3 . Notes and Precautions
 When the office dock is connected, the USB 3.0 port on your T800 will be
disabled.
 DO NOT touch the connectors of the office dock.
 DO NOT attempt to make connections if there is any object between the
computer and the office dock. Doing so could damage the computer and
the office dock.
 DO NOT attempt to move the office dock when it is connected to the
computer.
 If the computer malfunctions while the office dock is connected, turn off
the computer and disconnect the office dock. Connect the AC adapter to
the computer and check to see if the computer operates normally. If the
computer operates normally, the office dock may be malfunctioning.
 DO NOT place metal objects or containers of liquid on top of the office
dock. If paper clips, coins, or other metal objects, or water, or other
liquid spills, get inside the office dock, fire or electric shock may result.
Immediately unplug the power cable and remove the computer from the
office dock.
 Unplug the power cord and remove the computer from the office dock if
any of the following malfunctions occur:
– the office dock is damaged
– smoke is emitted
– an unusual smell is emitted
– the office dock is unusually hot
Continuing to use the office dock while any of the above conditions are
present may result in fire or electric shock.
Rugged Mobile Computing Solutions
T800
OFFICE DOCK
QUICK START GUIDE
561812210003 R00

1 . Introduction
The office dock duplicates most of your computer’s ports and provides extra
ports.
With peripheral devices such as a keyboard, mouse, monitor, and printer all
connected to the office dock, you have a handy work area on your desk.
2 . Installation
1. Push the release latch toward the right. The holding clamp will slide up
slowly.
2. Align the connector and place T800 on the dock. Press down the holding
clamp until it clicks into place.
3. Connect the cables of peripheral devices to the corresponding
connectors on your office dock.
4. Connect the AC adapter to the office dock. The DC-In LED lights up.
See reverse side for notes and precautions.
USB 2.0 Port x 3
Power Connector
VGA Port
LAN (RJ-45) Port
Microphone Connector
Docking Connector
Audio Output Connector
Release Latch
Holding Clamp
USB 3.0 Port
DC-In LED
Kensington Lock
