Ember TOURING EDITION 2023 User manual

2023 OWNER’S MANUAL
TOURING EDITION

2
This Manual Belongs to:
______________________________________________________________________________
VIN __________________________________________________________________________
DEALER _____________________________________________________________________
ADDRESS ____________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
DEALER PHONE ______________________________________________________________
DEALER CONTACT ___________________________________________________________

3
DATE DESCRIPTION OF SERVICE SERVICE PERFORMED BY

4
Congratulations on your new Ember, and welcome to the Ember Recreational
Vehicles family! On behalf of everyone at Ember, we’re glad you’re here. At Ember,
we’re focused on creating a truly unique and exceptional ownership experience.
We hope that you’ll see this in not only the quality we build into our units, but
through the interactions you’ll have with our company and our dealer partners if
you haven’t already!
Not only does it comply with all the Recreational Vehicle Industry Association’s
regulations, standards, and safety requirements, but it meets our own high standards
of quality and testing.
We ask that you please read and understand the contents of this owner’s manual as
well as the other manuals for the various components from other manufacturers that
came with your RV. Your personal safety and that of those traveling with you depends
upon you becoming familiar with and learning how to properly operate the various
systems, appliances, and components that your RV came equipped with. Take extra
care in reading all cautions, warnings, and notices, and familiarize yourself and your
family with the safety features built into your RV and what actions to take
to assure a safe camping trip.
We proudly back our units with our 1-2-3 Warranty: 1 time transfer in the first year of
ownership, a 2-year limited base warranty, and a 3-year limited structural warranty.
Dear Ember Owner,
Your Ember has been designed from
the ground up to provide you with a
reliable and quality way to enjoy family
fun and recreation.

5
Please read through the details of our warranty carefully so you are familiar with the
extent of the coverage and duration, along with the various exclusions, restrictions,
and limitations that may apply. Ongoing maintenance and upkeep are important to
upholding our warranties, so we ask that you please understand what those are. Some
components used in the construction of your Ember from other suppliers come with
additional warranties that extend beyond our warranty. Please be sure to understand
these warranties as well and submit any necessary registration forms included in your
Owners Packet.
Your dealership should be able to answer any questions or concerns you may have
after reading through this Owner’s Manual regarding your new Ember. If your dealer is
unable to do so, please feel free to contact our Ownership Experience department.
We hope that your Ember brings you many years of adventures and fun with memories
to last a lifetime! We are thankful you chose to be a part of the Ember family and wish
you safe travels!
Best,
ASHLEY BONTRAGER
Founder / CEO
Ember Recreational Vehicles

6
This Owner’s Manual for your Ember Recreational Vehicle (RV) is intended to serve as
a guide for safety, care, and normal operation of your unit. Information contained in
this document is subject to change without notice and includes relative information
available at time of the publication of this version. The photographs, drawings,
components, and systems described may not represent what is in the RV you
purchased due to available options, ongoing upgrades, and improvements. This
document also contains information for both the Overland Series and the Overland
Micro Series, and not all information applies to both series. Your Ember 1-2-3 Limited
Warranty is included at the end of this Owner’s Manual. Nothing in this Owner’s
Manual will or is intended to in any way modify, supplement, or change the terms and
conditions of the 1-time transfer in the first year of ownership, the 2-year limited base
warranty and the 3-year limited structural warranty that comes with your Ember RV. This
Owner’s Manual does not alter or supplement any component manufacturer warranty.
Your Ember came with an Owner’s Packet that contains various component
manufacturers’ manuals and warranty information. Please be sure to look through all
these documents and register for the available warranties beyond the 1-2-3 warranty
offered by Ember Recreational Vehicles.
Please use the procedures outlined in this guide for typical operating conditions.
The obligation for safe operation and use of your RV lies on you, and we have tried
to include information to help, but not serve as a tutorial for how to camp or where
to camp in your Ember RV. For questions, concerns, or assistance, please contact your
dealer or Ember directly.
MAILING ADDRESS:
Ember Recreational Vehicles
PO Box 970
Bristol, IN 46507
Phone: [phone]
Email: [e-mail]
Website: www.emberrv.com
About this Manual

