PowerPac PPT615 User manual

HALOGEN OVEN 12 L with 360 Grill and Timer
PPT615

The title is not clickbait - this appliance actually exists. Most of us have never heard of
a halogen oven. Some consumers already know of its benefits, while others have
come here out of curiosity. Let me introduce some great things about Halogen
Ovens ….
A halogen oven uses a halogen lamp to produce heat, which is spread throughout the
oven by a fan. A Thermostat inside the oven regulates the temperature by turning the
lamp on and off.
Firstly, food cooks in a much shorter time. Fancy Steak in 8 minutes, grilled fish in 25
minutes or a cake in 20 minutes? All possible!
Secondly, halogen ovens cook many types of food that traditional ovens cannot, e.g.
boiled potatoes, boiled eggs (that’s a surprise!), steamed vegetables, frozen food like
pizzas and French Fries. You can boil, bake, fry and roast. It is also safe to use foil.
Thirdly, halogen ovens consume 75% less energy than conventional ovens. You can
throw everything into one pot instead of cooking everything separately.
Fourthly, all of us could do with more space in the kitchen. Halogen oven just consists
of a Pot Holder, Pot and Cover. It’s a lot lighter too. To increase capacity from 12 litres
to 17 litres, a Frame is provided.
Lastly, after cooking comes the inevitable cleaning. Here, the Halogen Oven offers a
lifeline. The ‘Thaw Wash’function is a self-cleaning feature. Fill the Pot with 2 inches
of water with a few drops of dishwashing liquid. Let the appliance operate for 10
minutes. For really stubborn stains, use some liquid detergent on a soft cloth and rub
it off. Don’t forget to wipe the exterior of the appliance, too.
Timer dial
0 –60 mins
Temperature dial
125 –250 oC
0 –60 mins

Parts & Description s
LIST OF COMPONENTS
1.
Handle
2.
Cover
3.
Timer dial
4.
Temperature dial
5.
Tempered Glass Pot
6.
Pot
7.
Pot Holder
8.
Frame
9.
Food Tongs
10.
High Metal Holder
11.
Low Metal Holder
Handle
Cover
Pot
Pot Holder

Frame
High Metal Holder
Food Tongs
Low Metal Holder
Timer dial
0 –60 mins
Temperature dial
125 –250 oC
0 –60 mins

Warnings s
ATTENTION :
Read this booklet carefully as it contains important instructions for a safe installation,
use and maintenance.
Important instructions to be kept for future reference.
The following basic precautions should always be followed when using electrical
appliances:
1. Read all instructions before using the appliance.
The Appliance
2. This appliance must be used only for the purpose it was expressly designed; any
use NOT complying with the instructions contained in the manual is considered
inappropriate and dangerous. The manufacturer is NOT responsible for possible
damages caused by the inappropriate and/or unreasonable use.
3. The appliance is designed for boiling, steaming, stewing, frying, roasting, baking
and defrosting as well as heating dishes used in steamboat. In the process of
frying, oil and sauces may be added. However, DO NOT add a large quantity of
liquids other than water into the Tempered Glass Pot as the appliance was
designed for heating water only. Different liquids have different boiling points, with
volatile liquids having boiling points lower than 100C, the boiling point of water.
4. The installation/assembly of the appliance will be made in accordance with the
indications of the manufacturer. A wrong procedure may cause damages to
persons, animals or objects, for which the manufacturer cannot be considered
responsible.
5. Before use, check the integrity of the appliance and power cable. DO NOT operate
the appliance when its housing is damaged. In case you are not sure, contact a
qualified person. If the power cable is damaged, it must be replaced by the
manufacturer or its service agent or a qualified technician in order to avoid a shock
hazard.
6. Before powering the appliance make sure the rating (voltage and frequency)
corresponding to the grid and the socket is suitable for the plug of the appliance,
and that the wall socket is properly grounded. This appliance is fitted with an earth
wire for extra safety.
7. DO NOT power the appliance using multiple sockets. If possible, avoid the use of
adapters and/or extension cables; if their use is absolutely necessary, use only
materials in compliance with the current safety regulations and according to the
electrical parameters of the adapters.
8. The appliance must NOT be switched on using external timers and/or other remote
control appliances which are not specified in this manual.

