About This Manual
This is a user's guide for your ENW-3502-T PCMCIA 10Mbps Ethernet
Card. Please read this manual before you attempt to install the product.
This manual includes the following topics:
ØProduct descriptions, features and specifications.
ØHardware installation procedures
ØSoftware installation procedures

ii
Table of Contents
TABLE OF CONTENTS........................................................................................II
INTRODUCTION..............................................................................................1
1.1 PRODUCT DESCRIPTION...............................................................................1
1.2 FEATURES..................................................................................................2
1.3 QUICK INSTALLATION.................................................................................2
HARDWARE INSTALLATION.......................................................................3
2.1 PACKAGE CONTENTS..................................................................................3
2.2 HARDWARE DESCRIPTION...........................................................................3
2.3 INSTALLING THE ENW-3502-T ETHERNET PC CARD ..................................3
DRIVER INSTALLATION FOR WINDOWS 95.............................................5
DRIVER INSTALLATION FOR WINDOWS 98.............................................7
DRIVER INSTALLATION FOR WINDOWS NT 4.0....................................10
CLIENT DRIVER INSTALLATION..............................................................14
6.1 DRIVER INSTALLATION.............................................................................14
6.1.1 DRIVER INSTALLATION PROGRAM........................................................14
6.1.2 QUICK INSTALLATION.........................................................................14
6.2 THE INSTALL PROGRAM.........................................................................15
6.2.1 USING THE INSTALL PROGRAM.........................................................15
6.3 MANUAL INSTALLATION...........................................................................23
6.3.1 ENABLER............................................................................................23
6.4 CLIENT DRIVER INSTALLATION.................................................................24
6.4.1 NETWARE 3.X / 4.X CLIENT...............................................................24
6.4.2 MICROSOFT WINDOWS FOR WORKGROUPS 3.11....................................24
6.4.3 MICROSOFT WINDOWS NT 3.51..........................................................24
6.4.4 MICROSOFT LAN MANAGER...............................................................25
6.4.5 ARTISOFT LANTASTIC VERSION 6.0....................................................25
6.4.6 CONFIGURATION REFERENCE...............................................................25
TROUBLESHOOTING FOR WINDOWS ENVIRONMENTS.....................26
A.1 WINDOWS 9X..........................................................................................26
A.2 WINDOWS NT 4.0 AND 3.51.....................................................................26
ERROR MESSAGES OF ENABLER PROGRAM........................................27

iii
CARDGO.EXE .............................................................................................27
SPECIFICATIONS..........................................................................................29

iv
This page left blank intentionally!

1
Chapter 1
Introduction
1.1 Product Description
Thank you for purchasing PLANET ENW-3502-T Ethernet PC Card.
ENW-3502-T 10Mbps Ethernet Card is a network adapter card for notebook
computers and complies with the PCMCIA TYPE II standard. An
Ethernet adapter cable with male RJ-45 connector two kinds of
connections :
•Connect to a Hub directly, or
•Connect to a network cable with male RJ-45 connector
ENW-3502-T, the 10Mbps Ethernet Card is switchless and software
configurable. An enabler program can successfully drive the card. Even
without the card and socket service drivers for PCMCIA controller
installed, you will still be able to use the card by running the enabler
program.

PLANET ENW-3502-T PC Card User’s Manual
2
1.2 Features
•5.0 mm Type II credit card size
•Complies with IEEE 802.3 10Base-T.
•Complies with PCMCIA Release 2.1 Spec
•PC Card standard 68-pin 16-bit PCMCIA Interface
•Half-duplex 10Base-T
•5.0V Power consumption
1.3 Quick installation
This section briefly outlines the steps needed to install the PCMCIA
10Mbps Ethernet Card and its driver software, and how to connect the
card to the network.
To install ENW-3502-T 10Mbps Ethernet PC Card to your notebook
computer:
1. Connect the Ethernet adapter cable to the card, then insert the card
into the PCMCIA slot. (Refer to Chapter 2 for details.)
2. Connect the Ethernet adapter cable to the network. (See Chapter 2
2.3 Installing the PCMCIA 10Mbps Ethernet Card for details.)
3. Install the driver software like Windows 95/98, NT or other Network
Operation System. (See Chapter 3, Chapter 4, Chapter 5, and
Chapter 6 for details.)

