Introduction
x
1
1Introduction
1.1 Product Definition
The cPCIS-2501 3U CompactPCI 6-slot Cubic Chassis is designed for 3U
CompactPCI cards and modules without rear I/O. It is 4U in height, 237 mm
deep, and suitable for bench top use or wall mounting. It is ideal for industrial
or transport applications where small chassis size and versatility are
important. A built in cooling system with removable filter provides maximum
cooling efficiency, and the 250W cPCI power supply allows easy
maintenance. The cPCIS-2501’s ability to handle a wide range of
temperatures and excellent shock and vibration characteristics make it
suitable for operating in a rigorous environment.
This user’s manual provides unpacking, operating, and maintenance
information for the cPCI-2501 3U CompactPCI 6-slot Cubic Chassis. The
cPCI-2501 chassis is assembled using the following components:
Components:
xChassis: cPRK-2501
xPower Supply: cPS-H325/AC 3U cPCI
xBackplane: cBP-3206 6-slot 32-bit 3U cPCI
xPower Backplane: cBP-3061
cPCIS-2501 Front View

2
x
Introduction
1.2 Features
xCompact size, 4U high enclosure for 3U CompactPCI cards w/o rear I/O
xBoard Space: 1 system slot, 5 peripheral slots, 1 PSU slot
xSide handle design for portable applications
xStand feet on the bottom for desktop use
xVersatile wall-mount applications with mounting kit
xStandard PICMG 2.11 47-Pin modular power supply
xBuilt-in cooling system
xBottom-access removable air filter for easy maintenance
1.3 Specifications
CompactPCI Standards PICMG 2.0 R3.0
Form Factor 3U CompactPCI card without rear I/O
Enclosure Coated metal plate outer covering with aluminum
framework
Cooling System Bottom-access removable fans for in-take:
12V DC brush-less, dual ball bearing
Two fans with 67.02 CFM/each
Rated speed for each fan: 4500 RPM
Rated power for each fan: 6 W
Power Supply Power backplane: cBP-3061
Supports single in-rack 3U cPCI 8HP power module
PICMG 2.11 47-pin power interface
Available power module: cPS-H325/AC (250W)
Backplane cBP-3206: 6-slot 32-bit 3U cPCI Backplane
Chassis Partition 5 slots for peripheral cards
3 slots for system module
2 slots for three 3U 8HP cPCI power modules
Dimension 221.4 x 237 x 177 (mm, W x D x H, w/o wall mount kit
or stand feet)
Operating temperature 0 to 60°C
Storage temperature -20 to 80°C
Humidity 5% to 95%, non-condensing
Shock 15G peak-to-peak, 11ms duration, non-operation
Vibration Non-operation: 1.88Grms, 5-500Hz, each axis
Safety, Certification, EBS CE

Introduction
x
3
1.4 Mechanical Drawing
cPCIS-2501 Front View
cPCIS-2501 Side View

This page intentionally left blank.

Getting Started
x
5
2Getting Started
In this chapter, we will describe the unpacking procedure for the cPCIS-2501
and installation procedures for CompactPCI boards and power supply unit
(PSU).
2.1 Shipping Contents
Check the shipping carton for any damage. If the shipping carton and
contents are damaged, please notify the dealer for a replacement. Retain
the shipping carton and packing material for inspection by the dealer. Obtain
authorization before returning any product to ADLINK.
Check that the following items are included in the package. If there are any
missing items, please contact your dealer:
xOne cPCIS-2501 chassis
xcPS-H325/AC power supply
xThis user’s manual
xPower cord (either N. American or European)
2.2 CompactPCI Board & PSU Installation
CompactPCI connectors are rigid, and therefore require careful handling
when inserted and removed. Improper manipulation of the cards will result in
damage to the backplane.
System slots usually have obvious indicators (e.g. red card guide rail, triangle
mark enclosing the slot number on the backplane, etc.). System cards can
only be installed in a system slot. Do not insert a system card into any other
slot, or insert any peripheral card into system slot.
The PSU slot also has an obvious indicator such as a green card guide rail in
a standard CompactPCI chassis (see photo below).
The handle on CompactPCI cards and PSUs ensures simple and safe
installation and removal. Please follow the procedures below to install a
CompactPCI module into the cPCIS-2501 chassis:

6
x
Getting Started
CompactPCI Card Installation/Removal Procedure
1. Place the chassis on a level surface. Remove the blanking plates where
required by undoing the retaining screws at each end. Retain the blanking
plates for possible future use. The system should not be put into use
without blanking plates for all empty slots, otherwise the EMC and cooling
performance will be compromised
2. Hold the SBC module, peripheral card or PSU module vertically. For PSU
modules, make sure that the handle is unlatched (i.e. that it is pulled
downwards) by first pressing on the locking button with your thumb.
3. Carefully insert the module into the desired slot by sliding the edges of the
board into the appropriate card guide rail. Take care to ensure correct
alignment of the card with the chassis during insertion to prevent damage
to the card and/or backplane.
4. Continue inserting the card until the handle engages with the chassis.
5. Pull upwards on the handle for final insertion. For PSU modules, ensure
that the locking button on the handle is fully latched into position. Fasten
the retaining screws at each end of the card (2 for single slot cards, 4 for
double slot cards).
S
y
stem Card Slot
Peri
p
heral Card Slots
Insert Module