7
Contents
OVERVIEW OF OWNER’S MANUAL
Safety Terms 11
Key Safety Items 11
Bunk Loads 11
Egress Windows 12
Extinguisher 12
Smoke Detector 12
Propane Gas / Carbon
Monoxide Detector 12
Conditions that could adversely
affect your alarm 13
Maintaining Your Alarm 13
Safety Regulations for LP 14
Fire Safety 15
YOUR EMBER RECREATIONAL VEHICLE
Technical Data and General
Specifications 17
PRE-TRIP PREPARATION
Pre-Trip Checklist 18
Loading 18
Wheel Lug Nuts 18
Tire Inflation 18
VersaCoupler™ 18
Safety Chains 18
Electrical 18
Exterior 19
Interior 19
Tool Kit Items 19
Hitching 20
Pre-Hitch/Coupling/Trip
Considerations and Inspection 20
7-Way Connector 21
Hitching Steps and Instructions 22
Sway Control and Weight
Distribution Hitch 23
LOADING
Key Terms 24
Cargo Capacities 25
How to Weigh your RV 25
TOWING
Guidelines 26
Safety Chains 26
Breakaway Switch 26
Tire Pressure 27
Brakes 27
Lights 27
General Towing and Driving 27
Cub Lane Change Assist 27
Sway and Fishtailing 28
Winding Narrow Roads 28
Sharp Turns 29
Steep and Long Grades 29
Slippery and Icy Pavement 29
Freeways and Highways 29
Corner Turns 29
Mud and Sand 29
Parking 29
Additional Towing and
Safety Information 29
TIRES
General Information 30
Tire Fundamentals 30
Sidewall Markings and
Important Terms 30
Tire Tread 31
Pressure and Load Limits 31
Checking Tire Pressure 31
Tire Pressure Management
System (TPMS) 32
Wheel Nut Torque 32

8
Torque Adjustments 32
Tire Safety Checklist 33
Travel Trailer Set Up at Destination 34
Site Requirements and Selection 34
Leveling 34
EXTERNAL EQUIPMENT
AND SYSTEMS
Cub Lane Change Assist 36
European Windows 36
Condensation 37
Cleaning 37
Electric Tongue Jack 37
Gear Box 37
Exterior Telescoping Ladder 38
Outdoor Kitchen 38
Griddle 38
Outside Refrigerator 39
Rear 2” Accessory Receiver 39
Stabilizers 39
INTERNAL EQUIPMENT
AND SYSTEMS
Safety 40
Propane Appliance Maintenance 40
Operating Appliances at High Altitude 41
Heating and Cooling 41
Air Conditioner 41
Furnace 41
Access 42
Key Points 42
Before Operating the Furnace 42
Maintenance 42
Thermostat – Wall-Mounted 42
Dual-Zone Thermostat 42
Entertainment and Connectivity 43
Television 43
Winegard AIR 360 43
Cable Hook-Up 43
Awning 43
Appliances 44
Microwave 44
Gas Cooktop (Range) and Oven 44
Refrigerator 45
Roof Vents (Power and Manual) 46
Removable Table 46
Solar on the Side 46
D Rings 46
Elevated Bunks 47
Standard Elevated Beds 47
Use of Bed Rails 47
Tips for Safe Elevated Bed Usage 47
Murphy Beds 48
Murphy Bed Setup and Storage 49
Slideout Systems 49
Slideout Operation 49
Troubleshooting the Slide Room 50
Slideout Manual Override 51
ELECTRICAL SYSTEM
Electrical System Maintenance 52
120-Volt Alternate Current System 52
Inverter 55
Battery Cutoff Switch 55
12-Volt Direct Current System 56
Power Center 56
Converter 56
Converter Inspection and
Maintenance 57
Solar Power and Batteries 57
Solar Controller 57
Controller Remote 57
Batteries 58
Solar Panels 59
Solar Docking Port 59
Solar on the Side 59
EmberLink™ Smart System 59

