Polaroid PL3266TB User manual

Wall Mounted Turntable
User Manual
PL3266TB

2
Welcome
Welcome to your experience with Polaroid products.
All Polaroid products we bring to you are manufactured to the highest standards of performance and safety. As part of
our philosophy of customer service and satisfaction, your purchase is backed by a comprehensive 1 Year Warranty.
This user manual tells you all you need to know about setting up and using your new product.
Please take special note of any important safety and usage information presented with the symbol.
Mounting the product requires specialist knowledge. We assume no liability for any injury or material
damage incurred due to incorrect assembly or use. Make sure to follow all instructions and if you require
professional advice, please consult a relevant tradesperson.
The Turntable can only be used wall mounted. Table top use is not recommend. The vinyl will easily be
damaged if having contact with the tonearm if used flat for a table.
WARNING

3
Contents
Welcome 2
Contents 3
Unpack And Prepare 4
Controls and Connections 8
Installation 10
Operation 13
Bluetooth® 19
Troubleshooting 20
Specications 21
Compliance and Responsible Disposal 22

4 | UNPACK AND PREPARE
Before setting up your new Turntable, check you have everything:
A. Wall Mounted Turntable
B. Power Adaptor
C. USB Cable
D. Magnetic Record Lock
E. Driver CD
F. Protective Cover
G. Warranty Certificate
H. General Safety Warnings
I. User Manual
Unpack And Prepare
What's in the box

UNPACK AND PREPARE | 5
Important Tips
• Place the turntable away from any source that may generate heat or vibrations.
• Make sure there is enough space around the turntable for airflow. Leave at least
10cm clearance around the product.
• Unplug the turntable before cleaning it.
• Clean using a dry cloth only - do not use water or chemicals.
• Only use the provided power supply.
• Keep liquid, children and pets away from the turntable at all times.
• Repack in its original packaging when transporting the turntable.

6 | UNPACK AND PREPARE
Before rst use
• Unpack the product but keep all packaging materials until you have made
sure your new product is undamaged and in good working order. Plastic
wrapping can be a suffocation hazard for babies and young children, so
ensure all packaging materials are out of their reach.
• Unwind the cord to its full length and inspect it for damage. Do not use the
product if the product or its cord have been damaged or are not working
properly. In case of damage, contact our after sales support line for advice
on examination or repair or return of the damaged product.
• Read this manual to familiarise yourself with all the parts and operating
principles of the product.
• Do not connect the unit to the mains power socket before checking the
mains voltage and before all other connections have been made.

UNPACK AND PREPARE | 7
• Connect the DC plug into the DC IN power jack
of the turntable.
• Plug in the adaptor into the AC power outlet.
Connect to power
Make sure the turntable is switched off at the power
outlet until you have finished connecting your cables.
Don't forget to plug in the
turntable to the power outlet.
Leave the power switched off
until installation is finished.

8 | CONTROLS AND CONNECTIONS
Controls and Connections
1. Speakers
2. Magnetic record lock
3. Turntable
4. Speed control knob
5. On/o/volume knob
6. Stylus cartridge
7. Tonearm
8. Tonearm lock
9. DC IN power jack
10. Line Out Jack
11. AUX IN jack
12. PC port
1
1
2
3
4
5
6
7
8
912
10 11
Product Overview

PRODUCT OVERVIEW | 9
1. Screws (2)
2. Wall mounting bracket
3. Plastic anchors (2)
Installation Kit (Assembly Hardware)
The illustration below shows the contents of the installation pack. These are the parts that
you will need to wall mount the turntable. Some parts are not shown at the same scale.
1
2
3

10 | OPERATION
Installation
Make sure you read and understand all instructions. Handle and use all materials strictly according to the instructions.
If you do not understand these directions, or have any questions in relation to the safety of the installation, we
recommend you contact a qualied professional.
Note: This turntable is for indoor home use only.
TIP: Installation of the Turntable will be easier with two people.
WARNING: Be sure to choose a structurally sound wall area that is strong enough to hold the weight of the turntable.
Mount the wall plate far away from any water source and direct sunlight.
WARNING: DO NOT attach the turntable to a hollow wall or decorative cardboard.
Tools Required: To complete the following steps you will need:
A. Pencil
B. Phillips Head Screwdriver
C. Power Drill
D. Hammer
E. Stud Detector
A
DE
BC

