PORSCHE DESIGN PDB70/00 User manual

User manual
PDB70/00
Soundbar speaker with built-in subwoofer

2
Contents
1 Important 3
Safety 3
Care for your product 4
Care of the environment 4
Compliance 5
What’s in the Box 6
2 Your Soundbar 6
Main unit 6
Connectors 7
Remote control 7
Prepare the Remote Control 8
Placement 9
Wall mount 9
3 Connect 10
Dolby Atmos® 10
Connect to HDMI Socket 11
Connect to Optical Socket 11
Connect to Power 12
4 Use your Soundbar 12
Turn ON and OFF 12
Automatically wake up 12
Auto Standby 12
Select Modes 13
Adjust the Volume 13
Surround sound mode. 13
Factory Reset 13
Setup Menu 13
Play-Fi (Wi-Fi) Operation 14
Bluetooth Operation 15
OPTICAL / HDMI Operation 16
USB Operation 16
6 Product specications 17
7 Troubleshooting 18

English
3
1 Important
Read and understand all instructions before you
use your product. If damage is caused by failure
to follow instructions, the warranty does not
apply.
Safety
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the presence
of uninsulated “dangerous voltage” within
the product’s enclosure that may be of
sucient magnitude as to constitute a
risk of electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.
Risk of electric shock or re!
• Before you make or change any
connections, make sure that all devices are
disconnected from the power outlet.
• Never expose the product and accessories to
rain or water. Never place liquid containers,
such as vases, near the product. If liquids
are spilt on or into the product, disconnect it
from the power outlet immediately. Contact
Consumer Care to have the product checked
before use.
• Never place the product and accessories
near naked ames or other heat sources,
including direct sunlight.
• Never insert objects into the ventilation
slots or other openings on the product.
• Where the mains plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain readily
operable.
• Battery (battery pack or batteries
installed) shall not be exposed to excessive
heat such as sunshine, re or the like.
• Disconnect the product from the power
outlet before lightning storms.
• When you disconnect the power cord,
always pull the plug, never the cable.
Risk of short circuit or re!
• For identication and supply ratings, see
the type plate at the back or bottom of the
product.
• Before you connect the product to the
power outlet, ensure that the power
voltage matches the value printed on
the back or bottom of the product. Never
connect the product to the power outlet if
the voltage is dierent.
Risk of injury or damage to this product!
• For wall mounting, this product must
be securely attached to the wall in
accordance with the installation
instructions. Use only the supplied wall
mount bracket (if available). Improper wall
mounting may result in accident, injury
or damage. If you have any query, contact
Consumer Care in your country.
• Never place the product or any objects
on power cords or on other electrical
equipment.
• If the product is transported in
temperatures below 5°C, unpack the
product and wait until its temperature
matches room temperature before
connecting it to the power outlet.
• Parts of this product can be made of
glass. Handle with care to avoid injury and
damage.

4
Risk of overheating!
• Never install this product in a conned
space. Always leave a space of at least four
inches around the product for ventilation.
Ensure curtains or other objects never
cover the ventilation slots on the product.
Risk of contamination!
• Do not mix batteries (old and new or
carbon and alkaine, etc.).
• CAUTION: Danger of explosion if batteries
are incorrectly replaced. Replace only with
the same or equivalent type.
• Remove batteries if they are exhausted or
if the remote control is not to be used for a
long time.
• Batteries contain chemical substances,
they should be disposed of properly.
Risk of swallowing batteries!
• The product/remote control may contain
a coin/button type battery, which can be
swallowed. Keep the battery out of reach
of children at all times! If swallowed, the
battery can cause serious injury or death.
Severe internal burns can occur within two
hours of ingestion.
• If you suspect that a battery has been
swallowed or placed inside any part of the
body, seek immediate medical attention.
• When you change the batteries, always
keep all new and used batteries out of
reach of children. Ensure that the battery
compartment is completely secure aer
you replace the battery.
• If the battery compartment cannot be
completely secured, discontinue use of the
product. Keep out of reach of children and
contact the manufacturer.
This is CLASS II apparatus with double
insulation, and no protective earth
provided.
Care for your product
Use only microber cloth to clean the product.
Care of the environment
Disposal of your old product and battery
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
This symbol on a product means that the
product is covered by European Directive
2012/19/EU.
This symbol means that the product contains
batteries covered by European Directive
2013/56/EU which cannot be disposed of with
normal household waste.
Inform yourself about the local separate
collection system for electrical and electronic
products and batteries. Follow local rules and
never dispose of the product and batteries
with normal household waste. Correct disposal
of old products and batteries helps prevent
negative consequences for the environment
and human health.
Removing the disposable batteries
To remove the disposable batteries, see battery
installation section.
For 5G WiFi Device
The device for operation in the band 5150–5350 MHz
is only for indoor use to reduce the potential for harmful
interference to co-channel mobile satellite systems.

