SUBJECT: Service Manual Correction to Periodic Maintenance Chart
MODELS: All 2014 Sportsman 570 Models and All 2015 Sportsman EXT / 570 Models
Polaris has identified an error in Chapter 2 of the 2015 SPORTSMAN ETX 2014-2015 SPORTSMAN
570 / UTE Service Manual (9925712).The Periodic Maintenance Interval chart did not print.
Please print pages 2-4 of this communication and permanently fasten them within any printed copy of
the 2015 SPORTSMAN ETX 2014-2015 SPORTSMAN 570 / UTE Service Manual (9925712) in your
possession.
AFFECTED MANUALS:
Service Manual Part Number
Service Manual Description
Page
9925712
2015 SPORTSMAN ETX
2014-2015 SPORTSMAN 570 /UTE
2.14
NOTE: The electronic Service Manual content was updated upon the release of this Team Tip.
A-15-01-01
January 21, 2015

2.14
9925712 R02 - 2015 SPORTSMAN ETX 2014-2015 SPORTSMAN 570 / UTE Service Manual
© Copyright Polaris Industries Inc.
Periodic Maintenance Chart Key
SYMBOL DESCRIPTION
►Perform these operations more often for vehicles subjected to severe use.
EEmission-related Control System Service (California)
Failure to conduct this maintenance will not void the emissions warranty but may affect
emissions
DHave an authorized POLARIS dealer perform these services.
SEVERE USE ITEM: Severe Use is defined as frequent vehicle immersion in mud, water or sand, racing or race-style
high rpm use, prolonged low speed - heavy load operation or extended idle. More preventative maintenance is
required under these conditions. Fluid changes, cable and chassis lubrication are required more frequently. For engine
oil, short trip cold weather riding also constitutes severe use. Pay special attention to oil level. A rising oil level in cold
weather can indicate contaminants collecting in the oil sump or crankcase. Change oil immediately and monitor level. If
oil level begins to rise, discontinue use and determine cause.
NOTE: Inspection may reveal the need for replacement parts. Always use genuine Polaris parts.
WARNING
Improperly performing the procedures marked with a ■ could result in component failure and lead to serious injury or
death. Have an authorized Polaris dealer perform these services.
Periodic Maintenance Chart
Periodic Maintenance Chart
ITEM
MAINTENANCE INTERVAL
(WHICHEVER COMES FIRST)
REMARKS
HOUR-
S
CALEN-
DAR MILES (KM)
Steering -Pre-Ride -
Make adjustments as needed.
Front-suspension -Pre-Ride -
Rear-suspension -Pre-Ride -
Tires -Pre-Ride -
Brake fluid level -Pre-Ride -
Brake lever /
pedal travel
-Pre-Ride -
Brake systems -Pre-Ride -
Wheels /fasteners -Pre-Ride -
Frame fasteners -Pre-Ride -
Engine Oil Level -Pre-Ride -
Winch (if equipped) -Pre-Ride -
▶
EAir filter, pre-filter - Pre-Ride - Inspect; clean often
▶Air box sediment tube - Daily - Drain deposits when visible
Coolant -Daily - Check level daily, change coolant every 2 years
Power Steering unit (if
equipped) -Daily - Inspect daily; clean often
Head lamp / tail lamp /
worklight - Daily - Check operation; apply dielectric grease if replacing
MAINTENANCE

