Power One PVI-RADIOMODULE Reference manual

PVI-RADIOMODULE
Remote Controller
Quick Installation Guide and Short
Introduction Manual
Note: This document contains proprietary information of Power-One, Inc. The
contents of this document or any part thereof should not be reproduced or
disclosed to any third party without Power-One's express written consent.
Model number: PVI-RADIOMODULE Rev. 1.1

Quick installation guide and short introduction manual
(PVI-RADIOMODULEtop Rev:1.1)
REVISION TABLE
Document
Revision Date Change Description
1.0 01/10/2009 First emission
1.1 02/02/2010 Complete review
SAVE THESE INSTRUCTIONS!

Quick installation guide and short introduction manual
(PVI-RADIOMODULEtop Rev:1.1)
IMPORTANT SAFETY INSTRUCTIONS
This manual contains important safety instructions that must be followed during the
installation and start-up of the equipment. To reduce the risk of electrical shock
hazards and to ensure the equipment is safely installed prior to operation, special
safety symbols are used in this manual to highlight potential safety hazards and
provide important safety information. The symbols are:
WARNING: The paragraphs highlighted by this symbol contain processes
and instructions that must be followed to avoid potential injury to personnel
and equipment damage.
NOTE: The paragraphs highlighted by this symbol contain processes and
instructions that must be followed to avoid potential equipment damage or
negative results.
FCC NOTICE
The device complies with part 15 of the FCC rules. Operation is subjected to the
following 2 conditions: (1) this device may not cause harmful interference and (2) this
device must accept any interference received, including interference that may cause
undesired operation
FCC ID: X6W-MOD

Quick installation guide and short introduction manual
(PVI-RADIOMODULEtop Rev:1.1)
INDICE
1INTRODUCTION.........................................................................5
1.1
WHAT
YOU’LL
FIND
IN
THE
PVI-DESKTOP
PACKAGE ...................6
1.2
WHAT
YOU’LL
FIND
IN
THE
PVI-RADIOMODULE
PACKAGE........6
2PRELIMINARY OPERATIONS.................................................7
2.1
BATTERY
CHARGING............................................................................7
2.2
INSTALLING
PVI-RADIOMODULE.......................................................7
2.3
RADIO
AFFILIATION............................................................................11
2.4
HOW
TO
RECONFIGURE
SYSTEM......................................................13
2.5
SHUTTING
ON
OR
OFF .........................................................................13
3FUNCTIONS AND MENU.........................................................14
3.1
STATISTICS
MENU................................................................................14
3.1.1
Total ......................................................................................................14
3.1.2
Partial....................................................................................................15
3.1.3
Today.....................................................................................................15
3.1.4
7 days.....................................................................................................15
3.1.5
30 days...................................................................................................16
3.1.6
365 days.................................................................................................16
3.1.7
User.......................................................................................................16
3.2
SETTINGS
MENU...................................................................................17
3.2.1
Date and Time.......................................................................................17
3.2.2
Money....................................................................................................17
3.2.3
Display ..................................................................................................17
3.2.4
Language...............................................................................................17
3.2.5
Configuration wizard.............................................................................17
3.2.6
Firmware update...................................................................................17
3.3
INFO
MENU ............................................................................................18
3.3.1
ID PVI-DESKTOP.................................................................................18
3.3.2
Firmware...............................................................................................18
4UPGRADE ...................................................................................19
4.1
UPGRADE
USING
SD
CARD.................................................................19

Quick installation guide and short introduction manual
(PVI-RADIOMODULEtop Rev:1.1)
1INTRODUCTION
NOTE: All the images, screenshots, figures and graphics reported in this
guide are based on prototypes. The final equipment could have some little
esthetical and functional differences.
This document is a short description and a quick guide for installation and operation
modes of PVI-DESKTOP, which is a remote controller for photovoltaic systems.
Following instructions will guide the end user to a correct set-up and a proper use of
the monitoring and controlling system.
The system is made of two different parts:
•PVI-DESKTOP – which is the effective controller
•PVI-RADIOMODULE – which is the optional radio board to install in the
inverter. This part is an option because you can communicate with inverter
via RS485. In that case you don’t need any radio link.
Figure 1 - PVI-DESKTOP

