmware and bootloader 21

Safety during operation, maintenance 22

Limiter table 23

Disposal, Impressum 24

Introduction

Congratulations on purchasing a PL-audio product! Your investment in the PL-audio brand guaranteed

quality and products "Made in Germany", excellent functionality, an almost unbeatable price /

performance ratio, as well as direct and uncomplicated customer service.

We created this manual to ensure an easy start with your newly purchased product. Before you start using

your new product please read this manual carefully and keep it at your hands for future reference

Safety advise and intendeds usage

In order to enjoy your device for a long time please make sure to follow the informations noted

hereunder:

•The device complies with the necessary directives of the EU and therefore it carries a CE mark.

•This device left our factory in perfect technical condition. In order to ensure saf opereation, the user

must absolutely observbe the following saftey and warning notices:

•The devicve is supplied with dangerous mains voltage (>50 Volt AC). Therefore

never intervene on the device on yourself! There is a risk of electric shock!

Connection cables has to be protected against crushing, tensile load and

bending. Cables and wires are to be laid or secured in such a way that no

one can trip over it or may fall.

•Use the device only for the applications recommended by PL-audio or which can be found in this

manual. In the event of improper use any warranty claims become obsolet and void.

•Use the device only indoor and protect it against dripping and splashing water, high humidity, heat and

direct sunlight.

•Do not place any objects filled with liquids, such as drinking water glasses,…, on the product.

•The heat generated by the amlipier modules must be dissipated by technical forced ventilation. The

built in fan switches on at a device temperature exceeding 60 and switches of at a device temperature

of 40 degrees. For this reason, do not cover the ventilation openings on the housing under any

circumstances. The device exhausts the warm air through the front grille.

•Do not put the device into operation and immediately pull the power plug of the device out of the

socket:

1. if there is visible damage to a device or to the power cord,

2. if after a crash or compartable mishandling there is a suspicion of a defect,

3. if malfunctions occur.

•In any case, send the devices back to PL-audio for inspection / repair. Please send any devices in

sufficient outer packaging to the PL-audio production site. You can find this on the website www.pl-

audio.de. Transport damage due to insufficient packaging on the part of the sender cannot be claimed.

A corresponding pre-registration of a claim with a precise description of the fault - so that the devices

sent in are correctly assigned - is inevitable.

•Never pull the power plug out of the socket by just pulling on the cable, always take hold of the power

plug.

•Only use a dry, soft cloth for cleaning; never water or chemicals.

When using compressed air please pay attention to lubricant-free

compressed air and keep a minimum distance of 20 cm to the

individual parts.

USER MANUAL MiniPac 2004 DSP

Transport and storage

Secure and smart handling of our products helps you to keep the value of your device. In addition to this

you benefit for a longer time from the quality of your product.

For this reason, we ask you to note the following information in relation to above mentioned content

point:

It is essential to install the device in a–ideally shock-absorbing –19“-Flightcase, to protect the device

from transport- and handling damage. Please note that these flight cases are not the proper housing for

shipping with parcel services. Please ensure that there is sufficient air ventilation when installed. Make

sure to handle the device as gently as possible during transport. We recommend to transport the unit in a

horizontal position as shown on the cover (page 1). Always store the device at a minimum temperatrure

of 05° Celsius with low humidity and without large temperature fluctuations. Avoid to expose the device

to permanent direct sunlight.

Warranty conditions

PL-audio gives its customers a manufacturer's guarantee of 5 years on the MiniPac 2004 DSP product. This

guarantee is retained even if the product is resold within the EU and Switzerland. The guarantee period

begins with the purchase from an authorized sales or distribution partner or directly ex works. Please

keep the original invoice. This must be submitted for the submission and acceptance of any warranty

claims. This manual is an essential part of the product. Devices without a serial number (illegible or

removed serial numbers) cannot be accepted under any guarantee.

PL-audio disclaims liability for transport damage, rough handling and / or incorrect use, external

manipulation on and inside the housing, unauthorized repair attempts, faulty mains voltage or mains

connection, operation of the amplifier below the minimum ohmic value specified in the operating

instructions, effects of moisture, massive contamination from dust, incorrect operation of emergency

power systems (power generators, UPS systems, ...) and faulty feeds into the device. Furthermore, PL-

audio does not recognize any warranty or guarantee claims for any direct or indirect damage caused by

installation, configuration, manipulation or storage of the specified software and its components.

Devices which are covered under the guarantee conditions must be sent back to PL-audio after prior

notification. Please send the devices in sufficient outer packaging (ideally in the original packaging) to the

PL-audio production site. You can find this on the website www.pl-audio.de. Please note that any service

manipulation can lead to data errors or complete data loss on the device sent in. Data errors and / or data

loss are not covered by warranty or guarantee. You should therefore save your presets several times on

different storage media in the course of the configuration in your own interest.

In the event of any claim, no guarantee or subsidiary liability is assumed for upstream / downstream

products

Individual goodwill decisions on the part of PL-audio are always related to the respective individual case

and in no case represent an acknowledgment of any defects. In a recognized warranty case, PL-audio

decides on repair or replacement at its own discretion.