English
5
FCC INFORMATION
Warning:
• This equipment should be installed and
operated with minimum distance 20cm
between the radiator & your body.
• Changes or modications to this unit not
expressly approved by the party responsible
for compliance could void the user’s authority
to operate the equipment. ”
NOTE: This equipment has been tested and
found to comply with the limits for a Class
B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio / TV technician for help.
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful
interference, and
(2) this device must accept any
interference received, including
interference that may cause undesired
operation.
IC Notice:
This device contains licence-exempt
transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is
subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference,
including interference that may cause
undesired operation of the device.
Compliance
This product complies with the radio
interference requirements of the European
Community.
Hereby, TP Vision Europe B.V. declares that this
product is in compliance with the essential
requirements and other relevant provisions of
Directive 2014/53/EU.
You can nd the Declaration of Conformity on
https://www.porsche-design.com.

6
2 Your Soundbar
Main unit
This section includes an overview of the main
unit.
1
5
78
6
234
1-/+ (Volume) button
Decrease/Increase the volume.
2(Play/Pause) button
Start, pause or resume play.
3(Source) button
Select an input source for the Soundbar.
4(Standby-On) button
• Press the button to trun ON.
• Set is ON, press the button to switch
to semi-standby, the display ashes
“STANDBY ” when power o.
• Set is ON, long press the button to
switch to ECO standby, the display ashes
“ Eco STANDBY” ashes when power o.
* The button on the side will display aer
power on, and the power o light will go out.
5Remote Control Sensor
6Display panel
7Power LED
What’s in the Box
Check and identify the items in the package:
• Soundbar x 1
• Remote Control x 1
( AAA Batteries x 2 )
• Power Cord * x 1
• HDMI Coble x 1
• Wall Mount kit x 1
(Wall Brackets x2, Screws x4, Dowels x4)
• User manual / Quick Start Guide /
Warranty Card / x 1
* Power cord quantity and plug type vary by regions.
Images, illustrations and drawings shown on
this User Manual are for reference only, actual
product may vary in appearance.
Remote Control
AAA Batteries x 2
Soundbar
Wall Mounting Screws
Wall Bracket
Gum Cover
Screws (for wall)
Power Cord *HDMI Cable
* Power cord quantity and plug type vary by regions.
Quick start guide
Warranty Card
User manual
4 X
4 X

English
7
8Wi-Fi LED indicator (Yellow)
LED State Status
Blink Wi-Fi AP mode
Double blink WPS is active
Constant on Connected / Pairing successful
Connectors
This section includes an overview of the
connectors available on your Soundbar.
1 2 3 4 5 6
7
1HDMI OUT (eARC/ARC)
Connect to the HDMI input on the TV.
2HDMI 1/ HDMI 2
Connect to HDMI OUT socket of external
devices (e.g. games consoles, DVD players
and Blu-ray).
3(Wi-Fi Setup) button
Trigger Wi-Fi setup for Play-Fi.
Press and hold to active the Wps or AP
mode and recongure the network.
4OPTICAL
Connect to an optical audio output on the
TV or a digital device.
5USB
• Audio input from a USB storage device.
• Upgrade soware of this product.
6AC~
Connect to the power supply.
7Wall bracket slot
Remote control
This section includes an overview of the remote
control.
1
4
7
9
2
3
5
6
8
1(Standby-On)
• Press the button to trun ON.
• Set is ON, press the button to switch
to semi-standby, the display ashes
“STANDBY ” when power o.
• Set is ON, long press the button to
switch to ECO standby, the display ashes
“ Eco STANDBY” ashes when power o.
2(Source)
Select an input source for the Soundbar.
3
Turn on/o the surround sound mode.
4(Mute)
Mute or restore volume.

