PMX PARKES Series Reference guide

Parkes series caravan
customer guide

1
Owners Name: __________________________
Model: _______________________________
VIN #: ________________________________
Preparing vehicle
● Brake controller tted. Yes: □
● Tow tongue suitable for 3.5T. Yes: □
Hand over check list
● Locks / keys. Yes: □
● Pole bag. Yes: □
● Canvas. Yes: □
● Power system explained. Yes: □
● Hot water system explained. Yes: □
● Toilet cassette explained. Yes: □
● Kitchen Gas / water explained. Yes: □
● Wheel nut check 50km / 150km. Prior to any trip and daily if using
o road/ rough roads explained. Yes: □
● Service hand book included in pack. Yes: □

2
Points of interest
When empty caravan tows best with water tanks full.
Wheel nuts should be checked often when new or wheels are removed.
Preferred torque is 125nm.
As a daily check - Before driving o , check: Wheel nut torque, Hand brake,
Jockey wheel, stabilizer legs, all doors shut(best locked), roof is locked down
with clips.
Setting up
Firstly select area that is large enough to allow easy access around caravan
plus room for annex if setting up at this stage. About 3m from door of caravan
will be plenty plus length
of van when rear open.
Engage hand brake & chock wheels.
Stabilizer Legs
Each caravan is tted with 4 stabilizer legs & winder. Simply pull plastic handle
to release
then wind down until van is supported & level. Using drill to wind
out is not recommended
as may damage winding unit.
Lifting Roof
1. Remove all 4 external “R” clips on over centre latches at corners.
(Tip: put “R” clip back
through eye catch to stop from getting caught when
closing)
2. Entering inside remove “D”clips from roof lifting braces.
3. Lift roof, usually easiest to lift front rst then back.
Opening Back
1. Remove spare wheel support pins. (Tip: put back in when open so not lost)
2. Lower spare wheels (Note: these are weighty and best done with 2 people.)
3. Open side catches, lift rear, support and open barn doors making sure
they are well
seated into corners of roof. Reach over and lift up rear wall.
Secure in place with latches.
Closing Roof
1. Simply reverse opening steps ensuring that all windows, skylights and any
openings are
locked down.
2. Alway check lid latches are securely pinned back and clamps are secure.

3
Internal
● Power up van using main power switch inside switch box (rst on left). There
are labelled
switches for lighting and power in switch box that once you
have practiced will be just
like home.
● Just inside door is toggle switch to lower / raise step.
● Depending on model there should also be switch for hot water system
for choosing between gas and 240v which is explained later but for now
please note HWS must be primed with water before turning on.
Main Power System
Under front of bed is the battery (3 x 100 A/H), Inverter / charger system. It is
best to familiarise
yourself with layout and check is set for type of camping
prior to making up bed.
● 240V - IN. This is a 15 amp socket so a 15 amp extension lead is necessary.
2 Way Power Switch
1 - Inverter 2 - 240 Volt
● Main switch box. This is simply to allow you to switch from external 240v
power from mains to inverter. Please note inverter will use power constantly
if left on and is not rated for large electrical items. Simply select method
of power source prior to setting bed. (Tip: Always leave in mains mode so
charger can be operated on mains power whenever plugged in)
● Charger. The charger is powered when on mains and plugged in / turned
on. On initial start up a red light will appear when turned on (switch on side)
with fan if batteries are low. Once charged light will go green. Best to have
charger set to come on as soon as you plug in extension cord. Please Note:
The charger is not designed to be left on indenitely.
Typically a few hours
each day when in use or 24 hours monthly when in storage is sucient.
● Inverter. To use inverter the mains switch must be icked to inverter.
Depending on model
there may be a 240v plug & lead on inverter plus
toggle on/o switch or the inverter may be controlled at main switch
board. The inverter is designed to oer small amount of 240v power for
charging lap tops, small appliances. Please check output power of inverter
(watts) against what appliance will use. Small items such as kettle can
actually use a lot of energy and damage inverter. (Easier to use gas stove)
Remember: All inverters use battery power heavily. Always turn o and consider the loss of 12v
power when using.

