Poulan Pro 176851 User manual

OWNER'S MANUAL
MODEL NO. PC14542B
14.5 HP 42 Inch
LawnTractor
For Parts and Service, contact our authorized distributor: call 1-800-849-1297
For Technical Assistance: call 1-800-829-5886
176851 1.24.01 JH
PRINTED IN U.S.A.

2
Safe Operation Practices for Ride-On Mowers
IMPORTANT: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROWING OBJECTS.
FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH.
SAFETY RULES
I. GENERAL OPERATION
• Read, understand, and follow all instructions in the
manualandonthemachinebeforestarting.
• Onlyallowresponsibleadults,whoarefamiliarwiththe
instructions, to operate the machine.
• Cleartheareaofobjectssuchas rocks,toys,wire,etc.,
which could be picked up and thrown by the blade.
• Besuretheareaisclearofotherpeoplebeforemowing.
Stop machine if anyone enters the area.
• Nevercarrypassengers.
• Do not mow in reverse unless absolutely necessary.
Alwayslookdownandbehindbeforeandwhilebacking.
• Be aware of the mower discharge direction and do not
point it at anyone. Do not operate the mower without
either the entire grass catcher or the guard in place.
• Slowdownbeforeturning.
• Neverleavearunningmachineunattended. Alwaysturn
offblades,setparkingbrake,stopengine,andremove
keysbeforedismounting.
• Turnoffbladeswhennotmowing.
• Stop engine before removing grass catcher or unclog-
gingchute.
• Mow only in daylight or good artificial light.
• Donotoperatethemachinewhileundertheinfluenceof
alcoholordrugs.
• Watchfortrafficwhenoperatingnearorcrossingroad-
ways.
• Useextracarewhenloadingorunloadingthemachine
into a trailer or truck.
• Dataindicatesthatoperators,age60yearsandabove,
are involved in a large percentage of riding mower-
relatedinjuries. Theseoperatorsshouldevaluatetheir
ability to operate the riding mower safely enough to
protect themselves and others from serious injury.
II. SLOPE OPERATION
Slopes are a major factor related to loss-of-control and tipover
accidents, which can result in severe injury or death. All slopes
requireextracaution. Ifyoucannotbackuptheslopeorifyoufeel
uneasy on it, do not mow it.
DO:
• Mow up and down slopes, not across.
• Remove obstacles such as rocks, tree limbs, etc.
• Watch for holes, ruts, or bumps. Uneven terrain could
overturn the machine. Tall grass can hide obstacles.
•Useslowspeed. Choosealowgearsothatyouwillnot
have to stop or shift while on the slope.
•Followthemanufacturer’srecommendationsforwheel
weights or counterweights to improve stability.
•Use extra care with grass catchers or other attach-
ments. Thesecan changethestabilityofthemachine.
•Keep all movement on the slopes slow and gradual . Do not
make sudden changes in speed or direction.
•Avoid starting or stopping on a slope. If tires lose traction,
disengage the blades and proceed slowly
straight down the
slope.
DO NOT:
• Donot turnonslopesunlessnecessary,andthen,turn
slowly and gradually downhill, if possible.
• Do not mow near drop-offs, ditches, or embankments.
Themowercouldsuddenlyturnoverifawheelisoverthe
edge of a cliff or ditch, or if an edge caves in.
• Donot mowonwetgrass.Reducedtractioncouldcause
sliding.
• Do not tryto stabilize themachine by putting your foot
ontheground.
• Do not use grass catcher on steep slopes.
III. CHILDREN
Tragicaccidentscanoccurif the operator is not alert tothe
presence of children. Children are often attracted to the
machine and the mowing activity. Never assume that
children will remain where you last saw them.
•Keep children out of the mowing area and under the
watchfulcareof another responsibleadult.
•Bealertandturnmachineoffif children enter the area.
•Before and when backing, look behind and down for
smallchildren.
•Nevercarrychildren. Theymayfalloffandbeseriously
injuredorinterferewithsafemachineoperation.
•Neverallowchildrentooperatethemachine.
•Useextracarewhenapproachingblindcorners,shrubs,
trees, or other objects that may obscure vision.
IV. SERVICE
•Use extra care in handling gasoline and other fuels.
Theyare flammable and vapors are explosive.
- Useonlyanapprovedcontainer.
- Never remove gas cap or add fuel with the engine
running. Allowenginetocoolbeforerefueling. Donot
smoke.
- Neverrefuelthemachineindoors.
- Neverstorethemachineorfuelcontainerinsidewhere
there is an open flame, such as a water heater.
•Never run a machine inside a closed area.
•Keepnutsandbolts,especiallybladeattachmentbolts,
tightandkeep equipment in good condition.
•Never tamper with safety devices. Check their proper
operationregularly.
•Keep machine free of grass, leaves, or other debris
build-up. Cleanoilorfuelspillage. Allowmachinetocool
beforestoring.
•Stopand inspect theequipment if you strike an object.
Repair,ifnecessary,beforerestarting.
•Never make adjustments or repairs with the engine
running.
•Grass catcher components are subject to wear, dam-
age,anddeterioration,whichcouldexposemovingparts
orallowobjectstobethrown. Frequentlycheckcompo-
nents and replace with manufacturer's recommended
parts,whennecessary.
•Mowerbladesaresharpandcancut. Wraptheblade(s)
or wear gloves, and use extra caution when servicing
them.

3
Safe Operation Practices for Ride-On Mowers
SAFETY RULES
SAFETY RULES ........................................................ 2-3
PRODUCT SPECIFICATIONS....................................... 4
CUSTOMER RESPONSIBILITIES ......................4, 14-18
ASSEMBLY................................................................ 6-8
OPERATION............................................................. 9-13
MAINTENANCE SCHEDULE....................................... 14
SERVICE AND ADJUSTMENTS .............................19-23
STORAGE ................................................................... 24
TROUBLESHOOTING .............................................25-26
REPAIR PARTS ......................................................28-43
WARRANTY ................................................................ 45
TABLE OF CONTENTS
•Checkbrakeoperationfrequently. Adjustandservice
asrequired.
•Be sure the area is clear of other people before mowing.
Stop machine if anyone enters the area.
•Never carry passengers or children even with the blades
off.
•Do not mow in reverse unless absolutely necessary. Al-
ways look down and behind before and while backing.
•Never carry children. They may fall off and be seriously
injured or interfere with safe machine operation.
•Keep children out of the mowing area and under the
watchful care of another responsible adult.
•Be alert and turn machine off if children enter the area.
•Before and when backing, look behind and down for small
children.
•Mow up and down slopes (15°Max), not across.
•Remove obstacles such as rocks, tree limbs, etc.
•Watch for holes, ruts, or bumps. Uneven terrain could
overturn the machine. Tall grass can hide obstacles.
•Useslowspeed.Choosealowgearsothatyouwillnothave
to stop or shift while on the slope.
•Avoid starting or stopping on a slope. If tires lose traction,
disengage the blades and proceed slowly straight down
the slope.
•If machine stops while going uphill, disengage blades, shift
into reverse and back down slowly.
•Do not turn on slopes unless necessary, and then, turn
slowly and gradually downhill, if possible.
Look for this symbol to point out im-
portant safety precautions. It means
CAUTION!!! BECOMEALERT!!! YOUR
SAFETY IS INVOLVED.
CAUTION: Inordertopreventacciden-
talstartingwhensettingup,transport-
ing, adjusting or making repairs, al-
ways disconnect spark plug wire and
placewirewhereitcannotcontactspark
plug.
CAUTION: Do not coast down a hill in
neutral, you may lose control of the
tractor.
CAUTION: Tow only the attachments
thatare recommendedby andcomply
withspecificationsofthemanufacturer
of your tractor. Use common sense
when towing. Operate only at the low-
est possible speed when on a slope.
Too heavy of a load, while on a slope,
is dangerous. Tires can lose traction
withtheground andcauseyoutolose
controlofyourtractor.
WARNING
Engine exhaust, some of its constituents, and cer-
tainvehiclecomponentscontainoremitchemicals
knowntotheStateofCaliforniatocausecancerand
birthdefectsorotherreproductiveharm.
WARNING
Battery posts, terminals and related accessories
containleadandleadcompounds,chemicalsknown
to the State of California to cause cancer and birth
defects or other reproductive harm. Wash hands
afterhandling.