8
5(Play/Pause)
Start, pause or resume play in USB/BT mode.
Conrm a selection.
• , , , (Cursors)
• / (Previous/Next)
Skip to the previous or next track.
Navigate Le/Right in menu structure.
• /
Navigate Down/Up in menu structure.
6(MENU)
Enter audio setup.
7← (Back)
Return to previous menu. Exit menu.
Press and hold the button for 10 seconds
to reset the Wi-Fi module of soundbar to
factory settings.
8+/- (Soundbar’s Volume)
Increase / decrease the soundbar’s
volume.
9+/- (Subwoofer’s Volume)
Increase / decrease the subwoofer’s volume.
Prepare the Remote Control
The provided Remote Control allows the unit to
be operated from a distance.
• Even if the Remote Control is operated
within the eective range 19.7 feet
(6m), remote control operation may be
impossible if there are any obstacles
between the unit and the remote control.
• If the Remote Control is operated near
other products which generate infrared
rays, or if other remote control devices
using infra-red rays are used near the unit,
it may operate incorrectly. Conversely, the
other products may operate incorrectly.
Replace the Remote Control Battery
1 Press and slide down from the receiver
side on the back cover to open the battery
compartment of the remote control.
2 Insert two AAA size batteries (included).
Make sure the (+) and (–) ends of the
batteries match the (+) and (–) ends
indicated in the battery compartment.
3 Close the battery compartment cover.
1 2 3
Precautions Concerning Batteries
• Be sure to insert the batteries with correct
positive “” and negative “” polarities.
• Use batteries of the same type. Never use
dierent types of batteries together.
• Either rechargeable or non-rechargeable
batteries can be used. Refer to the
precautions on their labels.
• Be aware of your ngernails when
removing the battery cover and the
battery.
• Do not drop the remote control.
• Do not allow anything to impact the
remote control.
• Do not spill water or any liquid on the
remote control.
• Do not place the remote control on a wet
object.
• Do not place the remote control under direct
sunlight or near sources of excessive heat.
• Remove the battery from the remote
control when not in use for a long period of
time, as corrosion or battery leakage may
occur and result in physical injury, and/or
property damage, and/or re.
• Do not use any batteries other than those
specied.

English
9
• Do not mix new batteries with old ones.
• Never recharge a battery unless it is
conrmed to be a rechargeable type.
Placement
For best results, place your subwoofer as shown
below.
Wall mount
Note
• Improper wall mounting may result in accident, injury or
damage. If you have any query, contact Consumer Care
in your country.
• Before wall mounting, make sure the wall can support
the weight of your Soundbar.
• Before wall mount, you need not remove the rubber
feet at the bottom of the Soundbar, otherwise the
rubber feet cannot be xed back.
• Depending on the type of wall mounting your Soundbar,
make sure that you use screws of a suitable length and
diameter.
• Please check whether the USB port on the back of the
Soundbar is connected to a USB device. If it is found
that the connected USB device aects the wall-mount,
you need to use another USB device of the appropriate
size.
b. Place the whispering wall on the TV rack
If your TV has a base (such as Philips Porsche
Design TV 70PD9000 TV), you can place the
whispering gallery on the TV base.
1 Use a screwdriver (not included) to remove
the 4 screws behind the whispering wall.
2 Remove the aluminum base of the
whispering wall.
» Keep the newly removed screws and
aluminum bottom in case you need to
use them again.
3 Place the main body of the whispering
gallery on the TV rack.
1
2
3

