PortaCo SR-10-26-O Quick start guide

ORIGINAL OPERATION MANUAL
RAIL SAW
SR-10-26-O & SR-10-26-1

2
RAIL SAW SR-10-26-O & SR-10-26-1 ORIGINAL OPERATION MANUAL
Change overview
Auditing
Date
Comment, including chapter
changed by
01
11-26-2018
Creation
Jesse Bunn

3
RAIL SAW SR-10-26-O & SR-10-26-1 ORIGINAL OPERATION MANUAL
1About this manual................................................................................................................................................. 5
2General ................................................................................................................................................................. 6
2.1 General information...............................................................................................................................................................6
2.2 Designated use.......................................................................................................................................................................6
2.3 Unintended use......................................................................................................................................................................7
2.4 Environment requirements....................................................................................................................................................7
2.4.1 Operating requirements...........................................................................................................................................7
2.4.2 Emissions ..................................................................................................................................................................7
3Safety.................................................................................................................................................................... 8
3.1 Basics .....................................................................................................................................................................................8
3.2 Important safety information ................................................................................................................................................9
3.3 Qualification of the operating and maintenance personnel ................................................................................................12
3.4 Emergency information / safety devices..............................................................................................................................13
3.5 Safety signs ..........................................................................................................................................................................13
4Design and function .............................................................................................................................................14
4.1 Design ..................................................................................................................................................................................14
4.2 Accessories and kits descriptions.........................................................................................................................................15
4.3 Specification.........................................................................................................................................................................15
4.3.1 Hydraulic fluid ........................................................................................................................................................16
4.3.2 Supply, interfaces and connections........................................................................................................................16
4.4 Function ...............................................................................................................................................................................16
4.5 Boundaries and interfaces ...................................................................................................................................................16
5Transport, assembly and dismantling...................................................................................................................17
6Commissioning and operation..............................................................................................................................17
6.1 General information for start-up .........................................................................................................................................17
6.1.1 Tool preparation.....................................................................................................................................................18
6.1.2 Testing ....................................................................................................................................................................20
6.1.3 Specification of the hydraulic system.....................................................................................................................20
6.2 Tool connecting procedures ................................................................................................................................................22
6.3 Cut off blade installation......................................................................................................................................................22
6.4 Rail clamp installation ..........................................................................................................................................................23
6.5 Saw Mounting ......................................................................................................................................................................24
6.6 Connecting hoses .................................................................................................................................................................24
6.7 Operation.............................................................................................................................................................................25
6.8 Disconnecting Hoses ............................................................................................................................................................26

4
RAIL SAW SR-10-26-O & SR-10-26-1 ORIGINAL OPERATION MANUAL
6.9 Cold Weather Operation......................................................................................................................................................26
7Maintenance ........................................................................................................................................................27
7.1 Change of hydraulic fluid .....................................................................................................................................................27
8Troubleshooting...................................................................................................................................................28
8.1 General information for maintenance and repairs ..............................................................................................................28
8.2 Troubleshooting and repairs................................................................................................................................................28
9Shutdown and re-commissioning .........................................................................................................................29
10 Storage.................................................................................................................................................................29
11 Dismantling and disposal .....................................................................................................................................29
Publisher: PortaCo Inc.
1805 2nd Ave N, Moorhead, MN 56560
Phone [phone], Fax [phone]
[email protected], www.portaco.com/
Date of publication: 12-01-2018
Documentation version: 1.0
Document / order number: 6559-OOP