4
PRODUCT SPECIFICATIONS
GASOLINE CAPACITY 1.25 GALLONS
AND TYPE: UNLEADED REGULAR
OILTYPE(API-SF-SJ): SAE 30 (above 32°F)
SAE 5W-30 (below 32°F)
OILCAPACITY: 3 PINTS
SPARK PLUG: CHAMPION RC12YC
(GAP: .030")
GROUND SPEED (MPH): FORWARD:
1st 1.1
2nd 1.4
3rd 2.2
4th 3.3
5th 4.4
6th 4.9
REVERSE: 1.4
TIRE PRESSURE: FRONT: 14 PSI
REAR: 12 PSI
CHARGING SYSTEM: 3 AMPS BATTERY
5 AMPS HEADLIGHTS
BATTERY: AMP/HR: 25
MIN. CCA: 190
CASESIZE: U1R
BLADE BOLT TORQUE: 27-35 FT. LBS.
CONGRATULATIONS onyourpurchaseofanewtractor. It
has been designed, engineered and manufactured to give
youthebest possibledependabilityandperformance.
Should you experience any problem you cannot easily
remedy, please contact your nearest authorized service
centre/department. Wehavecompetent,well-trainedtech-
niciansand thepropertools toserviceor repairthistractor.
Please read and retain this manual. The instructions will
enableyoutoassembleandmaintainyourtractorproperly.
Always observe the “SAFETY RULES”.
CUSTOMER RESPONSIBILITIES
•Read and observe the safety rules.
•Followaregularscheduleinmaintaining,caringforand
usingyour tractor.
•Follow the instructions under “Customer Responsibili-
ties”and “Storage”sections of this owner’s manual.
WARNING: This tractor is equipped with an internal com-
bustion engine and should not be used on or near any
unimproved forest-covered, brush-covered or grass-cov-
ered land unless the engine’s exhaust system is equipped
withasparkarrestermeetingapplicablelocalorstatelaws
(ifany). If a sparkarrester is used,it should bemaintained
ineffective working order by theoperator.
A spark arrester for the muffler is available through your
nearest authorized service centre/department (See RE-
PAIR PARTS section of this manual).

5
UNASSEMBLEDPARTS
Steering Wheel
Steering
Wheel
Insert
(1) Large Flat
Washer
(1) Locknut
5/16-18
(1) Hex Bolt
5/16-18 x 1-1/4
(1) Hex Bolt
3/8-16 x 1
(1) Lockwasher 3/8
Steering
Boot
Steering
Extension
Shaft
Steering
Wheel
Adapter
(1) Bolt
(1) Washer
17/32 x 1-3/16 x 12 Gauge
Seat
(2) Keys
Slope Sheet
Keys
(1) Lock
Washer 1/2
(1) Oil Drain Tube

6
ASSEMBLY
TOOLS REQUIRED FOR ASSEMBLY
A socket wrench set will make assembly easier. Standard
wrench sizes are listed.
(1) 9/16"wrench Pliers
(2) 1/2"wrenches Tirepressuregauge
Utility knife
Whenrightorlefthandismentionedinthismanual,itmeans
when you are in the operating position (seated behind the
steeringwheel).
TO REMOVETRACTOR FROM CARTON
UNPACK CARTON
•Remove all accessible loose parts and parts cartons
fromcarton.
•Cut, from top to bottom, along lines on all four corners
of carton, and lay panels flat.
•Check for any additional loose parts or cartons and
remove.
Yournewtractorhasbeenassembledatthefactorywithexceptionofthosepartsleftunassembledforshippingpurposes. To
ensure safe and proper operation of your tractor all parts and hardware you assemble must be tightened securely. Use the
correct tools as necessary to insure proper tightness.
FIG. 1
BEFORE REMOVING TRACTOR FROM
SKID
ATTACH STEERING WHEEL (See Fig. 1)
ASSEMBLE EXTENSION SHAFT AND BOOT
•Slide extension shaft onto lower steering shaft. Align
mountingholesinextensionandlowershaftsandinstall
5/16 hex bolt and locknut. Tighten securely.
•Place tabs of steering boot over tab slots in dash and
pushdown to secure.
INSTALLSTEERINGWHEEL
•Positionfrontwheels of the tractorsotheyarepointing
straightforward.
•Removesteeringwheeladapterfromsteeringwheeland
slide adapter onto steering shaft extension.
•Positionsteeringwheelsocrossbarsarehorizontal(left
to right) and slide inside boot and onto adapter.
•Assemble large flat washer, 3/8 lock washer, 3/8 hex
bolt and tighten securely.
•Snapsteeringwheelinsertintocenterofsteeringwheel.
•Removeprotectivematerialsfromtractorhoodandgrill.
IMPORTANT: CHECKFORANDREMOVEANYSTAPLES
INSKIDTHATMAYPUNCTURETIRESWHERETRACTOR
IS TO ROLL OFF SKID.
5/16 LOCKNUT
LOWER
STEERING
SHAFT
STEERING
BOOT
EXTENSION SHAFT
5/16 HEX BOLT
STEERING
WHEEL
INSERT
ADAPTER
3/8 HEX BOLT
3/8 LOCK WASHER
LARGE FLAT
WASHER
TABS
TAB
SLOTS

