Porsche 911 CARRERA 4 - User manual

EN
Porsche
911 Speaker.
Betriebsanleitung_911_Speaker_420x148mm_EN.indd 32-1 15.08.17 09:13

[EN]The 911 Speaker
2
|
3
Contents
Important safety instructions .............................. Page 3
Unpacking.......................................................... Page 8
Product contents................................................ Page 8
Operating elements ............................................ Page 9
Connections ....................................................... Page 9
Bluetooth®connection ...................................... Page 10
Bluetooth®connection via NFC.......................... Pa ge 11
AUX connection ................................................ Page 12
True Wireless ................................................... Page 14
Charging function ............................................. Page 18
Battery operation ............................................. Page 18
Battery status .................................................. Page 20
Voice messages ............................................... Page 20
LED status display ............................................ Page 21
Troubleshooting................................................ Page 22
Technical data .................................................. Page 28
Welcome to the world of Porsche
24h of exhilaration. 60 watts of passion. 911 % excitement. This is the new 911Speaker. With a sound as powerful as a 4.0-litre,
6-cylinder naturally aspirated boxer engine hurtling around a circuit. Deep basses and clear tones in CD quality emanate from the glossy
black twin exhaust module of a Porsche 911 GT3.
The new 911Speaker takes the fascination of Porsche and turns it into a breathtaking designer piece equipped with
cutting-edge technology – a real treat for the senses – with True Wireless mode and a
battery life of up to 24h.
Ensure that the Speaker
is placed on a level
surface
Avoid
moisture
Avoid
knocks and shakes
Do not touch the
power cable with wet
hands
Do not dispose of in
the household waste
Avoid direct sunlight Protect against extreme
cold
Do not open casing Ensure that power supply
is always freely accessible
Protect product from
falling down.
Ensure sufficient distance
from sources of heat
Do not use aggressive,
alcohol-based or abrasive
cleaning agents
Pull out the plug
in the event of a storm
When the system is
overloaded,
turn the sound down
Charge the battery at
a room temperature of
between 0 and 35°C
The user is responsible for handling the 911 Speaker
as instructed. Porsche cannot accept responsibility for
damages or accidents caused by improper assembly,
connection or use.
The original Porsche 911 GT3 twin exhaust integrated
into the 911 Speaker was produced under regular series
production conditions. It is therefore impossible to rule
out certain manufacturing tolerances. These tolerances
must be accepted.
Claims relating to these original pieces are therefore
excluded.
Thank you for your understanding.
General information .......................................... Page 29
License-related information............................... Page 30
Important safety instructions
Betriebsanleitung_911_Speaker_420x148mm_EN.indd 2-3 15.08.17 09:13

[EN]The 911 Speaker
4
|
5
Read and follow all instructions.
Keep these instructions in a safe place.
Observe all cautions and safety instructions.
Operate this device in temperate climates only [not in tropical climates
].
Do not use the power cord over 2,000 m above sea level.
The power cord is for indoor use only. Do not use outdoors or in humid spaces.
To prevent the risk of fire or electric shock, do not expose the device to rain or moisture.
Do not operate this device in the proximity of water.
Do not allow liquid to drop or spray onto the device.
Strong temperature fluctuations can lead to condensation [water droplets]inside the device. Wait until the moisture
build up has evaporated [ at least 3 hours
]before switching the device on again.
Do not place objects containing liquid [ e. g., vases
]on top of the device.
Do not place the device close to open fire, e. g. burning candles.
Never place the device close to sources of heat, e. g. radiators, storage heaters, ovens or other devices [ including amplifiers
]
that emit heat.
Avoid direct sunlight.
Ensure that there is at least 5 cm of space surrounding the device.
To prevent electric shocks, only connect the plug-in power supply with plug sockets or extensions into which the pins can be fully inserted,
so as to avoid exposed pins.
Never touch the signal cable or the plug-in power supply with wet hands.
Do not step on or clamp the plug-in power supply, in particular not close to the plug, plug sockets or in the area at which the cable exits the device.
The plug-in power supply must always be freely accessible in order to be able to pull it out in emergencies.
In stormy weather or if the device is to remain unused for a longer period, disconnect the plug-in power supply from the mains.
To disconnect the device from the mains, pull the plug-in power supply out of the plug socket.
Always switch the device off before you plug or unplug any connecting cables.
Always pull on plugs, not on cables.
Mount the device according to the manufacturer’s instructions.
Place the device in an horizontal position, standing it on the rubber-coated area so that the Porsche logo is on the top.
Do not place the device close to any edges [table or shelf edges
]to prevent any knocks and shakes from causing it to fall down.
If necessary, secure the device to prevent it from falling.
Always ensure that the Speaker is placed on a level surface. The device must always be in an upright position.
CAUTION
Risk of electric shock
Do not open!
CAUTION:
To prevent fire and electric shocks, refrain from opening the device.
The device does not contain any parts to be maintained by the user.
Any maintenance and repair work is to be conducted by qualified
specialists [ service staff
] only.
Important safety instructions
Betriebsanleitung_911_Speaker_420x148mm_EN.indd 4-5 15.08.17 09:13