9
PROPANE SYSTEM
Overview 60
Regulator 60
Regulator Freeze-Up 60
Other Cold Weather Factors 61
LP Pigtail 61
Propane Gas Detector 61
In the event of an alarm 62
Conditions that could adversely
affect your alarm 62
Maintaining Your Alarm 62
PLUMBING SYSTEM
Docking Station 63
Nautilus Water Management System 63
Fresh Water System 64
Fresh Water System - First Use 64
Sanitizing the Fresh Water System 64
Filling the Fresh Water Tank 64
Using a Pressurized Water Source 65
Exterior Spray Ports 65
Draining the Fresh Water System 66
Water Heater 66
Basic Maintenance and Care 67
Water Pump 68
Monitoring Tank Status 68
Holding Tank Sensor Problems 68
The Lavatory 69
Showermi$er 69
Shower Maintenance 69
Bathroom Skylight 69
Toilet 69
Toilet Maintenance 69
Wastewater System 70
Black & Gray Water Holding Tanks 70
Rinsing and Draining the Black Tank 70
Emptying the Black and Gray
Water Tanks 71
Vents & Vent Pipes 71
WARRANTY, REPAIR, AND SERVICE
General Care and Maintenance 72
Cleaning the Interior 72
Exterior Finish 72
Frame and Chassis 72
Hitch Couplers 73
Safety Chains 73
Jacks 73
Tires and Wheels 73
Brake Adjustment 73
Sealants 73
Ceiling, Interior Walls,
Countertop, Tabletops 73
Faucets and Fixtures 74
Fabric and Upholstery 74
Owner Responsibilities 74
Leaking 74
Mold 74
Warranty Registration and
Change of Address 74
REQUIRED MAINTENANCE
SCHEDULE 75
WINTERIZING AND STORAGE
Winterizing Your RV 76
Dewinterizing Your RV 76
Storing your RV 77
SERIAL NUMBER, VIN, DECALS
Deciphering the VIN 78
WARRANTY
Obtaining Warranty Service 79
Obtaining Emergency
Warranty Repair 80
Service & Warranty 80
Have the Following
Available When You Call 81
Owner Aid 81
Verify the Issue 81

10
Do it Yourself 82
Write it Down 82
Part Lead Times 82
Inspect Repairs 82
Use Your Unit as Intended 82
THE 1-2-3 LIMITED WARRANTY
Important Definitions 83
What Is a 1-2-3 Limited
Warranty and How to Obtain
Warranty Service 83
EMBER’S TWO (2) YEAR LIMITED
BASE WARRANTY 84
EMBER’S THREE (3) YEAR LIMITED
STRUCTURAL WARRANTY 85
Remedies 87
Primary Remedy 87
Secondary Remedy 87
What is Not Covered by the
Ember Limited Warranties 87
Appliance and Component
Manufacturer Warranties and
Administration 88
Legal Remedies 89
ACCEPTING DELIVERY 90
Figures and Tables
Figure 1: RV Safe User’s Manual 12
Figure 2: Ember RV Website 17
Figure 3: Coupler Class and
Hitch Information 20
Figure 4: VersaCoupler™ Height Change 20
Figure 5: 7-Way Connector Wiring 21
Figure 6: TireLinc®Owner’s Manual 32
Figure 7: Wheel Nut Torque Sequence 32
Figure 8: Smart Jack Owner’s Manual 37
Figure 9: Quick Drop™ Stabilizers
Operator Manual 39
Figure 10: Dometic Furnace
Operator’s Manual 41
Figure 11: BAL Exact-Slide Manual 49
Figure 12: BAL Troubleshooting Guide 51
Figure 13: BAL Manual Override Video 51
Figure 14: 50-Amp Electrical
System Schematic 53
Figure 15: 30-Amp Electrical
System Schematic 54
Figure 16: Battery Power Schematic 55
Figure 17: WFCO Documentation 55
Figure 18: Power Center 57
Figure 19: Amp MPPT Controller Manual 57
Figure 20: Gamechanger Manuals 58
Figure 21: EmberLink™ Control Panel 59
Figure 22: LP/CO Detector
Operator’s Manual 61
Figure 23: Docking Station 63
Figure 24: Nautilus 2.5 User Instructions 63
Figure 25: Fresh Tank Overflow Hose 65
Figure 26: Fresh Water Holding
Tank Gate Valve 66
Figure 27: Hot and Cold Low
Point Drains 66
Figure 28: Truma Aqua Go Website 66
Figure 29: Dometic Water
Heater Manuals 66

