Poundex F6901 User manual

ASSEMBLY INSTRUCTION
ITEM NO: F6901; F6903; F6904
Unpack the box and place the contents on a flat, level surface. Verify that you have all the
parts and hardware, including the necessary bolts and washers. READ ALL INSTRUCTIONS
AND WARNINGS BEFORE USING THIS PRODUCT. IF THERE IS ANY QUESTION
ABOUT A CONDITION BEING SAFE OR UNSAFE, DO NOT USE THIS PRODUCT!
Parts List
ALAF SEAT BASE
1PC
RAF SEAT BASE
1PC
B
C
D
E
C1 LAF BACK 1PC
C2 RAF BACK 1PC
WOODEN LEG
ADJUSTABLE
METAL LEG
2 PCS
F
G
H
I
J
5/16" x 25 mm
4PCS
5/16" x 75 mm
2PCS
5/16" x Ø22 mm
8PCS
K1PC
5/16" x Ø22 mm
4PCS
4PCS
5/16" x 12 mm
2PCS
Step 1: Align female brackets at the back rest (C) to the male brackets at the
seat base (A), (B). Insert the back rest (C) to the seat base and push it to the
end. Make sure the brackets is scured in position.
C1
C2
A
B
POUNDEX R
L
PILLOWS
2 PCS

Step 2: Secure the two individual seat fame (A&B) together. Using bolt (G.J) nut
(H) and allen wrench (K)
Step 3: Attach the adjustable metal leg (E) and place it on the underside of
the seat base (A+B). Align the holes in the metal legs (E) with the holes in
the seat base (A+B). Using the bolts (F.J) and allen wrench (K) scure the
metal leg (E) to the seat base and tighten all of them firmly
Step 4: Insert wooden leg (D) and washer (I) onto the bottom of LAF& RAF
seat base (A+B). Using the adjustable metal leg (E) to level the whole seat
base
Step 5: Completed
G
KJ
H
J
F
J
K
I
E
A
B
DE
L
L