[EN]The 911 Speaker
6
|
7
Do not subject the operating elements, connections and cables to violence.
The device may only be operated at the voltage and frequency specified on the plug-in power supply or the rating plate.
Do not place any objects in the device’s openings as they may come into contact with and/or damage live wires or components inside the casing.
This may in turn lead to a short circuit, electric shock, or fire.
Use only mounting materials and accessories that have been approved by the manufacturer and/or provided together with the device.
Clean this device with a clean, dry cloth only.
Do not use aggressive, alcohol-based or abrasive cleaning agents.
To prevent electric shocks, refrain from opening the device. The device does not contain any parts to be maintained by the user.
Service and repair work is only to be performed by qualified professionals. This is necessary if the device has been damaged in any way, for example
if fluids or other objects have come into contact with the power cord or plugs, if the device has been exposed to water or moisture, if it does not work
properly, or if it has fallen.
Do not make any adjustments to the device or accessories. Any unauthorised adjustments can compromise the device’s safety, its compliance with legal
provisions, or its system performance. In such an event, the device’s operating license and guarantee become extinct.
If the device’s audio is distorted, emitting, for example, unnatural knocking, tapping or high-frequency clicking, reduce the volume immediately.
To prevent the risk of hearing loss, do not listen at high volumes for long periods. Pause the device if you hear ringing or whistling
in your ears or if you feel you cannot perceive high-pitched sounds properly [ even if this is just short-term]
Do not expose the batteries to high temperatures, for example direct sunlight, fire or similar.
The device may only be operated in ambient temperatures of between 0 and 45 °C.
The integrated battery may only be charged in ambient temperatures of between 0 and 35 °C. We recommend a temperature of 15–25 °C.
Temperatures outside this range can lead the device to stop playing or stop charging [ protective circuit
].
Do not under any circumstances store the device at temperatures below –10 °C or above 45 °C.
Avoid subjecting the device to extreme knocks and vibrations.
Use only the plug-in power supply provided to operate and charge the device.
The device and |or accessories kit can contain parts small enough to be swallowed.
They are therefore not suitable for children under 3 years of age.
This symbol indicates that, under the casing, there are uninsulated, dangerously high-voltage parts with an amplitude strong enough
to cause fire or electric shock.
This symbol indicates important operation and service instructions in the documents [ safety instructions, quick start guide ] included.
This symbol indicates that the device is a protection class II appliance, i. e., an appliance that protects against electric shock by having
double or strengthened insulation. It therefore does not require a protective earth connection.
Important safety instructions
Betriebsanleitung_911_Speaker_420x148mm_EN.indd 6-7 15.08.17 09:13