Product short description

Digital 4-channel power amplifier "Handmade in Germany".

The MiniPac 2004 DSP offers extensive functions that professional users need for many common sound

reinforcement tasks. The user interface, which has been deliberately kept simple, with a choice of 5 DSP

presets and a volume control on the front, makes the MiniPac 2004 the ideal installation power amplifier,

not just because of its compact dimensions. Audiophile presence, low weight and a freely programmable

DSP are features that mobile DJs, musicians or sound engineers need for smaller sound reinforcement

tasks. The MiniPac 2004 DSP solves a wide range of sound reinforcement tasks with flying colors.

USER MANUAL MiniPac 2004 DSP

Technical data overview

Product detailed description

The PowerPac 2004 DSP has two identical power amplifier modules. A digital signal processor with a

multitude of setting options (X-Over, Compressor, Limiter, signal routing, parametric equalizer, delay, ...)

takes care of signal processing and loudspeaker management in a deliberately simple menu. The over-

complete connection field on the back has - in addition to the loudspeaker system connections (4-pin

Speakon®) - XLR signal loop-through for the input channels. This means that the MiniPac 2004 DSP is

ideally equipped, especially in the installation area, to handle signal processing and signal routing for

simple multi-channel systems, while at the same time being simple to operate and comparatively low in

weight.

USER MANUAL MiniPac 2004 DSP

4-CHANNEL CLASS D AMPLIFIER: 4 X 500 W OR

2 X 1000 W MONO-BRIDGED INPUT-LIMITER AND PEAKLIMITER

switch-on current limitation Protection circuit

Mains fuse protection Under- and overvoltage protection

DC –protection temperature monitoring

silent fan Signal-noise rate < 120 db (20 Hz –20 Khz)

Distrotion THD+N under 0,05% (20 Hz –20 Khz) 2 HE aluminum casing

Wide range power supply with voltage detection and

automatic switching 120V –230V Detph 210 mm

Weight 2,8 kg Switch on/off on front

Powercon In –out 4 x Speakon 4 pole out for system connection

2 x XLR in und out Gain fader on front panel

HIGH END DSP ON BOARD REAL TIME OPERATION VIA ETHERNET AND USB

(OPTIONAL W-LAN)

Simple operation

5 presets direct accessable –80 presets through PC 96 Khz Sampling-Rate

120 db Dynamic Range flexible routing

X –Over Function 20 parametric EQ’s

Limiter- and Noisgate-Function short- and long delay

Phase Firmware –Upgrade over interface

APP in preperation

Technical data / detailed

USER MANUAL MiniPac 2004 DSP

Output Power 8Ω @ 1% THD+N 1kHz

1 400W 8Ω

2 400W 8Ω

3 250W 8Ω

4 250W 8Ω

Output Power 4Ω @ 1% THD+N 1kHz

1 500W 4Ω

2500W 4Ω

3 500W 4Ω

4500W 4Ω

Ampolification

factor

1 26dB

2 26dB

3 26dB

4 26dB

Amplifier

-Technology Class D

BTL-Mode: 32dB

BTL-Mode: 1.000W 8Ω

BTL-Mode: 32dB

BTL-Mode: 1.000W 8Ω

DSP-Technology

Preset memory (internal)

Input-Impedancy

Max. Input level

Bit rate

DSP-G2.3

20kΩ

+24dBu / 12V RMS

64Bit

Sampling rate 96kHz Sample-Rate

120dB (A)

0,6 ms

0,005% /8Ω, 1kHz

118dB (A) /8Ω, 1kHz

10Hz-25kHz

USB 1.1

Input Dynamic Range

Latency DSP

Distortion factor THD+N

Signal to noise-rate

Frequency range

USB

Ethernet

Input-Delay

Output-Delay

10MBit, with DHCP Server, Auto/Manual IP-Adress

800 ms / 274m (Input 1+2)

5 ms / 1,715m (Output 1+2+3)

Voltage

range

Automatic

voltage detection

AC Range 1 / 120V

85V

- 138V AC (US-Voltage)

AC Range 2 / 230V

170V

- 265V AC (Europe-Voltage)

Frequency

range

45Hz

–65Hz

Power

consumption at 230V

Standby

0,72 Watt / 0,026A

Idle

4 x 16,5 Watt =33 Watt / 0,14A

Rated

power consumption (without reactive current)

4 x 95 Watt = 380 Watt / 1,65A (

Ch 1+2 8Ω)

4 x 175 Watt = 700 Watt / 3,04A (

Ch 1+2 4Ω)

Maximum

1.400 Watt / 6,09A

Switch on

peak voltage @230V

32,5A

Switch on

peak voltage @115V

17,0A

= Amplifier ON –operation ready with no Input/Output-signal

Measurements

Width

482mm (19“)

Heigth

89mm (2HE)

–with rubber feets 92mm

Depth

210mm

–with operation controls 230mm

Weight

2,8 kg

Technical data / detailed

Scope of delivery

Beside the MiniPac 2004 DSP you can find following components in the carton box:

•Mains cable with PowerCon®-male connector. Please do just use this cable without any manipulation

on the cable itself.

