Popp INTERACT3 User manual

1
User manual
Wireless adaptor plug switch IP 20/IP 44, wireless adaptor plug dimmer
German/English
I
NTER
A
C
T
3
.
53916.00.001.01 Wireless adaptor plug switch IP 20 (Model ZW ZS 3500)
53917.00.001.01 Wireless adaptor plug switch IP 44 (Model ZW ZSA 3500)
53918.00.001.01 Wireless adaptor plug dimmer (Model Z-DAN 300)

2
I
NTER
A
CT
3
.
3
INTER
A
C
T
3
.
Dear INTERACT3user:
You can download this user manual in an appropriately larger
format from our internet website www.popp.eu.
Our service hotline is available for further product-relevant
questions at the service line: +49 (0) 92 73/73-150.
Index of contents/overview of chapters
1. General information on “Z-Wave”.........................................6
2. General information ..................................................................9
2.1 LED indication .............................................................................9
3. Before installation/startup .......................................................9
4. General Information on wireless plug adaptors ............10
5. Functions/operation ...............................................................13
5.1 Network inclusion ...................................................................13
5.2 Operation .................................................................................14
5.3 Special function wireless plug adaptor dimmer..............15
5.4 Special function Child Protection ....................................... 15
5.5 Reset.............................................................................................16
5.6 Including a wireless plug adaptor
into third-party networks .......................................................18
6. Technical Data .........................................................................19
7. Guarantee ................................................................................20

4
I
NTER
A
CT
3
.
5
INTER
A
C
T
3
.
1. GENERAL INFORMATION ON “Z-WAVE”:
INTERACT³ is a radio system that is based on Z-WAVE
technology. INTERACT³ offers a varied range of advanta-
ges in comparison to other radio systems:
Safe:
Generally, radio systems build a direct link between the trans-
mitter and the receiver. The radio signal is attenuated by every
obstacle along its path (in the household e.g. wall, furniture
etc.), in the worst case the radio system ceases to function. The
advantage of the intelligent INTERACT³ system is the so -called
routing function: All devices of INTERACT³ not only act as the
transmitter or the receiver but also simultaneously as the “re-
peater”. Should a direct radio link between the transmitter and
the receiver not be possible, communication will be established
with the assistance of other devices.
Communicative:
INTERACT³ is a bidirectional radio system. This means that a
signal is not just sent but also a feedback confirming the recep-
tion of the signal occurs automatically. The safety of transmission
of the INTERACT³ radio bus technology is comparable with that
of a wire-linked bus system. It is likewise possible to determine
the switching status by pushing a button: Has the cellar light been
definitely switched off?
Trouble-free:
INTERACT³ transmits at a regulated frequency band with a fre-
quency of 868 MHz. Every INTERACT³ network has its own
unique network identification. Therefore, it is possible to operate
two or more independently-operating networks in a room or home
without any interferences. Troubles that can be caused by other
devices, as is the case in open, non-regulated frequencies
(e.g. 433 MHz) are excluded.

6
I
NTER
A
CT
3
.
7
INTER
A
C
T
3
.
Established:
Although the Z-Wave technology is new, it has already develo-
ped to form a technical standard. Renowned manufacturers from
various fields offer solutions and applications that are based on
Z-Wave technology and compatible among one another. This
makes the system fit for the future and promises further upgrade
phases. Further information can be found on www.z-wave.
com.
Dynamic:
INTERACT³ is equipped with a dynamic network structure. Right
from the start, the position of the individual INTERACT³ devices
who are supplied with 230 Volts is monitored and automatically
updated in the case of changes. As a means of which it is pos-
sible to continuously adapt the network to its individual require-
ments, wholly automatically without the necessity of any program-
ming tasks.
2. GENERAL INORMATION:
2.1 LED indication:
Yellow: device is switched on.
Blue: device is switched off.
Red: device defective/
Configuration not successful.
Blinking yellow: device is dimming up.
Blinking blue: device is dimming down.
Green: Configuration successful.
Red/Green blinking: device is not programmed.
Red/yellow/green: Reset is accomplished.
Short green light: Child protection is deactivated.
Blinking red: Child protection is activated.
Thermoswitch is activated

8
I
NTER
A
CT
3
.
9
INTER
A
C
T
3
.
3. BEFORE INSTALLATION/STARTUP:
Please carefully read the enclosed user manual before installa-
tion in order to ensure an error-free functioning.
ATTENTION: Works with 230 voltage networks may be
done only by authorized technicians under consideration
of the country-specific installation guidelines/ norms. Prior
to the assembly of the product, the voltage network has to
be switched on and ensured against re-switching.
The product is permitted only for proper use as specified in the
user manual. Any kind of guarantee claim has to be forfeited if
changes, modifications or painting are undertaken. The product
must be checked for damages immediately after unpacking. In
the case of a damage, the product should not be operated in
any case.
If a danger-free operation of the equipment cannot be assured,
the voltage supply has to be immediately interrupted and the
equipment has to be protected from unintended operation.
NOTE: The product is dispatched in the delivery state “not pro-
grammed”. While installation or actuating the pushbutton, this
status is showed by a blinking red/ green LED.