OPERATION| 11
Preparation (for a Brick or Concrete Wall)
• Mark 2 holes in the locations as shown on the right.
• On the marked holes, pre-drill holes of 6mm diameter and
30mm depth into the concrete or brick wall.
• Wedge the plastic anchors into the holes, gently tap each
anchor with a hammer until they are flush with the concrete or
brick wall.
• Screw the wall bracket to the wall with the wall screws, insert
into each plastic anchor and then tighten the screws.
• Hold the turntable and hang on back side of bracket on the
turntable to the wall mount.
NOTE: the turntable is designed to only be used whilst wall
mounted. It is not recommended to use the turntable in a at
position on a table. The turntable may not be able to play the vinyl if
placed at on a table.
WARNING: Do not drill into mortar
joints. Please pay attention to
the electrical lines and also the
location of gas and water lines
when drilling holes.
18 mm
Wall
Back

12 | OPERATION
Preparation (for a Wood Stud Wall)
• Use a stud detector to locate the centre of the framing studs.
• Mark 2 holes in the locations as shown on the right.
• On the marked holes, install the screw into the wood stud wall.
• Hold the turntable and hang on back side of bracket on the
turntable to the wall mount.
WARNING: Please pay attention
to the electrical lines and also the
location of gas and water lines
when drilling holes.
NOTE: If you are installing the turntable to a wood stud wall,
consult a builder for advice. The wall must be strong enough
for the weight of the turntable.
NOTE: the turntable is designed to only be used whilst wall
mounted. It is not recommended to use the turntable in a at
position on a table. The turntable may not be able to play the
vinyl if placed at on a table.
18 mm
Wall
Back

OPERATION| 13
Operation
Power On and Mode selection
• Rotate the On/off/volume knob to turn the turntable on. The turntable will automatically be on Bluetooth®
mode by default.
• Once you place the tonearm on the vinyl, the turntable will switch to vinyl mode and Bluetooth® mode will
automatically be disabled. Place the tonearm back to the arm rest to switch back to Bluetooth® mode.
Playing a Record
• First, take out the magnet record lock and insert your vinyl. Put the
magnet record lock back to secure the vinyl. Turn on (with the On/
off/volume) and adjust the volume to an appropriate level.
1. Remove the stylus guard and unlock the tone arm lock. Push the
lift lever backward to raise the tone arm and then gently move
the tone arm to the desired position over the record. The platter
will begin to spin when the tone arm is moved toward the record.
NOTE: Ater 10 minutes of no sound input, the turntable will automatically go into standby mode. Turn the On/O/
Volume knob to switch the turntable OFF and switch ON again to restart the turntable.
To avoid damaging the stylus, ensure that the
included stylus guard is in place whenever the
turntable is being installed, moved or cleaned.
2. Push the lift lever backward to lower the tone arm slowly onto the desired position on the record and begin playing
the record.
• When you have finished playing the record, push the lift lever forward to raise the tone arm and gently move it back to its rest.
• When you have finished playing records, engage the tone arm lock to protect it from accidental movement. Turn the
On/off/volume knob to switch the unit OFF. Unplug it from the power supply if you are not going to use it for a while.

14 | OPERATION
1. Connect to an External Amplier using the Line Out Port
Use a RCA audio cable (not included) to connect to the Line Out port (L/R) at the side of the turntable, and then
connect to the your external amplifier.
Note that the internal speaker and the Line Out port will have output at the same time.
2. Connect to an External Amplier using the AUX IN Port
Use a 3.5mm AUX cable (not included) to connect to the AUX IN port at the side of the turntable, and then
connect to the your external device.
3. Connect to a PC for encoding
You can digitalise sound from the turntable to the computer.
Connect the supplied USB cable to the PC port on the turntable and the other end to your computer's USB port.
Insert the supplied Driver CD into the computer's disc and follow the on screen instruction to install the Audacity
software. Alternatively, you can download the software and user manual from www.audacityteam.org/download/
Audacity Logo Copyright © 2022 by Audacity. All rights reserved.
1 2 3

OPERATION| 15
Installing the Sotware
Using the included CD software and cable, you can connect the turntable to your computer, so that you may
record your vinyl records onto the computer.
• Insert the enclosed software CD into your computer.
• If the CD does not load automatically, browse the CD and double click on the executable file called
‘audacity-xxx-yyy.exe’ to run it. Follow the instructions on the computer screen to install the software.
Recording Vinyl Records to your Computer
1. Connect the square end of the USB cable to the USB port on the side of the turntable.
2. Connect the other end to a USB port on your computer.
3. On your computer, open the audacity software, you will see the following window:
PC Recording

