Polaroid PLTTB06 User manual

Turntable
User Manual
PLTTB06

2
Welcome
Welcome to your experience with Polaroid products.
All Polaroid products we bring to you are manufactured to the highest standards of performance and safety. As part of
our philosophy of customer service and satisfaction, your purchase is backed by a comprehensive 1 Year Warranty.
This user manual tells you all you need to know about setting up and using your new product.
Please take special note of any important safety and usage information presented with the symbol.

3
Contents
Welcome 2
Contents 3
Unpack And Prepare 4
Controls and Connections 8
Operation 9
Bluetooth® 14
Troubleshooting 15
Specications 16
Compliance and Responsible Disposal 17

4 | UNPACK AND PREPARE
Before setting up your new Turntable, check you have everything:
A. Turntable
B. Power Adaptor
C. Adaptor for 45rpm records
D. Warranty Certificate
E. General Safety Warnings
F. User Manual
Unpack And Prepare
What's in the box

UNPACK AND PREPARE | 5
Important Tips
• Place the turntable on a level surface.
• Place the turntable away from any source that may generate heat or vibrations.
• Make sure there is enough space around the turntable for airflow. Leave at least
10cm clearance around the product.
• Unplug the turntable before cleaning it.
• Clean using a dry cloth only - do not use water or chemicals.
• Only use the provided power supply.
• Keep liquid, children and pets away from the turntable at all times.
• Repack in its original packaging when transporting the turntable.

6 | UNPACK AND PREPARE
Before rst use
• Unpack the product but keep all packaging materials until you have made
sure your new product is undamaged and in good working order. Plastic
wrapping can be a suffocation hazard for babies and young children, so
ensure all packaging materials are out of their reach.
• Unwind the cord to its full length and inspect it for damage. Do not use the
product if the product or its cord have been damaged or are not working
properly. In case of damage, contact our after sales support line for advice
on examination or repair or return of the damaged product.
• Read this manual to familiarise yourself with all the parts and operating
principles of the product.
• Do not connect the unit to the mains power socket before checking the
mains voltage and before all other connections have been made.

UNPACK AND PREPARE | 7
• Connect the DC plug into the DC IN power jack of the turntable.
• Plug in the adaptor into the AC power outlet.
Connect to power
Make sure the turntable is switched off at the power
outlet until you have finished connecting your cables.
Don't forget to plug in the
turntable to the power outlet.
Leave the power switched off
until installation is finished.

8 | PRODUCT OVERVIEW
Controls and Connections
1. Protective Cover
2. Turntable
3. 45rpm Adaptor
4. Tonearm
5. Lit Lever
6. Auto Stop Control Switch
7. Speed Control Selection
8. Stylus Cartridge
9. Built-in Speakers (under the turntable)
10. Power/Volume Control Knob
11. Line Out Jack
12. DC IN Power Jack
13. Passive Radiator
1
2
3
4
5
6
7
8
9
13
10
1211
Product Overview

REMOTE CONTROL | 9
Operation
Power On and Mode selection
• Turn on (with the POWER/VOLUME Knob) and you will hear a doorbell sound, meaning that it is in
Bluetooth®mode. If there is a SD card or USB plugged in, it will automatically start to playback from
the SD card/USB.
• Once you place the tonearm on the vinyl or the Auto Stop switch is set to OFF, the turntable will
switch to vinyl mode and Bluetooth® or SD/USB mode will automatically be disabled; Place the
tonearm back to the arm rest to switch back to Bluetooth® or SD/USB mode. When the tonearm
is back in the arm rest, use the MODE button on the right side of the turntable to switch between
Bluetooth® and SD/USB mode.
Playing a Record
• Turn on (with the POWER/VOLUME KNOB) and adjust the volume to an appropriate level.
• Place a record on the turntable platter and select the correct playing speed: 33, 45, 78 RPM (according to the vinyl
being played).
• Set the AUTO STOP switch to ON if you are playing a 33 RPM record and you want the turntable to stop turning when
it has reached the end of the record. If the switch is set to OFF, the turntable will continue turning at the end of the
record.
• Remove the stylus guard and unlock the tone arm lock. Push the lift lever upward to raise the tone arm and then gently
move the tone arm to the desired position over the record. The platter will begin to spin when the tone arm is moved
toward the record.

