Playvision HDV-9818S50 User manual

HDMI 1x8 Splitter
Over CAT5e/CAT6
With EDID Control
User manual

1
Thankyouforpurchasingthisproduct.Foroptimum performanceand
safety,pleasereadtheseinstructionscarefullybeforeconnecting,
operatingoradjustingthisprod
uct.Pleasekeepthismanualforfuture
reference.
I
.Introduction
The
Splitterisaproductforsplittingand
extendingyourHDMIsignal
overlongdistancestoacompatibledisplay.Itisdesignedtoconvert
the
HDMIsignalandtransmit byInternetcable.Italso supports
TransferBidirectionalInfraredcontrol signaltogetherwiththeHDMI
signal,so youcancontrol theSou
rceintheSinksidewhichis5
0meters
outside,also youcan control theSinkin theS
ourcesidewhichis5
0
meters outsideusingthe
Splitter.
II
.Features
1.
Compliant withHDMI1.3,HDCP1.2andDVI1.0.
2.
Full HDsupport:1080p@60Hz@24 bit/pixels.
3.
Supports LPCM7.1CH,DolbyTrueHD,andDTS-HDMasterAudio.
4.
Operates forTMDSclockfrequencies upto 165MHz.
5.
UsesingleUTPLAN cable(CAT-5E/6)to substituteHDMIcableto
achievelongdistances transmission.
6.
UTPcableterminationfollows thestandardofIEEE-568B.
7.
Supports EDIDcontrol via EDIDselector.
8.
TransferBidirectional Infraredcontrol signal togetherwiththe
HDMIsignal.
III
.Package
1.
HDMISplitter-------------------------------------------------------1PCS
2.
Receiver-------------------------------------------------------------8PCS
3.
WidebandIR Tx----------------------------------------------------8PCS
4.
WidebandIR Rx----------------------------------------------------8PCS
5.
5V2A DC PowerSupplyadapter-------------------------------- 1PCS
6.
5V1A DC PowerSupplyadapter-------------------------------- 8PCS
7.
OperationManual -------------------------------------------------1PCS

2
IV
.Specifications
1.
Frequency Bandwidth1.65Gbps
2.
HDMISplitter Input/OutputPorts1xHDMIFemale port/8xCAT6
1xIR Transmitter/1xIRReceiver
3.
Receiver Input/OutputPorts1xHDMIFemale port/1xCAT6
1xIR Transmitter/1xIRReceiver
4.
PowerSupplyHDMISplitterDC5V2A
Receiver DC5V1A
5.
ESD ProtectionHumanBody Model:±8kV (air-gap discharge)
±4kV (contact discharge)
6.
Dimensions(mm)Splitter: 112(W)X 258 (D)X 256(H)
Receiver: 49(W)X 81(D)X 25 (H)
7.
WeightSplitter: 750g
Receiver: 150g x4
8.
Operating Temperature0°C~40°C/32°F ~104°F
9.
Operating Temperature0°C~40°C/32°F ~104°F
10.
StorageTemperature-20°C~60°C/-4°F ~140°F
11.
RelativeHumidity20 ~90%RH (Non-condensing)
12.
Power Consumption(Max) HDMISplitter10Wx1
Receiver5Wx8

3
V
.Operation controls and Functions
Splitter
1.
POWER SWITCH: PowerON\OFF Switch.
2.
POWER LED: Thisred
LEDilluminate when thedeviceis
connectedwithpowersupply.
3.
EDID Selector: Selectoutputsignal format via EDIDSelector.
See thedescription3.
4.
IR IN: SupperIRControl SystemoverLANCableIRReceiver.
Sourceto SINK,plugWidebandIR Rxinto this unit.
See thedescription1.
5.
IR OUT: SupperIRControl SystemoverLANCableIRTransmitter.
SINK to Source,plugWidebandIR Txinto this unit.
See thedescription2.
6.
UPDATE:Systemsoftwareupdate.
7.
OUTPUT Area: EightRJ45 Jacks providesignal output.
8.
INPUT Area: HDMIInputport.ConnectsourcewithHDMIcable.
9.
DC IN: Plugthe5V2ADCpowersupplyinto theunit.

4
Receiver
1.
HDMI Signal IN: HDMIsignal inputport.
2.
EQ Selector: Equalizeselector.SelectHighorLowdependonthe
distanceofUTPLANcable.Lowwork betwee
n0and20 meters,
Highwork between 20 and50 meters.
3.
LINK LED: ThisredLEDilluminate when theSplitter
andReceiver
is connectedwithLAN cable,andthesignal has transmit.
4.
HDMI OUT: HDMIOutputport.ConnectTV withHDMIcable.
5.
DC IN: Plugthe5V1ADCpowersupplyinto theunit.
6.
IR RX: SupperIRControl SystemOverLANCableIR
Receiver.SINK
to Source,plugWidebandIR Rxinto this unit.
See thedescription2.
7.
IR TX: SupperIRControl SystemOverLANCableIR
Transmitter.
Sourceto SINK,plugWidebandIR Txinto this unit.
See thedescription1.

5
VI
.Application Example

6
Dscription 1
Dscription 2

7
Dcription 3
EDID Selector description as follow:
Number EDIDSelector Description
1 0000 Reserve
2 0001 1080P,Stereo Audio 2.0
3 0010 1080P,Dolby/DTS5.1
4 0011 1080P,HDAudio 7.1
5 0100 1080I,Stereo Audio 2.0
6 0101 1080I,Dolby/DTS5.1
7 0110 1080I,HDAudio 7.1
8 0111 3D,Stereo Audio 2.0
9 1000 3D,Dolby/DTS5.1
10 1001 3D,HDAudio 7.1
11 1010 Reserve
12 1011 Reserve
13 1100 Reserve
14 1101 Reserve
15 1110 Reserve
16 1111 1080P,Stereo Audio 2.0(default)