Porsche
911 Speaker.
Saftey Instructions
170530_Safety Instructions_911 Speaker_A6_RZ_v4.indd 1 30.05.17 10:55
Porsche
911 Speaker.
Quick Start Guide
170530_Quickstart_911 Speaker_A6_RZ_v6.indd 1 30.05.17 10:55
1×
1×
1×1×1×
CNUSUKEU
3
2
1
6
5
54
32
1
321
AUX-INServiceDC IN
[EN]The 911 Speaker
8
|
9
Unpacking
Ensure that the 911Speaker and the plug-in power supply including adapter are all in the box. If the box does not contain all the aforementioned parts,
please contact your authorised dealer directly. Please keep all the packaging material in a secure place. We recommend that you fully charge the battery
of the 911Speaker before using it for the first time.
Connections
1. DC IN [ For plug-in power supply
]
2. Service jack
3. AUX-IN [ 3.5-mm jack]
Product contents
1. 911Speaker
2. Plug-in power supply
3. 5 country-specific adaptors
[ EU, UK, US, CN ]
911Speaker
Operating elements
1. Power [on/off]
2. Bluetooth®input
3. AUX input
4. Mute [Mute function]
5. Volume [ + / – ]
6. NFC sensor [ Near-field communication
]
Betriebsanleitung_911_Speaker_420x148mm_EN.indd 8-9 15.08.17 09:13

1. 2. 3.
[EN]The 911 Speaker
10
|
11
Bluetooth® connection
1. Turn the 911 Speaker on using the power button .
2. Briefly press the Bluetooth®button LED flashes in blue ].
3. Activate the Bluetooth®function on your source device.
4. Keep the Bluetooth®button pressed down for around 2 seconds.
The LED will flash in white and you will hear the message ‘Bluetooth®Pairing’.
5. Look for nearby Bluetooth®devices on your source device [maximum reach 10 m
].
6. Select ‘911Speaker’.
7. When you are asked for a password, enter ‘0000’ and confirm.
8. If your device is connected, the LED will light up in blue and you will hear the message ‘Connected’.
9. The next time you switch on your 911Speaker and activate the Bluetooth® function on your source device,
the Bluetooth®connection will occur automatically and you will hear the message ‘Connected’.
Please note: To connect additional Bluetooth®-compatible source devices with your 911Speaker, repeat steps 3–8. The 911Speaker saves
the last 5 registered Bluetooth® devices. Of these, a maximum of two [ not in True Wireless mode
]can be simultaneously connected with the
911Speaker. This means that the use of a third source device is only possible once one of the already connected devices is disconnected.
The volume of the 911Speaker is normally synchronised with that of your source device. However, the extent to which this works will depend
on your end device.
Near-field communication
Bluetooth® connection via NFC
If your Bluetooth®-compatible audio playback device supports NFC technology, you can use this technology with the 911 Speaker as follows for an easier
connection:
1. Turn on the 911 Speaker using the power button .
2. Activate the Bluetooth®and NFC functions on your audio playback device.
3. Press the Bluetooth®button on the 911Speaker [ LED flashes in blue
].
4. Place your source device with the NFC antenna on the NFC sensor of the 911 Speaker until a connection request is displayed.
5. Remove your Bluetooth® device and confirm the connection request.
6. If you are asked for a password, enter the numbers ‘0000’ and confirm.
7. If your device is connected, the LED will light up in blue and you will hear the message ‘Connected’.
Please note: To disconnect the Bluetooth® connection using NFC, place your audio playback device with the NFC aerial on the NFC sensor of the
911 Speaker until you hear ‘Disconnected’. This function may not work properly depending on your audio playback device
Betriebsanleitung_911_Speaker_420x148mm_EN.indd 10-11 15.08.17 09:13

1
2
3
1. 2. 3.
[EN]The 911 Speaker
12
|
13
AUX connection
If your source device is equipped with a LINE-OUT or headphone output, it can also be connected with the 911Speaker via the AUX-IN
port using an optionally available 3.5-mm audio jack cable. The procedure is as follows:
1. Connect the source device with the audio jack cable.
2. Connect the 911Speaker AUX-IN port with the audio jack cable.
3. Turn the 911Speaker on by pressing the power button .
4. Select the AUX-IN port .
5. Play music on your source device.
6. When playing music via AUX connection, the volumes of the 911Speaker and source device are not synchronised. To achieve maximum possible volume,
set the volume of the 911Speaker to the maximum level and set the volume of your
source device to the desired level.
Please note: To reduce its energy consumption, your 911Speaker will automatically remove any Bluetooth®connections
while playing via AUX.
Please note: Before you remove the audio jack cable from your source device after you have finished playing it,
either lower the volume on your 911Speaker or switch it off.
AUX connection
1. 911Speaker
2. Source device
3. 3.5-mm audio jack cable
AUX
Betriebsanleitung_911_Speaker_420x148mm_EN.indd 12-13 15.08.17 09:13

