PORTABLE ELECTRIC Voltstack 2K User manual

From Power On to Standby
1.
2. on the front panel. This will cut
1.
2. Press the button(s) beneath and the blue button lights
will illuminate.
1.
2. Press the button(s) beneath and the blue button lights will
From Standby to Power On
1. Press the located on front panel.
The button light will illuminate.
2. You will hear two beeps and after 6 seconds the green
Output Lights will illuminate. You now have power!
QUICK GUIDE
VOLTstack® 2k & 5k
Unit images on pg. 2
1. From Standby or Power On states, ensure the Charging Breakers are ON.
2. Plug the extension cord’s ‘female’ end into the Charging Ports.
3. The orange Charging Lights will illuminate indicating there is charge power
coming in & the Battery Monitor will indicate the unit is charging.
NB: ‘Charging’ is defined by net power consumption.
4. Charging is complete when full bars are shown on the Battery Monitor.
| 601.207.0592 | 1
VOLTstack® Power States
The VOLTstack® power station has three power states:
Power On - All systems on with AC output
For full power output & usage - Green Output Lights ON
Standby - Systems on with NO AC output
For charging and between operations - Battery Monitor lights ON
- Zero power state with NO AC output
For shipping and long term storage -
TO TURN POWER ON TO TURN POWER OFF
TO CHARGE THE UNITCharging from Solar
1. To charge using solar – plug the solar
cable from the SUNstack™ solar kit
into the Solar Charging Ports.
NB: Using solar panels, solar cables or solar
connectors not supplied by Portable Electric may
cause permanent damage to your VOLTstack®
and/or void your warranty. Use only approved
SUNstack™ equipment from Portable Electric.
Troubleshooting Errors
1. IMPORTANT - Initial Troubleshooting Procedure:
• Ensure all breakers are in the ON position.
• Perform a Power Cycle:
• From Standby state, turn the unit to state (see pg. 1).
• Wait 10 seconds.
• Turn the unit back to Standby and then to Power On.
2. There is no power at the Output Receptacles.
• See Step 1.
• If there is still no power, please call the service provider.
3. The green Output Lights do not illuminate.
• Complete Step 1, then check for power at the Output
Receptacle.
• If there is power, it is an issue with the Output Lights.
The unit is still operational. Please call the service
provider.
4. The unit is not charging.
• See Step 1.
• If unit still does not charge, see Step 5.
5. The orange Charging Lights do not illuminate.
• Check input power source and connection.
• If the unit still does not charge, please call the
service provider.
6. The unit’s charge does not last as long as normal.
•
are illuminated.
• Charge the unit back to full.
• If the unit’s charge still does not last, please call
the service provider.
IMPORTANT INFORMATION
From
[e-mail] WWW.SHATTERED-PRISM.COM

2
Solar Charging
Ports
USB Data Ports
(No charging)
Master Battery
Back
Output
Receptacles
Output Lights
Charging Ports
Charging Lights
USB 5V
Front
Battery Monitor (Type 2)
Charging Breakers
Output Breakers
Back
Solar Charging
Ports
Master Battery
USB Data Port
(No charging)
Battery Monitor (Type 2)
Charging Light
Output Lights
Charging Port
Front
Output Receptacles
Charging Breaker
USB 5V
Output Breaker
Storing the VOLTstack
1.
use.
2.
Understanding the VOLTstack® Battery Monitor
Depending on the unit version, the VOLTstack will have one
of two monitor types. Please see the Battery Monitor Quick
Guide for more information.
VOLTstack®5k
VOLTstack®2k
| 601.207.0592 |
[e-mail] WWW.SHATTERED-PRISM.COM

BATTERY MONITOR QUICK GUIDE
Type 1 & Type 2
Type 1 Battery Monitor
The Type 1 Battery Monitor has ten blue LEDs. Full illumination of the ten LED’s indicates 100% State of Charge.
Discharging Charging State of Charge
Discharging
The Battery Monitor will show the State of
Charge when discharging.
Charging
The right most blue LED will blink.
Stateof Charge Low
The last remaining LED will blink indicating the
State of Charge is approaching zero.
Blink Low
Fault Warning
All of the LEDs will blink. This can indicate an overload
fault warning, or over temperature fault warning.
Connection Error
A single blue LED will move continually from left to right
and back again. This indicates a connection error in the
Battery Monitor.
Fault Connection
0% SOC 100% SOC
Blink

Type 2 Battery Monitor
The Type 2 Battery Monitor has an LCD screen which displays the State of Charge, Power State, discharge Run Time, charge Time Remaining, and Net Power
of the VOLTstack.
Discharging
The Battery Monitor will show the State
of Charge, as well as the estimated Run
Time in hh:mm format.
Idle
The Battery Monitor will display
Idle at a Net Power of 0.
03:02 1000W
State of Charge
Power
State
Net Power
Run Time (Discharging)
Time Remaining (Charging)
Power State Discharging Charging Idle
Symbol IDLE
State of Charge Low
The last remaining State of Charge interval
will blink indicating the State of Charge
is approaching zero. The Run Time will
indicate a capacity of less than 15
minutes remaining.
< 15 min –1000W
Blinking
Run
Time
Net
Power
Charging
Theright most interval will blink, and the
charging symbol with estimated charge
Time Remainingwill be displayed.
03:02 –1000W IDLE
0% 100%
Run
Time
(hh:mm)
Net
Power
03:02 1000W
Blink
Charge
Time Remaining
(hh:mm)
Net
Power
Fault Warning
All of the State of Charge intervals will
blink. This can indicate an overload fault
warning, or over temperature fault warning.
03:02
Blink
–1000W
Loading Screens
Loading Screen 3: The total usage of the
VOLTstack can be calculated by adding
the charging and discharging kWh used.
indicate time spent at Idle.
103 kWh In
100 kWh Out
Total
Charging
usage in
kWh
Total
Discharging
usage in kWh
0W
• The State of Charge is divided into 10 intervals based on 0-100% State of Charge.
• The Run Time and Time Remaining are based on average Net Power, and will
update as the Net Power changes.
• The loading screens display critical information and cannot be skipped. Loading
Screen 1 and 2 are for maintenance, and Loading Screen 3 displays the historical
usage of the VOLTstack.