10
Suggested wall mounting height
You are recommended to install the TV rst
before wall mounting the soundbar. With a
TV preinstalled, wall mount the soundbar
50mm/2.0’’ in distance from the bottom of the
TV.
1 Drill 4 parallel holes (Ø 3-8mm each
according to wall type) on the wall. The
distance between the holes should be
481mm / 18.4”.
» You can using the positioning paper
(included).
2 Firmly  x 1 dowel into each hole in the
wall if necessary. Tighten the wall mount
brackets on the wall with screws and
screwdriver (not included). Make sure that
they are securely installed.
» Attach the wall brackets (x2) to the
wall.
3 Install the wall mounting screws into the
back of the unit.
4 Li the unit onto the wall mount brackets
and slot into place.
481 mm / 18.4"
~50mm/2.0"
1
2
3
4
3 Connect
This section helps you connect your Soundbar
to a TV and other devices, and then set it up.
For information about the basic connections of
your Soundbar and accessories, see the quick
start guide.
Note
• For identication and supply ratings, see the type plate
at the back or bottom of the product.
• Before you make or change any connections, make sure
that all devices are disconnected from the power outlet.
Dolby Atmos®
Dolby Atmos gives you amazing experience you
have never heard before by overhead sound,
and all the richness, clarity, and power of Dolby
sound.
For using Dolby Atmos®
Dolby Atmos® is available only in HDMI mode.
For the details of the connection, please refer to
“HDMI Connection”.
1 To use Dolby Atmos® in HDMI 1 /HDMI 2
/ HDMI ARC mode, your TV has to support
Dolby Atmos®.
2 Make sure that “No Encoding” is selected
for bitstream in the digital audio output of
the connected external device (e.g. Blu-
ray DVD player, TV etc.).
3 While entering Dolby Atmos / Dolby
Digital / PCM format, the soundbar will
show DOLBY ATMOS / DOLBY AUDIO /
PCM AUDIO.

English
11
Note
• Your TV must support the HDMI-CEC and ARC
function. HDMI-CEC and ARC must be set to On.
• The setting method of HDMI-CEC and ARC may dier
depending on the TV. For details about ARC function,
please refer to your TV owner’s manual.
• Only HDMI 1.4 compatible cables can support the ARC
function.
Option 2: Standard HDMI
If your TV is not HDMI ARC-compliant, connect
your soundbar to the TV through a standard
HDMI connection.
HDMI
eARC / ARC
HDMI OUT
Blu-ray Player / DVD Player /
Recorder / Set-top Box...
HDMI IN 1 HDMI IN 2
HDMI OUT
eARC / ARC
1 Use an HDMI cable (included) to connect
the soundbar’s HDMI IN (1 or 2) socket
to your external devices (e.g. games
consoles, DVD players and blu ray).
2 Use an HDMI cable (included) to connect
the soundbar’s HDMI OUT (eARC/ARC)
socket to the TV’s HDMI IN socket.
Connect to Optical Socket
OPTICAL OUT
OPTICAL
Note
• The full Dolby Atmos experience is only available when
the Soundbar is connected to the source via a HDMI
2.0 cable.
• The Soundbar will still function when connected via
other methods (such as a Digital Optical cable) but
these are unable to support all of the Dolby features.
Given this, our recommendation is to connect via HDMI,
in order to ensure full Dolby support.
Connect to HDMI Socket
Some 4K HDR TVs require the HDMI input
or picture settings to be set for HDR content
reception. For further setup details on HDR
display, please refer to the instruction manual
of your TV.
Option 1: eARC/ARC (Audio Return
Channel)
Your Soundbar supports HDMI with Audio
Return Channel (eARC/ARC). If your TV is HDMI
ARC compliant, you can hear the TV audio
through your Soundbar by using a single HDMI
cable.
HDMI eARC/ARC
HDMI OUT
eARC / ARC
1 On your TV, turn on HDMI-CEC operations.
For details, see the TV user manual.
• The HDMI ARC connector on the TV
might be labeled dierently. For details,
see the TV user manual.
2 Using a High Speed HDMI cable, connect
the HDMI OUT (eARC/ARC)-TO TV
connector on your Soundbar to the HDMI
ARC connector on the TV.

