Poulan Pro PP446ET User manual

R
PARAMOUNT PARTS LIST
R
PARTS LIST
r
Replaces
1
Note: Illustration may differ from actual model due to design changes
PARTS L IST NO.
PAGE NO.
MODEL(s)
545014364 PP446ET
DATE
2/10/09 545014364 --- 6/06/08
All repairs, adjustments and
maintenance not described in
the Operator’s Manual must be
performed by qualified service
personnel.
WARNING
=NEW PART NUMBER FOR THIS IPLn=REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED AT END OF IPL)
K
Ref. Part No. Description Ref. Part No. Description Ref. Part No. Description
545186747 Manual
545003066 Decal--Warning
530150031 Att. -- Hanger
545167703 Decal--Upper Shaft
530031159 Wrench--Hex(5/32)
11 530058759 Trigger--Throttle
12. 530056570 Flex--Lower
13. 530057987 Clamp--Lower
14. 530015940 Screw
15. 530015820 Bolt
16. 530057986 Clamp--Upper
17. 530071936 Kit--Upper Shaft
18. 530016344 Screw
19. 545008090 Assy--Driveshaft
20. 530094408 Assy--Shoulder
Strap
1. 530015886 Screw
2. 530057983 Hsg.--Throttle right
3. 530016326 Screw--Cable Ret.
4. 530057984 Hsg.--Throttle left
5. 530058843 Assy--Wire
6. 530069572 Kit--Switch
7. 530059101 Assy--Handle
(Incl. 8,9,15)
8. 530059185 Clamp--Handle
9. 530016152 Wingnut
10. 530015805 Screw--Align
Not Shown
DANGER
STAND
CLEAR
50 FT
11
245
6
10
1
12
17
18
19
20
79
8
15
14
13
16
3
See Page 2
TYPE 1,2
n
n
n

R
PARAMOUNT PARTS LIST
R
PARTS LIST
r
Replaces
2
Note: Illustration may differ from actual model due to design changes
PARTS L IST NO.
PAGE NO.
MODEL(s)
545014364 PP446ET
DATE
2/10/09 545014364 --- 6/06/08
All repairs, adjustments and
maintenance not described in
the Operator’s Manual must be
performed by qualified service
personnel.
WARNING
=NEW PART NUMBER FOR THIS IPLn=REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED AT END OF IPL)
K
Ref. Part No. Description Ref. Part No. Description Ref. Part No. Description
545177333 Manual
545003066 Decal--Warning
530150031 Att. -- Hanger
545167703 Decal--Upper Shaft
530031159 Wrench--Hex(5/32)
11 530058759 Trigger--Throttle
12. 530056570 Flex--Lower
13. 530057987 Clamp--Lower
14. 530015940 Screw
15. 530015820 Bolt
16. 530057986 Clamp--Upper
17. 530071936 Kit--Upper Shaft
18. 530016344 Screw
19. 545008090 Assy--Driveshaft
20. 530094408 Assy--Shoulder
Strap
2. 530015886 Screw
2. 530057983 Hsg.--Throttle right
3. 530016326 Screw--Cable Ret.
4. 530057984 Hsg.--Throttle left
5. 530058843 Assy--Wire
6. 530071356 Kit--Switch
7. 530059101 Assy--Handle
(Incl. 8,9,15)
8. 530059185 Clamp--Handle
9. 530016152 Wingnut
10. 530015805 Screw--Align
Not Shown
DANGER
STAND
CLEAR
50 FT
11
245
6
10
1
12
17
18
19
20
79 8
15
14
13
16
3
See Page 2
TYPE 3
n
n
n
n
n

R
PARAMOUNT PARTS LIST
R
PARTS LIST
r
Replaces
3
Note: Illustration may differ from actual model due to design changes
PARTS L IST NO.
PAGE NO.
MODEL(s)
545014364 PP446ET
DATE
2/10/09 545014364 --- 6/06/08
All repairs, adjustments and
maintenance not described in
the Operator’s Manual must
be performed by qualified
service personnel.
WARNING
=NEW PART NUMBER FOR THIS IPLn=REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED AT END OF IPL)
K
Ref. Part No. Description Ref. Part No. Description Ref. Part No. Description
27. 530056524 Fitting--Oil Line
28. 530021160 Intake--Oil Line
29. 530037821 Filter--Oil
30. 530053072 Cap--Oil
31. 530030189 Plug--Oil Filter
32. 530015843 Screw
33. 530031163 Wrench--Bar
14 530016133 Bolt--Bar
15. 530056513 Hsg.--Upper
(incl. #14)
16. 530016284 Nut
17. 530071646 Kit--Gear Assy
18. 530056514 Hsg.--Lower
19. 530016312 Screw
20. 530015805 Screw--Align
21. 530015886 Screw
22. 530071645 Kit--Oil Assy
(incl. 23,24,25)
23. 530053764 Assy--Gear Plunger
24. 530053765 Barrel
25. 530056522 Block--Oil
26. 530056528 Assy--Oil Tank
(incl. 27,28,29,30,31)
1. 545008090 Assy--Driveshaft
2. 530071647 Kit--Sprocket Assy.
(incl. 3,4,5)
3. 530056521 Washer
4. 530056520 Sprocket
5. 530056563 Retainer--Sprocket
6. 530057100 Assy--Bar Clamp
(incl. #8)
7. 530015917 Nut--Bar Mounting
8. 530069611 Kit--Bar Adjust
(incl. 9,10)
9. 530015826 Pin--Bar Adjust
10. 530038593 Retainer--Bar Adjust
11. 952051549 Accy.--Chain--8”
12 530044908 Bar--8”
13. 530056523 Plate--Bar pad
2
34 56
7
8
910
11
12
13
151617
18
19
20
21
22
25
23
24
26
27 28 29 30
32 33
31
14
1
TYPE 1,2,3
n