IMPORTANT: Before you operate the MiniPac 2004 DSP you have to do the required settings in the free

downloadable software. If you use the MiniPac 2004 DSP directly out of the carton box without the

necessary settings fitting your requirements, connected speakers may get damaged or at least will not

bring their full power or sound capabilities!

How you can conduct these settings with the software (for PC and Mac, free of charge) is explained in

detail in the corresponding hand book for the digital signal processor (Operation manual DSP G2.3,

download www.pl-audio.de).

USER MANUAL MiniPac 2004 DSP

Protection

circuits

True

-RMS Compressor & Limiter for all Inputs and Outputs

Switch On and Switch Off

-Delay of Outputs

ICL

Inrush Current Limiter

Intelligent

current limitation prevents the triggering of fuses

Peak

current Limiter on the speaker outputs

-Protection on the speaker outputs

High

frequency protection on the outputs (>30kHz, 2Sek)

Temperature

observation with output power reduction by overheating

Temperature

range

Environment

tempereature

5°C bis +40°C not condensing!

Fan switch on

temperature

°C

Fan switch off

temperature

°C

Output power

reduction

°C

Temperature

–Emergency shut down

°C

Colling

concept

Air, front In

→front Out, 1-speed

Fan

80mm, 30cbm/h, 35db(A)

Construction and control interface

Following elements are located on the front side of the device (from left to right):

Following connectors and elements are located on the backside of the unit (from left to right):

USER MANUAL MiniPac 2004 DSP

Nr.

Element

Mains switch

Fan

Preset

selector with LED-indicator of loaded presets 1-5

Ethernet

connector for Netzwork connection of the DSP via Router or Computer

LowCut

button with control-LED (illuminates if filter is switched on)

Gain

Signal

-/Limiter-LED

Signal,

-24dB to around-

6dB

red

=Clip/limiter

Nr.

Element

XLR Input

symmetric

XLR Out

symmetric signal pass through

4 pol.

Speakon® connector for Bi-Amp operation (CH 4 = 1+/1-; CH3 = 2+/2-)

4 pol.

Speakon® connector for system cabling (CH 3 =1+/1-, CH 4 = 2+/2-) plus Bridged Mode connection

Mains connection 16A

Powercon® IN blue

Mains pass through connection 16A

Powercon® OUT grey

1 2 3 4 5 6 7

1 2 3 4 3 4 5 6

Signal flow DSP plus connections

USER MANUAL MiniPac 2004 DSP

XLR-Thru A & B for connection of eg.

additional amplifier or active speakers

Out 4 4

Mains connection

The device may only be connected to an electrical installation that complies with the VDE regulations

DIN VDE 0100. The electrical installation must be equipped with a residual current circuit breaker (RCD)

with> 30mA rated residual current.

The devicve is supplied with dangerous mains voltage (>50 Volt AC). Therefore never intervene on the

device on yourself! There is a risk of electric shock! Connection cables has to be protected against

crushing, tensile load and bending. Cables and wires are to be laid or secured in such a way that no

one can trip over it or may fall.

Damaged Mains-Power cables must not be used and should immediately be rendered unusable against

further use, e.g. cut off both plugs.

The device is powered by a Neutrik Powercon® connector. In contrast to a plug-in device (such as a

safety plug), the Powercon® plug-in connection must not be plugged in or disconnected under load and

also not under voltage! The consequences are stuck or burned-out contacts and the resulting loose

contacts lead to failures or even destruction of the electronics or even the risk of fire. You should

therefore only switch the device ON or OFF using the 2-pole power switch on the front panel of the unit.

The mains plug may only be connected to an earthed safety socket with the associated mains

connection cable. If extension cables are used, it must be ensured that the wire cross-section is

dimensioned and approved for the power supply required for the device! Make sure that the

mains voltage of the socket corresponds to the permissible voltage values in this manual.

The power supply of the amplifier is equipped with an intelligent mains voltage detection. It allows

worldwide operation on all power grids. After switching on, the electronics check the mains voltage

and switches the power pack to the correct voltage range 115VAC or 230VAC.

If a three-phase current generator is used at events on which the device is to be operated, the

correct mains voltage must be checked before connecting the amplifier! In the event of faulty

three-phase power supplies without a neutral conductor, a so-called neutral point shift can result

in up to 400Volt being applied to the protective contact sockets. This overvoltage leads to the

destruction of the electronics in the amplifier.

The device has a PowerCon®-Out (6) over the existing Powercon®-IN (5). This is provided for the option

of connecting another device through a short interlink PowerCon®-cable eg. when built in in a rack with

other amplifiers or other devices. Please make sure that the overall power consumption of all connected

devices does not exceed the maximum power of 16 Ampere, or the maximum allowed power limited by

the upstream line circuit breaker.

Please refer to the technical data for detailed information regarding power consumption of the MiniPac

2004 DSP.

Best option is to connect the MiniPac 2004 DSP to its own circuit with a 16A fuse (characteristic curve C).