[EN]The 911 Speaker
14
|
15
True Wireless
The True Wireless function enables you to wirelessly connect your 911Speaker with another 911Speaker as a second sound source in the same room. Here,
we differentiate between stereo mode, where 911Speaker 1 emits the audio signal from the left-hand channel and 911Speaker 2 emits the audio signal
from the right-hand channel [as with classic stereo systems
] and party mode, where both 911Speakers emit the same stereo signal.
When using the True Wireless function, the volume of both 911Speakers is controlled synchronously. The devices also switch off synchronously, i. e., if you
switch one 911Speaker off, the second 911Speaker automatically switches itself off too. When using True Wireless mode, we recommend that the source
device is always connected with 911Speaker 1.
Stereo mode
To activate stereo mode, proceed as follows:
1. Switch on both 911Speakers using the Power button .
2. Select the Bluetooth®input [
the LED flashes or illuminates in blue
] for 911Speaker 1.
3. Simultaneously press on 911 Speaker 1’s Bluetooth®and volume buttons for a short time; you will hear the message
‘True Wireless pairing’.
4. The left-hand LED of 911Speaker 1 will flash in blue.
5. 911Speaker 1 will emit an acoustic signal every five seconds.
6. Select the Bluetooth®input [
the LED flashes or illuminates continuously in blue
] for 911Speaker 2.
7. Simultaneously press on 911Speaker 2’s Bluetooth®and volume buttons for a short time; you will hear the message
‘True Wireless pairing’.
8. 911Speaker 2’s right-hand LED, located above the keypad, will flash in blue.
9. When the message ‘Stereo mode left’ is emitted from 911Speaker 1 and the message ‘Stereo mode right’ emitted from 911Speaker 2, and when the
LEDs above the keypads of both 911Speaker 1 and 2 turn from flashing to continuously illuminated, the connection has been established.
True Wireless
Speaker 1 Speaker 2
Betriebsanleitung_911_Speaker_420x148mm_EN.indd 14-15 15.08.17 09:13

[EN]The 911 Speaker
16
|
17
Party mode
To swap from stereo mode to party mode, press the Bluetooth® button on 911Speaker 1 multiple times for around three seconds, until you hear
the message ‘Party mode’. Now press the Bluetooth® button on 911Speaker 2 multiple times for around three seconds, until you hear the message
‘Party mode’. Both your 911Speakers are now in party mode.
To set both 911Speakers to party mode straight away, proceed as follows:
1. Switch on both 911Speakers using the Power button .
2. Select the Bluetooth®input [
the LED flashes or illuminates in blue
] for 911Speaker 1.
3. Simultaneously press on 911Speaker 1’s Bluetooth®and volume buttons for a short time; you will hear the message
‘True Wireless pairing’.
4. The left-hand LED of the 911Speaker 1 will flash in blue.
5. 911Speaker 1 will emit an acoustic signal every five seconds.
6. Select the Bluetooth®input [
the LED flashes or illuminates continuously in blue
] for 911Speaker 2.
7. Simultaneously press on 911Speaker 2’s Bluetooth®and volume buttons for a short time; you will then hear the message
‘True Wireless pairing’.
8. 911Speaker 2’s right-hand LED, located above the keypad, will flash in blue.
9. When you hear the message ‘Stereo mode left’ from 911Speaker 1 and ‘Stereo mode right’ from 911Speaker 2, and when the
flashing LEDs above the keypads of 911Speakers 1 and 2 light up continuously, the connection has been established.
10. Press the Bluetooth®button on 911Speaker 1 multiple times for around three seconds, until you hear the message ‘Party mode’.
11. Press the Bluetooth®button on 911Speaker 2 multiple times for around three seconds, until you hear the message ‘Party mode’.
Please note: The devices will automatically save the last True Wireless status; this status can only be deleted by simultaneously pressing the
Bluetooth®and Mute buttons . If the last True Wireless status remains saved, the devices will automatically link up the next time they are
switched on, provided they are within reach of each other.
AUX-IN True Wireless
The AUX-IN port can be used in True Wireless mode. For this, the AUX-IN port on the 911Speaker to which the 3.5-mm audio jack cable is connected must
be selected. The second 911Speaker remains set to Bluetooth®input.
Betriebsanleitung_911_Speaker_420x148mm_EN.indd 16-17 15.08.17 09:13