10 | REMOTE CONTROL
• Push the lift lever forward to lower the tone arm slowly onto the desired position on the record and begin playing the
record.
• When you have finished playing the record, push the lift lever backward to raise the tone arm and gently move it back
to its rest.
• When you have finished playing records, engage the tone arm lock to protect it from accidental movement. Turn the
POWER KNOB to switch the unit OFF. Unplug it from the power supply if you are not going to use it for a while.
• NOTE: If your record stops before the last track finishes, set the AUTO STOP switch to OFF. Your record will now play
to the end, but you will have to stop the turntable rotation manually.
• NOTE: Depending on the record length, AUTO STOP may be enabled before the end of the recording. Do not rely on
AUTO STOP alone to turn off playback.
To avoid damaging the stylus, ensure that the
included stylus guard is in place whenever the
turntable is being installed, moved or cleaned.

REMOTE CONTROL | 11
MODE
SD CARD
LED
USB
• If a USB or SD card has already been inserted when the unit is switched on, the music from the USB or SD card will
be played automatically.
• When playing a vinyl disk, press and hold the MODE button for 2 seconds to start recording and the LED on the right
side of the turntable will flash. Press the button to stop recording.
• To play the recorded file, put the tonearm back to the armrest. The music will be played automatically from the USB
or SD card. Then press the MODE button again, and the recorded file will be played.
• To delete the recorded music from the USB or SD card, press and hold the button until the music stops playing.
Connect to an External Amplier using the Line Out Port
Use a RCA audio cable to connect to the Line Out port (L/R) at the back of the turntable, and then connect to the your
external amplifier.
Note that the internal speaker and the Line Out port will have output at the same time.
Playing Music from or Record Music to USB/SD card
The panel on the side of the turntable allows you to play music from a USB/SD card and record music directly from the
vinyl.
1. MODE: Press to switch between
Bluetooth®/SD/USB.
If there is recorded music in the SD/
USB, pressing the button will switch
to the recorded folder.
2. : Play previous track
3. : Play next track
4. : Press to play or pause. Hold
to delete current music. In REC
mode, press to stop recording.
1 2 3 4
NOTES:

12 | REMOTE CONTROL
Tips to better performance
• When opening or closing the turntable cover, handle it gently, moving it either at the center or equally from
both sides.
• Do not touch the stylus tip with your fingers; avoid bumping the stylus on the turntable mat or on the edge of
the record.
• Clean the stylus tip frequently, using a soft brush with a back-to-front motion only.
• If you use a stylus cleaning fluid, use it very sparingly.
• Wipe the dust cover and turntable housing gently with a soft cloth. Clean the unit only with a dry, clean cloth.
Do not use liquid or aerosol cleaners.
• Never apply harsh chemicals or solvents to any part of the turntable system.
• Prior to moving the turntable, always unplug it from the AC power outlet and fasten the tone arm on the tone
arm rest with the vinyl twist-tie.

REMOTE CONTROL | 13
5
12
23
3
4
6
78
Push the arm lock to
release the tone arm.
Carefully insert the audio-
line connector to the new
cartridge.
Carefully slide the
cartridge into the
cartridge holder.
Gently clip the cartridge
into the cartridge holder.
Gently pull the audio-
lines from the cartridge,
pull from the terminal
connector and not the
wire itself.
Take off the cap of the
cartridge to expose the
needle.
Separate the cartridge
from the cartridge
holder by loosening
the locker.
Make sure the audio-
lines are not touching
each other.
Be very careful when changing the
stylus cartridge, to avoid damage to the
tone arm and audio wires.
Replacing the stylus

