Porta Phone Scrambler UHF SC1000 User manual

Introduction
Each Scrambler Plus is factory programmed to provide discreet private two-way voice contact. All
outgoing transmissions are digitally encrypted and scrambled to prevent eavesdropping. In addition,
CTCSS frequency guard protects the receive circuit by blocking outside interference. Combined, these
features ensure that communications remain completely private.
Features
Operation
1. Slide battery onto the back of the transceiver until the latch at the bottom clicks, then follow the
charging procedure before operation.
2. The Power switch / volume control knob (B) turns the transceiver on and off and also sets the
incoming sound level. Turn the power switch / volume control clockwise to turn the transceiver on.
3. Set the operating channel via the Channel Selector (A). Rotate the Channel Knob
setting it to the desired channel. Channel numbers are printed on the radio. The radio features an
audible channel announcement and will tell the user the channel selected.
4. Incoming messages are confirmed by green flashing light on LED indicator.
Using Your Headsets
Our headsets include special noise cancelling microphones. For optimum performance adjust
microphone boom so the element is directly in front of, and approximately 1 - 2” from the user’s mouth.
Battery Charging
Each Scrambler radio is supplied with a rechargeable Lithium Battery that will operate
8 - 10 hours.
Charging Procedure:
1. Plug the AC adapter cable into the jack located on the rear of desktop
charger base.
2. Slide the transceiver and battery pack into the charger.
3. Plug adapter into AC outlet.
4. Make sure the battery pack contacts are touching the terminals.
5. LED indications: RED: charging, GREEN: full charge.
6. Remove the transceiver from charging base when charging is
completed (charging time varies; up to 3 hrs for completely dead battery).
Lithium Batteries do not develop a memory, and do not need to be drained
after use.
LED indicators:
RED: Charging
GREEN: Full Charge
Once the battery is fully charged, and the LED turns green, the battery will continue to
receive a trickle charge - even if left in the charging base overnight. This will not harm
the battery.

Safety
1. Do not transmit more than 50% of time. It is important as the radio generates measurable RF energy exposure only when
transmitting.
2. Changes or modifications not expressly approved by the manufacturer could void the user's authority to operate the
equipment.
3. Radio frequency signals transmitted may cause interference to hearing aids.
4. Turn off the radio when near medical equipment.
5. This product should not be used by people with pacemakers.
6. Do not use the radio when driving a vehicle or operating machinery.
7. Do not use the radio when on board aircraft.
8. Do not hold the antenna when transmitting.
9. Do not use the radio when the antenna has damaged.
10. Turn off the radio and remove the batteries if you are not going to use it for a long time.
Two-way Radio Operation
The device was tested for typical body-worn operations using the supplied belt-clip. To maintain compliance with FCC RF
exposure requirements, body-worn operations are restricted to the supplied belt-clip. For hand-held operation, the radio should
be held at least 1 inch (2.5cm) from the user’s face. The use of accessories that do not satisfy these requirements may not
comply with FCC RF exposure requirements and should be avoided. For more information about RF exposure, please visit the
FCC web site at www.fcc.gov.
OPERATIONAL CAUTIONS
1. Never dispose of batteries in a fire. There is a serious risk of explosion and /or the release of highly toxic chemicals.
2. Do not expose your product to direct sunlight, extreme cold or place it near heating appliances.
3. Do not submerge any part of your product in water and do not use it in damp, humid or wet conditions.
4. Do not expose your product to fire, explosive or other hazardous conditions. For example, at petrol stations or areas where
explosive products are used.
FCC Statements FCC ID: B4HSC1000
This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and receiver.
 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Scrambler UHF
Model SC1000 – Professional Two-Way Radio
Instruction Manual
Warranty
Porta Phone items are warranted against defects in material and/or factory workmanship for a set period from the date of
purchase. Standard repairs due to misuse or wear and tear, as well as replacement parts including but not limited to batteries,
padding, USB cable, etc. are excluded. Shipping to Porta Phone is at customer’s expense, Porta Phone will pay for return
ground shipping if the product warranty applies to the repair. Call for details.
Shipping
Prior to returning your headset for warranty or service you must call Porta Phone for an RA (return authorization) number:
1.800.233.1113.
General Service
All repair work will be performed for the cost of replacement parts and return shipping from the Porta Phone factory.
Service / Porta Phone www.portaphone.com
145 Dean Knauss Drive 1.800.233.1113
Narragansett, RI. 02882