Quick installation guide and short introduction manual
(PVI-RADIOMODULEtop Rev:1.1)
Figure 2 - PVI-RADIOMODULE
1.1 WHAT YOU’LL FIND IN THE PVI-DESKTOP PACKAGE
In the PVI-DESKTOP package you’ll find the following parts:
1. PVI-DESKTOP (n°1), complete with SD card
2. Base (n°1)
3. Wall mounting kit (n°1)
4. Stylus pen (n°1)
5. AC/DC adapter (n°1)
6. USB Cable (n°1)
7. Manuals and instructions
Check you have all parts before starting the set-up procedure.
1.2 WHAT YOU’LL FIND IN THE PVI-RADIOMODULE PACKAGE
In the PVI-DESKTOP package you’ll find the following parts:
1. PVI-RADIOMODULE board (n°1)
2. Mounting screw (n°1)
3. Antenna (n°1)
4. Cable and plug to be mounted on the inverter (n°1)
5. Manuals and instructions
Check you have all parts before starting the set-up procedure.

Quick installation guide and short introduction manual
(PVI-RADIOMODULEtop Rev:1.1)
2PRELIMINARY OPERATIONS
If you want to correctly set-up the communication system you need to perform some
preliminary operations.
2.1 BATTERY CHARGING
First of all the PVI-DESKTOP has an internal rechargeable lithium battery and it is
necessary to recharge it completely. Connect the PVI-DESKTOP to the AC/DC
adapter or to a computer USB port and wait for the led indicator (see Figure 3) to
become green. Charging using AC/DC adapter will be faster.
Figure 3 - Led indicator position
2.2 INSTALLING PVI-RADIOMODULE
If you want to use radio communication you need to install the PVI-RADIOMODULE
into the inverter. This operation MUST be performed only by trained and authorized
personnel, because of safety reasons.
LED
indicator

Quick installation guide and short introduction manual
(PVI-RADIOMODULEtop Rev:1.1)
WARNING: Installation of PVI-RADIOMODULE must be performed only
by trained and authorized personnel. Don’t try to access, install or remove the
board into the inverter for safety reasons. Every unauthorized action will
cause losing of warranty and may cause serious damage or injury.
WARNING: Follow exactly the procedure in order to avoid risks of
electrical shocks.
Following procedure will help you to set the PVI-RADIOMODULE. Follow the
Aurora inverter manual to perform some of this operation (indicated by a *** symbol):
1. Disconnect the AC from Aurora Inverter, by proper switch, and wait 1
minute. (***)
2. Disconnect the DC from Aurora Inverter, by using the integrated switch or by
disconnecting the input cables. Wait at least 5 minutes in order to discharge
internal capacitance. (***)
3. Open the front side of Aurora Inverter. (***)
4. Remove one of the small plug in the bottom of the inverter (red circled in
Figure 4). (***)
Figure 4 - Bottom of the inverter
5. Pass the connection cable from the hole in the bottom of the inverter. Pass the
cable inside the locknut and screw the plug to the Inverter chassis.. (Figure 5
and Figure 6)

Quick installation guide and short introduction manual
(PVI-RADIOMODULEtop Rev:1.1)
Figure 5 - Antenna plug mounted, external view
Figure 6 - Antenna plug mounted, internal view
6. Screw the cable to the connector placed on a side of the board. (Figure 7)
Figure 7 - SMA connector
Screw
cable here