Please refer to the technical data for the power consumption in the different operating states.

The device corresponds to protection class 1.

In the event of a thunderstorm or danger, pull the power plug out of the socket immediately.

To avoid ground loops, we recommend using symmetrical signal routing and the power distribution in

the so-called star point earthing, which means, all ground connections meet at one single point.

Never interrupt the contact to the protective conductor (e.g. by cutting off the protective conductor,

disconnecting the connection to the protective conductor through insulation, etc.), because in the

event of a defect this increases the risk of a electric shock over the metal housing.

USER MANUAL MiniPac 2004 DSP

10© PL-audio GmbH & Co.KG | Siegener Straße 6 | 57482 Wenden | www.pl-audio.de Version: October 2021 V 1.0

Power generator operation

If the amplifier is operated on a power generator, this is done at your own risk!

Extensive precautionary measures must be taken before connecting and operating your device on a

power generator:

•Use only high-quality, generously dimensioned power generators

•perPowerPacat least3kVA rated power

•If possible, switch on an under / overvoltage shutdown, this should be at U min.200VAC

undervoltage and U max. 250VAC overvoltage!

•Always load three-phase generators equally to avoid unbalanced loads, e.g. PowerPac 1 on L1,

PowerPac 2 on L2, PowerPac 3 on L3

•Load the generator permanently with a stable base load in order to absorb voltage fluctuations.

e.g. 1000W halogen lamp, electric heater etc.

XLR connection

XLR inputs can be connected both balanced and unbalanced. Symmetrical cables are to be preferred, as

they provide better protection against external interferences on long cable routes. Depending on the

operating mode or preset of the power amplifier, only certain XLR inputs are used. The

operating mode of the device can be set using the preset button on the front for the first 5

presets (1-5) and via the software for the remaining 75 presets (6-80)by loading the respective

preset. The inputs Input A and Input B can be controlled with signals up to +24dBu. The user has the

option of further processing the fed-in XLR signals via the XLR Out socket, e.g. in another PowerPac.

Pay attention to the following assignment of the XLR connection.

Speaker connection

Before loudspeakers are connected to the Speakon® outputs of the MiniPac 2004 DSP, reduce the

output level of the upstream components to the lowest possible value (e.g. fader down or left stop; )

in order to reduce/avoid any unwanted and possibly damaging noises in the connected loudspeakers.

Make absolutely sure that any upstream crossover or any upstream limiter is set correctly. Due to the

high output power of the MiniPac 2004 DSP, non complete or incorrect settings can damage the

connected loudspeakers due to overload!

The upper Speakon® outputs on the rear panel (page 8, lower picture, number 4)

are intended for the system cabling of PL audio systems. With the system cabling –

assuming the correct preset is selected - only a single 4-pin Speakon® cable is laid

between the power amplifier and a sub / top combination to each side of the system.

Pins 1 + / 1- are wired for the tops, pins 2 + / 2- for the bass. The lower Speakon® out-

puts are available so that third-party systems can also be conveniently wired using a

four-pole Speakon® cable. These are - also assuming the selection of the appropriate

preset - wired mirror-inverted to the upper connections (pins 1 + / 1- bass and 2 + / 2 tops).

When connecting the system using prefabricated connection panels, patchbays or adapter plugs /

adapters, make sure that the signals are correctly assigned to the correct components! This is of top

importance when using the MiniPac 2004 DSP for wiring bi-amp systems. Special care must be taken,

as possible incorrect cabling can quickly lead to the destruction of the mid-range or high-frequency

driver!

Important notice: Do never load the output channels with less than 4Ω!

USER MANUAL MiniPac 2004 DSP

Shield

Input Output

To connect a XLR-connection with non-symmetrical

Signal, Pin 1 and Pin 2 must be bridged.

Speakon® connector

Backside

2.6 Speaker connection

Before loudspeakers are connected to the Speakon® outputs of the MiniPac 2004 DSP the corresponding

preset must be loaded on the signal processor! Only with the correct presets, specially developed for the

loudspeakers by PL-audio reach their maximum performance, the best possible sound and the necessary

operational reliability.

By loading the wrong the speakers my sound bad and / or may be damaged through overload!

If you want to operate loudspeakers from other manufacturers on the MiniPac 2004 DSP, there are

enough free preset memory spaces available on the device! As a starting point we recommend the "01.

Sub + Top Standard“ preset to be loaded and sent to your speakers plus conducting the absolutely

necessary adjustments (gain, HPF, LPF, EQ, limiter, etc.).

Bi-Amp connection

2-way actively separated loudspeakers do not have a built-in passive crossover. On such loudspeakers,

each path has its own amplifier channel. An amplifier channel operates the midrange speaker (s) (e.g.

channel 2 - mid) while another amplifier channel drives the Tweeter(s) (e.g. channel 3 - high). This Bi-

Amp system uses a 4-pole Speakon® cable (page 8, item 3, rear panel) between Speakon® connector

and loudspeaker, where pins 1 + / 1- transmit the processed and amplified signal of channel 2 and 4,

while the processed and amplified signal of channel 1 and 3 is transmitted via pins 2 + / 2-. When

wiring bi-amp systems it must be worked out with particular care, as incorrect cabling quickly leads

to possible destruction of the high-frequency driver!