9. Only use original components & accessories (e.g. Cover, Pot, Pot Holder, etc.)
provided by the manufacturer. Any non-original component or accessory NOT
recommended by the manufacturer (including, but not limited to, Covers, Pot, Pot
Holders, etc. made by other manufacturers or by the same manufacturer but for
other models of the same capacity or otherwise) may cause injuries to persons or
damage to the appliance.
10. The packing materials (plastic bags, expanded polystyrene, etc.) must be kept out
of the reach of children or disabled persons since they represent potential sources
of danger.
Location
11. This appliance is NOT suitable to be used or stored near heat sources (open flame,
ovens, heaters, stoves, etc.) and/or in an explosive environment (in the presence
of flammable substances such as gas, vapour, mist or dust, in atmospheric
conditions when, after ignition, the combustion is spread in the air). Items
containing these substances should never be placed in the appliance, and never
be used to clean the appliance in order to avert the risk of fire or explosion.
12. The appliance should NOT be placed on a surface, or in the vicinity of, objects
which can be damaged by heat, such as carpets or plastics. DO NOT locate
multiple portable socket outlets or power supplies at the bottom or rear of the
appliance. When using the appliance, the surface that the appliance is placed
upon as well the surface immediately above (e.g. a wooden cabinet above the
appliance), may become very hot. If the appliance is operated on wooden furniture,
use a protective pad to prevent damage to delicate finishes.
13. Place the appliance at a proper distance from the objects or surrounding walls
making sure that its functioning will NOT cause accidental damages. There should
be at least 10 cm of free space from the back, left & right sides, and at least 20 cm
the top of the appliance. Never put things on top of the Cover.
14. Avoid placing the power cable on abrasive or sharp surfaces or in positions where
it can be damaged easily. The cable must NOT be placed under carpets, or
covered with throw rugs, runners or similar. Arrange the cable away from the high
traffic area, and where it will NOT be tripped over.
15. DO NOT use or store the appliance outdoors. Store and use the appliance only
indoors, or in any case, protected from weathering such as rain, direct radiation of
the sun and dust.
Operation
16. If you are using the appliance for the first time, you should:
a. Clean the exterior of the appliance with a damp cloth and wipe dry. Wash the
Pot and Pot Holder with water & detergent with a non-abrasive sponge. DO
NOT use metal scouring pads. Make sure that the Cover DOES NOT come
into contact with water. Dry the Pot and Pot Holder thoroughly.
b. Place and use the appliance upright on a horizontal, stable, dry and heat-

resistant surface. Damage to the appliance may occur if it is placed on an
incline or decline.
c. Make sure to remove any label or protective sheet which may prevent its
proper functioning.
d. (First use)
Fill the Pot with 2 inches of water.
Holding the Handle, place the Cover onto the Pot securely.
Turn the Timer dial & Temperature dial anti-clockwise to ‘OFF’.
Plug the power cable into the wall socket and switch it ON.
Turn the Timer dial & Temperature dial clockwise to ‘10’ and ‘Thaw Wash’
respectively. The Power Indicator Light & Heat Indicator Light will light up
and heating will commence. After 10 minutes, heating will stop. Turn the
Temperature dial anti-clockwise to ‘OFF’. The Power Indicator Light &
Heat Indicator Light will turn off. Switch the wall socket off and unplug the
power cable.
Wait for the water to cool to room temperature. Discard the water and rinse
the Pot under running water. Wipe the underside of the Cover. Be careful
not to allow water to enter the internal parts of the Cover. Thereafter the
appliance is safe to use.
Switching the appliance ON
Turn the Timer dial & Temperature dial anti-clockwise to ‘OFF’. Plug
the power cable into the wall socket and switch it ON. Turn the Timer
dial & Temperature dial clockwise according to your requirements.
The Power Indicator Light & Heat Indicator Light will light up and
heating will commence.
(henceforth “switching the appliance on” is intended to include the steps
above)
Switching the appliance OFF
Turn the Timer dial & Temperature dial anti-clockwise to ‘OFF’. The
Power Indicator Light & Heat Indicator Light will turn off and heating
will cease. Switch the wall socket off and unplug the power cable.
Wait for the appliance and food within to cool before lifting the
Handle to remove the Cover. Remove the food carefully.
(henceforth “switching the appliance off” is intended to include the steps
above)
DO NOT:
cover the appliance during functioning;
obstruct totally nor partially the Cover;
insert objects or body parts inside the protection cover of the appliance;
switch the appliance on if the Pot is dry - however, should the pot be found