16 | OPERATION
4. Click on the Microphone list and select ‘Microphone Array (USB PnP Audio Device)’.
5. Play the song that you want to record, then click the record button to start recording.
6. Click the Stop button to stop recording.
7. Go to menu ‘File – Export – Export as WAV (or MP3)’ and then choose the location where
you want the file to be saved. Click once on the file to rename it and then click ‘Save’.
8. Go to menu ‘File – New’ to start a new window and record another song.
NOTE: Each recording creates one file, so you may record multiple songs in the
same file. If you want to record each song as a separate file, stop the recording
once the song is finished and start a new file to record the next song. The volume of
the song being recorded is not affected by the volume setting on the turntable.
If the input source is Bluetooth or AUX IN, please adjust the volume level on your external
device. Please note depending on the version software, there will be slight differences of
menu operation.
You can download the sofrware and user manual from www.audacityteam.org/download/
Audacity Logo Copyright © 2022 by Audacity. All rights reserved.

OPERATION| 17
Tips to better performance
• Do not touch the stylus tip with your fingers; avoid bumping the stylus on the turntable mat or on the edge of
the record.
• Clean the stylus tip frequently, using a soft brush with a back-to-front motion only.
• If you use a stylus cleaning fluid, use it very sparingly.
• Clean the unit only with a dry, clean cloth. Do not use liquid or aerosol cleaners.
• Never apply harsh chemicals or solvents to any part of the turntable system.
• Prior to moving the turntable, always unplug it from the AC power outlet and fasten the tone arm on the tone
arm rest with the vinyl twist-tie.

18 | OPERATION
5
12
23
3
4
6
78
Push the arm lock to
release the tone arm.
Carefully insert the audio-
line connector to the new
cartridge.
Carefully slide the
cartridge into the
cartridge holder.
Gently clip the cartridge
into the cartridge holder.
Gently pull the audio-
lines from the cartridge,
pull from the terminal
connector and not the
wire itself.
Take off the cap of the
cartridge to expose the
needle.
Separate the cartridge
from the cartridge
holder by loosening
the locker.
Make sure the audio-
lines are not touching
each other.
Be very careful when changing the
stylus cartridge, to avoid damage to the
tone arm and audio wires.
Replacing the stylus

BLUETOOTH | 19
Bluetooth®
You can listen to tracks from a media device if connected
to the unit via Bluetooth®wireless technology.
• When the turntable is switched on and the tonearm is
placed on the arm rest, Bluetooth®mode is automatically
activated.
• The first time you use your Bluetooth®device with the
turntable, you will need to pair them with one another.
• Activate Bluetooth®on your compatible device, and set it
to search for compatible devices.
• Select the speaker name: 'PL3266TB' from the list of
found devices.
• If your device asks for a passkey (depending on the
device manufacturers, model, and software version),
then enter digits “0000” and press OK.
Pairing Bluetooth®Devices
The operational range between this turntable and
a Bluetooth®device is approximately 10 metres
(without any object between the Bluetooth®enabled
device and the unit). Any obstacle between the
devices can reduce the operational range.
Before you connect a Bluetooth®enabled device to
this unit, ensure you know the device’s capabilities.
Compatibility with all Bluetooth®devices is not
guaranteed.
If the signal strength is weak, your Bluetooth®
receiver may disconnect, but it will re-enter pairing
mode automatically.
If a mobile phone on which you are playing music
receives a call, the music will be interrupted. The
phone call audio however is not played via the
speakers. Once you end the call, the devices are
connected to each other again and playback resumes.
Your device will also be disconnected when your
device is moved beyond the operational range. If you
want to reconnect your device, place it within the
operational range.
If the connection is lost, follow the instructions (left) to
pair your device to the player again.

20 | TROUBLESHOOTING
If you have problems with the turntable, check below for advice. If you don't find a solution here, contact After Sales Support on
1300 886 649.
Troubleshooting
Problem Solution
No power • Ensure that the power adaptor is properly connected.
• Ensure that there is power at the AC outlet.
No sound
• Rotate the On/off/volume knob clockwise to increase the volume.
• Check that the turntable is in the correct mode. If in Bluetooth®mode, check the Bluetooth®source device to
make sure that it's not muted or stopped playing.
• After 15 minutes of no sound input, the turntable will automatically go into standby mode. Turn the On/Off/
Volume knob to switch the turntable OFF and switch ON again to restart the turntable.
The vinyl record will
not play
• Make sure you have selected the correct speed (33, 45, 78rpm).
• Check whether the vinyl has already played to the end.
• Check whether the Magnetic Record Lock lock has secured the vinyl.
• The turntable is designed to be used while wall mounted.
For Technical and Warranty Support
1300 886 649
tempo.org/support
Distributed by Tempo (Aust) Pty Ltd,
PO Box 132, Frenchs Forest NSW 1640