11
After you have thoroughly reviewed the manual, you will have a good understanding
of the do’s and dont’s of owning and operating an Ember Recreational Vehicle. If you
aren’t sure of a certain feature, you can easily locate the section that addresses your
concern and look up the information you need. As you read through the manual, you
will encounter the following items:
DANGER indicates an imminently hazardous situation
that, if not avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation
that, if not avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation that,
if not avoided, may result in minor or moderate injury.
NOTICE is used to address practices not related to
personal injury. This applies to hazardous situations
involving property damage only.
BUNK LOADS
The maximum weight in single bunks is 300lbs and 600lbs for double bunks.
SAFETY TERMS
KEY SAFETY ITEMS
Overview of Owner’s Manual
EXCEEDING THE LOAD LIMITS FOR THE BUNKS MAY
RESULT IN FAILURE CAUSING SERIOUS INJURY.

12
EGRESS WINDOWS
Egress or “Emergency Exit” windows are labeled from the factory with the word EXIT. All
Egress windows can be distinguished by red operational handles or levers. Dependent upon
the window type, an egress window may be a large section or an entire window. Review the
locations and operational instructions posted upon the window with all people staying in the RV.
EXTINGUISHER
Each Ember Recreational Vehicle includes a fire extinguisher which is located near the main
entry door. The fire extinguishers are rated for Class B (gasoline, grease, and flammable liquids)
and Class C (electrical) fires. Check the extinguisher weekly. If the fill gauge is in the red, replace
the unit immediately. Also check tamper seals and replace if missing or damaged. Please refer
to the manufacturer’s instructions for additional details on care and operation.
SMOKE DETECTOR
For your safety a smoke detector is installed in every RV. Some may have multiple devices.
Most detectors are powered by a 9-volt battery. If the detector begins to beep regularly, replace
the battery. Check the manufacturer requirements for acceptable replacements. At least once
a week, test the alarm and clean the unit with a vacuum and a dry rag. Never use water or
solvents because this may cause damage. Please refer to the manufacturer’s instructions for
additional details on care and operation.
PROPANE GAS / CARBON MONOXIDE DETECTOR
One of the key safety features of your Ember is the propane gas and carbon
monoxide detector located near the floor in the living area. Please read the
owner’s manual for operations and maintenance.
If the detector senses the presence of LP gas, the light will turn from green to
red, accompanied by constant beeps.
ENSURE EVERYONE IN YOUR RV IS FAMILIAR WITH THE
OPERATION AND LOCATION OF ALL FIRE EXTINGUISHERS.
FIGURE 1:
RV SAFE USER’S
MANUAL