10
I
NTER
A
CT
3
.
11
INTER
A
C
T
3
.
4. GENERAL INFORMATION ON WIRELESS PLUG ADAPTORS:
Wireless adaptor plug switch IP 20 (761 293) (Model ZW ZS 3500)
Wireless adaptor plug switch IP 44 (761 309) (Model ZW ZSA 3500)
Wireless adaptor plug dimmer (761 316) (Model ZW ZDAN 300)
Flip-open cover
Status
LED Status
LED
Function
button Function
button
• Serves the purpose of switching or dimming of fitted lights
either via radio communication or directly over the
“FUNCTION” button of the wireless plug adaptor.
• Wireless plug adaptors IP 20 (761 293) and IP 44 (761
309) are suitable for the wireless switching of incandescent
bulbs, HV and NV-halogen bulbs (all transformer types).
• Wireless dimmer adaptor (761 316) is suitable for the
wireless dimming of HV and NV-halogen bulbs (all trans-
former types).
Attention: Applies only for iron-core transformers, see label!
NOTE: Do not interconnect more than one plug
adaptor!!

12
I
NTER
A
CT
3
.
13
INTER
A
C
T
3
.
NOTE:
• Insert wireless adaptor plugs only in sockets with safety
contact/ ground wire.
• Use of the wireless adaptor plug with devices that cannot
comply with the technical standards can cause malfunc-
tioning or damage connected equipments or wireless
adaptor plugs.
• Since the wireless adaptor plug deals with electronic equip-
ment, one has to take special care in contact with moisture
or cleaning agents. We recommend cleaning only with a
dry cloth.
5. FUNCTIONS/ OPERATION:
5.1 NETWORK INCLUSION:
For the adaptation of the wireless adaptor plug switch/dimmer,
you need a controller (remote control or wireless wall-switch).
Press the “UP” or “DOWN” button on the desired group/scene
of the remote control or the wireless wall-switch three times (blinks
green) and then three times on the device to be included: The
device is automatically associated with the selected group/
scene or wall-mounted switch.
...then... ...press 3 times
in each case

14
I
NTER
A
CT
3
.
15
INTER
A
C
T
3
.
NOTE: If a radio link should not be possible while network
inclusion, please bring the controller close to the wireless
adaptor plug.
NOTE: For the purpose of adaptation, both the controller
as well the wireless adaptor plug have to be supplied with
power.
5.2 OPERATION
The wireless adaptor plug can be operated either over a control-
ler (remote control or wireless wall-switch) or directly by actuating
the “FUNCTION” button on the device. By a brief pushing, it is
switched ON/ OFF. In the case of the dimmer, there is also the
possibility of dimming (UP/ DOWN) by prolonged pressing of
the “FUNCTION” button.
5.3 SPECIAL FUNCTIONS OF THE WIRELESS ADAPTOR
PLUG DIMMER:
The wireless adaptor plug dimmer saves the most recently-set
light intensity and automatically switches back to the same level
of brightness at which it was switched off.
5.4 SPECIAL FUNCTIONS – CHILD PROTECTION:
If the radio adaptor plug is present in the “child protection mode”
(also see the user manual wireless wall-switch or remote control),
this can be disabled by pressing the “FUNCTION” button thrice
within a span of 1.5 seconds. After 5 seconds of inactivity, the
tamper-proof “child protection mode” is automatically reactiva-
ted.