5
RAIL SAW SR-10-26-O & SR-10-26-1 ORIGINAL OPERATION MANUAL
1About this manual
This document is the original operation manual for the Rail Saw SR-10-26-O & SR-10-26-1-O of PortaCo Inc., 1805 2nd Ave N,
Moorhead, MN 56560.
The Rail Saws are designed to cut rail which is mounted to ties from a standing position.
The operation manual is intended to enable the operator to safely operate the system as intended and warn them of foreseeable
misuse. The manual is intended for the operating company´s specialized staff. In addition to the operation manual, the spare parts
catalogue and the maintenance manual of the manufacturers of the individual components are to be observed.
WARNING
Operating errors using the device, e.g. by instruction errors, may lead to personal injury or damage to the
device.
-The instruction for use must be accessible to operators and maintenance personnel at all times!
-A copy of the technical documentation including the instruction for use must be kept in a suitable and
accessible place.
The explanation of the hazard pictograms is contained in chapter safety.
This document is to be treated as confidential. No portion of the document may be disseminated to another party or reproduced
without written permission from PortaCo Inc. All rights reserved.

6
RAIL SAW SR-10-26-O & SR-10-26-1 ORIGINAL OPERATION MANUAL
2General
This chapter contains basic information about the machine and is intended to provide an initial overview.
2.1 General information
The rail saw is designed to cut rail which is mounted to ties from a standing position. This tool will help eliminate the use of other
methods that increase the likely hood of injury. When properly used this tool will help reduce back strain and also reduce operator
fatigue.
The tool is hydraulically powered. The hydraulic energy is provided by a hydraulic unit. The hydraulic unit is not part of the scope of
delivery. We recommend the Hydraulic Power Units D-23, E-15, G-18, G-21, G-23 or G-31.
Further design information is shown and described in chapter 4.
Regarding ergonomics, the stresses and strains resulting from the device are typical for a device in the construction industry.
Figure 1. Identification plate (type plate)
2.2 Designated use
The Rail Saws are designed to cut rail which is mounted to ties from a standing position.
To use the tool as intended, all persons who use the device must adhere to the guidelines in this operation manual.

7
RAIL SAW SR-10-26-O & SR-10-26-1 ORIGINAL OPERATION MANUAL
2.3 Unintended use
-Do not allow others to be near the tool when starting it or while operating. Keep bystanders and animals out of the work area.
-Do not operate the tool near energized transmission lines.
-Do not overreach. Maintain proper footing and balance at all times.
-Connecting to power source which exceeds the required flow and pressure rating
-Always connect hydraulic hoses to the tool before activating the hydraulic circuit on your power unit. Check that hydraulic
couplers are secure before activating the circuit.
-Never operate a tool that is damaged, improperly adjusted, or not completely and securely assembled.
-Never carry or pick this tool up by the hydraulic hose.
-Be sure to keep hands and other parts clear and free from all moving parts.
-During startup of the tool, do not rest the tool on any surface.
-Make sure the tool’s wheel has stopped turning before setting down tool.
-At the work site, never carry the tool with the wheel rotating.
-Always use sockets that meet the minimum requirements of the tool.
-Atmosphere temperature below -10°C/14°F or above 40°C/104F
-Hydraulic oil temperature below 10°C/50°F or above 80°C/180°F
2.4 Environment requirements
2.4.1 Operating requirements
The machine is designed for use on construction sites outdoors. It can be used at temperatures between
-10 °C to 40 °C (14°F to 104°F). The temperature of the hydraulic fluid should be at least 10 °C (50°F).
When working in tunnels, the country-specific safety regulations must be observed.
2.4.2 Emissions
In technically perfect condition, the A-weighted emission sound level at the work place is lower than 70 dB(A). Hearing protectors is
not required.
Other emissions do not occur during regular device operation.
In the event of damage, hydraulic fluid may leak. Should this be the case, eliminate the leak and remove any fluid which has leaked
with the intended binders.

