Planet Networking & Communication ICA-510 User manual

Dual Mode CCD Dome Internet Camera
ICA-510
User’s Manual

Copyright
Copyright (C) 2008 PLANET Technology Corp. All rights reserved.
The products and programs described in this User’s Manual are licensed products of PLANET
Technology, This User’s Manual contains proprietary information protected by copyright, and this
User’s Manual and all accompanying hardware, software, and documentation are copyrighted.
No part of this User’s Manual may be copied, photocopied, reproduced, translated, or reduced to
any electronic medium or machine-readable form by any means by electronic or mechanical.
Including photocopying, recording, or information storage and retrieval systems, for any purpose
other than the purchaser's personal use, and without the prior express written permission of
PLANET Technology.
Disclaimer
PLANET Technology does not warrant that the hardware will work properly in all environments and
applications, and makes no warranty and representation, either implied or expressed, with respect
to the quality, performance, merchantability, or fitness for a particular purpose.
PLANET has made every effort to ensure that this User’s Manual is accurate; PLANET disclaims
liability for any inaccuracies or omissions that may have occurred.
Information in this User’s Manual is subject to change without notice and does not represent a
commitment on the part of PLANET. PLANET assumes no responsibility for any inaccuracies that
may be contained in this User’s Manual. PLANET makes no commitment to update or keep current
the information in this User’s Manual, and reserves the right to make improvements to this User’s
Manual and/or to the products described in this User’s Manual, at any time without notice.
If you find information in this manual that is incorrect, misleading, or incomplete, we would
appreciate your comments and suggestions.
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the Instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
CE mark Warning
The is a class A device, In a domestic environment, this product may cause radio interference, in
which case the user may be required to take adequate measures.
Trademarks
The PLANET logo is a trademark of PLANET Technology. This documentation may refer to
numerous hardware and software products by their trade names. In most, if not all cases, these
designations are claimed as trademarks or registered trademarks by their respective companies.
WEEE WarningTo avoid the potential effects on the environment and human health as a result of
the presence of hazardous substances in electrical and electronic equipment, end
users of electrical and electronic equipment should understand the meaning of the
crossed-out wheeled bin symbol. Do not dispose of WEEE as unsorted municipal
waste and have to collect such WEEE separately.
Revision
User’s Manual for PLANET Dual Mode CCD Dome Internet Camera
Model: ICA-510
Rev: 2.0
Part No.: EM-ICA510
ICA-510 User Guide
2

Table of Contents
1. Introduction.................................................................................................................. 5
1.1 Package Contents................................................................................................... 5
1.2 System Requirements............................................................................................. 6
1.3 Features.................................................................................................................. 6
1.4 Application............................................................................................................... 7
1.5 Outlook.................................................................................................................... 7
1.5.1 Connectors ................................................................................................. 8
1.6 Technical Specifications .......................................................................................... 9
2. Installation.................................................................................................................. 10
2.1 Physical Installation............................................................................................... 10
2.2 Software Installation.............................................................................................. 12
2.3 Software Quick Configuration................................................................................ 16
3. Viewing Live Video .................................................................................................... 21
3.1 Connecting ICA-510 via Ethernet.......................................................................... 21
3.2 General Options.................................................................................................... 24
3.2.1 Directly zoom in / out the image ............................................................... 25
3.2.2 Language.................................................................................................. 25
3.2.3 Setting ...................................................................................................... 26
3.2.4 Client setting............................................................................................. 26
3.2.5 Image setup.............................................................................................. 27
4. Basic Setting.............................................................................................................. 28
4.1 System .................................................................................................................. 30
4.1.1 Information................................................................................................ 30
4.1.2 Date/Time ................................................................................................. 31
4.1.3 Initialize..................................................................................................... 32
4.2 Camera ................................................................................................................. 33
4.2.1 General..................................................................................................... 33
4.2.2 MPEG4 – Computer view ......................................................................... 35
4.2.3 MPEG4 – Mobile view .............................................................................. 37
4.2.4 MJPEG ..................................................................................................... 39
4.3 Network................................................................................................................. 40
4.3.1 Information................................................................................................ 40
4.3.2 PPPoE...................................................................................................... 42
4.3.3 DDNS ....................................................................................................... 43
4.3.4 UPnP ........................................................................................................ 44
4.3.5 IP Notification ........................................................................................... 45
4.4 Security ................................................................................................................. 47
4.4.1 Account..................................................................................................... 47
4.4.2 HTTPS...................................................................................................... 48
5. Advance Setting......................................................................................................... 49
5.1 FTP client.............................................................................................................. 51
Dual Mode CCD Dome Internet Camera
3

