PNI BOOMBOX BT240 User manual
PNI BOOMBOX BT240
Portable Bluetooth speaker/Tragbarer Lautsprecher mit Bluetooth/
Altavoz portátil con Bluetooth/Haut-parleur portable avec Bluetooth/
Hordozható Bluetooth hangszóró/Altoparlante portatile con Bluetooth/
Przenośny głośnik Bluetooth/Boxa portabila cu Bluetooth
EN User manual ............................................. 3
BG Ръководство за употреба .................... 7
DE Benutzerhandbuch ................................... 12
ES Manual de usuario .................................... 16
FR Manuel utilisateur ..................................... 20
HU Használati utasítás ................................... 24
IT Manuale utente ........................................ 28
NL Handleiding ............................................. 32
PL Instrukcja obsługi ..................................... 36
RO Manual de utilizare ................................... 40
3User manual
English
WARNING: To use this product correctly, first read the instructions below. We
are not responsible for product malfunctions resulting from improper use and
under inappropriate conditions.
MAIN FEATURES
»Outdoor speaker with Bluetooth
»Audio Streaming via Bluetooth
»RGB light
»FM radio
»Karaoke function
»Wired microphone included
»USB cable with power adapter included
»Built-in 3600mAh Lithium Battery
»Aluminum handle for easy transport
TECHNICAL SPECIFICATIONS
Bluetooth communication
distance up to 10 meters
Speakers
Tweeter: 2 x 1.4 inch
Subwoofer: 4 inch
Tweeter output: 2 x 2.5W, 4Ω
Subwoofer output: 19W,4Ω
Connections
1 x USB2.0
1 x micro SD slot (up to 32GB; the card is
not included)
1 x AUX-in 3.5 mm
1 x MIC 6.34 mm
1 x micro USB (for charging)
Supported audio formats MP3/WAV/WMA
Power supply Built-In Lithium rechargeable battery
3600mAh
Maximum operating time up to 2 hours (with max. volume)
Power voltage DC 5V >1A
(via USB-micro USB cable with power
adapter included)
User manual 4
English
Dimensions 390 x 180 x 211mm
BUTTONS AND FUNCTIONS
micro SD
EQ
BASS
1 2 3
8 9 10 11 12 13 14
4 5 6 7
1. Previous song/Fast rewind
2. Play/Pause
3. Next song/Fast forward play
4. USB port
5. LED display
6. DC 5V input
7. On/Volume Control/O
8. MODE (switch between Bluetooth, USB, micro SD, FM and AUX-in)
9. RGB light/EQ
10. Microphone input
11. Micro SD slot
12. 3.5 mm AUX-in jack
13. Adjust Bass + and -
14. Function ECHO microphone + and -
BLUETOOTH
»Turntheknobclockwise toturnthedeviceon.Immediatelytwoconfirmation
beeps will be heard, and the bt symbol will flash on the screen. The light on the
side speakers will automatically turn on in alternative colors. Press the button
to choose the preferred color or to turn o the LED light of the speakers.
5User manual
English
»Activate the Bluetooth function on your mobile phone. Search for nearby
Bluetooth devices, identify your speaker and connect to it.
»After the successful connection of the two devices, the speaker will emit 3
beeps.
»Press the buttons and on the speaker or phone to choose the desired
song.
»Press the button on the speaker or phone to play or pause the current
song.
»Turn the volume knob to adjust the volume or adjust the volume in the phone.
PLAY MUSIC FROM USB DISK OR MICRO SD CARD
»After you turn on the speaker, insert into the dedicated slot a micro SD card
or USB stick (that contains audio files MP3/WAV/WMA) .
»The speaker will automatically play the music.
»Press the buttons si on the speaker to choose the desired song.
»Press the button on the speaker to play or pause the current song.
»Turn the volume knob to adjust the volume.
Note: If you are in Bluetooth mode and insert a micro SD card or USB stick, the
speaker will automatically switch to the respective playback sources. If you want to
switch to Bluetooth again, press MODE (M).
FM RADIO
»After turning on the speaker, press the MODE (M) button until you reach
FM mode. The frequency will be displayed on the screen. Use the buttons
and to search for the desired frequency. Press the button to
automatically search and memorize radio stations (maximum 11 memories).
Use the buttons and to browse through the stored radio stations.
»The audio cable included in the package plays the role of antenna. Insert the
cable into the AUX port for better FM channel reception.
AUXIN
»Connect the supplied audio cable to the AUX port on the speaker to listen to
music from other compatible devices (phone, MP3/MP4 player)
»After you insert the audio cable, the speaker will automatically switch to AUX