4
Hot Water System
This is a storage system which must be primed before turned on. Simply ll both
water tanks, turn on both pumps and run hot tap until water comes through.
● 240V. For mains power only. Check tank is primed and 15A extension lead
is connected
to van. Select 240v.
● Gas. As above ensure tank is primed and 240v switch is o. Check gas bottle
is connected and open. Flick gas switch to on. Automatic igniter will start.
Please note if model has external door over HWS this door must be opened
to operate HWS.
Shower
Your shower will operate just like at home. There is even an extractor fan to
help get steam out. Once hot water has heated up you are ready to go.
Remember
to have both pump switches on.
Shower Waste
The van is tted with an outlet that a caravan waste water hose can be
attached to. Depending on model there may also be a waste holding tank.
Simply purchase a waste hose to connect and run to suitable drainage point.
Toilet Cassette
Lovely topic but done right is no fuss. Prior to using try some fresh water only
tests before adding Chemicals. You can just have chemical in waste tank or
use approved chemical in ushing tank as well.
Operation:
1. Fill ushing water tank with clean water. Use cap extender when lling.
2. Place mixed chemical into the cassette waste tank as per bottle instructions.
3. Slide waste tank into slot & lock in place.
Time To Empty: Don’t wait till full. Use dump zones.
1. Remove cassette from slot, extend handle and wheel to dump zone.
2. Swing out dump tube, remove cap and poor solution into dump point. The
small button on top allows air into cassette to speed process. Clean and
replace into slot.

5
Windows / skylights
Each opening is tted with both y screen and curtain. Simply join latches to
select whether you have privacy or fresh air. Windows will self lock open once
unlocked and pushed out. Just lift slightly higher to disengage and close.
Air Conditioner
Vans supplied with air conditioning have full booklet on operation. The A/C
is controlled by remote.
A few pointers - in humid conditions or when used at low temp condensation
may collect on roof. Setting van slightly o level to slope water away from
kitchen area is best.
Entertainment System
All in one Bluetooth stereo, FM radio, DVD player linked to LED TV, Remote x 2
Note: Don’t forget to Fade outside speakers if you have neighbours.
External kitchen
Slide out kitchen & swing down support legs mounted underneath. There is
also an addition
separate support leg for extended prep table. Remove foam
covers on gas cooker and store as these are provided to protect stove from
getting scratched during travel. There are 12V
plug is light, gas / water lines
that must be connected / disconnected on opening / closing.
Alway ensure
these are
away and clear before closing.
● Water lines. These just plug in noting which is hot by colour of hose. To
disconnect push
back outer socket and hose will pop out.
(Note: turn o pumps & open tap to release pressure before trying to remove
hose.)
● Gas hose. Located under kitchen is the gas hose which is push/turned
onto gas outlet similar to portable gas heater in house. (If connecting a
fresh bottle there will be a delay for gas to reach cooker) The cooker is tted
with electronic ignition which is powered by a D cell battery located above
cutlery drawer inside. Tip: bring matches or lighter in case battery goes at.
● Drainage. The sink is tted with a short drain hose that can be pulled out
and placed into
a bucket.

6
Fridge Box
The fridge box is tted with both 12 volt & 240 volt. 240 volt is only available
on mains power. Whilst small fridges will run okay on the ciggi style socket
there is also a 50A Anderson Plug which is recommended for all fridges to be
connected to. Fridge tie down points are also provided so purchasing fridge
tie down straps is also recommended.
Water Supply
There are two water tanks which supply water to both kitchen and shower.
The hot water system drawers water from front tank.
Cold water is drawn from rear tank for shower and kitchen. Both pump switches
must be on to use hot water. There are two lling necks with key lock caps.
Filling both is always recommended (and even rell if priming HWS as it will
take 28 litres). Please note: Fast lling may overcome breather hose giving false
impression tank is full.
Awning
A simple manual winding awning with legs for day use. Some models may
have ability to wall mount leg holders. On opening wind out awning until legs
can be popped out of holder.
Simply adjust height and use legs to support
by “walking”
them out as you wind.
Tip: Always wind back awning in same direction it came out of awning rail.
Annexe
Tip: a small ladder is very helpful.
Prepare by having poles and pegs / ropes ready in close position to where
they are needed.
1. Awning Cover: Fit rst by threading through sail rail behind awning -
front to back.
2. Thread roof of annex through pop top sail rail rear to front.
3. Zip together 1 & 2.
4. Slide east / west poles (#1,#7) into position then support with uprights
(#6,#3), then t the eye/eye poles (#2) - t roof and secure with elastic
cords.

