POWERSTROKE
RANDOM ORBIT SANDER
MODEL NO PSL1OS01
REPAIR SHEET
POWERSTROKE SANDER – MODEL NUMBER PSL1OS01
2
4
3
5
6
7
8
9
10
11
12
1
2
SEE NOTE “A”
PARTS LIST
* Complete assortment is available at your nearest Authorized Service Center.
POWERSTROKE SANDER – MODEL NUMBER PSL1OS01
3
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 * Sanding Disc ..............................................................................1
2 030157001021 Dust Bag Assembly ....................................................................1
3 030157001019 Screw (M5 x 6 mm, Flat Hd.) ......................................................4
4 039157009012 Data Label ..................................................................................1
5 039157009011 Logo Label..................................................................................1
6 030157001012 Fan..............................................................................................1
7 030157001013 Bearing Cap Assembly ...............................................................1
8 030157001014 Washer........................................................................................1
9 030157001015 Spring Washer ............................................................................1
10 030157001016 Screw (M4 x 10 mm, Pan Hd.)....................................................1
11 030157001017 Brake ..........................................................................................1
12 030157001018 Platen..........................................................................................1
NOT SHOWN
039157009003 Tool Bag......................................................................................1
988000959 Operator’s Manual
6-20-12
(REV:01)
The model number will be found on a label attached to the motor housing. Always mention the model
number in all correspondence regarding your SANDER or when ordering repair parts.
NOTE A: The assembly shown represents an important part of the double insulated system. To avoid
the possibility of alteration or damage to the
System, service should be performed by your nearest
Authorized Service Center. Contact your nearest Authorized Service Center for service center
information.
12
3
4
8
10
9
12
9
13
14
15
13
11
5
6
7
SECTION “A”
POWERSTROKE SANDER – MODEL NUMBER PSL1OS01
4
PARTS LIST FOR SECTION “A”
Section “A” represents an important part of the double insulated system of this tool. Any repair
to this tool requires dielectric testing to insure customer safety and to comply with company
requirements.
POWERSTROKE SANDER – MODEL NUMBER PSL1OS01
5
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 030155001024 Screw (M4 x 14 mm, Pan Hd.) .................................................... 5
2 039157005002 Top Cap w/Overmold.................................................................. 1
3 039157009001 Switch Trigger ............................................................................. 1
4 030155001035 Switch ......................................................................................... 1
5 030155001024 Screw (M4 x 14 mm, Pan Hd.) .................................................... 5
6 030155001021 Cord Clamp................................................................................. 1
7 039157009050 Power Cord Assembly ................................................................ 1
8 039157009002 Housing Assembly ...................................................................... 1
9 030155001002 Screw (M4 x 16 mm, Pan Hd.) .................................................... 3
10 030155001007 Rubber Plug ................................................................................ 1
11 030157001009 Field Assembly............................................................................ 1
12 030155001016 Screw (M4 x 20 mm, Pan Hd.) .................................................... 2
13 030155001013 Brush Assembly .......................................................................... 2
14 030157001010 Armature Assembly..................................................................... 1
15 030157001011 Sleeve ......................................................................................... 1
The model number will be found on a label attached to the motor housing. Always mention the model
number in all correspondence regarding your SANDER or when ordering repair parts.
POWERSTROKE SANDER – MODEL NUMBER PSL1OS01
6
RED LEAD
MOTOR
BRUSH ASSEMBLIES
WHITE LEAD
BLACK LEAD
POWER CORD
BLACK LEAD
SWITCH
WIRING DIAGRAM