7
ASSEMBLY
TOROLLTRACTOROFFSKID (SeeOperation
section, page 10, for location and function of
controls)
•Pressliftleverplungerandraiseattachmentliftleverto
its highest position.
•Releaseparkingbrakebydepressingclutch/brakepedal.
•Place gearshift lever in neutral (N) position.
•Roll tractor forward off skid.
•Remove banding holding deflector shield up against
tractor.
HOW TO SET UP YOUR TRACTOR
CHECK BATTERY (See Fig. 2)
•Lift seat pan to raised position and open battery box
door.
•If this battery is put into service after month and year
indicated on label (label located between terminals)
charge battery for minimum of one hour at 6-10 amps.
(See"BATTERY"inCUSTOMERRESPONSIBILITIES
section of this manual for charging instructions).
FIG. 2
BATTERY
BOX DOOR
SEAT PAN
LABEL
TERMINAL TERMINAL
ADJUSTMENT
BOLT
LOCK WASHER
FIG. 3
NOTE: You may now roll or drive your tractor off the skid.
Follow the appropriate instruction below to remove the
tractor from the skid.
INSTALL SEAT (See Fig. 3)
Adjust seat before tightening adjustment bolt.
•Remove adjustment bolt, lock washer and flat washer
securing seat to cardboard packing and set aside for
assembly of seat to tractor.
•Pivot seat upward and remove from the cardboard
packing.Remove thecardboardpackingand discard.
•Place seat on seat pan so head of shoulder bolt is
positionedover large slotted hole in pan.
•Pushdown on seat to engage shoulder bolt in slotand
pull seat towards rear of tractor.
•Pivot seat and pan forward and assemble adjustment
bolt,lockwasherandflatwasherloosely.Donottighten
•Lower seat into operating position and sit on seat.
•Slideseatuntilacomfortablepositionisreachedwhich
allowsyoutopressclutch/brakepedalallthewaydown.
•Get off seat without moving its adjusted position.
•Raise seat and tighten adjustment bolt securely.
SEAT PAN
SHOULDER
BOLT
FLAT WASHER
SEAT

8
ASSEMBLY
3 CHECKLIST
BEFOREYOUOPERATEANDENJOYYOURNEW TRAC-
TOR, WE WISH TO ASSURE THAT YOU RECEIVE THE
BESTPERFORMANCEANDSATISFACTIONFROMTHIS
QUALITYPRODUCT.
PLEASEREVIEWTHEFOLLOWINGCHECKLIST:
3 All assembly instructions have been completed.
3 Noremaining loose parts in carton.
3 Batteryisproperlypreparedandcharged. (Minimum1
hour at 6 amps).
3 Seat is adjusted comfortably and tightened securely.
3 All tires are properly inflated. (For shipping purposes,
the tires were overinflated at the factory).
3 Be sure mower deck is properly leveled side-to-side/
front-to-rear for best cutting results. (Tires must be
properlyinflatedforleveling).
3 Checkmoweranddrivebelts. Besuretheyarerouted
properlyaroundpulleysandinside all belt keepers.
3 Check wiring. See that all connections are still secure
andwiresareproperlyclamped.
WHILELEARNINGHOWTOUSEYOURTRACTOR,PAY
EXTRAATTENTIONTOTHEFOLLOWINGIMPORTANT
ITEMS:
3 Engine oil is at proper level.
3 Fuel tank is filled with fresh, clean, regular unleaded
gasoline.
3 Become familiar with all controls - their location and
function. Operate them before you start the engine.
3 Be sure brake system is in safe operating condition.
CHECK TIRE PRESSURE
Thetireson yourtractorwereoverinflatedat the factoryfor
shipping purposes. Correct tire pressure is important for
bestcuttingperformance.
•Reduce tire pressure to PSI shown in “PRODUCT
SPECIFICATIONS”section of this manual.
CHECK DECK LEVELNESS
Forbestcuttingresults,mowerhousingshouldbeproperly
leveled. See“TOLEVELMOWERHOUSING”intheService
and Adjustments section of this manual.
CHECK FOR PROPER POSITION OF ALL
BELTS
See the figures that are shown for replacing motion and
mower blade drive belts in the Service and Adjustments
section of this manual. Verify that the belts are routed
correctly.
CHECK BRAKE SYSTEM
Afteryoulearnhowtooperateyourtractor,checktoseethat
thebrakeisproperlyadjusted. See“TOADJUSTBRAKE”
in the Service and Adjustments section of this manual.
TO DRIVE TRACTOR OFF SKID (See Opera-
tion section, page 10, for location and func-
tion of controls)
WARNING:Beforestarting,read,understandandfollow
all instructions in the Operation section of this manual. Be
sure tractor is in a well-ventilated area. Be sure the area in
front of tractor is clear of other people and objects.
•Be sure all the above assembly steps have been
completed.
•Check engine oil level and fill fuel tank with gasoline.
•Sit on seat in operating position, depress clutch/brake
pedaland set the parking brake.
•Place gear shift lever in neutral (N) position.
•Pressliftleverplungerandraiseattachmentliftleverto
its highest position.
•Starttheengine.Afterenginehasstarted,movethrottle
control to idle position.
•Depress clutch/brake pedal into full "BRAKE" position
and hold. Move gearshift lever to 1st gear.
•Slowly release clutch/brake pedal and slowly drive
tractor off skid.
•Applybraketostoptractor,setparkingbrakeandplace
gearshiftlever in neutral position.
•Turn ignition key to "OFF" position.
Continue with the instructions that follow.

9
OPERATION
These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their meaning.
BATTERY CAUTION OR
WARNING REVERSE FORWARD FAST SLOW
ENGINE ON ENGINE OFF OIL PRESSURE LIGHTS ON
FUEL CHOKE MOWER HEIGHT PARKING BRAKE
LOCKED UNLOCKED
REVERSE NEUTRAL HIGH LOW
ATTACHMENT
CLUTCH ENGAGED
MOWER LIFT
DANGER, KEEP HANDS AND FEET AWAY FREE WHEEL
(Automatic Models only)
OVER TEMP
LIGHT
PARKING BRAKE
IGNITION ATTACHMENT
CLUTCH DISENGAGED
P
KEEP AREA CLEAR SLOPE HAZARDS
15
15 15
(SEE SAFETY RULES SECTION)