empty during operation, immediately switch off the appliance;
heat the Pot by any other means, e.g. in a microwave, oven or on a frying pan
filled with water and placed directly on a gas stove, as the plastic components
can be deformed as a result;
use metal utensils as they may scratch the surface of the Pot – use a wooden
or silicone utensil;
turn the Timer dial and Temperature dial too hard so as to avoid any damage;
leave the appliance unsupervised during operation.
17. During operation, DO NOT touch the appliance with wet body parts, and it is
recommended to have between you and the standing surface, an isolating element
(for example, wearing shoes with rubber soles).
18. During the period of operation, high temperature steam may escape from the
container. To avoid scalding:
DO NOT
fill the Pot with hot water;
allow all of the water to be boiled away;
overfill solids or liquids to avoid overflow of hot liquids;
remove the Cover while heating & ensure that the Cover sits securely onto the
Pot during heating;
use the appliance to heat oil or melt butter without any food present;
add food with its packaging (plastic wrapper, paper, foil, metal can, etc.) still
attached without first removing the packaging;
place any container inside the appliance;
move the appliance whilst the appliance is in operation;
touch any part of the appliance except the Handle, Timer dial or Temperature
dial when in operation or just after switching it off as it will still be very hot and
may cause scalding. The Pot becomes exceedingly hot as the cooker
operates. Do note that the food items and accompanying liquids & gases
inside the appliance, and the appliance itself would still be very hot during
heating, and for some time after the plug has been pulled out of the electric
mains. If you need to check on the progress of the food preparation, or to turn
over some food items, please use a utensil with a long handle;
direct steam at any person or animal & one’s hands and face should be angled
away from the Cover and the Vents at all times.
19. DO NOT soak the Cover in water or other liquids, wash it under the tap, or let any
liquid flow into the internal casing of the appliance to prevent electric shock. In
case of accidental fall in water, DO NOT try to take it out, but first switch the
appliance off.
20. Plug and unplug the power cable firmly holding it with dry hands. Always unplug
the power cable to avoid overheating and avoid stretching it (DO NOT pull it, tug
it or use it to drag the appliance to which is connected). Before unplugging the
appliance, turn the Timer dial or Temperature dial on the appliance to ‘OFF’ and

switch off the wall socket.
21. Switch the appliance off when not in use and before filling or emptying the
appliance. Before storing, cleaning or performing any maintenance operation,
leave to cool for at least 30 minutes.
22. In case of malfunction or anomaly during the functioning, switch the appliance off
immediately, turn off the power and check the cause of the anomaly, if possible,
with the support of a qualified person.
23. If smoke is observed coming out of the appliance, switch the appliance off
immediately. Remove the Cover from the Pot and any other utensil placed in the
Pot after it has stopped smoking.
24. This appliance is NOT intended for commercial use but to be used in households
and similar applications, such as:
Staff kitchen areas in shops, offices and other working environments;
Dormitories;
By clients in hotels, motels and other residential environments;
Bed and breakfast type environments.
25. This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved. Children shall
NOT play with the appliance. Cleaning and user maintenance shall NOT be made
by children unless they are older than 8 and supervised. Keep the appliance and
its cable out of reach of children less than 8 years old.
26. Save these instructions.

How to use s
If pre-heating is required:
1. Plug the power cable into the wall socket and switch it ON.
2. Turn the Timer dial clockwise to the desired cooking duration. The Power Indicator
Light will light up after the Timer dial is activated, and will turn off when the Timer
dial is deactivated.
3. Turn the Temperature dial clockwise to the desired temperature. The Heat
Indicator Light will light up after the Temperature dial is activated, and will turn off
when the Temperature dial is deactivated.
4. Heating will commence immediately.
5. When the heating time is over, the Timer will auto shut off.
6. If you wish to end the heating earlier than the set pre-heating time, please turn the
Timer dial anti-clockwise to ‘OFF’.
7. In the first use of this oven, there might be some light smoke coming out from the
oven. This is normal. After 5 minutes the smoke will disappear.
8. Turn the Temperature dial anti-clockwise to ‘OFF’, switch the wall socket off and
unplug the power cable before lifting the Cover.
If pre-heating is NOT required:
9. Fill the Pot with ingredients.
10. Follow steps 1 – 8 as above.
11. Wear protective, insulated oven gloves when inserting or removing items from the
hot appliance.
12. DO NOT direct steam at any person or animal & one's hands and face should be
angled away from the Pot or Pan at all times.

