Planar PUD3200 User manual

User’s Manual
PUD3200
USB 3.0 Dual Display Dock
www.planar.com

Content
Introduction ...................................................................................................1
Application .....................................................................................................
.........................................................................................
1
Features ...........................................................................................................2
System Requirements ................................................................................. 2
Package Contents 3
Front Panel .....................................................................................................3
Rear Panel .......................................................................................................4
Specications ................................................................................................4
Planar Support ..............................................................................................6
Regulatory Compliance ............................................................................. 6

Introduction
Application
Planar's USB 3.0 Universal Dual Display docking station enables
multiple USB devices to be connected to the computer using a single
USB 3.0 cable. Now with one simple cable connection to your
computer you can have access to large screen displays, stereo
speakers, external hard drive, optical disk drive, printer, USB keyboard
and mouse.
Any notebook can connect to the USB 3.0 Dual Display Dock.
Notebook upgrades no longer require the purchase of a new docking
station. Mac and Windows based computers, including ultra
notebooks and tablets, with USB3.0 or USB2.0 port are compatible.
Just plug in one USB 3.0 cable from the USB 3.0 Dual Display dock to
any USB 3.0 or USB 2.0 port on your laptop and your displays and
accessories will be activated in seconds. To undock, simply unplug
the one cable and go.
1
USB Peripherals
Ethernet Device
DVI / HDMI Monitor
USB 3.0 Port
Power Connection
Mobile Device Charging
USB 3.0 Peripherals
Earphone & Mic

2
Features
System Requirements
USB Downstream
■Compliant to USB 3.0 and USB 2.0.
■Two USB3.0 down-stream ports supports Super-speed,
high-speed and full-speed trac.
■Four USB2.0 down-stream ports support Super-speed,
high-speed, full-speed and low-speed trac.
■Supports USB Battery Charging Specication v1.2 (SDP,
CDP, DCP)on 1 USB3.0 down-stream port.
Ethernet
■IEEE 802.3, 802.3u, and 802.3ab compatible.
■Supports IPv4/IPv6.
■Supports full duplex operation with IEEE 802.3x ow control.
Video
■Dual digital video outputs.
■Extended Desktop (Default), Mirrored Desktop, Primary Display.
■Supports High Resolution up to 2048 x 1152.
Audio
■2 CH Stereo output & Mic-in with a combo jack.
■One available USB port
■One of the following operating systems
Windows®XP / Windows®7 / Windows®8 / Windows®8.1
Mac OS 10.6®and Later

3
Package Contents
Front Panel
Before installation, please check the items of the package. The
package should contain the following items:
■USB 3.0 display dock x1
■Power Adapter x1
■USB 3.0 Cable x1
■Driver CD with User’s Manual x1
■Quick Start Guide x1
Power LED:
Glows when the docking station is powered.
3.5 mm stereo audio output port:
For connection to stereo headphones or
speakers.
USB 3.0 downstream port:
For connection to USB peripherals.
USB 3.0 downstream & charging combo port: For
connection to USB peripherals. Or connection
and charging the mobile device.

4
Rear Panel
Specications
4 USB 2.0 downstream ports (A type female connector):
For connection to USB peripherals.
10/100/1000 Mbps ethernet port:
For connection to the Ethernet network via a network
cable.
DVI video output port:
For connection to a HDMI monitor.
DVI video output port:
For connection to a DVI monitor.
USB 3.0 upstream port:
For connection to the USB3.0 port of the host computer.
Power jack:
For connection to the provided power adapter. The Docking
Station always needs external power supply for operation.
Security lock slot:
Industry-standard Kensington® security slot.
General
Host Interface Compliant with USB specification 3.0, 2.0
Operating System
Support
Windows XP
Mac OS 10.6 and later
, Windows 7, ,Windows Windows8 8.1
Ports and Connectors
Upstream 1 x Upstream USB 3.0 Port (Type A male Connector)
USB Hub
Downstream
4 x Downstream USB 2.0 Port (Type A female connector)
2 x Downstream USB 3.0 Port (Type A female connector)

5
* Specication is subject to change without further notice.
Ethernet 1 x Ethernet Port (10/100/1000 Base-T Ethernet RJ-45 connector)
Video 1 x DVI-I Port (24pin + 5pin Female Connector)
1 x HDMI 19pin Female Connector
Audio 1 x Microphone/Speaker combo (3.5 mm stereo audio in)
Security Lock Slot
Industry-standard Kensington® security slot
LED
Power LED (Blue) On: Power is supplied to the Display dock.
Off: No power is supplied to the Display dock.
Power
Power Mode Self-powered
Power Adapter Input: AC 100-240V, 50~60 Hz
Output: DC 19V / 2A
Power
Consumption
Operation Mode: 14.43W
Suspend Mode : 0.5W
Features
USB Downstream
Compliant to USB 3.0 and USB 2.0
Two USB 3.0 down-stream ports supports Super-speed,
high-speed and full-speed traffic

6
Planar Support
Cables and Accessories
Technical Support
Planar Support
Tel: 1-866-PLANAR1 (866-752-6271) or [phone] outside the US.
Hours: 24 hours a day, 7 days a week.
Toll or long distance charges may apply.
To nd cables and accessories for your Planar monitor, touch screen or other
Planar products visit our online store at www.PlanarOnline.com.
Visit Planar at http://www.planar.com/support for operations manuals,
touchscreen drivers, warranty information and access to Planar's Technical
Library for online trouble shooting.
To speak with Planar Customer Support please have your model and serial
number available and dial:
Regulatory Compliance
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
FCC Caution:
Any changes or modications not expressly approved by the party responsible
for compliance could void the user’s authority to operate this equipment.