13
IN THE EVENT OF AN ALARM:
1. IMMEDIATELY EVACUATE ALL OCCUPANTS FROM THE RECREATIONAL VEHICLE.
2. SHUT OFF THE GAS SUPPLY AT THE TANK.
3. EXTINGUISH ANY OPEN FLAMES, PILOT LIGHTS AND ALL SMOKING MATERIAL.
4. TURN OFF YOUR GENERATOR.
5. DO NOT TOUCH ANY ELECTRICAL SWITCHES IN OR NEAR THE RV.
6. OPEN DOORS AND WINDOWS TO VENTILATE.
7. DO NOT USE THE RANGE HOOD OR OTHER POWER VENTS.
8. THE ALARM WILL CONTINUE TO SOUND IF LP GAS IS DETECTED OR UNTIL
TURNED OFF.
9. CONTACT A QUALIFIED SERVICE TECHNICIAN FOR REPAIRS.
10. IF YOU CANNOT REACH A GAS SUPPLIER OR QUALIFIED SERVICE TECHNICIAN,
CONTACT THE LOCAL FIRE DEPARTMENT.
11. HAVE THE LEAKAGE SOURCE CORRECTED BEFORE USING AGAIN.
FAILURE TO COMPLY COULD RESULT IN EXPLOSION RESULTING IN DEATH
OR SERIOUS INJURY.
Conditions that could adversely affect your alarm:
• Exposure to water, splashes, spray, and condensation
• Excessive dust or grease
• Cleaning supplies, chemical sprays, and perfume products
• Do not paint the alarm. Paint can block air flow to the sensor
• Silicone adhesives including hair sprays
• Corrosive liquids such as acids
• Alkaline base metals, like salt spray
• High concentrations of Hydrogen
• Closed interior doors or other obstructions blocking gases from reaching the alarm
MAINTAINING YOUR ALARM
Verify proper alarm function by pressing the Silence/Test button after storage, before
every use, and once per week during extended use. Vacuum the alarm with a soft brush
attachment to remove dust monthly.
Additional information on this critical safety component is available in the “Propane
System” section of this manual.

14
Cooking appliances need fresh air for safe operation. Before operation:
1. Open an overhead vent or turn on an exhaust fan.
2. Open a window.
A warning label is in the cooking area to remind you to provide an adequate supply
of fresh air for combustion. Unlike homes, the amount of oxygen supply is limited due
to the size of the recreational vehicle, and proper ventilation when using the cooking
appliance(s) will avoid dangers of asphyxiation.
SAFETY REGULATIONS FOR LP
Your Ember RV uses pressurized propane gas and, as such, requires that you as the owner
be made aware of the risks involved. The following warnings are posted throughout your
recreational vehicle to provide information on LP gas safety. They have been installed
not only because of the requirement to do so, but also as a reminder to occupants of
the recreational vehicle to exercise proper caution when using or being around LP gas
appliances and equipment. We list several safety procedures here for you to study. Be sure
that you and your family understand and follow them.
LP GAS CONTAINERS SHALL NOT BE PLACED OR
STORED INSIDE THE LIVING AREA OF A RECREATIONAL
VEHICLE. LP GAS CONTAINERS ARE EQUIPPED WITH SAFETY DEVICES WHICH
RELIEVE EXCESSIVE PRESSURE BY DISCHARGING GAS INTO THE ATMOSPHERE.
PROPANE POWERED APPLIANCES PRODUCE CARBON
MONOXIDE. CARBON MONOXIDE CAN BE FATAL!
IT IS NOT SAFE TO USE COOKING APPLIANCES FOR
COMFORT HEATING.
IT IS ESPECIALLY IMPORTANT THAT COOKING
APPLIANCES NOT BE USED FOR COMFORT HEATING
AS THE DANGER OF ASPHYXIATION AND/OR CARBON MONXIDE POISONING IS
GREATER WHEN THE APPLIANCE IS USED FOR PROLONGED PERIODS OF TIME.

15
If you smell gas:
• Extinguish any open flames, pilot lights, and all smoking materials.
• DO NOT touch electrical switches.
• Shut off the gas supply at the tank valve(s) or gas supply connection.
• Open doors and other ventilating openings.
• DO NOT USE THE RANGE HOOD.
• Leave the area until the odor clears.
• Have the system checked and leakage source corrected before using again.
FIRE SAFETY
Fire safety is an important part of owning a recreational vehicle. The following basic rules
of fire prevention can help eliminate the possibility of a fire.
1. Never store flammable liquids in the recreational vehicle.
2. Never leave cooking food unattended.
3. Never smoke in bed and always use an ashtray.
4. Never allow children to play with LP gas or electrical equipment.
5. Never use an open flame as a flashlight.
6. Have faulty or damaged wiring and electrical components repaired immediately.
7. Never overload electrical circuits.
8. Locate any LP leaks and have them repaired immediately.
9. Keep cooking surfaces clean and free from debris.
10. Don’t allow rubbish to accumulate.
11. Never clean with a flammable substance.
12. Spray fabrics annually with a flame retardant.
13. Be sure everyone in your RV is familiar with the location of the exits including
the emergency exit.
DO NOT FILL LP GAS CONTAINERS TO MORE THAN
80% CAPACITY.
DO NOT STORE LP GAS CONTAINERS, GASOLINE, OR
OTHER FLAMMABLE LIQUIDS INSIDE THE VEHICLE, AS
A FIRE OR EXPLOSION MAY RESULT.