3
Chapter 2
Hardware Installation
2.1 Package Contents
Please check whether the following items are in your package :
•ENW-3502-T, PCMCIA 10Mbps Ethernet Card
•Ethernet adapter cable with 15-pin flat connector at one end and
female RJ-45 connector at the other end for 10Base-T
connectivity.
•Plastic protective adapter case
•Driver Diskette (Device drivers, User’s manual)
2.2 Hardware Description
The PCMCIA 10Mbps Ethernet Card is encased in a stainless compact
frame that is easily transportable. It has a 68-pin connector and a 15-pin
flat connector for attaching to the Notebook and Ethernet adapter cable
respectively .
2.3 Installing the ENW-3502-T 10Mbps Ethernet PC Card
Follow the procedure below to install the PCMCIA 10Mbps Ethernet
Card.
1.Turn off the host computer.
2.With the card’s 68-pin connector facing the PCMCIA slot, slide the
card all the way into the PCMCIA slot. Do not force the
connection.
3.Plug the Ethernet adapter cable to the 15-pin connector on the card.
4.Connect the Ethernet adapter cable to a network. If there is an
Ethernet Hub or RJ-45 phone jack connected to a network and is
near by your notebook, you can connect the Ethernet adapter cable to
a port on the Hub or to the RJ-45 phone jack with another male-to-
male RJ-45 line or connector.

PLANET ENW-3502-T Ethernet PC Card User’s Manual
4
5. Turn on the computer.
Note:Use the Network coupler bundled in the package. Use of
other coupler could make the PC card or coupler
malfunction.

5
Chapter 3
Driver Installation for Windows 95
Installing the PCMCIA 10Mbps Ethernet Card is just the same as any
normal Windows 95 Plug & Play device. Follow the steps below to
install.
1. Insert the PCMCIA 10Mbps Ethernet Card into an open PCMCIA slot on
your notebook.
2. After Windows 95 detects the card, the Update Device Driver Wizard
window, as shown in Figure 3.1, will appear. Insert the driver diskette and
click Next to continue the installation.
Figure 3.1 Update Device Driver Wizard
3. When Windows 95 finds the installation file in Driver Diskette and shows
the window in Figure 3.2 on your screen, click Finish.

PLANET ENW-3502-T Ethernet PC Card User’s Manual
6
Figure 3.2 Found Driver
4. Windows 95 will follow the direction of the installation file to locate the
files that should be copied. Eventually Windows 95 may need to copy
required system files. Give the correct path, then click OK to continue.
5. After all files have been copied, Windows 95 will prompt you to restart the
system. Click Yes to complete installation.

7
Chapter 4
Driver Installation for Windows 98
Installing the PCMCIA 10Mbps Ethernet Card is similar as any normal
Windows 95 Plug & Play device. Follow the steps below to install.
1. Insert the PCMCIA 10Mbps Ethernet Card into an open PCMCIA slot on
your notebook.
2. After Windows 98 detects the PCMCIA 10Mbps Ethernet Card, the Add
New Hardware Wizard window, as shown in Figure 4.1, will appear. Click
Next to continue the installation.
Figure 4.1 Add New Hardware Wizard
3. Select Search for the best driver for your device. [Recommended] and
click Next.

PLANET ENW-3502-T Ethernet PC Card User’s Manual
8
Figure 4.2 Search Driver
4.Uncheck the Microsoft Windows Update. Let Windows 98 search floppy
drive. Then place the foopy disk and click Next to continue.
Figure 4.3 Search floppy Disk drive
5. Select the found updated driver, PCMCIA 10Mbps Ethernet Card, then
click Next.

Chapter 4 Driver Installation for Windows 98
9
Figure 4.4 The updated driver
6. After copying all required files, Windows 98 will prompt you to restart the
system. Click Yes to complete installation.

10
Chapter 5
Driver Installation for Windows NT 4.0
The installation procedure assumes the network component has been
installed on your computer. To check whether the network component
has been installed, double click the Network icon in Control Panel. If it
has not, refer to the Windows NT 4.0 installation guide to install the
component.
While installing the network component, Windows NT 4.0 will ask you
to install the driver of network adapter. The driver installation
procedure is similar to the following one.
Follow the steps below to install the driver.
1. Insert the PCMCIA 10Mbps Ethernet Card into an open PCMCIA slot on
your notebook. Login to NT 4.0 as the administrator.
2. Doublic click Network icon in Control Panel, and select Adapters tab,
the Figure 5.1 displayed.
Figure 5.1 Network Window
3. Click Add to add a new adapter, the window, Figure 5.2, popped up.