16
I
NTER
A
CT
3
.
17
INTER
A
C
T
3
.
Press the “EXCL.” button on the remote control for 2 seconds
(the LED blinks green) and then press the “FUNCTION” button
thrice within a span of 1.5 seconds.
The successful reset operation is signaled by a green light
(3 seconds), whereas a failure by red light (3 seconds).
KINDLY NOTE: The description for activation or deactivation of
the child protection function is described in the user manual of
the remote control/wireless wall-switch!
5.5 RESET:
Sometimes it might be necessary to reset the wireless adaptor
plug to the factory settings and delete all the programming steps
or associations. For resetting, a controller (remote control or
wireless wall-switch) is needed.
NOTE: A successful reset of the wireless adaptor plug means
that it has once again assumed the factory settings.
...then...
“EXCL.”
... press “UP” or
“DOWN” thrice

18
I
NTER
A
CT
3
.
19
INTER
A
C
T
3
.
6. TECHNICAL DATA:
Wireless adaptor plug switch IP 20 (Model ZW ZS 3500)
Wireless adaptor plug switch IP 44 (Model ZW ZSA 3500)
Receiving frequency: 868.42 MHz
Switching capacity: resitive 3,500 W
HV-Halogen, incandescent 1000 W
LV-Halogen, luminescent 690 VA
Operating voltage: 230 V, 50 Hz
5.6 INCLUDING A WIRELESS ADAPTOR PLUG INTO A
THIRD-PARTY NETWORK:
Start the inclusion step on the concerned controller of its network and
press the “FUNCTION” button of the equipment to be included thrice
within a span of 1.5 seconds.
NOTE: For information on handling or starting the inclusion step
of products of other manufacturers, please read the documents
of the respective manufacturer.
controller
third party
manufacturer
...then... ...or...
press 3 times press “UP” or
“DOWN” thrice

20
I
NTER
A
CT
3
.
21
INTER
A
C
T
3
.
7. GUARANTEE:
The products of the INTERACT³ series are fabricated by means
of modern technology and are subjected to strict quality controls.
Should defects still occur in your equipments, the POPP GmbH
offers guarantee to the following extent.
1. Our guarantee offer comprises the repair or new delivery of
an equipment, if it exhibits a defect in the function or material
composition that can be proven.
2. The guarantee offer is not based upon the natural wear and
tear or transport damages or damages as a consequence of not
paying attention to the installation instructions as well as impro-
per installation. One automatically loses the claim to the guaran-
tee offer, if the equipment has been disassembled after diagno-
sis of errors.
Wireless adaptor plug dimmer (model ZW ZDAN 300)
Receiving frequency: 868.42 MHz
Switching capacity: HV, incandescent bulbs: 25 – 300 W
LV-Halogen with iron core transformer
40 – 300 VA
Operating voltage: 230 V, 50 Hz
Operating temperature: 0°C to +40°C
Microfuse: T 1.25 A H
All the above-mentioned products (exception: ZW ZSA 3500)
comply with the norms only in indoor use: RTTE 1999/05/EG,
VDE 0620-1, EN 61058.

22
I
NTER
A
CT
3
.
23
INTER
A
C
T
3
.
3. The guarantee term amounts to 24 months from the date of
purchase by the end-user.
The compliance of the claim period has to be proved by a state-
ment of the purchase date by means of enclosed invoice, deli-
very note or similar documents.
Batteries, LEDs and rechargeable batteries that are sent along
with the delivery are not covered by the guarantee offer.
The POPP GmbH does not accept claims due to indirect, conse-
quential and property damages.
If defects are observed in the equipment, please send the equipment
with enclosed description of the defect to the following address:
POPP GmbH
Kulmbacher Str. 27
D-95460 Bad Berneck
53916.14.02 July 2008
Remark: Note for well-versed users.
All-manufacturer Z-Wave-compatible programming functions:
To effect Include mode Press “INCL.” button of the controller
thrice
To effect Include mode Press “EXCL.” button of the controller
for 2 seconds.
Associate Press “ASSOC.” button of the control-
ler for 2 seconds, subsequently press
the “UP” button on the controller follo-
wed by the “send Node Info Frame”
of the target equipment.
Re-include/Replicate Press the “INCL.” button of the control-
ler thrice followed by the “send Node
Info Frame” of the target equipment.

24
I
NTER
A
CT
3
.
25
Disassociate Press the “ASSOC.” button of the controller
for 2 seconds, subsequently the “DOWN”
button, followed by the “send Node Info
Frame” of the target equipment.
Learn Mode: Press “UP” or “DOWN” button thrice.
Send Node Info Frame - press “UP” or “DOWN” button thrice
- (Controller) press “INCL.” for two
seconds
Add node Press “UP” or “DOWN” button thrice
(inclusion or primary controller).
P
O
PP
G
m
b
H
K
u
lm
bac
h
e
r
S
tr
a
ß
e
2
7
D-95460 Bad Bernec
k
www
.
p
o
pp
.eu
Please visit our website www.popp.eu in the internet and get
to know about further innovative
p
roducts of the POPP GmbH,
such as e.g. the professional power outlet strip
ad
aptu
s
®
I
N
TERACT³ with integrated Z-Wave radio technology.