10
OPERATION
KNOW YOUR TRACTOR
READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR
Comparetheillustrationswithyourtractortofamiliarizeyourselfwiththelocationsofvariouscontrolsandadjustments. Save
thismanualforfuturereference.
Our tractors conform to the safety standards of the American National Standards Institute.
ATTACHMENT
CLUTCH
LEVER
ATTACHMENT CLUTCH LEVER: Used to engage the
mowerblades,orotherattachmentsmountedtoyourtractor.
LIGHT SWITCH: Turns the headlights on and off.
THROTTLE/CHOKE CONTROL: Used for starting and
controllingenginespeed.
CLUTCH/BRAKEPEDAL: Usedfordeclutchingandbrak-
ing the tractor and starting the engine.
PARKINGBRAKE:Locksclutch/brakepedalintothebrake
position.
AMMETER: Indicates charging (+) or discharging (-) of
battery.
GEARSHIFT LEVER: Selects the speed and direction of
tractor.
ATTACHMENT LIFT LEVER: Used to raise, lower, and
adjustthemowerdeckorotherattachmentsmountedtoyour
tractor.
LIFT LEVER PLUNGER: Used to release attachment lift
leverwhen changing its position.
IGNITION SWITCH: Used for starting and stopping the
engine.
FIG. 4
IGNITION
SWITCH LIFT LEVER
PLUNGER
ATTACHMENT
LIFT LEVER
MOWER DECK
HEIGHT ADJUSTMENT
POSITIONS
GEARSHIFT
LEVER
CLUTCH/BRAKE
PEDAL
THROTTLE/CHOKE
CONTROL
LIGHT SWITCH
PARKING
BRAKE
AMMETER

11
OPERATION
Theoperationofanytractorcan resultinforeignobjectsthrownintotheeyes,whichcan
resultinsevereeyedamage. Alwayswearsafetyglassesoreyeshieldswhileoperating
your tractor or performing any adjustments or repairs. We recommend a wide vision
safetymaskoverspectaclesorstandardsafetyglasses.
IMPORTANT: LEAVING THE IGNITION SWITCH IN ANY
POSITION OTHER THAN "OFF" WILL CAUSE THE BATTERY
TO BE DISCHARGED, (DEAD).
NOTE: Under certain conditions when tractor is standing
idlewiththeenginerunning,hotengineexhaustgasesmay
cause “browning”of grass. To eliminate this possibility,
alwaysstop engine when stopping tractor on grass areas.
CAUTION: Alwaysstoptractorcom-
pletely,asdescribedabove,before
leavingtheoperator'sposition;to
emptygrasscatcher,etc.
TO USE THROTTLE CONTROL (See Fig. 5)
Always operate engine at full throttle.
•Operating engine at less than full throttle reduces the
batterychargingrate.
•Fullthrottle offersthebestbagging andmowerperfor-
mance.
TO MOVE FORWARD AND BACKWARD
(See Fig. 5)
Thedirection and speed ofmovement is controlled by the
gearshift lever.
•Start tractor with clutch/brake pedal depressed and
gearshift lever in neutral (N) position.
•Move gearshift lever to desired position.
•Slowlyreleaseclutch/brake pedal to start movement.
IMPORTANT: BRING TRACTOR TO A COMPLETE STOP
BEFORESHIFTINGORCHANGINGGEARS.FAILURETODO
SOWILLSHORTENTHEUSEFULLIFEOFYOURTRANSAXLE.
TO ADJUST MOWER CUTTING HEIGHT
(See Fig. 5)
The position of the attachment lift lever determines the
cutting height.
•Grasp lift lever.
•Press plunger with thumb and move lever to desired
position.
Thecutting height rangeis approximately1-1/2to 4". The
heightsaremeasuredfromthegroundtothebladetipwith
theenginenotrunning. Theseheightsareapproximateand
may vary depending upon soil conditions, height of grass
and types of grass being mowed.
•Theaveragelawnshouldbecuttoapproximately2-1/2
inches during the cool season and to over 3 inches
during hot months. For healthier and better looking
lawns,mowoftenandaftermoderategrowth.
•For best cutting performance, grass over 6 inches in
height should be mowed twice. Make the first cut
relatively high; the second to desired height.
STOPPING (See Fig. 5)
MOWERBLADES-
•Tostopmowerblades,moveattachmentclutchleverto
“DISENGAGED”position.
GROUNDDRIVE-
•To stop ground drive, depress clutch/brake pedal into
full “BRAKE”position.
•Move gearshift lever to neutral (N) position.
ENGINE-
•Move throttle control to slow position.
NOTE: Failuretomovethrottlecontroltoslowpositionand
allowingenginetoidlebeforestoppingmaycauseengineto
“backfire”.
•Turn ignition key to “OFF”position and remove key.
Always remove key when leaving tractor to prevent
unauthorizeduse.
•Never use choke to stop engine.
HOW TO USE YOUR TRACTOR
TO SET PARKING BRAKE (See Fig. 5)
Yourtractorisequippedwithanoperatorpresencesensing
switch. Whenengineisrunning,anyattemptbytheoperator
to leave the seat without first setting the parking brake will
shut off the engine.
•Depress clutch/brake pedal into full “BRAKE”position
andhold.
•Placeparkingbrakelever in“ENGAGED”positionand
releasepressurefromclutch/brakepedal. Pedalshould
remainin“BRAKE”position. Makesureparkingbrake
will hold tractor secure.
PARKING BRAKE
"ENGAGED"
POSITION
GEARSHIFT
LEVER
THROTTLE/CHOKE
CONTROL LEVER
IGNITION KEY
"DISENGAGED"
POSITION
ATTACHMENT CLUTCH LEVER
"ENGAGED" POSITION
"BRAKE"
POSITION
FIG. 5
PARKING BRAKE
"DISENGAGED" POSITION
CLUTCH/BRAKE PEDAL
"DRIVE" POSITION