SELECTING THE CORRECT PRESET IS ABSOLUTELY CRUICAL FOR CORRECT OPERATION, CORRECT

CONFIGURED OUTPUT AND MAXIMUM SOUND QUALITY!!!

PL-audio Bi-Amp presets are usually locked in the signal processor with password protection in order to

prevent unintentional changing of the parameters. If you make changes here do this very carefully, with

caution and expertise! The signal processor allows very deep and detailed, but also serious changes in

the transmission parameters of the speaker system! To change the bi-amp presets, log in with the

password:"Admin1" in the administrator user level of the signal processor. Now you have full access to

change all necessary parameters.

This is easy and convenient with the PL-audio DSP-CONTROL software on the PC.

PL-audio Bi-Amp speakers without built in X-Over are:

TS 42

TS 61

TS 62

Banana Array

Big Banana Array Line

Array LA210

Line Array LA206

Line Array LA208

USER MANUAL MiniPac 2004 DSP

12© PL-audio GmbH & Co.KG | Siegener Straße 6 | 57482 Wenden | www.pl-audio.de Version: October 2021 V 1.0

IMPORTANT NOTICE FOR NORMAL OPERATION:

NEVER LOAD THE OUTPUT CHANNELS IN NORMAL MODE WITH LESS THAN 4Ω!!!

Example: 2 x 8Ω loudspeakers, connected in parallel result in 4Ω

2 x 16Ω loudspeakers, connected in parallel result in 8Ω

IMPORTANT NOTICE FOR BRIDGED MODE ON CHANNEL 1/2+3/4:

NEVER LOAD OUTPUT CHANNEL 2+3 IN BRIDGED-MODE WITH LESS THAN 8Ω!!!

In order to avoid overloading the power amplifiers, among other things, connect only ONE Speakon

connector® per power amplifier module 1 + 2 or 3 + 4 to your loudspeakers!

Damage to the amplifier modules due to overload due to low nominal impedance is not covered by

warranty or guarantee!

BTL-Mode

The bridged operation (BTL) couples the power from channel 1 + 2 (500W / 4Ω) and channel 3 + 4 (500W

/ 4Ω) to a strong 1x1000W / 8Ω mono channel. The maximum impedance is 8Ω, never connect 4Ω

loudspeakers!The BTL bridge operation increases the voltage gain from 26dB to 32dB (+ 6dB)!

Set-up BTL-Mode:

1. Connect the DSP to the PC. Start the software and open the control window.

2. In the MAIN window, switch on the link button (illuminates in blue) for channels 1/2 + 3/4

(linking Ch1 & Ch2 or Ch3 & Ch 4).

3. Make all settings for your loudspeaker in output Out 1 and Out 3 of the DSP.

4. Make sure you calculate the limiter with a gain factor of 32dB and set it correctly!

5. Now switch on the bridge mode in the PC software:

a) Click in the Menue on Hardware

b) Choose Configure →Output Mode →Outputs 1 and 2 and/or Outputs 3 and 4

c) Click on Bridge Mono

Connecting the loudspeaker in BTL mode:

Only use the two upper connection sockets on the connection panel for bridge operation! Make sure

that the Speakon® connectors are wired properly and protected against short circuits.

Speakon®-connector Loudspeaker,8Ω

1+ Pluspole, Channel 1/3(+)

1- Minuspole, Channel 1/3 (-)

2+ Pluspole, Channel 2/4 (+)

2- Minuspole, Channel 2/4 (-)

+ Pluspole Loudspeaker

- MinuspoleLoudspeaker

and are not accessable in the software

Out 2

In Bridge-Mono -mode all buttons of

ATTENTION: The bridge operation can NOT be set or recognized on the amplifier! You need a

computer with the DSP software to set the BTL bridge operation.

We recommend that power amplifiers with the BTL mode set be clearly marked or reset the BTL mode to

dual mode after using the MiniPac 2004DSP.

Never connect impedances with less than 8Ω to the amplifier in bridged operation !!!

USER MANUAL MiniPac 2004 DSP

All settings in the DSP controller must be made in Out 1 or Out 3.

Out 4

Network communication

Page8(MiniPac-front panel, item 4) Network / Ethernet Interface

With the network interface you can integrate the DSP controller into a local network, to control and

operate it remotely through longer distances with the PL-audio DSP-CONTROL software. If you connect a

wireless router to the network port, you can take advantage of wireless remote control with a W-LAN-

enabled device!

The network port also offers the option of connecting the DSP directly via a commercially available

network cable (up to 100m in length, CAT5e or higher) directly to a computer.

If the DSP is not automatically registered in the IP universe of the computer through the direct connection

PC → DSP , an intermediate router is required, which has DHCP server functionality that automatically

assigns an IP address that can be located by the computer.

The network port is designed as 10-Mbits Ethernet. RJ-45 connector standard.