8
RAIL SAW SR-10-26-O & SR-10-26-1 ORIGINAL OPERATION MANUAL
3Safety
3.1 Basics
The machine corresponds to the generally recognized standards of technology and practice. Nevertheless, knowledge of the
residual risks as well as general knowledge of the device is required to ensure safe and accident-free work.
The safety information is understood to be in addition to the existing accident prevention regulations and laws. The information is
intended to warn operating personnel about foreseeable misuse. Existing safety prevention measures and laws must be followed at
all costs!
The operation manual must be read and understood by all persons who work on the device. Introduction to the device is to be
documented in writing.
CAUTION
Hazards from the operational environment of the device can lead to injuries of persons.
-No alterations to the device may be made which lead to a change in function.
-All hazards from the environment or from unforeseeable operating conditions of the device cannot be
captured and depicted within this manual.
Modifications to the machine must be made by the distributing company. In this case this manual will also be
adapted.
The chapter on safety regulations serves to:
-explain the depiction of the safety regulations and symbols
-inform users about dangers, residual risks and measures for reducing risks
-specify the minimum requirements of the operating personnel

9
RAIL SAW SR-10-26-O & SR-10-26-1 ORIGINAL OPERATION MANUAL
Symbol
Meaning
DANGER
DANGER indicates a hazard with a high degree of risk, which when it is not avoided results in death or
serious injury.
WARNING
WARNING indicates a hazard with a medium degree of risk, which when it is not avoided may result in
death or serious injury.
CAUTION
CAUTION indicates a hazard with a low degree of risk, which when it is not avoided may result in minor
or moderate injury.
NOTICE
NOTE, non-compliance may result in environmental or material damage
Attention risk of injury!
General note for helpful tips and additions.
Read the safety information before using the machine. Non-compliance may result in injuries and
damage to property.
Table 1: Signal words and Symbols
3.2 Important safety information
Read this chapter and observe the safety information before using.
The safety regulations are to be observed by all persons who work on the device. The regulations and instructions for accident
prevention valid at the place of operation are to be observed. Instruction of the operating and maintenance personnel in system
safety is to be documented.
Please pay particular attention to this chapter to avoid accidents!
PortaCo Inc. is not liable for injury to persons or property which results from misuse of the machine.
DANGER
There is a danger of crushing in the area where the tool is working.
-Do not reach or step into the working area of the device when tool is working.
Use personal safety equipment.

10
RAIL SAW SR-10-26-O & SR-10-26-1 ORIGINAL OPERATION MANUAL
DANGER
The bursting of hydraulic components and uncontrolled whipping of the hydraulic hoses is possible.
-Only use the machine within the prescribed limits.
-Before disconnecting the hydraulic couplings, make sure that the pressure is relieved.
-The machine must be maintained at regular intervals, the intervals are specified by the operator's risk
assessment.
DANGER
Contact with live parts results in the worker sustaining a lethal electric shock.
-In the case of railway tracks with live rails, the busbar must be shorted or switched off by the control
room of the transport company.
-Check that no voltage is present in the rail system continuously!
DANGER
The operator inhales aerosol of hydraulic oil.
-Only use the device within the prescribed limits.
-The device must be maintained at regular intervals, the intervals are specified by the operator's risk
assessment.
-In the event of leaks switch the device to a safe state.
DANGER
If an employee is hit by a train or car, severe or fatal injuries may result.
-Pay attention to your own safety!
-Wear work clothing with reflectors and a safety vest!
-The foreman must ensure that the line being worked on has been closed.
-Place a track marshal with a horn on the opposite track.
DANGER
Employees may be severely or fatally injured by lightening during a thunderstorm.
Stop work during thunderstorms!
WARNING
The machine is heavy. There is a potential for serious injury during transport.
-When carrying the device, use the transport handles which are intended for this purpose.
-Wear safety shoes.