2
9925712 R02 - 2015 SPORTSMAN ETX 2014-2015 SPORTSMAN 570 / UTE Service Manual
© Copyright Polaris Industries Inc.
ITEM
MAINTENANCE INTERVAL
(WHICHEVER COMES FIRST)
REMARKS
HOUR-
S
CALEN-
DAR MILES (KM)
▶
EAir filter, main element - Weekly - Inspect; replace as needed
Recoil housing - Weekly - Drain water as needed, check often
if operating in wet conditions
▶
DBrake pad wear 10 H Monthly 100 (160) Inspect periodically
Battery 20 H Monthly 200 (320) Check terminals; clean; test
▶
E
Engine breather
filter (if equipped) 25 H Monthly 250 (400) Inspect; replace if necessary
Fuel System 25 H Monthly —
Inspect; Cycle the Key to pressurize the fuel
pump; check lines and fittings for leaks and
abrasion.
▶
E
Engine oil change
(break-in) 25 H Monthly 250 (400) Perform a break-in oil and filter change
▶Demand drive fluid 25 H Monthly 250 (400) Initial fluid level inspection; Change yearly*
▶Rear gearcase oil 25 H Monthly 250 (400) Initial fluid level inspection; Change yearly
▶Transmission fluid 25 H Monthly 250 (400) Initial fluid level inspection; Change yearly
▶General lubrication 50 H 3 M 500 (800) Lubricate all grease fittings, pivots, cables, etc.
D
E
Throttle Cable/
TRS Switch 50 H 6 M 500 (800) Inspect; adjust; lubricate; replace if necessary
EAir intake ducts/
flange 50 H 6 M 300 (500) Inspect ducts for proper sealing/air leaks
Drive belt 50 H 6 M 500 (800) Inspect; adjust; replace as needed
▶Cooling system 50 H 6 M 1000 (1600) Inspect coolant strength seasonally; pressure
test system yearly
▶Engine oil change 100 H 6 M 1000 (1600) Change the oil and filter
▶Oil lines and fasteners 100 H 6 M 1000 (1600) Inspect for leaks and loose
▶Demand drive fluid
(normal use) 100 H 12 M 1000 (1600) Change fluid
▶Rear gearcase oil 100 H 12 M 1000 (1600) Change fluid
▶Transmission oil 100 H 12 M 1000 (1600) Change fluid
▶Valve Clearance 100 H 12 M 1000 (1600) Inspect; Adjust
D
EFuel System 100 H 12 M 1000 (1600)
Cycle the key to prime and pressurize the fuel
system. Check for leaks at fuel cap, fuel line /
rail, and fuel pump; Replace lines every 2 years
D
EFuel Filter 100 H 12 M 1000 (1600) Replace yearly
▶Radiator
(if applicable) 100 H 12 M 1000 (1600) Inspect; clean external
▶Cooling hoses 100 H 12 M 1000 (1600) Inspect; clean external surfaces
MAINTENANCE

9925712 R02 - 2015 SPORTSMAN ETX 2014-2015 SPORTSMAN 570 / UTE Service Manual
© Copyright Polaris Industries Inc.
(if applicable)
▶Engine mounts 100 H 12 M 1000 (1600) Inspect
Exhaust muffler /
pipe 100 H 12 M 1000 (1600) Inspect
D
ESpark plug 100 H 12 M 1000 (1600) inspect; replace as needed
▶Wiring 100 H 12 M 1000 (1600)
Inspect for wear, routing, security; apply
dielectric grease to connectors subjected to
water, mud, etc.
D
Clutches
(drive and driven) 100 H 12 M 1000 (1600) Inspect; clean; replace worn parts
DFront wheel bearings 100 H 12 M 1000 (1600) Inspect; replace as needed
DBrake fluid 200 H 24 M 2000 (3200) Change every two years
Spark arrestor 300 H 36 M 3000 (4800) Clean out
D
EValve clearance 500 H 12 M 5000 (8000) Inspect; adjust as needed
▶Coolant -60 M - Replace Coolant
Idle speed - Adjust as needed
DToe adjustment -Inspect periodically; adjust when parts are
replaced
Headlight aim - Adjust as needed
▶= Perform these procedures more often for vehicles subjected to severe use.
E= Emission Control System Service (California)
D= Have an authorized POLARIS dealer perform these services.
*Service Note: Under extreme use, change demand drive fluid every 25 hours. "Extreme Use" is defined as
constant ADC operation on hilly or mountainous terrain, or if ADC is the primary mode of AWD operation.
MAINTENANCE