Getting Started
x
7
To remove the module, press the locking button (if necessary), and reverse
steps 1 through 5 above.
System Card
Full
y
Inserted
Locking Button

8
x
Getting Started
CompactPCI PSU Installation/Removal Procedure
The installation and removal procedures for a CompactPCI PSU are the
same as those for CompactPCI boards. See the figures below.
Fully Latched
Handle Engages
with Chassis
Insert Module
PSU Slot

Getting Started
x
9
2.3 Powering Up the System
Set the main power switch in the lower right corner of the rear panel to the off
position ( O ). Set the secondary power switch in the lower right corner of the
front panel to the off position ( I ). Connect the supplied power cord to the
socket on the back of the chassis. The supplied PSU is full range 90-240VAC
and does not require input voltage setting. Insert a system module and any
desired peripheral cards into the appropriate card slots.
To power up the system, set the secondary power switch on the front panel
to the on position ( II ).

This page intentionally left blank.

Backplane
x
11
3Backplane
In this chapter, we will describe the backplanes for the cPCIS-2501, the cBP-
3206 is a 3U CompactPCI 32-bit backplane and the cBP-3061 power
backplane.
3.1 cBP-3206 Backplane
Specifications
xStandard CompactPCI height for 3U cPCI cards
xCompactPCI Compliancy
oPICMG 2.0 CompactPCI core specification R3.0
oPICMG 2.1 CompactPCI hot swap R2.0
xDimensions: 100.7 x 128.7 mm
xPCI bus clock: up to 32-bit/33MHz
xSystem Slot: one R-hand side dual-slot
xPeripheral slots: 5
xPower Connectors: ATX connector x2, DC screw terminals
xV (I/O): 3.3V or 5V selectable, default 5V
xOther connectors: INH#, Reset, PWR_FAL#

12
x
Backplane
Mechanical Drawing
cBP-3206 Rea
r
View
cBP-3206 Front View
1 - P2
1 - P1
6 - P2
6 - P1
CN1
CN2
JP8 - JP10

Backplane
x
13
Pin Assignment
¾[1 – P1] System Slot
Pin Z A B C D E F
25 GND +5V REQ64#
ENUM# +3.3V +5V GND
24 GND AD[1] +5V V(I/O)
AD[0] ACK64# GND
23 GND +3.3V AD[4] AD[3] +5V AD[2] GND
22 GND AD[7] GND +3.3V AD[6] AD[5] GND
21 GND +3.3V AD[9] AD[8] M66EN C/BE[0]# GND
20 GND AD[12] GND V(I/O) AD[11] AD[10] GND
19 GND +3.3V AD[15] AD[14] GND AD[13] GND
18 GND SERR# GND +3.3V PAR C/BE[1]# GND
17 GND +3.3V IPMB_SCL IPMB_SDA GND PERR# GND
16 GND DEVSEL# GND V(I/O) STOP# LOCK# GND
15 GND +3.3V FRAME# IRDY# BDSEL TRDY# GND
12-14 Key
11 GND AD[18] AD[17] AD[16] GND C/BE[2]# GND
10 GND AD[21] GND +3.3V AD[20] AD[19] GND
9 GND C/BE[3]# IDSEL AD[23] GND AD[22] GND
8 GND AD[26] GND V(I/O)
AD[25] AD[24] GND
7 GND AD[30] AD[29] AD[28] GND AD[27] GND
6 GND REQ# GND +3.3V CLK AD[31] GND
5 GND Reserved
Reserved PCIRST# GND GNT# GND
4 GND IPMB_PWR HEALTHY# V(I/O)
INTP INTS GND
3 GND INTA# INTB# INTC# +5V INTD# GND
2 GND TCK
+5V TMS TDO TDI GND
1 GND +5V -12V TRST#
+12V +5V GND
Pin Z A B C D E F

14
x
Backplane
¾[1 – P2] System Slot
Pin Z A B C D E F
22 GND GA4 GA3 GA2 GA1 GA0 GND
21 GND CLK6 GND NC NC NC GND
20 GND CLK5 GND NC NC NC GND
19 GND GND GND NC NC NC GND
18 GND NC NC NC NC NC GND
17 GND NC NC PRST# REQ6# GNT6# GND
16 GND NC NC DEG#
NC NC GND
15 GND NC NC FAL#
REQ5# GNT5# GND
14 GND NC NC NC NC NC GND
13 GND NC NC NC NC NC GND
12 GND NC NC NC NC NC GND
11 GND NC NC NC NC NC GND
10 GND NC NC NC NC NC GND
9 GND NC NC NC NC NC GND
8 GND NC NC NC NC NC GND
7 GND NC NC NC NC NC GND
6 GND NC NC NC NC NC GND
5 GND NC NC NC NC NC GND
4 GND V(I/O)
NC NC NC NC GND
3 GND CLK4 GND GNT3# REQ4# GNT4# GND
2 GND CLK2 CLK3 GND
GNT2# REQ3# GND
1 GND CLK1 GND REQ1# GNT1# REQ2# GND
Pin Z A B C D E F