R
PARAMOUNT PARTS LIST
R
PARTS LIST
r
Replaces
4
Note: Illustration may differ from actual model due to design changes
PARTS L IST NO.
PAGE NO.
MODEL(s)
545014364 PP446ET
DATE
2/10/09 545014364 --- 6/06/08
11
7
8
9
10
All repairs, adjustments and
maintenance not described in
the Operator’s Manual must
be performed by qualified
service personnel.
WARNING
=NEW PART NUMBER FOR THIS IPLn=REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED AT END OF IPL)
K
Ref. Part No. Description
1. 530071788 Kit--Lower Shaft Assy.
(Incl. flex shaft)
2. 530071802 Kit--Shield Assy.
(Incl. 3,4,5,6)
3. 530052286 Limiter--Line
4. 530015814 Screw
5. 530015820 Bolt
6. 530016152 Wingnut
7. 530095776 Assy--Hub/Arbor
8. 530053241 Spring--Return
9. 530401957 Retainer--Spool
10. 952711624 Accy--Wound Spool
11. 952711630 Accy--Cutting Head
(Incl. 7--10)
545209101 Decal--Lower Shaft Warning
3
2
1
5
6
4
Not Shown
TYPE 1,2,3
n

R
PARAMOUNT PARTS LIST
R
PARTS LIST
r
Replaces
5
Note: Illustration may differ from actual model due to design changes
PARTS L IST NO.
PAGE NO.
MODEL(s)
545014364 PP446ET
DATE
2/10/09 545014364 --- 6/06/08
Engine
Gasket
Kit
1
1. 530047721 Bulb--Purge
2. 530071717 Kit--Choke Lever
3. 530015843 Screw--tank
4. 530049386 Cap--Fuel w/ret.
5. 530095646 Assy--Fuel pickup
6. 530071404 Kit--Fuel line
7. 530069216 Kit--Fuel/Purge line
8. 530015775 Screw
9. 545000501 Cover--Air box
10. 545082301 Filter--Air
11. 530015849 Screw--Carb.
12. 545000601 Box--Air
13. 545006017 Kit--Carb assy. (C1U--W32)
14. 545030102 Seal--Carb.(kit)
15. 545075304 Assy--Fuel Tank
16. 530015771 Screw--Crankcase
17. 530015952 Screw--Shroud
18. 545000701 Assy--Rear Shroud
19. 545030102 O--ring--Shroud (kit)
20. 530027593 Valve--Reed
21. 530029781 Stop--Reed
22. 530016064 Screw--Reed stop
23. 530015875 Screw--Retainer
24 530055492 Isolator--Tank
25. 530054941 Ret.--Tank
26. 530054834 Handle--Starter
27. 545050410 Kit--Rope
28. 545081601 Bearing--Inner
29. 530015787 Retainer
30. 530019158 Seal
31. 530032102 Bearing--Outer
32. 530015789 Ret.--Crankshaft
33. 530028807 Assy--Crankshaft
34. 545081901 Assy--Crankcase
( Incl. 28,29,30,31)
35. 545006037 Assy--C’case/C’shaft
( Incl. 32,33,34)
36. 530055524 Assy--Flywheel
37. 530016030 Washer
38. 530055620 Spacer
39. 530015775 Screw--Baffle
40. 530054939 Plate--Baffle
41. 545050408 Kit--Pulley
42. 545054901 Spring--Starter
43. 530019182 Grommet
44. 530015810 Screw--F/hsg.
45. 530055248 Assy--Fan Housing
46. 530094189 Washer--Clutch
Ref. Part No. Description Ref. Part No. Description
47. 530055122 Assy--Clutch
48. 530150247 Assy--Drum/Adapter
49. 530010960 Assy--Conn. Rod
50. 530015162 Ret.--Piston pin
51. 530012595 Ring--Piston
52. 530072000 Kit--Piston
(Incl. 50,51)
53. 545030102 Gasket--Cylinder(kit)
54. 530058846 Assy--Leadwire
55. 530016387 Bolt--Muffler 1/4”--20
56. 530015241 Screw
57. 545030502 Kit--Spark Arrestor
58. 545030102 Gasket--Muffler (kit)
59. 545033201 Shield
60. 545006016 Kit--Muffler
(Incl. 55,56,57,58,59)
61. 530012589 Cylinder
62. 952030249 Plug--Spark(RCJ--6Y)
63. 530001624 Bolt--Cyl. 1/4”--20
64. 530039234 Module--Ignition
65. 530016357 Screw--Module
66. 545030102 Kit--Gasket/Seal
( Incl. 14,19, 53,58)
67. 530058962 Assy--Throttle cable
Ref. Part No. Description
3
4
56 78
910
11 12 13 14 15 16
17 18
19 20 21 22
23 24
25
26
27
28 29 30 31 32
33
34
35 36 37 38 39 40 41 42
43
44
49
50 51
52
53
54
59
61 62 63 64
65 66
45 46 47
All repairs, adjustments and
maintenance not described in
the Operator’s Manual must be
performed by qualified service
personnel.
WARNING
2
(Note: Repair kits are not available
for this carburetor)
=NEW PART NUMBER FOR THIS IPLn=REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED AT END OF IPL)K
48
67
60
55
56 57
58
TYPE 1