14 | BLUETOOTH
Bluetooth®
You can listen to tracks from a media device if connected
to the unit via Bluetooth®wireless technology.
• When the turntable is switched on and the tonearm
is placed on the arm rest, Bluetooth® mode is
automatically activated (if there is no SD/USB plugged in).
• The first time you use your Bluetooth® device with the
turntable, you will need to pair them with one another.
• Activate Bluetooth® on your compatible device, and set
it to search for compatible devices.
• Select the speaker name: 'PLTTB06' from the list of found
devices.
• If your device asks for a passkey (depending on the
device manufacturers, model, and software version),
then enter digits “0000” and press OK.
• You can also use the control buttons on the right side of
the turntable to play, play previous/next and pause the
music.
Pairing Bluetooth®Devices
The operational range between this turntable and
a Bluetooth®device is approximately 10 metres
(without any object between the Bluetooth®enabled
device and the unit). Any obstacle between the
devices can reduce the operational range.
Before you connect a Bluetooth®enabled device to
this unit, ensure you know the device’s capabilities.
Compatibility with all Bluetooth®devices is not
guaranteed.
If the signal strength is weak, your Bluetooth®
receiver may disconnect, but it will re-enter pairing
mode automatically.
If a mobile phone on which you are playing music
receives a call, the music will be interrupted. The
phone call audio however is not played via the
speakers. Once you end the call, the devices are
connected to each other again and playback resumes.
Your device will also be disconnected when your
device is moved beyond the operational range. If you
want to reconnect your device, place it within the
operational range.
If the connection is lost, follow the instructions (left) to
pair your device to the player again.

TROUBLESHOOTING | 15
If you have problems with the turntable, check below for advice. If you don't find a solution here, contact After Sales Support on
1300 886 649.
Troubleshooting
Problem Solution
No power • Ensure that the power adaptor is properly connected.
• Ensure that there is power at the AC outlet.
No sound
• Rotate the volume knob clockwise to increase the volume.
• Check that the turntable is in the correct mode. If in Bluetooth®mode, check the Bluetooth®source device to
make sure that it's not muted or stopped playing.
The vinyl record will
not play
• Make sure you have selected the correct speed (33, 45, 78rpm).
• Check whether the vinyl has already played to the end.
SD card or USB can
not playback
• Check that the tonearm is back in the armest.
• Check that it is in the correct mode.
• Check that the Auto Stop switch is set to ON.
• Check that the SD/USB le system should be FAT32 and check that the music le format is mp3 or ac.

16 | SPECIFICATIONS
Specications
Power Adaptor Input AC 100-240V, 50/60Hz 0.5A
Power Adaptor Output DC 5V/1A
Dimensions (Turntable) 430 x 118 x 364mm (w x h x d)
USB & SD Max 64GB
Supported Formats mp3, ac
Recording 128kpbs
Vinyl Records
Speed Supports playback speed
33 / 45 / 78 RPM
Record size support
7” = 17.7cm
10” = 25.5cm SP
12” = 30cm LP
Speaker 2 x 3W
Net Weight 3kg
Gross Weight 4.85kg

SPECIFICATIONS | 17
Compliance and Responsible Disposal
Compliance
This product complies with the Australian Safety Standard
AS/NZS 60065 to ensure the safety of the product.
Packaging
The packaging of your product has been
selected from environmentally friendly
materials and can usually be recycled. Please ensure
these are disposed of correctly. Plastic wrapping can
be a suffocation hazard for babies and young children,
please ensure all packaging materials are out of reach
and are safely disposed of. Please recycle these
materials rather than throwing them away.
Product
At the end of its working life, do not throw this product
out with your household rubbish. An environmentally
friendly method of disposal will ensure that valuable
raw materials can be recycled. Electrical and electronic
items contain materials and substances which, if
handled or disposed of incorrectly, could potentially be
hazardous to the environment and human health.

18
Notes

19
Notes

Have questions? We’ve got
answers.
Visit us at tempo.org/support or
give us a call at 1300 886 649
Polaroid, Polaroid Color Spectrum and Polaroid Classic Border Logo are trademarks of PLR IP Holdings, LLC, used under license .
PLR IP Holdings, LLC does not manufacture this product or provide any Manufacturer’s Warranty or support.
©2020 All rights reserved.