Installation

Please note that if the device is cold and transported into a warm environment, condensation will form

inside the device. To avoid damage and malfunctions due to condensation / moisture, let the device

acclimatise first.

To avoid unpleasant and possibly damaging noises in the loudspeakers, always switch the individual

components on in the direction of the signal path. So first the player, then the mixer and only at the end

the power amplifiers. When switching off, just proceed in reverse order.

After switching on the device, a self-test and initialization are carried out. The fan runs up once for

approx. 4 seconds. During the start-up process, the loudspeaker outputs of the power amplifier are

muted and are activated automatically as soon as the power amplifier is ready for operation. This

protective circuit prevents unpleasant "cracking" noises in the loudspeakers.

The amplifier is ready for operation approx. 10 seconds after switching on.

Before switching on the power amplifier for the first time, it is not possible to check which volume or

which speaker preset is set! Therefore, please always turn the volume level of your signal source (mixer)

to a minimum.

ATTENTION: The power amplifier has a gain control on the front (page 8, upper figure, number 6)! To be

on the safe side, turn it all the way to the left BEFORE switching on. Alternatively, you can also unplug the

XLR signal cable or the Speakon® speaker cable.

When you have made all connections, switch on the amplifier, check whether the correct preset is loaded

and in-crease volume gently until you hear the signals from your speaker system. If you do not hear an

output signal on the connected loudspeakers, check the cabling again before turning the level up any

further. In any case, avoid the limiter LED lighting up continuously (page 8, upper figure, item 7). This not

only leads to a loss of sound, but can also damage connected speakers!

USER MANUAL MiniPac 2004 DSP

Limiter settings

If you program your own presets in addition to the factory presets, we strongly recommend that you

calculate and set the limiter settings for the respective channels precisely in order to protect your

connected speakers from overload! The limiters are already set at the factory presets.

Network connection

If you want to remotely monitor the DSP via W-LAN, for example, connect the network connection

socket (RJ 45) on the front to a suitable router or directly to your computer. You can then easily make

the settings on the computer and monitor the power amplifier remotely.

Limiter settings

If you should program your own presets in addition to the factory presets, we strongly recommend that

you calculate and set the limiter settings for the respective channels precisely in order to protect your

connected speakers from overload! The limiters are already preset in the factory presets.

LowCut-button (Page 8, uooer picture, item 5)

The LowCut button on the front can be used to switch a LowCut filter that can be programmed via the

software into the input path. To program, go to the "IN 1" menu of the software. At the bottom you will

find a button "HPF" with the option of entering the desired crossover frequency and the option of

selecting the filter slope via the drop-down menu. Here you can set or select both the frequency and the

slope. If you leave this input window empty, the LowCut switch on the front has no effect on the signal

reproduction.

If the "HPF" filter is activated in the software,

the associated red LowCut indicator LED also

lights up on the PowerPac 2004 DSP. After

saving the settings in the desired preset this

high-pass filter can can be switched on or off

using the LowCut button on the front of the

MiniPac 2004DSP.

The MiniPac 2004 DSP offers the user numerous possibilities:

The amplifier has 2 output channels per amplifier block, 2 x 500W 4Ω. This power is made available at

the Speakon sockets®, which are located one above the other for each power amplifier module. The

upper sockets are connected as system cabling sockets with Ch 1 to 1 + / 1-, Ch 2 to 2 + / 2- and Ch 3 to 1

+ / 1-, Ch 4 to 2 + / 2-, while the lower sockets are used as bi-amping sockets with Ch 1 on 2 + / 2-, Ch 2

on 1 + / 1 + and Ch 3 on 2 + / 2-, Ch 4 with 1 + / 1-.

Several configurations can be operated per power amplifier block (see examples below):

•Up to 2 subwoofers á 8 ohms and 2 tops with built-in crossover á 8 ohms.

•Up to two monitors with built-in crossover of 8 ohms plus, for example, two side or front fills of 8

ohms with built-in crossover

•many other combinations (e.g. multi-room or multi-speaker applications) in which the sum of the

nominal apparent resistance per power amplifier channel does not fall below 4 ohms.

If you connect an 8Ω loudspeaker to channel 1 or 2 of the MiniPac 2004 DSP, it receives 250W

into 8Ω. If an additional loudspeaker á 8Ω is added to channel 1 or 2, the impedance is reduced to

4Ω.The 500W (which are available at 4Ω) are now divided between both speakers, and each

speaker receives 250W at 8Ω. Calculation example: (250W 8Ω + 250W 8Ω = 500W 4Ω).

The same principle mentioned above applies to channels 3 + 4 of the MiniPac 2004 DSP.

The ideal use of the MiniPac 2004 DSP is as a system amplifier for smaller system applications - with

subwoofer and tops or - thanks to the extensive setting options of the built-in digital signal processor -

various multi-room or multi-speaker applications in the installation area. Last but not least, the MiniPac

2004 DSP can also drive smaller subwoofers with at least 8 ohms in bridge mode with 1kW.

The following examples give a brief overview of the various configuration options.