R
PARAMOUNT PARTS LIST
R
PARTS LIST
r
Replaces
6
Note: Illustration may differ from actual model due to design changes
PARTS L IST NO.
PAGE NO.
MODEL(s)
545014364 PP446ET
DATE
2/10/09 545014364 --- 6/06/08
Engine
Gasket
Kit
1
2. 530047721 Bulb--Purge
2. 530071717 Kit--Choke Lever
3. 530015843 Screw--tank
4. 530049386 Cap--Fuel w/ret.
5. 530095646 Assy--Fuel pickup
6. 530071404 Kit--Fuel line
7. 530069216 Kit--Fuel/Purge line
8. 530015775 Screw
9. 545000501 Cover--Air box
10. 545082301 Filter--Air
11. 530015849 Screw--Carb.
12. 545000601 Box--Air
13. 545006017 Kit--Carb assy. (C1U--W32)
14. 545030102 Seal--Carb.(kit)
15. 545075304 Assy--Fuel Tank
16. 530015771 Screw--Crankcase
17. 530015952 Screw--Shroud
18. 545000701 Assy--Rear Shroud
19. 545030102 O--ring--Shroud (kit)
20. 530027593 Valve--Reed
21. 530029781 Stop--Reed
22. 530016064 Screw--Reed stop
23. 530015875 Screw--Retainer
24 530055492 Isolator--Tank
25. 530054941 Ret.--Tank
26. 530054834 Handle--Starter
27. 545050409 Kit--Rope
28. 545081601 Bearing--Inner
29. 530015787 Retainer
30. 530019158 Seal
31. 530032102 Bearing--Outer
32. 530015789 Ret.--Crankshaft
33. 530028807 Assy--Crankshaft
34. 545081901 Assy--Crankcase
( Incl. 28,29,30,31)
35. 545006037 Assy--C’case/C’shaft
( Incl. 32,33,34)
36. 530055524 Assy--Flywheel
37. 530016030 Washer
38. 530055620 Spacer
39. 530015775 Screw--Baffle
40. 545115201 Plate--Baffle
41. 545050408 Kit--Pulley
42. 545054901 Spring--Starter
43. 530019182 Grommet
44. 530016386 Screw--F/hsg.
45. 530055248 Assy--Fan Housing
46. 530094189 Washer--Clutch
Ref. Part No. Description Ref. Part No. Description
47. 530055122 Assy--Clutch
48. 530150247 Assy--Drum/Adapter
49. 530010960 Assy--Conn. Rod
50. 530015162 Ret.--Piston pin
51. 530012595 Ring--Piston
52. 530072000 Kit--Piston
(Incl. 50,51)
53. 545030102 Gasket--Cylinder(kit)
54. 530058846 Assy--Leadwire
55. 530016387 Bolt--Muffler 1/4”--20
56. 545030102 Gasket--Muffler (kit)
57. 545033201 Shield
58. 545081871 Kit--Muffler
(Incl. 55,56,57)
59. 530012589 Cylinder
60. 952030249 Plug--Spark(RCJ--6Y)
61. 530001624 Bolt--Cyl. 1/4”--20
62. 530039234 Module--Ignition
63. 530016357 Screw--Module
64. 545030102 Kit--Gasket/Seal
( Incl. 14,19, 53,56)
65. 545026801 Assy--Throttle cable
Ref. Part No. Description
3
4
56 78
910
11 12 13 14 15 16
17 18
19 20 21 22
23 24
25
26
27
28 29 30 31 32
33
34
35 36 37 38 39 40 41 42
43
44
49
50 51
52
53
54
57
59 60 61 62
63 64
45 46 47
All repairs, adjustments and
maintenance not described in
the Operator’s Manual must be
performed by qualified service
personnel.
WARNING
2
(Note: Repair kits are not available
for this carburetor)
=NEW PART NUMBER FOR THIS IPLn=REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED AT END OF IPL)K
48
65
58
55
56
TYPE 2