1 2 3
1×
US CNUKEU
1× 1× 1×
1×
[EN]The 911 Speaker
18
|
19
Charging function
The 911Speaker is equipped with a long-life lithium-ion battery. Before using the 911Speaker for the first time, we recommend that you first fully charge
this battery [approx. 3 hours
]. For this, use the plug-in power supply provided and the adapter for your region. You can begin to use the 911Speaker while
the battery is charging. During the charging process, the LED in the power button will display the battery charging status.[see battery status
]. When the LED
light in the power button is blue, the battery of your 911 Speaker is fully charged.
In order not to reduce your battery’s longevity, we recommend that you now stop the charging process. High ambient temperatures can lead to longer
charging times. In the event of extreme ambient temperatures, the protective circuit in place to protect the integrated battery will stop the charging process.
Battery operation
The integrated lithium-ion battery enables you to listen to music on the move for up to 24 hours without having to connect back up to a plug socket.
The duration for which you can play the device on the battery will depend mainly on the ambient temperature, the music played and the volume selected.
Listening to music at louder volumes will reduce battery longevity. If the LED in the power button is flashing in red, we recommend that you preserve the
battery by stopping the music and recharging the 911Speaker’s battery. During battery operation, the 911Speaker will automatically switch to standby
mode after around 5 minutes of inactivity [ 60 minutes with mains operation
].
Charging function
1. 911Speaker
2. Plug-in power supply
3. Plug socket
Betriebsanleitung_911_Speaker_420x148mm_EN.indd 18-19 15.08.17 09:13

[EN]The 911 Speaker
20
|
21
Battery status
The LED in the power button also serves to display the battery charging status. The three display modes indicate the following statuses:
Continuous blue light 90–100 %
Flashing blue light 20–90 %
Flashing red light <20 %
Voice messages
To simplify the connection procedures when in Bluetooth® mode, your 911Speaker is
equipped with user-friendly voice messages These voice messages mean the following:
‘Bluetooth®pairing’ Bluetooth®registration process
‘Connected’ Bluetooth®connection established
‘Disconnected’ Bluetooth®connection removed
The True Wireless function that facilitates connection with another 911Speaker is also quick and simple thanks to the voice messages:
‘True Wireless pairing’ True Wireless registration process [ 911Speaker 1/911Speaker 2]
‘Stereo mode left’ True Wireless mode, left channel
‘Stereo mode right’ True Wireless mode, right channel
‘Party mode’ True Wireless mode, stereo operation [party mode]
LED status display
LED Colour Meaning
Power blue light Start up [for up to 10 seconds after switching on
]
Power blue light Battery charging status 90–100 %
Power flashing blue light Battery charging status 20–90 %
Power flashing red light Battery charging status <20 %
Power quickly flashing red light [ 2× per second
]Fault
Bluetooth®blue light Connected
Bluetooth®flashing blue light No connection
Bluetooth®flashing white light Registration process
Bluetooth®flashing white light Two devices connected to the 911 Speaker simultaneously
Bluetooth®|AUX off Standby
AUX blue light Input selected
Mute flashing white light Mute function activated
Mute white light flashing for 5 seconds Maximum volume level reached
Keypad flashing blue light on the left or right True Wireless registration process
Keypad continuous blue light on the left Stereo mode left channel
Keypad continuous blue light on the right Stereo mode right channel
Keypad flashing blue light on the left or right Party mode
Please note: During battery operation, all LEDs switch themselves off after around 5 seconds in order to save energy.
Only the LED display for the input selected remains active.
Betriebsanleitung_911_Speaker_420x148mm_EN.indd 20-21 15.08.17 09:13