Quick installation guide and short introduction manual
(PVI-RADIOMODULEtop Rev:1.1)
7. Insert the PVI-RADIOMODULE into the connectors indicated in Figure 8.
Check connection to be sure you did the right operation.
Figure 8 - PVI-RADIOMODULE mating connectors
8. Fix the board by means of mounting screw. Mounting board incorrectly will
not allow you to screw it.
9. Mount the external antenna screwing it to the external connector in the plug
(Figure 5).
WARNING: Antenna must be installed by authorized and trained personnel
only. Don't try to remove or change antenna. Every improper use will cause
the lose of warranty.
WARNING: Really take care in the next operations in order to avoid
electrical shocks. Use all personal protection against direct or indirect
contact.
10. Reconnect the DC to Aurora Inverter, by using the integrated switch or by
reconnecting the input cables. Wait until the display unit will be on. (***)
11. Look at the orange led on the PVI-RADIOMODULE,press the button on the
PVI-RADIOMODULE for more than 3 seconds if you don't see it blinking.
Now you'll see the orange led correctly blinking. Use protective gloves in
order to avoid electrical shock.
Mating
Connectors

Quick installation guide and short introduction manual
(PVI-RADIOMODULEtop Rev:1.1)
12. Close the front side of Aurora Inverter. (***)
13. Reconnect the AC to Aurora Inverter, by proper switch. (***)
Now the radio module is ready to be configured and affiliate to your PVI-DESKTOP.
To complete the affiliation see the procedure in the next pages.
2.3 RADIO AFFILIATION
Switch on the PVI-DESKTOP, read the screen and select the proper option. Once you
switched on your PVI-DESKTOP you’ll see the following screen
Click on “Next”.
Using the buttons set date and hour, then click on “Next”
Aurora Desk – Configuration Wizard
Next
Previous
Please select your channel of
communication
Radio
Rs485

Quick installation guide and short introduction manual
(PVI-RADIOMODULEtop Rev:1.1)
Select the communication channel you’ll use, then click on “Next”.
Set the number of the inverter you want to connect to PVI-DESKTOP, then click on
“Next”.
Select “Scan now”, click on “Next”.
PVI-DESKTOP will scan the radio channels to find the inverters. Remember that PVI-
DESKTOP will find them only if they are switched on. If, for some reasons, the
inverters are switched off, repeat the configuration wizard switching on the inverters.
The table will report all the inverters found on the radio link. Select your inverter
clicking on “+” or deselect it clicking on “-“. Once you’re sure you selected all your
inverters click on “Next”.
At this point you configured your communication channel and the PVI-DESKTOP
will automatically synchronize all inverters data and will start to collect and record
information.

Quick installation guide and short introduction manual
(PVI-RADIOMODULEtop Rev:1.1)
2.4 HOW TO RECONFIGURE SYSTEM
Sometimes it is necessary to configure again your system, like when you decide to add
to or remove from your plant an inverter. There’s a very user friendly menu that helps
you doing that. You simply have to go on menu “SETTINGS” and choose
“Configuration”. The configuration wizard will start again and you could decide which
inverter remove or add to your communication system.
2.5 SHUTTING ON OR OFF
PVI-DESKTOP has a marked button on the top. Pressing this button you’ll turn on the
equipment. Pressing the button for more than 5 seconds you’ll see a message on the
screen requesting you the confirm for shutting off.
PVI-RADIOMODULE receives power supply from the inverter. It is simply on when
the inverter display is on and off when the inverter display is off.

Quick installation guide and short introduction manual
(PVI-RADIOMODULEtop Rev:1.1)
3FUNCTIONS AND MENU
Here’s reported a short description of PVI-DESKTOP’s menu. The menu will depend
on the firmware version because of continuous adding of new features and functions,
anyway it’s very easy and user friendly.
3.1 STATISTICS MENU
Selecting this menu you have the possibility to evaluate and visualize historical data
about your photovoltaic inverter. The menu is divided into different submenus.
3.1.1 Total
This section gives the total energy production of the plant.

Quick installation guide and short introduction manual
(PVI-RADIOMODULEtop Rev:1.1)
3.1.2 Partial
This section gives the energy production of the plant since the last resetting. It is
possible to reset statistics clicking on the proper button
3.1.3 Today
This section gives the energy production of the last day.
3.1.4 7 days
This section gives the energy production of the last 7 days.