R
PARAMOUNT PARTS LIST
R
PARTS LIST
r
Replaces
7
Note: Illustration may differ from actual model due to design changes
PARTS L IST NO.
PAGE NO.
MODEL(s)
545014364 PP446ET
DATE
2/10/09 545014364 --- 6/06/08
Engine
Gasket
Kit
1
3. 530047721 Bulb--Purge
2. 530071717 Kit--Choke Lever
3. 530015843 Screw--tank
4. 530049386 Cap--Fuel w/ret.
5. 530095646 Assy--Fuel pickup
6. 530071404 Kit--Fuel line
7. 530069216 Kit--Fuel/Purge line
8. 530015775 Screw
9. 545000501 Cover--Air box
10. 545082301 Filter--Air
11. 530015849 Screw--Carb.
12. 545000601 Box--Air
13. 545006017 Kit--Carb assy. (C1U--W32)
14. 545030102 Seal--Carb.(kit)
15. 545075304 Assy--Fuel Tank
16. 530015771 Screw--Crankcase
17. 530015952 Screw--Shroud
18. 545000701 Assy--Rear Shroud
19. 545030102 O--ring--Shroud (kit)
20. 530027593 Valve--Reed
21. 530029781 Stop--Reed
22. 530016064 Screw--Reed stop
23. 530015875 Screw--Retainer
24 530055492 Isolator--Tank
25. 530054941 Ret.--Tank
26. 530054834 Handle--Starter
27. 545050409 Kit--Rope
28. 545081601 Bearing--Inner
29. 530015787 Retainer
30. 530019158 Seal
31. 530032102 Bearing--Outer
32. 530015789 Ret.--Crankshaft
33. 530028807 Assy--Crankshaft
34. 545081901 Assy--Crankcase
( Incl. 28,29,30,31)
35. 545006037 Assy--C’case/C’shaft
( Incl. 32,33,34)
36. 530055524 Assy--Flywheel
37. 530016463 Washer
38. 530055620 Spacer
39. 530015775 Screw--Baffle
40. 545115201 Plate--Baffle
41. 545050408 Kit--Pulley
42. 545054901 Spring--Starter
43. 530019182 Grommet
44. 530016386 Screw--F/hsg.
45. 530055248 Assy--Fan Housing
46. 530094189 Washer--Clutch
Ref. Part No. Description Ref. Part No. Description
47. 530055122 Assy--Clutch
48. 530150247 Assy--Drum/Adapter
49. 530010960 Assy--Conn. Rod
50. 530015162 Ret.--Piston pin
51. 530012595 Ring--Piston
52. 530072000 Kit--Piston
(Incl. 50,51)
53. 545030102 Gasket--Cylinder(kit)
54. 530058846 Assy--Leadwire
55. 530016387 Bolt--Muffler 1/4”--20
56. 545030102 Gasket--Muffler (kit)
57. 545033201 Shield
58. 545081871 Kit--Muffler
(Incl. 55,56,57)
59. 530012589 Cylinder
60. 952030249 Plug--Spark(RCJ--6Y)
61. 530001624 Bolt--Cyl. 1/4”--20
62. 530039229 Module--Ignition
63. 530016357 Screw--Module
64. 545030102 Kit--Gasket/Seal
( Incl. 14,19, 53,56)
65. 545026801 Assy--Throttle cable
Ref. Part No. Description
3
4
56 78
910
11 12 13 14 15 16
17 18
19 20 21 22
23 24
25
26
27
28 29 30 31 32
33
34
35 36 37 38 39 40 41 42
43
44
49
50 51
52
53
54
57
59 60 61 62
63 64
45 46 47
All repairs, adjustments and
maintenance not described in
the Operator’s Manual must be
performed by qualified service
personnel.
WARNING
2
(Note: Repair kits are not available
for this carburetor)
=NEW PART NUMBER FOR THIS IPLn=REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED AT END OF IPL)K
48
65
58
55
56
TYPE 3
n
n