16
ENSURE EVERYONE IN YOUR RV IS FAMILIAR WITH THE
OPERATION AND LOCATION OF ALL FIRE EXTINGUISHERS.
USE ONLY THE APPROVED FIRE EXTINGUISHER TO
PUT OUT A FIRE. DO NOT ATTEMPT TO USE WATER.
WATER MAY SPREAD CERTAIN TYPES OF FIRE AS WELL AS INCREASE THE
LIKELIHOOD OF ELECTROCUTION.
Use the ‘PASS’ method. Familiarize yourself and all RV
occupants with this procedure:
1. Pull the pin. (Some extinguishers may have a
cartridge that you need to push).
2. Aim the nozzle at the base of the fire.
3. Squeeze the handle to release the extinguishing agent.
4. Spray the base of the fire. (If you aim at the flames,
you won’t extinguish the fire).
In the event of a fire, get everyone outside, then determine if you should attempt to
extinguish the fire. If it is a large fire or a chemical fire, DO NOT HESITATE! Leave the
vehicle immediately and call the fire department.
If you decide it is safe to fight a fire with an extinguisher:
1. Remove the tamper tape which covers the discharge push button.
(Do not shake).
2. Hold it upright and stand six to ten feet from the fire, with a clear path to an exit.
3. Press the button down completely, aiming at the base of the fire, and spray with
a quick side to side sweeping motion.
AVOID INHALING THE DRY CHEMICALS FROM THE FIRE
EXTINGUISHER. ALTHOUGH NON-TOXIC, THEY COULD
CAUSE TEMPORARY IRRITATION. WHEN THE FIRE IS OUT, CLEAN THE AREA AS SOON
AS POSSIBLE. THE DRY CHEMICALS MAY CAUSE SURFACE DAMAGE IF LEFT TOO LONG.

17
LP GAS REGULATORS MUST ALWAYS BE INSTALLED
WITH THE DIAPHRAGM VENT FACING DOWNWARD.
REGULATORS THAT ARE NOT IN COMPARTMENTS HAVE BEEN EQUIPPED WITH A
PROTECTIVE COVER. BE SURE THAT THE REGULATOR VENT FACES DOWNWARD
AND THE COVER IS KEPT IN PLACE TO MINIMIZE VENT BLOCKAGE WHICH COULD
RESULT IN EXCESSIVE GAS PRESSURE CAUSING FIRE OR EXPLOSION.
PORTABLE FUEL BURNING EQUIPMENT, INCLUDING
WOOD OR CHARCOAL BURNING GRILLS AND STOVES,
SHALL NOT BE USED INSIDE THE RV. DOING SO MAY CAUSE A FIRE, EXPLOSION,
CARBON MONOXIDE POISONING, OR ASPHYXIATION.
TECHNICAL DATA AND GENERAL SPECIFICATIONS
This information is available via a QR Code located at the entry to
your coach. You can also visit www.emberrv.com for general weights
and measures for your specific floorplan.
Your Ember Recreational Vehicle
FIGURE 2:
EMBER WEBSITE