Quick installation guide and short introduction manual
(PVI-RADIOMODULEtop Rev:1.1)
3.1.5 30 days
This section gives the energy production of the last month.
3.1.6 365 days
This section gives the energy production of the last year.
3.1.7 User
This section gives the energy production of a selectable period.
+
-
00 +
-
Jan +
-
2009
+
-
00 +
-
Jan +
-
2009
Start
Stop

Quick installation guide and short introduction manual
(PVI-RADIOMODULEtop Rev:1.1)
3.2 SETTINGS MENU
Selecting this menu you have the possibility to change the behaviour of your system
and to calibrate it. The menu is divided into different submenus.
3.2.1 Date and Time
In this section you can change date and time visualized on the screen.
3.2.2 Money
Entering this section you can set the right currency in order to perform calculation on
money saving. You have the possibility to create new currencies.
3.2.3 Display
Entering this section you can set and calibrate screen backlight or touch screen. We
suggest to periodically recalibrate touch screen in order to avoid mismatch.
3.2.4 Language
In this section you can choose and set the language
3.2.5 Configuration wizard
Choose this section if you want to reconfigure the radio communication system.
Following the information on the screen you can add, remove or change the affiliation
of the inverters to your PVI-DESKTOP.
3.2.6 Firmware update
Choose this option if you want to update the firmware version. We suggest to
periodically check power-one web site (www.power-one.com) for new firmware
releases.

Quick installation guide and short introduction manual
(PVI-RADIOMODULEtop Rev:1.1)
3.3 INFO MENU
Selecting this menu you have the possibility to get info about your equipment. The
menu is divided into different submenus.
3.3.1 ID PVI-DESKTOP
This section gives you the identification code of your equipment. The ID is useful to
avoid conflict with other communication system.
3.3.2 Firmware
This section gives you the actual firmware version.

Quick installation guide and short introduction manual
(PVI-RADIOMODULEtop Rev:1.1)
4UPGRADE
PVI-DESKTOP has the capability to evolve continuously. New functions, small bug
fixtures and other upgrades will be released by power-one very often. The equipment
can be updated using USB port, the optional Bluetooth, or directly coping files into the
SD card which contains some part of the firmware. The PVI-DESKTOP maintain a
back-up of the last working firmware to avoid system failures and it is possible to roll-
back to the old firmware using the menu.
4.1 UPGRADE USING SD CARD
This procedure explain how to upgrade the firmware using the SD card. Follow the
steps to correctly upgrade the equipment:
1. Shut down PVI-Desktop pushing more than 5 seconds on the ON/OFF button
and confirming on the display.
2. Extract the SD card by pushing softly on it.
3. Insert the SD card on a PC card reader.
4. Check the formatting of the SD card by clicking on the right button and
selecting Properties. Verify that the format is FAT and not FAT32.
5. Open the SD card and you will find several folders (language, theme, etc.),
including the folder 'boot'. If a 'boot' file does not exist, create it.
6. Copy the file downloaded from the Power-One website into the 'boot' folder,
and if necessary rename it "boot.ben”.
7. Remove SD card from the PC being careful to perform the procedure for
safely removing hardware and put it back in the PVI-DESKTOP. Reinsert it
on PVI-Desktop
8. Push the ON/OFF button.
9. Navigate the menu to select the firmware update.
10. Clicking next PVI-DESKTOP will begin the update process.
11. Once you have read and loaded the new software a request for selection will
appear on the screen. From this screen you can decide whether to install the
new firmware, return to the previous version, or cancel the process and keep
the current firmware.

Quick installation guide and short introduction manual
(PVI-RADIOMODULEtop Rev:1.1)
Wait until PVI-DESKTOP concludes the installation process to see the menu
automatically reappear.
The procedure requires few minutes. You'll see a 'Boot...' screen appearing, just wait
that PVI-Desktop has concluded the procedure. Your PVI-DESKTOP is now upgraded
to the last firmware version.
This manual suits for next models
1
Table of contents
Other Power One Remote Control manuals
