powerCon TRUE1 TOP User manual
INSTRUCTION
R
A
Page 1BDA 558
BC
1. CONNECTING /
Note:
The proper twist-lock is achieved when the silvery tab is in
the position shown in C and an audibel «click» is heard.
C
click
Note:
After inserting properly as in illustration A ,
twist the cable connector clockwise to lock.
A
Power OUT Connector
powerCON®TRUE1 TOP
Note:
When connecting, match the notch
on the cable connector to the
corresponding guide slot on the
chassis.
SAFETY WARNING
incorrect insertion may cause electrical contact
misalignmentresultinginequipmentmalfunction
and/orpersonalinjury.
max. 1 Newton
2. UNLOCKING
ABC
www.neutrik.com
R
Page 2
Draft. Nr.: BDA 558 Update: .20115.11 8
II
Neutrik AG LI T: +423 / 237 24 24 F: +423 232 53 93/
Neutrik USA Inc. USA T: +1 704 / 972 3050 F: +1 704 438 9202/
Neutrik ()
UK Ltd. UK T: +44 1983 / 811 441 F: +44 1983 811 439/
Neutrik Vertriebs GmbH DE/NL/AT/DK T: +49 8131 / 280 890 F: +49 8131 280 830/
Neutrik France FR T: +33 1 4131 6750 F: +33 1 4131 0511//
Neutrik Tokyo Ltd. JP T: +81 3 3663 4733 F: +81 3 3663 4796//
Neutrik Hong Kong Ltd. HK T: +852 2687 6055 F: +852 2687 6052//
Neutrik India Pvt. Ltd. IND T: + F: +91 22 26163 54091/982 05 43 424 /
Data subject to change without prior notice. 201 NEUTRIK ALL RIGHTS RESERVED8 . NEUTRIK are registered trademark of NEUTRI AG. .©®®
power TRUE1 TOPCON®IOPERATING INSTRUCTION
Approval based:
Rating:
Cable Type:
Strain Relief:
Cable O.D.:
UL
UL 498 / CSA C22.2 No. 182.3
250 V ac / 20 A
SJTOW, SJOOW 3 x 12 AWG
White chuck
6.0 - 12.0 mm
VDE
EN 60320-1/EN60320-2-2
250 V ac / 16 A
H05VV-F3G 1.0 mm , Length max. 2 m
2
H05VV-F3G 1.5 - 2.5 mm2
H07RN-F3G 1.5 mm2
White chuck
6.0 - 12.0 mm
NAC3PX-TOP
NAC3MPX-TOP
NAC3MPX-WOT-TOP
NAC3FPX-TOP
NAC3FPX-WOT-TOP
NAC3FPX-ST-TOP
Power IN
Power OUT
Power OUT
NAC3FX-W-TOP
(Connector)
NAC3MX-W-TOP
(Plug connector)
-w
-w
20
250
P S
E
JET
-w
-w
20
250
P S
E
JET
20
250
PS
E
JET
16
250
20
250
NAC3MX-W
20
250
PS
E
JET
16
250
20
250
NAC3MX-W
NAC3FX-W-TOP
(Connector)
NAC3MX-W-TOP
(Plug connector)
Power IN
CONNECTOR ASSIGNMENT:
APPLIANCE INLET APPLIANCE OUTLET APPLIANCE INLET / OUTLET
uCombination
power TRUE1 TOP line is full backward compatible with the preceding power TRUE1 products.CON CON
Application:
The power TRUE1 system is certified as connector with breaking cap ity accordingCON TOP a ac
to 0625. to an appliance coupler and interconnectionIEC 60320, VDE It is intended use as
coupler. anIt serves to supply power to appliance and from an appliance to other equipment.
To be installed by qualified personnel only.