USER MANUAL PowerPac 2004 DSP

In 1

Connection example stereo to passive subwoofers and tops :

USER MANUAL MiniPac 2004 DSP

Mixer

XLR L/R

Speakon®

4-pol

Speakon®

4-pol

Signal flow (from mixing console to speakers):

XLR Out mixer to Input A/B In on the MiniPac 2004 DSP

Thru A/B from MiniPac 2004 DSP to external amlplifier or active speakers

Speakon® CH 3/CH 4 to Subwoofer R (2+/2-)

Speakon® CH 1/CH 2 to Subwoofer L (2+/2-)

Speakon® from Subwoofer R to Top R (1+/1-)

Speakon® from Subwoofer L to Top L (1+/1-)

Top L with

integr. X-Over

MiniPac 2004 DSP

Top R with

integr. X-Over

Subwoofer R

In the example given above, the MiniPac 2004 DSP takes on the supply of up to 2 subwoofers á 8Ohm

(500W) and up to two tops with integrated crossover á 8Ohm (500W) per power amplifier block. The

specific frequency range assignment for the subwoofer (Low Pass / HiPass) or the tops (HiPass) is made in

the DSP. With PL-audio, both components, subwoofer and tops ,can be connected to the upper Speakon

sockets® (CH 1 / CH 2 and CH 3 / CH 4) using a 4-pin Speakon cable®, whereby channel 2 + / 2- transmits

the bass signal and channel 1 + / 1- transmits the signal to the tops (mid & high). The signal assignment to

the midrange and tweeter in the tops is done by a crossover built into the tops. In the example above,

the XLR Thru could control the front or side fill via an external amplifier (e.g. MiniPac 2004 DSP). In this

case, please note that the signal coming from the input signal is looped through unchanged.

Subwoofer L

Eg. to an external power

amplifier with loudspeakers or

active loudspeakers for eg front

or side fill

XLR

Connection example MiniPac 2004 DSP in BTL-Mode as power amplifier for 8Ohm-Subwoofer:

USER MANUAL PowerPac 2004 DSP

Mixer

Topteil BiAmp

zB BananaArray

XLR L/R

Speakon®

4-pol

XLR

Speakon®

1+ to Speaker+

2+ to Speaker -

Signal flow (from mixing console to speakers):

XLR Out mixer to Input A/B In on Block 2 PowerPac 4004 DSP

Thru A/B from Block 2 to Input A/B Block 1 PowerPac 4004 DSP

DSP Out Channel 1 from Block 1&2 to Input A/B MiniPac 2004 DSP

Speakon® BiAmp Out Block 2 to BananaArray R

Speakon® BiAmp Out Block 1 to BananaArray L

Speakon® SPECIAL CABLE to Subwoofer (Modul 1 & 2) pls see connection graph on page 13

Topteil BiAmp

zB BananaArray

Subwoofer

min. 8 Ohm

PowerPac 4004 DSP

MiniPac 2004

Speakon®

4-pol

In this example, the inputs A / B of the MiniPac 2004 DSP receive the Hi- and Low-Pass processed

subwoofer signals from an external power amplifier with DSP (here the PL-audio PowerPac 4004 DSP) or

a crossover. In this example, the MiniPac 2004 DSP drives an 8-ohm subwoofer in BTL mode (Bridge Tied

Load) with a maximum output of 1.000 watts at 8 ohms per power amplifier module using a specially

wired Speakon cable® (1+ to subwoofer + and 2+ to subwoofer -).

Subwoofer

min. 8 Ohm

Speakon®

1+ to Speaker+

2+ to Speaker -

XLR

Multi zone connection:

USER MANUAL PowerPac 2004 DSP

Speakon®

4-pol

Zone 1

Zone 2

Zone 3 Zone 4

MiniPac 2004 DSP

MiniPac 2004DSP

Speakon®

4-pol

2 woofer á 8Ohm plus 4 Tops á 16Ohm

1 Woofer 8Ohm plus 4 Tops á 16Ohm

XLR Out to additional MiniPac 2004DSP to 4 pcs TS41

XLR Out to active speakers

XLR A/B

XLR B

XLR A

In the example outlined here, the MiniPac 2004 DSP supplies up to 2 subwoofer á 8Ohm (500W) and up

to four tops with an integrated crossover á 16Ohm (500W) per power amplifier block. Both components,

subwoofers and tops, can be connected to the upper Speakon sockets® using a 4-pin Speakon cable®,

whereby channel 2 + / 2- transmits the bass signal and channel 1 + / 1- transmits the signal to the tops

(mid & high). The signal assignment to the midrange and tweeter in the tops is done by a crossover built

into the respective tops.

In the example above, the loudspeaker groups are divided into different zones. For this example, it is very

likely that you will not use the stereo sum of the mixer, but rather deliver an individual matrix mix to the

two inputs A and B. The XLR-Thru is fed to 4 passive loudspeakers (e.g. TS 41) via an external four-

channel amplifier (e.g. MiniPac 2004 DSP) using an XLR cable. In this case, please note that an individual

signal or level adjustment on the output side is not possible for the XLR Thru, as the signal is looped

through directly and unchanged. The volume for the 4 TS41s in Zone 3 listed in the example - driven by a

MiniPac 2004 DSP - could be achieved here, for example, using the frontside located gain control of the

MiniPac 2004 DSP in Zone 3.