12
1 Using an optical cable, connect the
OPTICAL connector on your Soundbar to
the OPTICAL OUT connector on the TV or
other device.
• The digital optical connector might be
labeled SPDIF or SPDIF OUT.
Connect to Power
• Before connecting the AC power cord,
ensure you have completed all other
connections.
• Risk of product damage! Ensure that
the power supply voltage corresponds
to the voltage printed on the back or the
underside of the unit.
1 Connect the mains cable to the AC~
Socket of the unit and then into a mains
socket
2 Connect the mains cable to the AC~
Socket of the subwoofer and then into a
mains socket.
* Power cord quantity and plug type vary by
regions.
4 Use your
Soundbar
This section helps you use the Soundbar to play
audio from connected devices.
Before you start
• Make the necessary connections described
in the quick start guide and the user
manual.
• Switch the Soundbar to the correct source
for other devices.
Turn ON and OFF
• When you rst connect the unit to the
main socket, the unit will be in STANDBY
mode. The STANDBY indicator will light up
white.
• Press the button to trun ON
• Set is ON, press the button to switch
to semi-standby, the display ashes
”STANDBY “ when power o.
• Set is ON, long press the button to
switch to ECO standby, the display ashes
“ Eco STANDBY” ashes when power o.
According to demand, you can choose half
standby or energy saving standby:
• Semi-standby: Wi-Fi is still in standby
mode. It still supports Play-Fi and Airplay2
functions.
• ECO standby: Wi-Fi is o. The entire
system enters the lowest power
consumption mode. Restarting the system
will take a relatively long time.
Automatically wake up
• If a TV or an external device ( for HDMI
socket) is connected, the unit will switch
on automatically when the TV or the
external device is switched on.
Auto Standby
The unit automatically turns to Standby mode
aer about 15 minutes if the TV or the external
unit is disconnected, switched o.

English
13
• To switch the unit o completely, remove
the mains plug from the mains socket.
• Please turn the unit o completely to save
energy when not in use.
• When product is in Play- mode,the
product has only “fully on mode” or “o
mode”(by remote controller). In order to
save eciency, please remember to turn
o the product or log out the Play- mode
when there is no further use.
Select Modes
1 Press the button repeatedly on the
unit or on the remote control to select the
OPTICAL, HDMI ARC, HDMI 1, HDMI 2, BT,
USB mode.
» The selected mode will show on the
display.
Mode Display
USB
BT
BT
OPTICAL
OPT
HDMI ARC
HDMI eARC
ARC
E-ARC
HDMI IN 1
HDMI1
HDMI IN 2
HDMI2
Tips
• Play-Fi is not an optional source. Play-Fi needs to be
directly controlled by APP.
Adjust the Volume
Adjust the Soundbar’s Volume
1 Press +/- (Volume) to increase or
decrease a volume level.
• To mute sound, press Mute.
• To restore the sound, press Mute again
or press Vol+/Vol- (Volume).
Adjust the Subwoofer’s Volume
1 Press +/- (subwoofer) to increase or
decrease the subwoofer’s volume level.
Surround sound mode.
Experience an immersive audio experience with
surround modes.
1 Press the button on the remote control
to turn surround mode on or o.
• On: Create a surround listening
experience.
• O: Two-channel stereo sound. Ideal
for listening to music.
Factory Reset
Reset device to default setting
• In standby mode, press the [ , , vol- ]
buttons on the remote control them in
sequence, the display shows “RESET” to
reset the factory default settings of the
host.
• Set is ON, press and hold the ← button
until the display shows “RESET” to reset
the Wi-Fi module to the factory default
settings.
Setup Menu
The unit allows you to congure advanced
settings to provide you with an even better
experience.
1 Press the (MENU) button on the
remote control to open the menu.
2 Select the content with / (Down / Up)
on the remote controller