5.1.1 General..................................................................................................... 51
5.1.2 Alarm sending........................................................................................... 52
5.1.3 Periodical sending .................................................................................... 54
5.2 SMTP .................................................................................................................... 56
5.2.1 General..................................................................................................... 56
5.2.2 Alarm sending........................................................................................... 58
5.2.3 Periodical sending .................................................................................... 60
5.3 HTTP event ........................................................................................................... 62
5.3.1 General..................................................................................................... 62
5.3.2 Alarm sending........................................................................................... 63
5.4 Schedule ............................................................................................................... 65
5.4.1 Setting ...................................................................................................... 65
5.5 Alarm buffer........................................................................................................... 66
5.5.1 Setting ...................................................................................................... 66
5.6 Motion detection.................................................................................................... 67
5.6.1 Setting ...................................................................................................... 67
5.7 system Log............................................................................................................ 68
5.7.1 Setting ...................................................................................................... 68
Appendix A --- Enable ActiveX options on your PC.................................................... 69
Appendix B --- Bandwidth Estimation.......................................................................... 70
Appendix C --- Mobile phone viewing.......................................................................... 71
ICA-510 User Guide
4

1. Introduction
Simultaneously providing MPEG-4 and M-JPEG video streaming, the PLANET ICA-510 is a
Dual Mode CCD Dome Internet Camera which uses high resolution of 1/3-inch CCD sensor
for capturing color images. Equipped with network and analog video output interfaces make
the ICA-510 a flexible viewing and recording implementation.
Compliant with IEEE 802.3af PoE (Power over Ethernet), the ICA-510 offers the benefit of
easy deployment to users to install camera without concerning for power outlet located. The
2-Way audio feature directly makes audio communication between local and remote side
by adding external microphone and speaker. Besides web browsers, it also provides 3GPP
capability that can remotely view the live video via a 3G mobile phone.
The ICA-510 supports the professional management software, PLANET Cam Viewer,
which is a multi-camera video surveillance application, and it can handle the ICA-510 to
provide monitoring, recording and event management functions. The Cam Viewer offers
you to setup a comprehensive and effective surveillance system quickly and easily. There
are so many features to make PLANET ICA-510 be the most cost efficient IP camera for
multiplex occasions that could express video and audio from everywhere at anytime over
the Internet. It can provide a real professional security environment to protect your property
and life.
1.1 Package Contents
Please inspect your package. The following items should be included in the package:
z1 x ICA-510
z1 x Power Adapter
z1 x Mounting Screws
z1 x CD
z1 x Quick Installation Guide
Dual Mode CCD Dome Internet Camera
5

1.2 System Requirements
Network Interface 10/100Base-TX Ethernet
Monitoring System Recommended for Internet Explorer 6.0 or above
System Hardware · CPU: Pentium 4, 1.5GHz or above
· Memory Size : 512 MB or above
· VGA card resolution : 1024 x 768 or above
Optional:
· Sound Card (for PC)
· Microphone (for PC and ICA-510)
· Speaker (for PC and ICA-510)
1.3 Features
¾Simultaneous MPEG-4 and M-JPEG dual codec
¾Supports 2-Way audio
¾3GPP for 3G mobile remote application
¾Provides 3 motion detection area
¾FTP / SMTP alarm by motion detection
¾Up to 30 fps in Full D1 resolution
¾Supports analog video output
¾IEEE 802.3af Power over Ethernet compliant
¾UPnP for fast and easy installation
¾Cam Viewer - Central management software supported
ICA-510 User Guide
6

1.4 Application
Remote Monitoring Applications
1.5 Outlook
Dual Mode CCD Dome Internet Camera
7

ICA-510 User Guide
8
1.5.1 Connectors
Connector Description
AUDIO OUT An external speaker can be plugged in.
AUDIO IN An external microphone can be plugged in.
PWR
Connect the supplied power adapter.
When this device is obtained power from PoE, you don’t have to attach
the power adapter.
Video OUT Analog video output.
LAN (PoE) Connect your Camera to a 10/100Base-TX hub or switch. It is compliant
with IEEE 802.3af PoE. Either mid-span PSE or end-span PSE supported.
AUDIO OUT (Green)
AUDIO IN (Red)
PWR
Video OUT
LAN (PoE)