[EN]The 911 Speaker
22
|
23
Problem Possible causes Solution
The 911Speaker
won’t switch on.
1. The battery is fully discharged
[
e. g. due to a long periodin storage
].
1. Charge the battery.
2. The device temperature is lower than 0 °C or higher
than 60 °C. An internal protective circuit is blocking
operation.
2. The 911Speaker can only be operated in temperate conditions
[
see safety instructions, page 7
].
No sound 1. Source device is not emitting any signals. 1. Volume is set to ‘0’ [please refer to the source device’s
instructions
].
2. The audio jack cable is not correctly connected
or is defective [ only applies to AUX operation
].
2. Check the connection between your source device and the
911Speaker. If applicable, exchange the signal cable.
3. The 911Speaker is set to mute
[LED flashes in white ].
3. Clear the mute setting on the 911Speaker.
4. The protective circuit for the amplifiers has
activated [due to overloading or
overheating
].
4. Lower the volume and prevent the device’s temperature from
becoming too high.
Problem Possible causes Solution
Volume too low. The volume of the 911 Speaker is set too low. Please
note: With some android devices and when using the
AUX connection, the volume
is not synchronised between the 911Speaker and the
source device.
1. Raise the volume of the 911Speaker using the volume button
‘+’ .
2. Raise the volume of the source device.
Sound distorted. 1. The volume is too high. 1. Reduce the volume.
2. The AUX input has been overridden [only applies to
AUX operation
]. The maximum input level for the
AUX input is 1.2 Vrms.
2. Reduce the output level of your source device.
Pairing via NFC is not
working.
1. The VFC function on your source device is
deactivated.
1. Activate the NFC function on your source device.
2. The NFC antenna on your source device is outside
the reach of the
911Speaker [ max. 2–3 cm
].
2. The NFC antenna on your source device must be placed
centrally above the ‘Centerpad’ of the 911Speaker. The antenna
position of source devices is often indicated as ‘NFC’.
3. You did not remove the source device from the 911
speaker before confirming the pairing request.
3. Before confirming the pairing request on your source device,
remove the source device from the 911 speaker. Repeat the
procedure.
Your source device is
not automatically
connecting
with the 911Speaker.
1. The Bluetooth®function on your source device is
deactivated.
1. Activate the Bluetooth®function on your source device.
2. The 911Speaker has been deleted from the
Bluetooth®menu of your source device.
2. Pair the 911 Speaker with your source device anew.
3. The AUX input on your 911Speaker is selected. 3. Select the Bluetooth® input on the 911Speaker.
4. 5 or more source devices were paired with the 911
Speaker since it was last used.
4. Pair the 911 Speaker with your source device anew. Please note:
This will delete the source device that, of the devices listed, has
gone the longest without being connected with the 911 Speaker.
Troubleshooting
Here you will find an overview of possible problems. If you have any more questions, please contact your authorised dealer or our service hotline:
Tel. +49 [0] 6083-287 -87 |Mail 911speaker@ porsche-design.com
Please note: The 911 Speaker service hotline is operated by an authorised partner of the Porsche Design Group.
Betriebsanleitung_911_Speaker_420x148mm_EN.indd 22-23 15.08.17 09:13