Chapter 5 Driver Installation for Windows NT 4.0
11
Figure 5.2 Select Network Adapter Window
4.Click Have Disk …, after Insert Disk window, shown in Figure 5.3,
popped up, give the search path, A:\WINNT (suppose A: is your floppy
drive), then insert driver diskette, and click OK.
Figure 5.3 Insert Compact Disk Window
7. After finding the installation file, the Select OEM Option window shown
in Figure 5.4 is displayed. Click OK to choose the PCMCIA 10Mbps
Ethernet Card option.

PLANET ENW-3502-T Ethernet PC Card User’s Manual
12
Figure 5.4 Select OEM Option Window
8. In the PCMCIA 10Mbps Ethernet Card setup window, Figure 5.5, select
the desired IRQ level and I/O Port address. After selecting desired
configuration, click OK to continue.
Figure 5.5 Setup Window-1

Chapter 5 Driver Installation for Windows NT 4.0
13
Select the PCMCIA type option as figure 5.6 and click OK to continue.
Figure 5.6 Setup Window-2
Click Close to close the Network window, and let Windows NT 4.0
binding the adapter with network component.
Eventually, Windows NT 4.0 will prompt you to restart the computer,
click Yes to finish installation.

14
Chapter 6
Client Driver Installation
6.1 Driver Installation
Before your computer system can recognize your ENW-3502-T
Ethernet PCCard, the driver programs must first be installed to enable the
card.
6.1.1 Driver Installation Program
INSTALL.EXE is the ENW-3502-T Ethernet PC Card driver
installation program. The INSTALL.EXE program allows you to do
auto-configuration where the program automatically selects the most
suitable option settings, or do a custom configuration where you
individually select each option setting.
6.1.2 Quick Installation
This section gives a brief overview of the installation process. (For a
clearer step-by-step procedure, refer to the next section.)
1.If the Card and Socket Services software is included as part of your
computer, it is recommended that you use this software when installing
your ENW-3502-T Ethernet PC Card.
A system with Card and Socket Services installed allows the PCMCIA
card to automatically configure itself. While the system is on, available
system resources and insertion or removal of the card will
automatically be detected.
2.Run the INSTALL.EXE program found on your Installation floppy
disk. The install program guides you through the installation process
and will install the network drivers needed to run the card on your
network operating system.
If you have successfully completed the installation, jump to step 5. If
installation was unsuccessful, then go on to next step.
3.Use the Card Service client driver, CARDGO.EXE, found on your
Installation floppy disk. You can install the client driver by typing
CARDGO at the DOS prompt or including it as a line in your
CONFIG.SYS or AUTOEXEC.BAT file. When installing the client
driver, it is important to note that the driver should be loaded after
Card and Socket Services are loaded.

Chapter 6 Client Driver Installation
15
4.Turn off your computer and insert the ENW-3502-T Ethernet PC
Card into the PCMCIA socket. The card is keyed to go in one way
only. Then attach the network cable to the card.
5.Now turn your computer on and connect to your network. If you cannot
connect to the network, refer to the Appendix A and B.
6.2 The INSTALL Program
Before you can use your ENW-3502-T Ethernet PC Card, you need to
install and modify some files in your computer system. You can make
these changes manually, or you can let the INSTALL.EXE program do
them for you.
This section explains how you can use the INSTALL.EXE program to
install the enabler and the files needed by the network operating system.
6.2.1 Using the INSTALL Program
To run the INSTALL.EXE program, type INSTALL and press <Enter> at the
DOS prompt. You should see an opening screen which welcomes you to the
program and asks if you wish to continue.
Figure 6-2.1 Opening Screen
Press <Enter> to continue the installation.
PLANET ENW-3502-T Ethernet PC Card Installation Program
DO YOU WANT TO PROCEED?
Welcome to 10Mbps Ethernet Card Installation Program. INSTALL will set up
your 10Mbps Ethernet Card.
If you have your network operating system installed, please insert your Card in
any available PCMCIA slot on your computer and press <Enter> to continue.
Otherwise press <F3> to return to DOS.
<Enter> to continue <F3> to return to DOS

PLANET ENW-3502-T Ethernet PC Card User’s Manual
16
The program will then prompt you for the directory where you want to install
the driver files. You can choose the default directory name or enter a new
name. Then, press <Enter> to continue with installation.
Figure 6-2.2 Specify Directory Path
PLANET ENW-3502-T Ethernet PC Card Installation Program
ENTER PATH TO INSTALL
INSTALL will create a directory with all of the necessary files to use
10Mbps Ethernet Card. Please enter the drive and directory name, or confirm
default displayed.
<Enter> to continue <F3> to return to DOS
C:\PCMCIA