1.6 Technical Specifications
Video
Image Sensor 1/3” SHARP CCD
Horizontal Resolution 420 TVL
Lens 6 mm, F1.8 fixed board
Illuminator 0.1 Lux
Video Codec MPEG-4 / M-JPEG
Video Resolution Up to 30 fps @ 704x480 ; 352x240 ; 176x120
Image Control AWB, AEC, AGC
Audio
Audio Codec G.726 ADPCM, 64Kbps
Interfaces
LAN 1 x RJ-45, 10/100Base-TX, IEEE 802.3af
VIDEO 1 x BNC
AUDIO 1 x Audio In
1 x Audio Out
Network
Protocols TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP, DNS, DDNS,
NTP, UPnP, RTSP, RTP, HTTP, TCP, UDP
Management
Client Web browser / Cam Viewer software
Security Username and password authentication
Alarm and Event
Motion detection (3 areas definable)
Triggered and scheduled events
Pre and post alarm buffer
Environment
Power Requirement 12V DC, 1.0A
Dimensions (H xΦ) 70 x 110 mm
Weight 400 g
Operating Temperature 0 ~ 50 Degree C
Emission CE, FCC
Dual Mode CCD Dome Internet Camera
9

2. Installation
The followings are instructions for setting up the IP camera. Refer to the illustration and
follow the simple steps to quickly install.
2.1 Physical Installation
1. Hold the base and rotate the cover to open this camera.
2. Use the provided screws to mount the camera on the ceiling.
ICA-510 User Guide
10

3. Attach the provided power adapter to the camera’s power connector. If there is a PoE
switch/hub existing, you can connect the camera’s LAN port to your PoE switch/hub to
power up. If this camera is obtained power from PoE, you don’t have to attach the power
adapter.
Note:
Please use the bundle power adapter that in package. Using a power supply with a different
voltage rating will damage and void the warranty for this product.
4. Set camera face to the location you want, and you can connect the Video Out connector
to a monitor then turn the lens to adjust focus.
5. When the position and focus adjustment done, rotate the housing back to the main base
and then turn the hemisphere cover to the proper direction.
6. Connect camera’s LAN port to your network device, if it is not power up from PoE
switch/hub.
Dual Mode CCD Dome Internet Camera
11

2.2 Software Installation
1. Insert the bundled product CD into CD-ROM drive to launch the autorun program.
2. When the web page displayed, select and click the “Setup Tool” hyperlink on the menu
to start the installation process.
Note:
If the CD’s menu does not appear, click “Start” on the task bar and select “Run” to type
“X:\Utility\SetupTool.exe”, assume X is your CD-ROM drive.
3. Click “Yes” to start the Setup Tool Installation.
4. Choose the language you need, and click “Next” to continue.
ICA-510 User Guide
12

5. Follow the step for configuring the Setup Tool, and click “Next” to continue.
6. If you wish to install the Setup Tool in an alternative location, click “Browse”;otherwise
click “Next” to continue.
Dual Mode CCD Dome Internet Camera
13

7. If you wish to install the Setup Tool in an alternative folder of star menu, type a new folder
or select one of the exiting ones; otherwise click “Next” to continue.
8. Check the installation summary, and click “Install” to install the Setup Tool.
ICA-510 User Guide
14

9. The program starts to install the Setup Tool in your computer.
10. The Setup Tool installation successful. Click “Finish” to complete the installation.
Dual Mode CCD Dome Internet Camera
15

2.3 Software Quick Configuration
This section shows how to perform basic communication functions by Setup Tool.
1. Double click the icon of Setup Tool on the desktop.
2. The Setup Tool screen will show up as below. It will automatically search and list the IP
cameras on your network.
ICA-510 User Guide
16

3. Select the IP camera you want, and then click the “Setup” button on the right side. The
administrator login window will pop up. If the Administrator Name and Administrator
Password have been set, you will be prompted to enter them. If using the default values,
please enter “admin” for both name and password. Click “OK” to continue.
4. On the following System information screen, it displays the Product Name, Firmware
Version and Hardware Version. Click on “Next” to continue.
Dual Mode CCD Dome Internet Camera
17

5. On the following Account settings screen, you can configure some accounts as Admin,
Operator or Viewer. Click “Next” to continue.
6. On the following Date/Time settings screen, you can adjust the date and time as
synchronize with PC, manual setting or synchronize with NTP server. Click “Next” to
continue.
ICA-510 User Guide
18

7. On the following Network settings screen, you can configure the device HTTP port, IP
address, subnet mask, default gateway and DNS. If you use PPPoE, please use DHCP
for both IP address and DNS settings. Click “Next” to continue.
8. On the following PPPoE settings screen, if you want to use PPPoE for connection,
please select “On” to fill the correct User ID and Password for dialling. Click “Next” to
continue.
Dual Mode CCD Dome Internet Camera
19

9. On the following DDNS settings screen, if you have registered the account from the
DDNS provider and want to use DDNS function, please select “On” to fill the correct
User ID, Password and Hostname for connecting. Click “Next” to continue.
10. On the following Apply settings screen, please make sure all settings are correct and
valid. Click “Apply” to finish, or click “Previous” to change settings.
After modifications, you may now connect the camera with new settings via web browser.
ICA-510 User Guide
20