14
Display Description
Select Equalizer (EQ) Eect
Adjust the Bass Level
Adjust the TREBLE Level
Set the Audio Delay
Set display brightness
Auto turn o display
3 Press (Enter) to conrm your selection.
4 Change the initial values for each of the
settings with the cursors / (Le /
Right)
5 Press (Enter) to confirm your
selection.
• To return to the previous screen/ exit the
settings, press ← (Back).
• If no button is pressed within 5 seconds,
the system will automatically exit the
menu.
EQ
Select Equalizer (EQ) Eect.
Several preset EQ modes are available:
MUSIC , VOICE, MOVIE, SPORT, CUSTM.
» By default, the EQ is set to MOVIE.
BASS/TREBLE
Adjust the Bass/Treble Level.
» bass + 5 ~ bass – 5
» treble +5 ~ treble –5
» By default, the Bass/Treble is set to 0.
AV SYNC
Set the Audio Delay.
• Video image processing, sometimes longer
than the time required to process the
audio signal. This is called “delayed.” Audio
Delay feature is designed to remedy this
delay.
• Set the audio delay, provided only for the
current playback mode. (As provided in
the HDMI ARC audio delay mode, the delay
mode is valid only for the HDMI ARC).
» AV00 ~ AV200
» By default, the audio delay is set to 00.
DIMMER
Set display brightness.
» DIM 03, DIM 02, DIM 01
» By default, the dimmer is set to DIM 03.
Automatically turn o the display
According to your needs, you can set the
display to turn o the display (except the Wi-Fi
light) aer 3 seconds of idle (no user operation).
» LD ON: Set to ON
» LD OFF: Set to OFF
Play-Fi (Wi-Fi) Operation
By connecting this unit and mobile phones,
tablets (such as iPad, iPhone, iPod touch,
Android phones, etc.) to the same Wi-
Fi network, you can then use the Play-Fi
application to control the echo gallery to listen
to audio les.
Preparation before connection
1 Download and run the Play-Fi app on a
phone or tablet. Set up your device in the
Play-Fi app.

English
15
• Make sure your router is turned on and
working properly. Write down the name
and password of the home network.
• Make sure the unit is turned on. Switch the
network status by long pressing the
(Wi-Fi) button on the back of the unit, and
observe the Wi-Fi light on the front of the
unit to determine.
Wi-Fi LED indicator (Yellow)
LED State Status
Blink Wi-Fi AP mode
Double blink WPS is active
Constant on Connected / Pairing successful
Wireless Network Setup
2 Turn on the Wi-Fi function on the
smartphone and connect to the Wi-Fi
network.
3 Press and hold for 8 sec of (Wi-Fi)
button located at the back cabinet to reset
the Wi-Fi connection.
4 Until the second chime can be heard.
5 The wi light on the top panel is changing
from fast Blink (Attempting to connect
or connecting to a Wi-Fi router) to Slow
Pulse (Setup Mode)
6 Set up the Soundbar with Play-Fi app
» The wi light on the top panel is
changed to solid when the connection
is successful.
7 Open the Play-Fi app. Upgrade to latest
rmware version when rst time set up.
Note
• Always upgrade the Soundbar with latest rmware
version to improve the functionality and features of the
Soundbar.
8 Aer connection, you can change the
device name to your custom name.
Otherwise, it follows the default name.
9 When the rst time set up is not
successful, you need to step out of Play-Fi
app and restart the app again. Start the
set up again.
Bluetooth Operation
Through Bluetooth, connect the Soundbar with
your Bluetooth device (such as an iPad, iPhone,
iPod touch, Android phone, or laptop), and then
you can listen to the audio les stored on the
device through your Soundbar speakers.
What you need
• A Bluetooth device which supports
Bluetooth prole A2DP, AVRCP and with
Bluetooth version as 4.2 + EDR.
• The maximum operational range between
the Soundbar and a Bluetooth device is
approximately 10 meters (30 feet).
1 Press the button repeatedly on the
unit or on the remote control to switch the
Soundbar to Bluetooth mode.
» NO BT is displayed on the display
panel.
2 On the Bluetooth device, switch
on Bluetooth, search for and select
Porsche Design PDB70 to start
connection (see the user manual of
the Bluetooth device on how to enable
Bluetooth).
3 Wait until you hear the voice prompt from
the Soundbar.
» If the successfully connected, BT is
displayed on the display panel.
4 Select and play audio les or music on your
Bluetooth device.
• During play, if a call is coming, music
play is paused. Play resumes when the
call ends.