18
Before leaving on your first trip with your new Ember Recreational Vehicle, read the
information in this manual very carefully. After reading through the manual, run through
the following checklist at least once.
PRE-TRIP CHECKLIST
LOADING
Properly load and secure your trailer by carefully and evenly distributing the weight,
properly following add-on equipment (Thule, Yakima, etc.) guidelines, and not
exceeding the overall weight. (See Towing Guidelines)
WHEEL LUG NUTS
Check the torque on your wheels before your first trip. Recheck them at 25- and
50-mile intervals to be sure they remain secure.
TIRE INFLATION
Tires leave the dealer at the recommended pressure as indicated on the tire sidewall.
To help ensure that you don’t run into premature or uneven tire wear, always check
the tire pressure before heading out on the road.
VERSACOUPLER™
Check that the VersaCoupler™ is securely latched to the tow vehicle’s ball hitch.
Inspect the bolts to ensure they are tight and no play exists in the assembly.
SAFETY CHAINS
Check that safety chains are attached to your tow vehicle.
ELECTRICAL
Attach the 7-way connector to the tow vehicle’s mating electrical outlet. Check to
see that all camping trailer lights are functioning properly.
Pre-Trip Preparation

19
EXTERIOR
Close the valves on the LP bottles.
Empty gray/black holding tanks.
Inspect all exterior baggage doors and ensure they are secured for travel.
Inspect the Gear Box and ensure the LP canisters and batteries are secure.
Ensure the lid is fastened.
Inspect tires and check the pressures.
Check the torque on the wheel lug nuts.
Inspect the awning to ensure it is properly retracted and secured.
Turn the battery disconnect on.
Remove all snow from the roof.
Disengage the wheel brake.
Disconnect all park connections and securely store.
INTERIOR
Close all vents and windows.
Retract all slide rooms.
Inspect the interior of the RV to ensure all doors, including the refrigerator,
are closed and secured.
Verify that all safety devices are in working condition.
Engage the deadbolt on the entrance door for travel.
TOOL KIT ITEMS
Before leaving on your first trip, it is a good idea to put together your own tool kit that
contains the following items:
¾-inch lug wrench or ¾-inch socket (for lug nuts)
Socket set with metric sockets (10, 13, and 17mm)
Tire pressure gauge
Phillips head screwdriver
Small level
Pliers
Adjustable wrench (1-inch standard)
Metric hex set (4, 5, and 6mm)
Spare key to storage box
Electrical tape
Duct tape
Repair kits for tent and mattress pads

20
HITCHING
Ember RVs are equipped standard with a 2 5/16” or 2” diameter
ball type hitch mounted in a variable height coupler referred
to as a VersaCoupler™ Hitching System. The compatible ball
size is stamped on the rear of the coupler. The figures below
demonstrate how to change coupler height.
Use of any other sized hitch ball than what is compatible with your
VersaCoupler™ can create an extremely dangerous condition that
can result in separation of the coupler and ball, and/or hitch ball
failure. If you so choose, there are numerous trailer hitches and
hitching components available to you for your trailer after market,
separate from Ember. Be sure to consult with your tow vehicle
manufacturer for hitch and/or hitch assembly alternatives.
PRE-HITCH/COUPLING/TRIP CONSIDERATIONS AND INSPECTION
Be sure your hitch and tow vehicle are rated for the Gross Vehicle Weight Rating (GVWR)
of your trailer. Remember that the hitch load rating must be equal to or greater than the
coupler load (the hitch is attached to the towing vehicle, the coupler to the trailer). Be
sure the hitch size matches the coupler size. All Ember Touring Edition floorplans require
a Class 3 or Class 4 Hitch.
Examine all hitch components before hitching. Look for wear, corrosion, deformations,
stripping, and cracks. Replace worn, corroded, or cracked hitch components before
coupling the trailer to the tow vehicle. Be sure the hitch components are tight and
that the ball-locking device works freely before coupling the trailer to the tow vehicle.
FIGURE 4: VERSACOUPLER™ HEIGHT CHANGE
FIGURE 3: COUPLER CLASS
AND HITCH INFORMATION
AN IMPROPERLY COUPLED TRAILER CAN RESULT IN
DEATH OR SERIOUS INJURY.
