Polytree TV70M3X05D00 User manual

ASSEMBLY INSTRUCTIONS MADE IN CHINA
Top view Side view
Fig. C
MODEL #: TV70M3X05D00
*Electrical Rating For The Tree
(For Indoor Use Only)
Input:120VAC, 60Hz, 0.16A
Output: 29V DC 0.28A
Fig. B - Tree and Light Assembly
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Congratulations on purchasing your new tree from Polytree®! Carefully follow the instructions below
on how to quickly and easily set up your new tree.
TREE ASSEMBLY INSTRUCTIONS
3. Each tree section is numbered with a tag.Please identify all sections before assembling.
4. Assemble the tree from the bottom to the top. Start with the bottom section and remove protective
cap before inserting into the assembled stand.Make sure the pole is firmly inserted and secured into
the stand.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Allow branches to fall into place or gently pull up and out.When adjusting branches, be sure that all
wires are free of branch hinges.
7. (For pre-lit trees only) Connect the light strings as per the color labels indicated in Fig. B and insert
green label plug into the wall outlet.Your entire tree should now be lit. If some bulbs do not light or
flickers, search for any loose plugs and/or broken, loose or missing bulbs. Replace bulbs promptly in
order to maintain the performance and life expectancy of your pre-lit tree.
8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from
the pole and fan out one to the right, one to the left and one at the center of the main stem. (See Fig. C)
Section 3
Section 2
Section 1
Adaptor
To Be Plugged
Into Wall
Outlet
Insert Green
Label Extension
Cord into Adaptor
Control box
Insert Red Label
Plugs Into Red
Labeled Extension Cord
Fig. A - Tree Stand Assembly
Pull apart the legs of the stand so that they
are snapped into an x-shape, place the tree
stand on a level surface.
To close the stand, press the metal button
and fold the legs together.
Click

ASSEMBLY INSTRUCTIONS MADE IN CHINA
9. After shaping the entire tree following the previous step, slightly upsweep all branch tips for a uniform
look. Shift branches to fill any gaps.Your Christmas tree is now complete and ready to be decorated.
STORAGE INSTRUCTIONS
TROUBLE SHOOTING TIPS
SPARE PARTS
1. Remove all ornaments and decorations. For pre-lit trees, first unplug extension cord from the wall outlet
and then disconnect light extension cord between each section of the tree.
2. Disassemble the tree from the top to the bottom. Start with the tree top and gently lift straight up to
remove from section below and fold all branches toward the pole.
3. In case of difficulty separating the tree pole (trunk), apply a small amount of lubricant at the joint and
rotate the upper pole in both directions. Lift up the upper pole again.
4. Continue by gently lifting straight up each section(s) from the section below and fold all branches
toward the pole until the bottom section is removed from the tree stand.
5. Carefully place all tree sections into shipping box and tape it shut.
6.When not in use, please store your tree in a cool, dry place away from sunlight. Exposing your tree to
excessive heat or humidity may damage your tree.
For Pre-lit Trees, If The Tree Does Not Illuminate
1. Please check to make sure that all plugs are properly connected according to the color labels indicated
in Fig.B and the power cord is plugged into the wall outlet. Refer to assembly guide for instructions. (If
the tree comes with a foot pedal, try stepping on the on/off button).
2. Please check for blown fuses at the light string plugs and power cord plug. Replace as needed.
Note: Please make sure to use appropriate replacement fuses as indicated on the light string plug and
power cord plug.
3. Please check for loose, broken or missing light bulbs and replace as needed.
For pre-lit trees spare bulbs and fuses are included, if extra parts are needed, please contact our customer
service center.
CUSTOMER SERVICE FOR CHRISTMAS TREES
For any questions, assistance, or missing parts, Do Not Return To Place Of Purchase. Please contact
us at 1-888-919-0070 or visit our website at www.polygroup.com. One of our customer service
representatives will be happy to assist you.
TREE ID# IS LOCATED ON END PANEL OF BOX.TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.
Customer Name:
Address:(No P.O. Boxes)
City & State:
Zip Code:
Day Phone:
Date Purchased:
Tree ID#:
Tree UPC#:
Store Purchased:
Specify Problem:
Press the selector button on the “Dual Color Light Controller” or
“Remote Controller” to select among: (1) CLEAR AND
MULTI-COLOR ALTERNATING; (2) CLEAR LIGHTS; (3) MULTI
LIGHTS and (4) TURN OFF BOTH LIGHTS.
For the remote controller, replace only with CR2032 battery.
See bottom of the remote controller for replacement instruction.
WARNING
1. Use only power adaptor supplied with this product, using a different adaptor will damage the lights.
and cause fire, electrical shock hazards.
2. FOR INDOOR USE ONLY.
HOW TO USE THE DUAL COLOR LIGHT CONTROLLER AND
REMOTE CONTROL:
Light
Controller
Selector
Button
Remote
Controller