12
OPERATION
TO OPERATE MOWER (See Fig. 7)
Yourtractor isequippedwithanoperatorpresencesensing
switch. Any attempt by the operator to leave the seat with
theenginerunningandthe attachment clutch engaged will
shut off the engine.
•Select desired height of cut.
•Start mower blades by engaging attachment clutch
control.
•TO STOP MOWER BLADES - disengage attachment
clutch control.
TO OPERATE ON HILLS
CAUTION: Donotdriveupordownhills
withslopesgreater than15°anddo not
driveacross any slope.
•Choose the slowest speed before starting up or down
hills.
•Avoid stopping or changing speed on hills.
•If slowing is necessary, move throttle control lever to
slowerposition.
•If stopping is absolutely necessary, push clutch/brake
pedal quickly to brake position and engage parking
brake.
•Move gearshift lever to 1st gear. Be sure you have
allowed room for tractor to roll slightly as you restart
movement.
•Torestartmovement,slowlyreleaseparkingbrakeand
clutch/brakepedal.
•Make all turns slowly.
TO TRANSPORT
•Raiseattachmentlifttohighestpositionwithattachment
lift control.
•Whenpushingor towingyourtractor,be suregearshift
lever is in neutral (N) position.
•Do not push or tow tractor at more than five (5) MPH.
NOTE: Toprotecthoodfromdamagewhentransportingyour
tractor on a truck or a trailer, be sure hood is closed and
securedtotractor. Useanappropriatemeansoftyinghood
to tractor (rope, cord, etc.).
TOWING CARTS AND OTHER ATTACH-
MENTS
Tow only the attachments that are recommended by and
comply with specifications of the manufacturer of your
tractor. Use common sense when towing. Too heavy of a
load,whileonaslope,isdangerous.Tirescanlosetraction
withthegroundandcauseyoutolosecontrolofyourtractor.
BEFORE STARTING THE ENGINE
CHECK ENGINE OIL LEVEL
•Theengine in your tractor has been shipped, from the
factory, already filled with summer weight oil.
•Check engine oil with tractor on level ground.
•Removeoilfillcap/dipstickandwipeclean,reinsertthe
dipstick and screw cap tight, wait for a few seconds,
remove and read oil level. If necessary, add oil until
“FULL”mark on dipstick is reached. Do not overfill.
•For cold weather operation you should change oil for
easier starting (See “OIL VISCOSITY CHART”in the
Customer Responsibilities section of this manual).
•Tochangeengineoil,seetheCustomerResponsibilities
section in this manual.
FIG. 6
FIG. 7
LOW
POSITION
ATTACHMENT LIFT
LEVER HIGH POSITION
"ENGAGED" POSITION
ATTACHMENT
CLUTCH LEVER
"DISENGAGED"
POSITION
3/8 WASHER
3/8-16
LOCKNUT
GAUGE
WHEEL
MOUNTING
BRACKET
SHOULDER
BOLT
GAUGE WHEEL
TO ADJUST GAUGE WHEELS (See Fig. 6)
Gaugewheels areproperlyadjustedwhentheyareslightly
offthegroundwhenmowerisatthedesiredcuttingheightin
operating position. Gauge wheels then keep the deck in
proper position to help prevent scalping in most terrain
conditions.
•Adjustgaugewheelswithtractoronaflatlevelsurface.
•Adjust mower to desired cutting height (See “TO AD-
JUST MOWER CUTTING HEIGHT”in the Operation
section of this manual).
•With mower in desired height of cut position, gauge
wheelsshouldbeassembledsotheyareslightlyoffthe
ground. Install gauge wheel in appropriate hole with
shoulder bolt, 17/32 washer, 3/8 washer, and 3/8-16
locknut and tighten securely.
•Repeatforoppositesideinstallinggaugewheelinsame
adjustmenthole.
CAUTION: Do not operate the mower
withouteitherthe entire grass catcher,
onmowerssoequipped,orthedeflector
shield in place.
17/32 WASHER

13
OPERATION
MOWING TIPS
•Tirechainscannotbeusedwhenthemowerhousingis
attached to tractor.
•Mower should be properly leveled for best mowing
performance. See“TOLEVELMOWERHOUSING”in
the Service and Adjustments section of this manual.
•Thelefthandsideofmowershouldbeusedfortrimming.
•Drivesothatclippingsaredischargedontotheareathat
has been cut. Have the cut area to the right of the
machine. This will result in a more even distribution of
clippingsand more uniform cutting.
•Whenmowinglargeareas,startbyturningtotherightso
thatclippingswilldischargeawayfromshrubs,fences,
driveways, etc. After one or two rounds, mow in the
opposite direction making left hand turns until finished
(See Fig. 8).
•If grass is extremely tall, it should be mowed twice to
reduce load and possible fire hazard from dried clip-
pings. Make first cut relatively high; the second to the
desiredheight.
•Do not mow grass when it is wet. Wet grass will plug
mowerandleaveundesirableclumps. Allowgrasstodry
beforemowing.
•Alwaysoperateengineatfullthrottlewhenmowing
to assure better mowing performance and proper dis-
chargeofmaterial. Regulategroundspeedbyselecting
a low enough gear to give the mower cutting perfor-
mance as well as the quality of cut desired.
•When operating attachments, select a ground speed
thatwillsuittheterrainandgivebestperformanceofthe
attachmentbeingused.
FIG. 8
TO START ENGINE (See Fig. 5)
Whenstartingtheengineforthefirsttimeoriftheenginehas
run out of fuel, it will take extra cranking time to move fuel
from the tank to the engine.
•Sit on seat in operating position, depress clutch/brake
pedalandsetparkingbrake.
•Place gear shift lever in neutral (N) position.
•Move attachment clutch to “DISENGAGED”position.
•Move throttle control to choke position.
NOTE: Before starting, read the warm and cold starting
proceduresbelow.
•Insert key into ignition and turn key clockwise to
“START”position and release key as soon as engine
starts. Do not run starter continuously for more than
fifteensecondsper minute. Iftheenginedoesnotstart
after several attempts, move throttle control to fast
position,waitafewminutesandtryagain.Ifenginestill
does not start, move the throttle control back to the
choke position and retry.
WARMWEATHERSTARTING(50°Fandabove)
•Whenenginestarts,movethethrottlecontroltothefast
position.
•Theattachments andgrounddrivecannowbeused.If
theengine doesnotaccepttheload,restarttheengine
andallow it to warmup for one minuteusing the choke
asdescribed above.
ADD GASOLINE
•Fill fuel tank. Use fresh, clean, regular unleaded
gasolinewithaminimumof87octane. (Useof leaded
gasoline will increase carbon and lead oxide deposits
and reduce valve life). Do not mix oil with gasoline.
Purchase fuel in quantities that can be used within 30
days to assure fuel freshness.
IMPORTANT: WHEN OPERATING IN TEMPERATURES
BELOW32°F(0°C),USEFRESH,CLEANWINTERGRADE
GASOLINE TO HELP INSURE GOOD COLD WEATHER
STARTING.
WARNING: Experienceindicatesthatalcoholblendedfuels
(called gasohol or using ethanol or methanol) can attract
moisture which leads to separation and formation of acids
during storage. Acidic gas can damage the fuel system of
anenginewhileinstorage. To avoid engine problems, the
fuelsystemshouldbeemptiedbeforestorageof30daysor
longer. Drainthegastank,starttheengineandletitrununtil
thefuellinesandcarburetorareempty. Usefreshfuelnext
season. SeeStorageInstructionsforadditionalinformation.
Neveruseengineorcarburetorcleanerproductsinthefuel
tankorpermanentdamagemayoccur.
CAUTION: Fill to bottom of gas tank
fillerneck. Donotoverfill. Wipeoffany
spilled oil or fuel. Do not store, spill or
use gasoline near an open flame.
COLDWEATHER STARTING(50°F andbelow)
•Whenenginestarts,allowenginetorunwiththethrottle
control in the choke position until the engine runs
roughly,thenmovethrottlecontroltofastposition.This
may require an engine warm-up period from several
secondstoseveralminutes,dependingonthetempera-
ture.
•The attachments can also be used during the engine
warm-upperiod.
NOTE: If at a high altitude (above 3000 feet) or in cold
temperatures(below32 F) thecarburetorfuelmixturemay
needtobeadjustedforbestengine performance. See “TO
ADJUST CARBURETOR”in the Service and Adjustments
section of this manual.