7
5. Draw annex roof out to full width and length then working some height
in you can nish o spreader bars (#5) and extra wall supports (#4).
6. Make sure all is properly pegged and roped out.
7. Zip / velcro walls, wall skirt, oor as desired.
Rain Tip: In rain or chance of rain. Drop ends to create a larger“fall” on roof
away from van
and re-secure guy ropes.
Care for your caravan
Do not leave caravan & canvas packed away wet. Even precipitation moisture
can be enough
to invite mold. Always air her out on return.
Batteries require regular charging. Allowing batteries to become low (below
11.6v is low)
will damage batteries.
Maintenance. Just like a car your caravan needs regular servicing. Always
check wheel nuts before & during trip plus check tyres for uneven wear.
Simple inspections can save costly breakdowns. If planing a big trip it is
always advised to get serviced and inspected prior by local PMX store or
mechanic.
Get to know your caravan. A basic tool kit which has correct socket for wheel
nuts, checking your car jack is tall enough for van, all basic but critical.
Remember Murphy’s Law. You won’t need it unless you didn’t pack it. Using
groups such as EZYtrail Owners/ Parkes owners on facebook is also another
way to learn plus you can ad your own wisdom
to these groups. Of course
before you get yourself in a bother a sta member at PMX or EZYTrail is never
too
busy to help.
DUE TO CONTINUED PRODUCT DEVELOPMENT THIS INFORMATION IS SUBJECT TO CHANGE.
From all of us at PMX Caravans & Camper Trailers we warmly
welcome you to our family and hope you have many wonderful
adventures.

8
Service Record
1st service @ 1000km / 6 months
Date: …………………………………………………
Place: …………………………………………………
Service operator: ………………………………….
Comments: ………………………………………………………………………………….
…………………………….……….……………………………………………………………
……………………………………………………………………….……….…………………
…….……….……….………….……….……….………….……….……….…….…….….……
…….……….……….………….……….……….………….……….……….…….…….….……
…….……….……….………….……….……….………….……….……….…….…….….……
2nd service @ 5000km / 12 months
Date: …………………………………………………
Place: …………………………………………………
Service operator: ………………………………….
Comments: ………………………………………………………………………………….
…………………………….……….……………………………………………………………
……………………………………………………………………….……….…………………
…….……….……….………….……….……….………….……….……….…….…….….……
…….……….……….………….……….……….………….……….……….…….…….….……
…….……….……….………….……….……….………….……….……….…….…….….……
12 month / every 5000km
Date: …………………………………………………
Place: …………………………………………………
Service operator: ………………………………….
Comments: ………………………………………………………………………………….
…………………………….……….……………………………………………………………
……………………………………………………………………….……….…………………
…….……….……….………….……….……….………….……….……….…….…….….……
…….……….……….………….……….……….………….……….……….…….…….….……
…….……….……….………….……….……….………….……….……….…….…….….……

9
12 month / every 5000km
Date: …………………………………………………
Place: …………………………………………………
Service operator: ………………………………….
Comments: ………………………………………………………………………………….
…………………………….……….……………………………………………………………
……………………………………………………………………….……….…………………
…….……….……….………….……….……….………….……….……….…….…….….……
…….……….……….………….……….……….………….……….……….…….…….….……
…….……….……….………….……….……….………….……….……….…….…….….……
12 month / every 5000km
Date: …………………………………………………
Place: …………………………………………………
Service operator: ………………………………….
Comments: ………………………………………………………………………………….
…………………………….……….……………………………………………………………
……………………………………………………………………….……….…………………
…….……….……….………….……….……….………….……….……….…….…….….……
…….……….……….………….……….……….………….……….……….…….…….….……
…….……….……….………….……….……….………….……….……….…….…….….……
12 month / every 5000km
Date: …………………………………………………
Place: …………………………………………………
Service operator: ………………………………….
Comments: ………………………………………………………………………………….
…………………………….……….……………………………………………………………
……………………………………………………………………….……….…………………
…….……….……….………….……….……….………….……….……….…….…….….……
…….……….……….………….……….……….………….……….……….…….…….….……
…….……….……….………….……….……….………….……….……….…….…….….……

10
12 month / every 5000km
Date: …………………………………………………
Place: …………………………………………………
Service operator: ………………………………….
Comments: ………………………………………………………………………………….
…………………………….……….……………………………………………………………
……………………………………………………………………….……….…………………
…….……….……….………….……….……….………….……….……….…….…….….……
…….……….……….………….……….……….………….……….……….…….…….….……
…….……….……….………….……….……….………….……….……….…….…….….……
12 month / every 5000km
Date: …………………………………………………
Place: …………………………………………………
Service operator: ………………………………….
Comments: ………………………………………………………………………………….
…………………………….……….……………………………………………………………
……………………………………………………………………….……….…………………
…….……….……….………….……….……….………….……….……….…….…….….……
…….……….……….………….……….……….………….……….……….…….…….….……
…….……….……….………….……….……….………….……….……….…….…….….……
12 month / every 5000km
Date: …………………………………………………
Place: …………………………………………………
Service operator: ………………………………….
Comments: ………………………………………………………………………………….
…………………………….……….……………………………………………………………
……………………………………………………………………….……….…………………
…….……….……….………….……….……….………….……….……….…….…….….……
…….……….……….………….……….……….………….……….……….…….…….….……
…….……….……….………….……….……….………….……….……….…….…….….……

Mon-Fri: 8:30am to 5:00pm
