ICA-107_W_P
Wired / Wireless / PoE CMOS IP Camera
Key Feature
Data Sheet
Searching for a powerful and economical Internet Camera? PLANET is glad
to introduce our ICA-107/ICA-107W/ICA-107P. Those Internet Cameras
have an Integrated Microcomputer and a high quality CMOS digital-Image-
Sensor, enabling it to display high quality live streaming video over your
LAN and the Internet.
The motion detection in the ICA-107 series can notify users via email or ftp
when detecting any movement. With its admin software, no expertise
required, your first surveillance network can be easily, efficiently established
in few minutes.
ICA-107W support 802.11b/g wireless network, that will save your time
and cost for wiring. And ICA-107P has provided 802.3af standard PoE
interface. It can help you to locate the camera to the location that is no
power outlet. With the Windows based utility, IP Camera Viewer, the ICA-
107 series could take a snapshot, record and playback the video files.
1
• Easy Configuration
The network administrator can configure and manage the camera via
Windows-based utility or web interface based on 10BaseT/100BaseTX
Ethernet with Auto- MDIX or 802.11g wireless interface (ICA-107W).
Supporting TCP/IP networking, SMTP e-mail, and HTTP network
standards, PLANET ICA-107 series can be applied and utilized in the
mixed IP network environment
• Meeting SOHO
business, or public facilities surveillance needs. PLANET ICA-107 series
can be deployed in many different situations, such as library, train
station or factory production line to provide efficient, human-resource
reducing, and offers flexibility, affordability, and reliability for the
proper surveillance of manufacturing facilities
• Support Windows-based and Web-based Monitoring Utility
These tools allow users to access the Internet Camera from a remote
site via Intranet or Internet. They also provide users to make function
configuration including image monitoring, recording images to a hard
drive, viewing up to 32 cameras on one screen, snapshots and so on
• Simultaneous Viewing
This Internet Camera allows multiple users login to view live video
simultaneously. The advanced video compression produces a high-
quality, high-frame rate, VGA,QVGA video stream
• Motion Detection
Monitors any suspicious movement in front of the camera
• Supports DDNS & UPnP
The camera also supports UPnP and DDNS. DDNS allows the camera
to use an easier to remember naming format rather than an IP
address. UPnP will allow users of Windows XP to access the camera
with the click of a mouse without knowing IP address of the camera

PLANET reserves the right to change specifications without prior notice. All brand names and trademarks are property or
their respective owners. Copyright©2007 PLANET Technology Corp. All rights reserved.
07-07 C-ICA107_W_P-1
PLANET Technology Corporation
11F, No. 96, Min Chuan Road, Hsin Tien, Taipei, Tawian R.O.C.
Tel: [phone]  Fax: [phone]
Email: [email protected] www.planet.com.tw
VoIP Gateway: vip.planet.com.tw
CMOS IP Camera
Wireless CMOS IP Camera
PoE CMOS IP Camera
ICA-107
ICA-107W
ICA-107P
Wired / Wireless / PoE CMOS IP Camera
Product
Specification
Ordering Information
Data Sheet
2
Model
Hardware
Sensor
Focus
LAN
Wireless
Encryption
PoE Interface
Image (Video Setting)
Image Compression
Video Resolution and Frame Rate
Image Quality
Environment
Operating Temperature
Power Requirement
EMC / EMI
Network and Configuration
Connection Type
Management
Remote monitoring application (Home)
Applications
ICA-107   ICA-107W   ICA-107P
Micron MI-360 300,000 Pixels CMOS Sensor
Manual Focus, F=1.8
1 x 10/100Base-TX RJ-45
-    802.11b/g   -
-    WEP, WPA-PSK, WPA2-PSK  -
-    -   802.3af
M-JPEG
640 x 480 (30fps), 320 x 240 (30fps), 176 x 144 (30fps)
5 Level
0~45 Degree C, 10~90% (Non-Condensing)
12V DC
CE, FCC
Static IP, DHCP
Web, Camera Utility
Office
ICA-107W ICA-107 ICA-107P
WAP-4035
PoE
Internet