16
• If your Bluetooth device supports
AVRCP prole, on the remote control
you can press / to skip to a track,
or press to pause/resume play.
5 To exit Bluetooth, select other source.
• When your switch back to Bluetooth
mode, Bluetooth connection remains
active.
Note
• The music streaming may be interrupted by obstacles
between the device and Soundbar, such as wall,
metallic casing that covers the device, or other devices
nearby that operate in the same frequency.
• Compatibility with all Bluetooth devices is not
guaranteed.
• If you want to connect your Soundbar with another
Bluetooth device, press and hold on the remote
control to disconnect the currently connected
Bluetooth device.
OPTICAL / HDMI Operation
Ensure that the unit is connected to the TV or
audio device.
1 Press the button repeatedly on the
unit or on the remote control to select
the OPTICAL, HDMI ARC, HDMI 1, HDMI 2
mode.
2 Operate your audio device directly for
playback features.
3 Press the VOL +/– buttons to adjust the
volume to your desired level.
Tip
• While in OPTICAL/HDMI ARC mode, if there’s no sound
output from the unit and the status Indicator ashes,
you may need to activate PCM or Dolby Digital Signal
output on your source device (e.g. TV, DVD or Blu-ray
player).
• The unit may not be able to decode all digital audio
formats from the input source. In this case, the unit
will mute. This is NOT a defect. Ensure that the audio
setting of the input source (e.g. TV, game console, DVD
player, etc.) is set to PCM or Dolby Digital (Refer to the
user manual of the input source device for its audio
setting details) with HDMI 1 / HDMI 2 / HDMI ARC /
optical input.
• In HDMI mode, when the DOLBY ATMOS audio format
is entered, the Soundbar display shows DOLBY ATMOS.
• When the DOLBY DIGITAL audio format is entered, the
Soundbar display shows DOLBY AUDIO.
• When the PCM audio format is entered, the Soundbar
display shows PCM AUDIO.
• When entering non-PCM or DOLBY DIGITAL audio
formats, if there’s no sound output from the unit and
the display show NO SUPPORT.
USB Operation
Enjoy audio on a USB storage device, such as an
MP3 player and USB ash memory, etc.
1 Insert the USB device.
2 Press the button repeatedly on the unit
or on the remote control to select the USB
mode.
3 During playback:

English
17
Button Action
Start, pause or resume play.
/ Skip to the previous or next track.
Tips
• The unit can support USB devices with up to 32 GB of
memory.
• This unit can play MP3.
• Support a USB port: 5V , 500mA.
6 Product
specifications
Note
• Specications and design are subject to change
without notice.
Bluetooth
•Bluetooth Proles: A2DP, AVRCP
•Bluetooth Version: 4.2 + EDR
•Frequency Band/Output Power:
2400 MHz ~ 2483.5 MHz / ≤ 5dBm
Network Supported
•WiFi IEEE 802.11a/b/g/n/ac Wireless
Frequency Band (Wi-Fi) / Radio Frequency
Power Transmitted
•2.4G Wi-Fi: 2400 MHz ~ 2483.5 MHz /
≤20dBm
•5G Wi-Fi:
5150 MHz~5350 MHz / ≤20dBm
5470 MHz~5725 MHz / ≤27dBm
5725 MHz~5850 MHz / ≤14dBm
Main Unit
•Power Supply: 100-240V~ 50/60Hz
•MAX Output Power by speaker:
120W (RMS)
•Power Consumption: 30 W
•Standby Consumption: < 0.5 W
•USB: 5V 500mA
•Frequency Response: 60Hz - 20KHz
•Speakers Impedance: 8Ω + 8Ω + 4Ω
•Dimension (W x H x D ): 858 x 73 x 115 mm
•Weight: 5.6 kg
• Operating Temperature: 0°C - 45°C
Remote Control
• Distance/Angle: 6m/30°
• Battery Type: AAA (1.5V x 2)
Supported Audio Formats
• HDMI ARC / eARC / HDMI IN1 / HDMI IN2
Dolby Digital, Dolby Digital plus,
Dolby True HD, Dolby Atmos®,
LPCM 2ch/Mch , Dolby MAT.
• OPTICAL
Dolby Digital, Dolby Digital plus, LPCM 2ch
• BLUETOOTH
SBC
• USB
MP3