Loading of presets on the device

Load preset:

–Press the preset selection button on the front (page 8, upper figure, number 3) until you have reach-

ed the desired memory location with the control LED. At memory location 5 the selection jumps back

to 1 after pressing it again.

–Allow the DSP a few seconds to load the preset properly before sending a signal to the inputs.

The preset is now in the signal processor and the parameters are executed.

Tip: When configuring for installation purposes, we recommend that you save the installation configuration

identically in memory locations 1-5, so that if you accidentally press the preset selection button, undesired

configurations and any associated undesired sound parameters do not occur.

Mixer

Using the built-in DSP, the signal curve and the signal level can be set individually for each input and output

channel via the mixer. Inputs A & B and outputs 1 & 2 or 3 & 4 can be linked in pairs using the link buttons

below the respective faders. When the function is switched on, the color of the button changes from gray to

blue. Any settings can only be made in input A and outputs 1 and 3 for linked inputs and outputs.

The values are adopted directly for

input B and outputs 2 and 4.

For the respective outputs, the mixer selects which input signal is used at which level. When using the output

for a subwoofer, we recommend using the input signal from both inputs. For stereo localization, the input

channel that is signal-relevant for the respective output is used (e.g. input A for left →in the mixer input A

to the desired value, while input B is set to “mute” using the fader).

USER MANUAL PowerPac 2004 DSP

Up to 80 presets can be stored in the flash memory of the DSP controller. You can load the first 5 presets

from a list with a maximum of 80 presets stored in the memory using the preset selection button on the

front panel (page 8, upper picture, number 3). The presets that cannot be called up using the button on

the front of the MiniPac 2004 DSP can be called up using the software and, if necessary, also reconfigured

to the first five memory locations.Presets can be labeled with up to 16 characters. Please do not use any

special characters when naming.

DSP control via PL-audio DSP Control

User levels / Access-Level (Password protection)

Firmware Update Process

USER MANUAL PowerPac 2004 DSP

To prevent inadvertent or undesired changes to the signal processor during operation or when renting /

lending, the DSP can be locked with password protection. (Access Level: Locked)

In the PL- Audio DSP-Control software click in the control window on the menu item:

Hardware → Lock Unit → Confirm the upcoming advise with OK.

The DSP has 3 user levels, which can be called up by entering the corresponding password.

1: Locked –Level

2: User –Level

3: Admin –Level

DSP Locked

Password: PLAudio1

Password: Ad_min

If you have blocked DSP access via the display or the control window on the PC, all setting options in the

controller cannot be configured.

To regain access, enter the passwords for either the user or admin level via the display or the control

window on the PC and activate the user rights. All setting options can now be called up again.

The input field for the password in the computer software can be found in the control window under

the menu item

Hardware → Enter Passwort→ now the input window opens in the software.

In order to always have the latest firmware on the signal processor, you should carry out a firmware

update regularly. The update can only be carried out with a PC. Please always download the latest DSP

control software from the PL-audio homepage and install it on your computer.

This application contains 2x the firmware uploader.

Once in the network manager for a complete new installation and in the control window under the

menu item Hardware → Firmware Update

Important: Please note that with a firmware update all presets saved on the flash memory of the DSP

will be lost. It is therefore essential to save these presets on your computer BEFORE an update!

For the firmware update you should preferably use the network interface on the DSP, since the bootloader

of the network chip is updated at the same time.

Table of contents

Other PL-AUDIO Amplifier manuals

PL-AUDIO

PL-AUDIO D6K4 User manual

PL-AUDIO

PL-AUDIO PowerPac 4003 DSP User manual

PL-AUDIO

PL-AUDIO PowerPac 4004 DSP User manual

PL-AUDIO

PL-AUDIO PowerPac 5002 User manual

Popular Amplifier manuals by other brands

Spectron

Spectron SPA2150 owner's manual

Kramer

Kramer VM-114H2C user manual

Duncan

Duncan KTG-2075 owner's manual

Fortin Amplification

Fortin Amplification SIGIL quick start guide

NAD

NAD M33 user manual

NAD

NAD 114 datasheet

Kicker

Kicker CX.1 Series owner's manual

Blaupunkt

Blaupunkt MPA 4 Fitting instructions / operating instructions

Indiana Line

Indiana Line MIO Kit owner's manual

Monacor

Monacor PA-900 instruction manual

Toa

Toa KD-1 Operating instructions manual

SPHINX

SPHINX Project Two MKII Service manual

IKUSI

IKUSI NBS-600 Series manual

Sony

Sony TAE-8450 Service manual

Massive Audio

Massive Audio Nano Block N3 instruction manual

pro bel

pro bel V6271 user guide

Sony

Sony TA-E511 operating instructions

Tecamp

Tecamp Raptor Top manual

PL-AUDIO MiniPac 2004 DSP User manual

Popular Amplifier manuals by other brands