14
CUSTOMERRESPONSIBILITIES
BEFOREEACH USE
T
R
A
C
T
0
R
Adjust Motion Drive Belt(s) Tension
Inspect Muffler/Spark Arrester
Lubrication Chart
Check Brake Operation
Clean Air Filter
Change Engine Oil
Replace Air Filter Paper Cartridge
Replace Spark Plug
Check Battery Level
Check Tire Pressure
Clean Battery and Terminals
FILL IN DATES
AS YOU COMPLETE
REGULAR SERVICE
MAINTENANCE SCHEDULE
EVERY 8 HOURS EVERY 25 HOURS EVERY 50 HOURS EVERY 100 HOURS
EVERY SEASON
SERVICE DATES
Check for Loose Fasteners
BEFORE STORAGE
Check Engine Oil Level
Clean Engine Cooling Fins
Sharpen/Replace Mower Blades
Check Operator Presence and
Interlock Systems
Clean Air Screen
1 - Change more often when operating under a heavy load or in high ambient temperatures.
2 - Service more often when operating in dirty or dusty conditions.
3 - If equipped with oil filter, change oil every 50 hours.
4 - Replace blades more often when mowing in sandy soil.
E
N
G
I
N
E
Replace Oil Filter (If equipped)
Check Transaxle Cooling
Adjust Blade Belt(s) Tension
Replace Fuel Filter
1
4
2
2
2
2
5 - If equipped with adjustable system.
6 - Not required if equipped with maintenance-free battery.
7 - Tighten front axle pivot bolt to 35 ft.-lbs. maximum.
Do not overtighten.
1 ,
12,3 ,
2
5
5
6
7
GENERAL RECOMMENDATIONS
Thewarrantyonthistractordoesnotcoveritemsthathave
beensubjectedtooperatorabuseornegligence. Toreceive
fullvaluefromthewarranty,operatormustmaintaintractor
as instructed in this manual.
Some adjustments will need to be made periodically to
properlymaintainyourtractor.
All adjustments in the Service and Adjustments section of
thismanualshouldbecheckedatleastonceeachseason.
•Onceayearyoushouldreplacethesparkplug,cleanor
replaceairfilter,andcheckbladesandbeltsforwear. A
newsparkplugandcleanairfilterassureproperair-fuel
mixtureandhelpyourenginerunbetterandlastlonger.
BEFORE EACH USE
•Check engine oil level.
•Checkbrakeoperation.
•Checktire pressure.
•Checkoperatorpresenceand
interlocksystemsfor proper operation.
•Check for loose fasteners.
IMPORTANT: DONOTOILORGREASETHEPIVOTPOINTS
WHICH HAVE SPECIAL NYLON BEARINGS. VISCOUS
LUBRICANTSWILLATTRACTDUSTANDDIRTTHATWILL
SHORTEN THE LIFE OF THE SELF-LUBRICATING
BEARINGS. IF YOU FEEL THEY MUST BE LUBRICATED,
USE ONLY A DRY, POWDERED GRAPHITE TYPE
LUBRICANT SPARINGLY.
LUBRICATIONCHART
SAE 30 or 10w30 motor oil
GeneralPurposeGrease
RefertoCustomerResponsibilities“ENGINE”Section
FRONT
WHEEL
BEARING
ZERK
ENGINE
FRONT
WHEEL
BEARING
ZERK
GEARSHIFT
PIVOTS
SPINDLE ZERK SPINDLE ZERK
Â
Á
À
À
Á
Á
Á
Á
Â

15
CUSTOMERRESPONSIBILITIES
BLADE REMOVAL (See Fig. 9)
•Raise mower to highest position to allow access to
blades.
•Removehexbolt,lockwasherandflatwashersecuring
blade.
•Install new or resharpened blade with trailing edge up
towards deck as shown.
IMPORTANT:TOENSUREPROPERASSEMBLY,CENTER
HOLEINBLADEMUSTALIGNWITH STARONMANDREL
ASSEMBLY.
•Reassemble hex bolt, lock washer and flat washer in
exact order as shown.
•Tighten bolt securely (27-35 Ft. Lbs. torque).
IMPORTANT: BLADEBOLTISGRADE8HEATTREATED.
TRAILING
EDGE UP
FLAT WASHER
LOCK WASHER
BLADE
BLADE
CENTER HOLE
5/8" BOLT
OR PIN
FIG. 10
MANDREL
ASSEMBLY
*A GRADE 8 HEAT TREATED BOLT CAN BE
IDENTIFIED BY SIX LINES ON THE BOLT HEAD.
HEX BOLT (GRADE
8)*
FIG. 9
TO SHARPEN BLADE (See Fig. 10)
NOTE: Wedonotrecommendsharpeningblade-butifyou
do, be sure the blade is balanced.
Care should be taken to keep the blade balanced. An
unbalancedbladewillcauseexcessivevibrationandeven-
tualdamagetomowerandengine.
•Thebladecanbe sharpened with a fileoronagrinding
wheel. Donot attempt to sharpen while on the mower.
•To check blade balance, you will need a 5/8" diameter
steelbolt, pin,oraconebalancer. (Whenusingacone
balancer,followtheinstructionssuppliedwithbalancer).
NOTE: Donot use a nailfor balancing blade. The lobesof
the center hole may appear to be centered, but are not.
•Slidebladeontoanunthreadedportionofthesteelbolt
orpinandholdtheboltorpinparallelwiththeground. If
blade is balanced, it should remain in a horizontal
position. If either end of the blade moves downward,
sharpen the heavy end until the blade is balanced.
TRACTOR
Always observe safety rules when performing any mainte-
nance.
BRAKE OPERATION
Iftractorrequiresmorethansix(6)feetstoppingdistanceat
high speed in highest gear, then brake must be adjusted.
(See“TOADJUSTBRAKE”intheServiceandAdjustments
section of this manual).
TIRES
•Maintainproperairpressureinalltires(See“PRODUCT
SPECIFICATIONS”section of this manual).
•Keeptiresfreeof gasoline, oil, or insect control chemi-
calswhich can harm rubber.
•Avoid stumps, stones, deep ruts, sharp objects and
other hazards that may cause tire damage.
NOTE: To seal tire punctures and prevent flat tires due to
slow leaks, tire sealant may be purchased from your local
parts dealer. Tire sealant also prevents tire dry rot and
corrosion.
OPERATOR PRESENCE SYSTEM
Besureoperatorpresenceandinterlocksystemsarework-
ingproperly. Ifyourtractordoesnotfunctionasdescribed,
repairtheproblemimmediately.
•The engine should not start unless the clutch/brake
pedalisfullydepressedandattachementclutchcontrol
is in the disengaged position.
•Whentheengineisrunning,anyattemptbytheoperator
to leave the seat without first setting the parking brake
should shut off the engine.
•Whentheengineisrunningandtheattachmentclutchis
engaged,anyattemptbytheoperatortoleavetheseat
should shut off the engine.
•Theattachmentclutchshouldneveroperateunlessthe
operator is in the seat.
BLADE CARE
Forbestresultsmowerbladesmustbekeptsharp. Replace
bentordamagedblades.
CENTER
HOLE
STAR