[EN]The 911 Speaker
24
|
25
Problem Possible causes Solution
True Wireless Pairing
is not possible.
1. The pairing process can fail if a source device in
connected with one of the
911Speakers.
1. Remove all Bluetooth®connections between source
device[ s ] and the 911Speaker and repeat the
die True Wireless pairing procedure.
2. You did not press simultaneously on the Bluetooth®
button and the corresponding volume button
[ + or –].
2. Press simultaneously on the Bluetooth®button and the volume
button.
3. Two source devices are connected with one of the
911 Speakers.
3. Remove the connection with at least one of the two source
devices.
4. The two 911 Speakers are too far apart. 4. Reduce the distance between the two 911Speakers
to under 10 metres.
5. You selected the AUX input on at least one of the
two 911Speakers.
5. Select the Bluetooth® input on both 911Speakers before you
begin the procedure.
6. One of the two 911Speakers is already connected
with another [third] 911Speaker via True Wireless.
6. Remove the True Wireless connection between the two
911Speakers as explained in the instructions. Start the
procedure with the two 911Speakers in question, as explained
in the instructions.
7. You entered the same key combination on both 911
speakers.
7. Repeat the registration procedure as explained in the
instructions.
One or both of the
911Speakers are not
playing the desired
channel [ l, R, l+R
].
As a rule, after the connection, 911Speaker 1 emits
the left-hand music channel and 911Speaker 2 the
right-hand one.
Change the True Wireless mode as explained in the instructions.
Problem Possible causes Solution
No sound, or only
distorted sound, through
Bluetooth®
wireless technology.
1. There is no connection between the 911 Speaker
and your source device.
1. Connect your source device as described.
2. Your source device is paired, but not connected. 2. The source device did not automatically connect and needs
to be manually connected.
3. Your source device is connected. 3.1. Make sure that there are no sources of interference
[ e. g., a W-LAN router] in the direct proximity of the
911Speaker or source device.
3.2. It is often not possible to connect the 911 Speaker with a
mobile end device via simultaneous W-LAN and Bluetooth®
connections without experiencing interference. Deactivate
W-LAN on your source device.
4. You are outside the
911Speaker's maximum reach [ max. 10 m
].
4. Reduce the distance between the 911 Speaker and your source
device.
The Bluetooth®
connection between your
source device and
911Speaker was
unexpectedly
disconnected.
1. The 911Speaker switched itself off because it
had not played any music for five minutes [battery
operation
]or for 60 minutes [
mains operation
].
1. To prevent the 911Speaker from switching itself off
automatically, lower the volume of your source device to a
minimum [mute].
2. You placed your already connected NFC-compatible
source device close to the ‘Centerpad’.
2. If you place an already connected NFC-compatible source device
close to the ‘Centerpad’, the Bluetooth®connection will be cut
off again. To re-establish the connection, place the source
device close to the ‘Centerpad’ again.
3. You selected the AUX input on your 911Speaker. 3. Select the Bluetooth®input and wait until the
911Speaker connects.
Betriebsanleitung_911_Speaker_420x148mm_EN.indd 24-25 15.08.17 09:13

[EN]The 911 Speaker
26
|
27
Problem Possible causes Solution
The AUX input cannot be
selected.
This 911Speaker is connected via True Wireless with
a second 911Speaker, for which the AUX input has
already been selected.
Only select the AUX input on the 911 Speaker you want to connect
the source device with. The Bluetooth®input must be selected on
the second 911 Speaker. Alternatively, you can remove the
True Wireless mode as explained in the instructions.
The 911Speaker
will switch itself off
automatically.
1. The battery is fully discharged. 1. Charge the battery.
2. The 911Speaker was switched off by its automatic
cut-off function [ battery operation: 5 minutes, mains
operation: 1 hour
].
2. Have the 911Speaker emit an audio signal and set the
911Speaker to mute in order to stop it switching itself off.
3. The 911 Speaker’s protective circuit detected a
defect.
3. Make sure that you only operate the 911Speaker within the
specified temperature range and that you do not overload it.
The battery in the 911
Speaker cannot be
charged.
1. The plug-in power supply is connected neither with
the mains nor with the 911 Speaker.
1. Make sure that the plug-in power supply is connected with the
911 Speaker and with the mains.
2. You are trying to charge the battery using the
911 Speaker’s USB port.
2. The USB port on the 911Speaker cannot be used to charge
the battery. It is to be used exclusively by the manufacturer for
service purposes.
3. The ambient temperature is lower than 0 °C or
higher than 35 °C
3. The 911Speaker may only be charged in temperate conditions
[ see safety instructions, page 7 ].
4. You are not using the original plug-in power supply. 4. Please use only the original plug-in power supply.
If you have lost it, please contact our service hotline.
5. The integrated battery is defective. 5. Please contact our service hotline.
6. The plug-in power supply is defective. 6. Please contact our service hotline.
Problem Possible causes Solution
True Wireless mode
After switching them off,
the two 911 Speakers
are not connecting with
each other.
1. You waited for less than 20 seconds between
switching off the first and switching off the second
911 Speaker.
1. Always wait for 20 seconds between switching off the first and
switching off the second 911 Speaker.
2. Two source devices are connected with one of the
911 Speakers.
2. Remove the connection with at least one of the two source
devices.
3. The distance between the two 911Speakers
is too great. Here, too, the maximum distance is
10 metres.
3. Reduce the distance between the two 911Speakers.
4.1. You have cancelled the True Wireless mode
on one of the 911Speakers via the Bluetooth®
and Mute buttons.
4. Reconnect the two
911Speakers with each other as explained in the instructions.
4.2. At least one of the two 911Speakers is already
connected with another [third] 911Speaker via
True Wireless.
5. You selected the AUX input on both 911Speakers. 5. Select the Bluetooth® input on at least one of the 911 Speakers.
Betriebsanleitung_911_Speaker_420x148mm_EN.indd 26-27 15.08.17 09:13