11
RAIL SAW SR-10-26-O & SR-10-26-1 ORIGINAL OPERATION MANUAL
WARNING
In case of poor weather conditions (rain, snow) there is a risk of injury due to poor visibility or slippery
standing surfaces.
-Stop work if standing surfaces are slippery.
-Stop work if visibility is poor.
WARNING
In case of leakage, there is a risk of slipping on the oil film.
-Remove spilled hydraulic oil with the prescribed absorbent material.
-Put on S3 safety shoes.
WARNING
Improper maintenance or maintenance not carried out on time may result in damage to the machine or
injury to persons.
-Maintenance intervals are to be determined by the operator within the scope of their risk assessment.
-Observe the maintenance intervals and maintenance instructions of the manufacturer and existing
directives.
-Components may only be replaced with identical spare parts. It is imperative that the specifications of
the component manufacturer be followed when mounting the component.
WARNING
Spilled hydraulic oil can lead to an increased risk of fire and environmental pollution.
-Remove spilled hydraulic oil with the prescribed absorbent material.
WARNING
Operating errors using the device, e.g. by instruction errors, may lead to personal injury or damage to the
device.
-The instruction for use must be accessible to operators and maintenance personnel at all times!
-A copy of the technical documentation including the instruction for use must be kept in a suitable and
accessible place.
CAUTION
The hydraulic oil heats up during operation. Leaking hydraulic oil can easily burn the operator.
-Wear safety clothing.

12
RAIL SAW SR-10-26-O & SR-10-26-1 ORIGINAL OPERATION MANUAL
CAUTION
Noise emissions occur during operation of the hydraulic unit.
-Wear ear protection
-Switch the device off if unusual noises occur
CAUTION
Vibrations occur in the device during operation as a result of the cutting mechanism.
-Wear appropriate work gloves.
-Only use the device with the handles provided for this purpose.
NOTE
Inadequate lighting may result in incorrect switching operations or mix-ups.
Adhere to the break and recovery times prescribed by law.
3.3 Qualification of the operating and maintenance personnel
The intended circle of users for the machine includes the operators and maintenance personnel.
Anyone who carries out work on the device must be familiar with the functions and dangers of the machine. Introduction to the
machine is to be documented in writing.
All operators as well as employees that regularly enter the area of the machine should at least be instructed on the following
topics:
-Basic device functions (operators)
-instruction for use (operators)
-Conduct in work area (all)
-Location of safety devices (operators)
-Personal protective equipment (all)
Furthermore, operators should possess the necessary physical and mental capacities which are required to operate and service the
machine.
The operating personnel must wear personal protective equipment according to the job at hand and dangers of the environment.
The operational procedures as well as the professional association guidelines and safety data sheets are to be observed.

13
RAIL SAW SR-10-26-O & SR-10-26-1 ORIGINAL OPERATION MANUAL
3.4 Emergency information / safety devices
The specification of the Working Conditions Act must be observed when working with the machine. Persons who work with the
machine are required to use their personal protective equipment as intended. In this case that means:
-work gloves
-safety glasses or safety mask
-safety shoes S3
-hearing protection
3.5 Safety signs
Safety sign
Meaning
Mandatory sign “Wear hearing protection”: indicates that while working with the machine hearing
protection must be worn by all persons near to the machine.
Mandatory sign “Wear safety glasses”: indicates that while working the machine safety glasses must
be worn by the operator.
Mandatory sign “Wear protective shoes”: indicates that while working the machine protective shoes
must be worn by the operator.
Mandatory sign “Wear protective gloves”: indicates that while working the machine protective gloves
must be worn by the operator.
Mandatory sign “Wear protective clothing”: indicates that while working the machine protective
clothing must be worn by the operator.
Table 2: Safety signs

14
RAIL SAW SR-10-26-O & SR-10-26-1 ORIGINAL OPERATION MANUAL
4Design and function
4.1 Design
Figure 2 Overall design
No.
Description
1
Couplers
2
Blade guard
3
Handles
4
Start / stop lever
5
Trigger lock
6
Rail clamp
The Rail Saws require a flow of 10 gpm (38 lpm) at 2000 psi (138 bar) for best performance. Use this tool on an open center
hydraulic system only with a maximum pressure of 2150 psi (148.3 bar).
The saw mounts to the rail clamp (6) which is secured to the rail and pivots at two positions from the top of a tower, which allows
for a wide range of movement. The rail clamp has a cut indication marker for precise positioning of the cut.
The hydraulic hoses connect to the couplers (1) near the handle.
The operator is protected from the blade by a rotating blade guard (2) which automatically rotates during cutting to stay between
the blade and the operator.