16
CUSTOMERRESPONSIBILITIES
ENGINE
LUBRICATION
Only use high quality detergent oil rated with API service
classification SF-SJ. Select the oil’s SAE viscosity grade
accordingtoyourexpectedoperatingtemperature.
TEMPERATURE RANGE ANTICIPATED BEFORE NEXT OIL CHANGE
SAE VISCOSITY GRADES
-20°0°30°40°80°100°
-30°-20°0°20°30°40°
° F
° C
32°
-10°10°
60°
5W-30 SAE 30
FIG. 11
FIG. 12
V-BELTS
CheckV-beltsfordeteriorationandwearafter100hoursof
operation and replace if necessary. The belts are not
adjustable. Replace belts if they begin to slip from wear.
TRANSAXLE COOLING
Keeptransaxlefreefrombuild-upofdirtandchaffwhichcan
restrict cooling.
BATTERY
Your tractor has a battery charging system which is suffi-
cient for normal use. However, periodic charging of the
battery with an automotive charger will extend its life.
•Keepbattery and terminals clean.
•Keep battery bolts tight.
•Keep small vent holes open.
•Rechargeat 6-10amperesfor 1 hour.
NOTE: The original equipment battery on your tractor is
maintenancefree.Donotattempttoopenorremovecapsor
covers. Adding or checking level of electrolyte is not
necessary.
TO CLEAN BATTERY AND TERMINALS
Corrosionanddirtonthebatteryandterminalscancausethe
batteryto “leak”power.
•Openbattery boxdoor.
•DisconnectBLACKbatterycablefirst thenRED battery
cable and remove battery from tractor.
•Rinse the battery with plain water and dry.
•Cleanterminalsandbatterycableendswithwirebrush
untilbright.
•Coatterminals with grease or petroleumjelly.
•Reinstallbattery(See“REPLACINGBATTERY”inthe
Service and Adjustments section of this manual).
TO CHANGE ENGINE OIL (See Figs. 11 and 12)
Determinetemperaturerangeexpected before oil change.
All oil must meet API service classification SF-SJ.
•Be sure tractor is on level surface.
•Oilwilldrain more freely when warm.
•Catch oil in a suitable container.
•Removeoil fill cap/dipstick. Be careful not to allow dirt
toentertheenginewhenchangingoil.
•Removecapfrombottomfittingofdrainvalveandinstall
the drain tube onto the fitting.
•Unlockdrainvalvebypushinginwardandturningcoun-
terclockwise.
•To open, pull out on the drain valve.
•Afteroilhasdrainedcompletely,closeandlockthedrain
valvebypushinginwardandturningclockwiseuntilthe
pin is in the locked position as shown.
•Removethedraintubeandreplacethecaponto to the
bottom fitting of the drain valve.
•Refill engine with oil through oil fill dipstick tube. Pour
slowly. Do not overfill. For approximate capacity see
“PRODUCTSPECIFICATIONS”sectionofthismanual.
•Usegauge onoilfill cap/dipstickforchecking level. Be
sure dipstick cap is tightened securely for accurate
reading. Keep oil at “FULL”line on dipstick.
CLOSED
AND
LOCKED
POSITION
CAP DRAIN
TUBE
OIL DRAIN VALVE
NOTE: Although multi-viscosity oils (5W30, 10W30 etc.)
improve starting in cold weather, these multi-viscosity oils
will result in increased oil consumption when used above
32°F. Checkyour engine oil levelmore frequently to avoid
possibleengine damagefromrunninglowon oil.
Change the oil after every 25 hours of operation or at least
onceayearifthetractorisnotusedfor25hoursinoneyear.
Checkthecrankcaseoillevelbeforestartingtheengineand
after each eight (8) hours of operation. Tighten oil fill cap/
dipstick securely each time you check the oil level.

17
CUSTOMERRESPONSIBILITIES
AIR FILTER (See Fig. 14)
Yourenginewillnotrunproperlyusingadirtyairfilter. Clean
the foam pre-cleaner after every 25 hours of operation or
every season. Service paper cartridge every 100 hours of
operation or every season, whichever occurs first.
Service air cleaner more often under dusty conditions.
•Removeknob(s)andcover.
TOSERVICEPRE-CLEANER
•Slidefoampre-cleaneroffcartridge.
•Washit in liquid detergent and water.
•Squeeze it dry in a clean cloth.
•Saturateitinengineoil. Wrapitinclean,absorbentcloth
and squeeze to remove excess oil.
•Ifverydirtyordamaged,replacepre-cleaner.
•Reinstallpre-cleanerovercartridge.
•Reinstall cover and secure with knob(s).
TOSERVICECARTRIDGE
•Removecartridgenut.
•Carefullyremovecartridgetopreventdebrisfromenter-
ing carburetor. Clean base carefully to prevent debris
fromenteringcarburetor.
•Cleancartridgebytappinggentlyonflatsurface. Ifvery
dirtyordamaged,replacecartridge.
•Reinstall cartridge, nut, precleaner, cover and secure
withknob(s).
IMPORTANT: PETROLEUM SOLVENTS, SUCH AS
KEROSENE, ARE NOT TO BE USED TO CLEAN THE
CARTRIDGE. THEY MAY CAUSE DETERIORATION OF
THE CARTRIDGE. DO NOT OIL CARTRIDGE. DO NOT
USEPRESSURIZEDAIRTOCLEANORDRYCARTRIDGE.
CARTRIDGE
NUT
COVER
KNOB
FOAM
PRE-CLEANER
PAPER
CARTRIDGE
COVER
BASE
FIG. 14
ENGINE COOLING FINS SPARK
PLUG
AIR SCREEN
HEX
BOLTS
HEX
BOLTS BLOWER HOUSING
FIG. 13
OILL FILL/
DIPSTICK
TUBE
CLEAN AIR SCREEN
Air screen must be kept free of dirt and chaff to prevent
enginedamagefromoverheating. Cleanwithawirebrushor
compressedairtoremovedirtandstubborndriedgumfibers.
ENGINE COOLING FINS (See Fig. 13)
Remove any dust, dirt or oil from engine cooling fins to
preventenginedamagefromoverheating.
•Remove oil fill cap/dipstick.
•Removehexboltsfromblowerhousingandlifthousing
offengine.
•Cover oil fill opening to prevent entry of dirt.
•Use compressed air or stiff bristle brush to thoroughly
clean engine cooling fins.
•Toreassemble,reverseaboveprocedure.