How to clean s
1. Turn the Timer dial & Temperature dial anti-clockwise to ‘OFF’, switch the wall
socket off and unplug the power cable when not in use. Wait until the oven has
completely cooled before cleaning or performing any maintenance operation.
2. Never immerse the Cover in water or other liquids.
3. Wipe the Cover of the oven using a soft, damp cloth or sponge. Remove stubborn
spots with a cloth moistened with mild liquid detergent. DO NOT use abrasive
scouring pads or powders.
4. Wash the Pot and Pot Holder with detergent with a non-abrasive sponge. Rinse
under running water. DO NOT use metal scouring pads. Rinse under running water.
5. Dry the Pot and Pot Holder thoroughly and place them in their working positions.
Using the ‘Thaw Wash’ function
6. The ‘Thaw Wash’ function is a self-cleaning feature. Fill the Pot with 2 inches of
water with a few drops of dishwashing liquid. Let the appliance operate for 10
minutes. For really stubborn stains, use some liquid detergent on a soft cloth and
rub it off.

ENVIRONMENTAL TIP s
This appliance, along with all other electronic appliances, should, when it is no longer
capable of functioning, be disposed with the least possible environmental damage
according to the local regulations in your area. In most cases you can discard the
appliance at your local recycling centre.
DISPOSAL: Do not dispose this appliance as unsorted municipal waste as it contains
batteries and/or recyclable electric waste. Collection of such waste separately for
special treatment is necessary.
SPECIFICATIONS s
MODEL
PPT615
VOLTAGE
220 –240 V ~50 –60 Hz
POWER
750 W
CAPACITY
17 L (with Frame)
12 L (without Frame)
DIMENSIONS
Diameter 420 mm (with Pot Holder)
Diameter 320 mm (without Pot Holder)
Height 405 mm (with Frame)
Height 330 mm (without Frame)

WARRANTY s
Warranty Conditions
1. This warranty provides against defective materials and manufacturing faults
throughout for two years from the date of purchase of the appliance. The warranty
on the Compressor is 10 years subject to the same conditions as above.
2. This warranty also does not cover normal wear and tear, replacement of
consumable materials and accessories, and the cost of maintenance of the
appliance.
3. This warranty does not cover the repair or replacement of part/s damaged by
misuse, accidents, negligence, alterations, or modifications in any way, or repairs
done by any repair organisation without the prior consent of PowerPac Electrical
Pte Ltd.
4. Repair and service are to be performed at: 5 Changi South Lane #03-01 Singapore
486045. A transport fee will be charged for personal doorstep service.
5. The original purchaser of the appliance must furnish proof of purchase to our
Service Centre with the email or number as registered during submission of
warranty when this appliance is sent for repair/service. Failure to do so may delay
the receipt of said repair/service by the customer.
6. Under no circumstances whatsoever shall the serial number be erased, defaced
or altered by the customer and/or his representatives, or the dealer and/or his
agents. Failure to ensure this shall invalidate the warranty.
7. This warranty is deemed to be void if the defect is cause by the attack of household
pests, fire, lightning, natural disasters, pollution, abnormal voltage or the usage of
generators.
8. This warranty is valid in Singapore only.
9. This warranty will be honoured subject to the customer’s registration of the
warranty inclusive of original invoice or valid purchase receipt. Failure to present
these documents will result in denial of service. However, if the customer still
requests that the defective appliance be repaired, PowerPac Electrical Pte Ltd
may, at its discretion, repair the appliance but impose a labour charge, as well as
the costs of the replacement parts, to be borne solely by the customer.
10. Please refer to the attached picture for the location of
one of our appliance’s serial number, as an example.

Please complete the on-line registration warranty form available on our website. There
is no further requirement to send us any hard copy as part of our efforts to save the
environment.
In accordance with the terms and conditions of this limited warranty as stated above,
PowerPac Electrical Pte Ltd, at its expense shall provide free services for the
appliance within the warranty period from its date of purchase from our Authorised
dealers.