15
RAIL SAW SR-10-26-O & SR-10-26-1 ORIGINAL OPERATION MANUAL
The saw features two handles (3) to maintain constant control while cutting. These handles are insulated to reduce vibration and
operator fatigue.
Start and stop of blade rotation is controlled by a lever (4) mounted under the handle. Accidental starting is prevent by a trigger
lock (5).
The handle which features the trigger and hydraulic connections, can be adjusted to different lengths by removing bolts on the
back side of the frame and siding the handle in or out and replacing the bolts to lock the handle in position.
The SR-10-26-O Model utilizes a 14” diameter (350 mm) cut off wheel.
The SR-10-26-1 Model utilizes both a 14” diameter (350 mm) and 16” diameter (400 mm) cut off wheel.
4.2 Accessories and kits descriptions
PortaCo, Inc carries a complete line of abrasive blades for cutting rail. The following abrasive blades can be purchased from
PortaCo, Inc by calling 218-236-0223 or e-mail at [email protected] :
-4263-OOP 14 x 1/8 x 1 General purpose
-4264-OOP 16 x 1/8 x 1 General purpose
-4265-OOP 14 x 1/8 x 1 Premium life
-4266-OOP 16 x 1/8 x 1 Premium life
-4267-OOP 14 x 1/8 x 1 Premium long life
-4268-OOP 16 x 1/8 x 1 Premium long life
4.3 Specification
Criteria
Value
Rail Saw
Length
1,143 mm / 45.0 inch
Width
686 mm / 27.0 inch
Height
452 mm / 18 inch
Weight (less blade)
15.0 kg / 35 lb
Hydraulic pressure
max. 150 bar / 2,150 psi
Hydraulic flow
max. 40 lpm / 10 gpm
Rail Clamp
Length
250 mm / 10.0 inch
Width
220 mm / 9.0 inch
Height
457 mm / 18 inch
Weight
6 kg / 15 lb
Table 3: Specifications

16
RAIL SAW SR-10-26-O & SR-10-26-1 ORIGINAL OPERATION MANUAL
4.3.1 Hydraulic fluid
The hydraulic fluid should meet the following requirements.
Criteria
Value
Viscosity (at 10 °C)
95 cSt
Viscosity (at 38 °C)
27-42 cSt
Viscosity (at 60 °C)
16,5 cSt
Pour point
-10 °C
Viscosity index (ASTM-D2220)
min. 140
Flash point (ASTM-D92)
min. 171 °C
Pump wear test (ASTM-D2882)
max. 60 mg
Demulsibility (ASTM-D1401)
max. 30 minutes
Table 4: Hydraulic fluid data
The following hydraulic fluids or equivalent are suitable for use.
Manufacturer
Type
Chevron
Clarity AW ISO 32
Mobil
Univis J32
Gulf
Harmony AW-HVI-150-32
Shell
Tellus T32
Table 5: Suitable hydraulic fluids
4.3.2 Supply, interfaces and connections
The machine is powered by a hydraulic unit. There are quick couplings (3/8" flat face) for connecting the hydraulic unit.
4.4 Function
The rail saw has a back saver design that allows the operator to stand while using the saw. It also has extended blade life and a
convenient handle with trigger that automatically stops tool operations when released. The trigger has a safety lock to avoid
unplanned operation. The saw has a durable aluminum frame construction along with a high-efficiency, pressure-loaded, hydraulic
motor that provides maximum power while reducing heat and minimizing energy waste. The over-speed valve protects the motor
and blades from excessive RPM. There is an automatic spark guard for optimum protection.
4.5 Boundaries and interfaces
The Rail Saw consists of the parts pictured in chapter Design and Function. The battery limit is the connection to the hydraulic unit.
Power and auxiliary materials are not part of PortaCo Inc´s scope of service. Other parts which are not directly part of the machine
are also excluded.