18
CUSTOMERRESPONSIBILITIES
MUFFLER
Inspectandreplacecorrodedmufflerand spark arrester (if
equipped)asit could create a firehazard and/or damage.
SPARK PLUGS
Replace spark plugs at the beginning of each mowing
season or after every 100 hours of operation, whichever
occurs first. Spark plug type and gap setting are shown in
“PRODUCTSPECIFICATIONS”sectionof this manual.
IN-LINE FUEL FILTER (See Fig. 15)
Thefuelfiltershouldbereplacedonceeachseason. Iffuel
filter becomes clogged, obstructing fuel flow to carburetor,
replacementisrequired.
•With engine cool, remove filter and plug fuel line sec-
tions.
•Place new fuel filter in position in fuel line with arrow
pointingtowardscarburetor.
•Be sure there are no fuel line leaks and clamps are
properlypositioned.
•Immediately wipe up any spilled gasoline.
CLAMP
FUEL
FILTER
CLAMP
FIG. 15
CLEANING
•Clean engine, battery, seat, finish, etc. of all foreign
matter.
•Keepfinishedsurfacesandwheelsfreeofallgasoline,
oil, etc.
•Protect painted surfaces with automotive type wax.
We do not recommend using a garden hose to clean your
tractor unless the electrical system, muffler, air filter and
carburetorare covered to keep water out. Water in engine
can result in a shortened engine life.

19
SERVICEANDADJUSTMENTS
CAUTION: BEFOREPERFORMINGANYSERVICEORADJUSTMENTS:
•Depressclutch/brake pedalfullyandsetparkingbrake.
•Place gearshift lever in neutral (N) position.
•Place attachment clutch in “DISENGAGED”position.
•Turn ignition key “OFF”and remove key.
•Make sure the blades and all moving parts have completely stopped.
•Disconnectsparkplugwirefromsparkplugandplacewirewhereitcannotcomeincontactwith
plug.
TRACTOR
TO REMOVE MOWER (See Fig. 16)
Mowerwillbeeasiertoremovefromtherightsideoftractor.
•Place attachment clutch in “DISENGAGED”position.
•Moveattachmentliftleverforwardtolowermowertoits
lowestposition.
•Roll belt off engine pulley.
•Remove small retainer spring, and lift clutch spring off
pulley bolt.
•Removelarge retainer spring,slide collar off and push
housing guide out of bracket.
•Disconnect anti-swaybar from chassis bracket by re-
movingretainerspring.
•Disconnect suspension arms from rear deck brackets
byremovingretainersprings.
•Disconnect front links from deck by removing retainer
springs.
•Raise lift lever to raise suspension arms. Slide mower
outfromundertractor.
IMPORTANT: IF AN ATTACHMENT OTHER THAN THE
MOWER DECK IS TO BE MOUNTED ON THE TRAC-
TOR, REMOVE THE FRONT LINKS AND HOOK THE
CLUTCH SPRING INTO SQUARE HOLE IN FRAME.
TO INSTALL MOWER (See Fig. 16)
•Raise attachment lift lever to its highest position.
•Slidemowerundertractorwithdischargeguardtoright
side of tractor.
•Lower lift lever to its lowest position.
•Install mower in reverse order of removal instructions.
SUSPENSION ARMS
RETAINER SPRINGS
(BOTH SIDES)
RETAINER
SPRING
ANTI-SWAY BAR
HOUSING
GUIDE
FRONT LINK
COLLAR
ENGINE PULLEY
LARGE
RETAINER
SPRING
CLUTCH
SPRING
SMALL
RETAINER
SPRING
BRACKET
SQUARE HOLE
Fig. 16

20 FIG. 21
IDLER
PULLEYS
MANDREL
PULLEY
MANDREL
PULLEY
TO REPLACE MOWER BLADE DRIVE BELT
(See Fig. 21)
Themower blade drive belt may be replaced without tools.
Park the tractor on level surface. Engage parking brake.
BELT REMOVAL -
•Remove mower from tractor (See “TO REMOVE
MOWER”in this section of this manual).
•Work belt off both mandrel pulleys and idler pulleys.
•Pull belt away from mower.
BELTINSTALLATION-
•Install new belt in reverse order of removal.
•Makesurebeltisinallpulleygroovesandinsideallbelt
guides.
•Install mower in reverse order of removal instructions.
SERVICEANDADJUSTMENTS
TO LEVEL MOWER HOUSING
Adjustthemower while tractor isparkedonlevelgroundor
driveway. Makesuretiresareproperlyinflated(See“PROD-
UCTSPECIFICATIONS”sectionofthismanual). Iftiresare
over or underinflated, you will not properly adjust your
mower.
SIDE-TO-SIDEADJUSTMENT(See Figs. 17 and18)
•Raise mower to its highest position.
•Atthemidpointofbothsidesofmower,measureheight
frombottomedgeofmowertoground. Distance“A”on
both sides of mower should be the same or within 1/4"
of each other.
•If adjustment is necessary, make adjustment on one
side of mower only.
•To raise one side of mower, tighten lift link adjustment
nut on that side.
•Tolower one side of mower,loosen lift link adjustment
nut on that side.
NOTE: Threefullturnsofadjustmentnutwillchangemower
heightabout1/8".
•Recheckmeasurementsafteradjusting.
NUT "E"
"D"
"D"
MANDREL
FIG. 19
NUT "F"
FRONT LINKS
FIG. 20
FRONT-TO-BACKADJUSTMENT(SeeFigs.19and20)
IMPORTANT: DECK MUST BE LEVEL SIDE-TO-SIDE. IF
THE FOLLOWING FRONT-TO-BACK ADJUSTMENT IS
NECESSARY,BESURETOADJUSTBOTHFRONTLINKS
EQUALLY SO MOWER WILL STAY LEVEL SIDE-TO-
SIDE.
Toobtainthebestcuttingresults,themowerhousingshould
be adjusted so that the front is approximately 1/8" to 1/2"
lowerthantherearwhenthemowerisinitshighestposition.
Checkadjustmentonrightsideoftractor. Measuredistance
“D”directlyin front and behindthe mandrel at bottomedge
ofmowerhousingas shown.
•Beforemakinganynecessaryadjustments,checkthat
bothfrontlinksareequalinlength. Bothlinksshouldbe
approximately10-3/8".
•If links are not equal in length, adjust one link to same
length as other link.
•Tolowerfrontofmowerloosennut“E”onbothfrontlinks
anequalnumberofturns.
BOTH FRONT LINKS MUST BE EQUAL IN LENGTH
FIG. 17
SUSPENSION ARM
LIFT LINK
ADJUSTMENT
NUT
FIG. 18
“A”“A”
BOTTOM EDGE
OF MOWER
TO GROUND
BOTTOM EDGE
OF MOWER
TO GROUND
GROUND LINE
TRUNNION
•Whendistance“D”is1/8"to1/2"loweratfrontthanrear,
tighten nuts “F”against trunnion on both front links.
•Toraisefrontofmower,loosennut“F”fromtrunnionon
both front links. Tighten nut “E”on both front links an
equalnumber ofturns.
•Whendistance“D”is1/8"to1/2"loweratfrontthanrear,
tighten nut “F”against trunnion on both front links.
•Recheckside-to-sideadjustment.