18
7 Troubleshooting
Warning
• Risk of electric shock. Never remove the casing of the
product.
To keep the warranty valid, never try to repair
the product yourself.
If you have problems using this product, check
the following points before you request service.
If you still have a problem.
No power
• Ensure that the AC cord is properly
connected.
• Ensure that there is power at the AC outlet.
• Press standby button on the remote control
or Soundbar to turn the Soundbar on.
No sound
• Increase the volume. Press Volume Up on
the remote control or on the Soundbar.
• Press MUTE on the remote control to
ensure the Soundbar is not muted.
• Press source buttons to select a dierent
input source.
• When using either of the Digital input, if
there is no audio:
- Try setting the TV output to PCM or
- Connect directly to your Blu-ray/other
source, some TVs do not pass through
digital audio.
• Your TV may be set to variable audio
output. Conrm that the audio output
setting is set to FIXED or STANDARD, not
VARIABLE. Consult your TV’s user manual
for more detailed information.
• If using Bluetooth, ensure that the volume
on your source device is turned up and that
the device is not muted.
• When the playback freezes and there is
no sound in Wi-Fi mode, please check
whether your home network is normal.
Remote control does not work
• Before you press any playback control
button, rst select the correct source.
• Reduce the distance between the remote
control and the unit.
• Insert the battery with its polarities (+/-)
aligned as indicated.
• Replace the battery.
• Aim the remote control directly at the
sensor on the front of the unit.
I can’t nd the Bluetooth name of this
unit on my Bluetooth device
• Ensure the Bluetooth function is activated
on your Bluetooth device.
• Re-pair the unit with your Bluetooth
device.
This is a 15 mins power o function,
one of the ERPII standard requirement
for saving power
• When the unit’s external input signal
level is too low, the unit will be turned
o automatically in 15 minutes. Please
increase the volume level of your external
device.
Wi-Fi Connection cannot be
established.
• Check the availability of WLAN network on
the router.
• Place the Wi-Fi router closer to the unit.
• Make sure the password is correct.
• Check the WLAN function or reboot the
modem and Wi-Fi router.

For DTS patents, see http://patents.dts.com. Manufactured under license from DTS, Inc. (for companies headquartered in the U.S./Japan/Taiwan) or
under license from DTS Licensing Limited (for all other companies). DTS, Play-Fi, and the DTS Play-Fi logo are registered trademarks or trademarks
of DTS, Inc. in the United States and other countries. © 2020 DTS, Inc. ALL RIGHTS RESERVED.
The Wi-Fi CERTIFIED™ Logo is a registered trademark of Wi-Fi Alliance®.
To control this AirPlay 2–enabled speaker, iOS 11.4 or later is required. Use of the Works with Apple badge means that an accessory has been
designedto work specically with the technology identied in the badge and has been certied by the developer to meet Apple performance
standards.
Apple® and AirPlay® are trademarks of Apple Inc., registered in the U.S. and other countries.
Google, Google Play and Chromecast built-in are trademark of Google LLC. Google Assistant is not available in certain languages and countries.
Dolby, Dolby Vision, Dolby Atmos, and the double-D symbol are registered trademarks of Dolby Laboratories Licensing Corporation. Manufactured
under license from Dolby Laboratories. Condential unpublished works. Copyright © 2012-2020 Dolby Laboratories. All rights reserved.
The Adopted Trademarks HDMI, HDMI High-Denition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI
Licensing Administrator, Inc. in the United States and other countries.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by MMD Hong Kong Holding
Limited is under license. Other trademarks and trade names are those of their respective owners.