17
RAIL SAW SR-10-26-O & SR-10-26-1 ORIGINAL OPERATION MANUAL
5Transport, assembly and dismantling
The machine must be disconnected from the hydraulic unit for transport. For this purpose, the hydraulic unit must be switched off
and the system depressurized. After that the hydraulic hose couplings can be detached. Then the machine can be transported fully
assembled without being taken apart.
The 2 main parts of the machine can be transported by a single worker.
6Commissioning and operation
6.1 General information for start-up
DANGER
Incorrect operation of the machine or disregard of safety instructions may lead to
endangerment of persons or damage to the machine.
-Familiarize yourself with the complete instruction for use before beginning work on the
machine. Pay particular attention to chapter 3!
NOTE
A thorough, visual inspection of the machine is to be carried out by the operator before start-up.
Start-up of the machine may only be carried out by qualified specialist personnel. The start-up engineer must be acquainted with
the machine. Requirements for start-up are:
If the tool is used in cold weather, preheat the hydraulic fluid by running power source at low engine speed. Fluid temperature
should be at or above 50° F/10° C (400-ssu/82 centistroke) before use, when using recommended fluids. Using too thick of fluid
may result in tool damage.
all detachable connections have been checked and tightened if necessary
check for loose nuts and bolts, keep all fasteners tight to prevent parts from separating and causing unsafe conditions
check hydraulic fittings and hoses for leaks or damage. Keep all hydraulic components in good condition to prevent tool
failure and for operator safety
CAUTION
Do not search for leaks with bare hands. Pressurized fluid escaping from a damaged hose
or fitting can penetrate the skin and be injected in the body causing injury or death.
-Wear appropriate work gloves.

18
RAIL SAW SR-10-26-O & SR-10-26-1 ORIGINAL OPERATION MANUAL
6.1.1 Tool preparation
Hydraulic system
-Use calibrated flow meter and pressure gauge to check the hydraulic power source. The source should provide a flow of 10
gpm/40 lpm at 2000 psi/ 140 bar. A relief valve setting between 2100-2250 psi/ 145-155 bar is required for the operation of
this tool.
-The hydraulic system’s back pressure should be less than 250 psi/17 bar, measured at the end of the tool’s operating hoses. All
systems checks should be made at minimum operating temperatures (maximum fluid viscosity of 400 ssu/82 centistokes).
-The hydraulic fluid cooling system should limit the maximum fluid temperature to 140º F/60º C at the maximum expected
ambient temperature. The minimum cool capacity should be 5hp/3.73 kW at the 40 º F/22 º C difference between ambient
temperature and fluid temperature.
-A minimum of 25 micron filtration is required for the hydraulic system. For cold weather startup and maximum dirt holding
capacity a filter element sized for 30gpm/120 lpm is recommended.
-If the tool is used in cold weather, preheat the hydraulic fluid by running power source at low engine speed. Fluid temperature
should be at or above 50 ºF/10 ºC (400ssu/82 centistokes) before use, when using recommended fluid.
CAUTION
Using too thick of fluid may result in tool damage.
The PortaCo G-18D55-53-W power unit is recommended for hydraulic supply. This unit is equipped with two 5 gpm/20 lpm circuits
that can be combined for one 10 gpm/40 lpm circuits.
Tool trigger and trigger lock
-Check that trigger lock presses into handle tube easily and returns to locking position when released.
-Check that trigger cannot be activated with trigger lock in the released position.
-With the trigger lock pressed into the handle tube, pull the trigger to the tube. The trigger should return to the “Off” position
when released.
-If trigger or trigger stop sticks or doesn’t operate easily check for obstructions. If trigger or trigger lock doesn’t return to “Off”
or lock position when released, check the return springs.
WARNING
Do not operate a tool if the trigger or trigger lock is not working properly!