[EN]The 911 Speaker
28
|
29
Technical data
Information regarding 'proper operation'
The 911Speaker may not be used in wet/damp environments.
The device may not be exposed to temperatures of below –10 °C or
above 45 °C. The device may not be modified or changed in any way.
Connect the 911Speaker as described in the instructions, paying close
attention to the safety instructions. Only use the plug-in power supply
at the voltage and frequency specified on the rating plate.
Information regarding environmentally-friendly operation:
Pull the plug-in power supply out of the socket whenever you finish charging
the 911 Speaker. This prevents the plug-in power supply from constantly
supplying power, thus reducing costs.
Mains operation:
Switch the 911Speaker to standby mode when not in use in order to keep
the power supply to a minimum, thus reducing costs.
General information
Information regarding CE marking
Electric and electronic devices sold within the European Union
must have a CE marking showing that they comply with the
applicable requirements [ e.g. regarding electromagnetic
tolerance and device safety
].
Disposal instructions
According to the EU Directive on waste electrical and electronic
equipment, devices that bear this symbol may not be disposed
of with the municipal waste [household waste]. To find out
more about how to dispose of waste electrical and electronic
equipment free of charge,contact your competent waste disposal
provider or municipal/town administration. The Directive serves
to protect the environment and public health, and to recover
[rare]raw materials through recycling.
Use Portable Bluetooth®speaker
Principle Bass reflex system with passive radiator
Performance 60 watts
Maximum sound pressure 95 dB SPL
Frequency range 41.5Hz–20,000Hz
Passive radiator 2× [ 70 × 50mm
] metal, wave surround [passive]
Full range 2× 50mm [cellulose graphite]
Rechargeable battery Lithium ion 4,300 mAh, 7.3 V
Dimensions approx. 290 mm × 155 mm × 120 mm [ L × B × H
]
Weight approx. 3.3kg
Connections AUX-IN
DC IN [ 12V 1.5A
]
Mini-USB-IN [service jack]
Bluetooth®Bluetooth®standard 4.0 [A2DP]
Supports CSR aptX®decoding
Range of up to 10m
2.400–2.483,5 MHz frequency range [ 2,4 GHz ISM band
]
Max. transmission power of 10 mW [+10 dBm]
Betriebsanleitung_911_Speaker_420x148mm_EN.indd 28-29 15.08.17 09:13

[EN]The 911 Speaker
30
|
31
Bluetooth®:
The Bluetooth®word mark and logos are registered
trademarks owned by Bluetooth® SIG, Inc., and any
use of such marks by Porsche Design is under license.
Other trademarks and trade names are those of their
respective owners.
aptX®:
The aptX® software is a copyright of CSR plc or its group
companies. All rights reserved. The aptX®mark and
the aptX logo are trademarks of CSR plc or one of its
group companies and may be registered in one or more
jurisdictions.
License-related information
Betriebsanleitung_911_Speaker_420x148mm_EN.indd 30-31 15.08.17 09:13