19
RAIL SAW SR-10-26-O & SR-10-26-1 ORIGINAL OPERATION MANUAL
Blade guard
Inspect the blade guard and fasteners for damage. Repair any damage before using the tool.
WARNING
Do not operate tool without the wheel guard!
Blade backups
-If reducing bushings are used in a blade’s mounting hole, check that it doesn’t protrude beyond the surface of the blade.
Bushings that are too thick will not allow the backups to contact the blade properly.
-Do not use blades that have bushings which are loose in the mounting holes. Do not use shim shock to tighten or replace
bushings.
Reducing bushings
-If reducing bushings are used in a wheel’s mounting hole, check that it doesn’t protrude beyond the surface of the wheel.
Bushings that are too thick will not allow the backups to contact the wheel properly.
-Do not use wheels that have bushings which are loose in the mounting holes. Do not use shim stock to tighten or replace
bushings
Blade inspection
-Prior to mounting, all wheels should be visually inspected by the operator for damage and cracks.
WARNING
Do not use damaged or cracked tool blades.
-The “ring test” may be used to check for cracks in the blade which are not visible to the naked eye. To perform the test
suspend the blade from the hole on a small pin or finger. Tap the blade gently with a non-metallic implement such as a
screwdriver handle. The best spot to tap is about 45º either side of the vertical center line 1” or 2” from the periphery. An
undamaged blade will give a clear tone. If cracked there will be a dead sound instead.
-Check that the surface of the blotters and backups are free of dirt and other foreign contaminants.
-Use only blades which meet or exceed the requirements of the tool.

20
RAIL SAW SR-10-26-O & SR-10-26-1 ORIGINAL OPERATION MANUAL
Care of abrasive wheel
-All abrasive blades are breakable and therefore care should be exercised in handling and storage to prevent damage. All
abrasive blades should be stored in a dry area and not be subjected to exposure to water or other solvents. Also avoid freezing
temperatures or humid conditions which cause condensation on the blades.
-Thin organic bonded blades, (Rail Saw blades or Slotting discs used for cutting), should be laid flat on a flat surface of steel or
similar rigid material away from excessive heat, moisture, and other liquids. If thin blades are supplied with blotters attached,
suitable separators should be used to preserve flatness.
-Blades used on cutoff saws carried on emergency vehicles should be removed after use and discarded or carefully stored as
described in this section
Wheel breakage
-If a blade breaks during use, the operator should investigate to determine and correct the cause. If the operator cannot
determine the cause, the blade manufacturer should be consulted.
-Blades designed for use with hand-held portable tools are reinforced and specifically manufactured for this application. They
are extremely tough and difficult to break under normal use.
6.1.2 Testing
WARNING
Never stick foreign objects, fingers, or other extremities into moving mechanisms. Failure to follow these
instructions may lead to severe personal injury or tool damage.
-Mount the rail saw clamp to a test rail. Position the clamp so the cut off piece is only about 1 inch wide.
-Mount the saw to the clamp.
-Install a new cut off blade in the saw
-Connect the saw to the power source. Run the saw at full speed and using a tachometer measure the RPM of the blade. The
blade should be rotating between 4,000 and 4,800 RPM. If the blade doesn’t fall with in this range see the Trouble Shooting
section of this manual.
-With the RPM with in the specified range cut through the rail.
-Check that the cut is square. Measure across the base with a tee square and from the base to the ball of the rail, the cut should
be square to within 0.06 inches (1.5 mm) in both directions. If the difference is greater see the Tool Maintenance section of this
manual for adjusting procedures.
6.1.3 Specification of the hydraulic system
The hydraulic unit should ensure a flow of at least 40 lpm (10 gpm) at a pressure of 138 bar (2,002 psi). The pressure must be
limited to 150 bar (2,176 psi). Measurements must be carried out at the minimum operating temperature by 10 °C (50 °F) of the
hydraulic fluid. Warm the hydraulic fluid if necessary.
The temperature of the hydraulic fluid must be limited to 60 °C (140°F).
We recommend the use of the hydraulic units D-23, E-15, G-18, G-21, G-23 or G-31 from PortaCo Inc.
