PowerPac PPF136 User manual

Model: PPF136
170494-24

PPF136 136L
274 74

PARTS & DESCRIPTION
LIST OF COMPONENTS
1.
2.
3.
4.
5.
6.
Wire Tray in Freezer
Temperature Regulator
Storage Shelves
Crisper Cover
Crisper
Door Shelves (Egg Tray at upper shelf)
1
2
4
6
5
3
1

ATTENTION :
Read this booklet carefully as it contains important instructions for a safe installation,
use and maintenance.
Important instructions to be kept for future reference.
The following basic precautions should always be followed when using electrical
appliances:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Read all instructions before using the appliance.
This appliance must be used only for the purpose it was expressly designed; any
use NOT complying with the instructions contained in the manual is considered
inappropriate and dangerous. The manufacturer is NOT responsible for possible
damages caused by the inappropriate and/or unreasonable use.
This appliance is NOT suitable to be used in an explosive environment (in the
presence of flammable substances such as gas, vapour, mist or dust, in atmospheric
conditions when, after ignition, the combustion is spread in the air). Items
containing these substances should never be placed in the appliance, and never be
used to clean the appliance in order to avert the risk of fire or explosion.
The packing materials (plastic bags, expanded polystyrene, etc.) must be kept out
of the reach of children or disabled persons since they represent potential sources
of danger.
The installation/assembly of the appliance will be made in accordance with the
indications of the manufacturer. A wrong procedure may cause damages to persons,
animals or objects, for which the manufacturer cannot be considered responsible.
During transportation of this appliance, it should NOT be subjected to an inclination
of greater than 45° to the horizontal, so as to prevent damage to the compressor
and refrigeration system of the appliance.
During use and storage, the appliance must be kept away from direct sunlight, and
at a safe distance from sources of heat (open flame, appliances, heaters, stoves, etc.)
or any flammable and/or potentially explosive substances.
Place and use the appliance on a horizontal, stable and heat-resistant surface. The
appliance shall NOT be placed on a surface, or in the vicinity of, objects which can
be damaged by heat such as wood, carpets or plastics. During operation, as heat is
transferred away from the appliance, the surface that the appliance is placed upon
and the rear of the appliance may become very hot. DO NOT locate multiple
portable socket outlets or power supplies at the bottom or rear of the appliance. If
the appliance is operated on wooden furniture, use a protective pad to prevent
damage to delicate finishes.
DO NOT touch the back and bottom of the appliance while it is operating to prevent
scalding, as the regions become hot as the appliance operates.
Place the appliance at a proper distance from objects or surrounding walls making
sure that its functioning will not cause accidental damages. There should be at least
10 cm of free space from the back, left & right sides and at least 30 cm from the top
to allow adequate air circulation to cool the compressor. Never put things on top of
the appliance.
WARNINGS
2

Clean the inside of the appliance with water & detergent with a non-abrasive
sponge.
DO NOT use metal scouring pads.
Ensure that the appliance is completely dry before use and standing at an upright
position for at least an hour before switching on the appliance.
Upon switching on the appliance for the first time, turn the Temperature Control
Rotary Knob to between 3~4. After half an hour, the temperature inside the
appliance should already be cool, and gradually getting colder.
Check that the Indicator Light, Compressor and Ventilation Fan are all working
smoothly. Let the Compressor operate for a period of at least 2 – 3 hours before
placing food & drinks into the appliance.
Always wear protective, insulated gloves when inserting or removing frozen
items from the appliance, especially if contact with the frozen items is prolonged.
Switch off the appliance and unplug the socket from the electric mains during
cleaning or performing any maintenance operation. Make sure at least 5 minutes
have elapsed before switching the appliance back on in order to protect the
compressor and the refrigeration system.
cover the appliance during functioning;
obstruct totally nor partially the air vents;
insert objects or body parts inside the protection cover of the appliance;
turn the Temperature Control Rotary Knob from a high value to a much lower one
without first gradually decreasing its value;
use electrical devices (e.g. hairdryers, heaters, radiators, fans, etc. to melt ice),
mechanical devices (sharp knives, ice-picks, etc. to scrape ice), a direct flame or by
any other means to remove ice from the interior surfaces) when defrosting;
place or use any electrical appliances inside the appliance unless recommended
by the manufacturer;
put oversized foods or large amounts of food into the appliance at the same time;
11.
12.
13.
14.
15.
16.
Before use, check the integrity of the appliance and power cable. In case you are not
sure, contact a qualified person. If the power cable is damaged, it must be replaced
by the manufacturer or its service agent or a qualified technician in order to avoid a
shock hazard.
Before powering the appliance make sure the rating (voltage and frequency)
corresponding to the grid and the socket is suitable for the plug of the appliance,
and that the wall socket is properly grounded.
DO NOT power the appliance using multiple sockets. If possible, avoid the use of
adapters and/or extension cables; if their use is absolutely necessary, use only
materials in compliance with the current safety regulations and according to the
electrical parameters of the adapters.
The appliance must NOT be switched on using external timers and/or other remote
control appliances which are not specified in this manual.
Any accessories NOT recommended by the manufacturer may cause injuries to
persons.
If you are using the appliance for the first time, you should:
a.
b.
c.
d.
e.
f.
Make sure to remove any label or protective sheet which may prevent its proper
functioning.
DO NOT:
•
•
•
•
•
•
•
3

17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
Plug and unplug the power cable holding it firmly with dry hands. (DO NOT pull it,
tug it or use it to drag the appliance to which is connected). Before unplugging the
appliance, switch it off, using the proper command on the control panel
During operation, DO NOT touch the appliance with wet body parts, and it is
recommended to have between you and the standing surface, an isolating element
(for example, wearing shoes with rubber soles).
DO NOT soak the appliance in water or other liquids, wash it under the tap, or let
any liquid flow into the internal casing of the appliance to prevent electric shock.
Keep the cable away from heated surfaces, abrasive or sharp surfaces or in positions
where it can be damaged easily.
Avoid carrying out operations which are NOT specified in this manual (such as
disassembling and/or altering).
In case of malfunction or anomaly during the functioning, switch off the appliance
immediately, turn off the power and check the cause of the anomaly, if possible,
with the support of a qualified person.
If smoke is observed coming out of the appliance, unplug the power cable
immediately.
This appliance is intended to be used in households and similar applications,
such as:
• Staff kitchen areas in shops, offices and other working environments;
• Dormitories;
• By clients in hotels, motels and other residential environments;
• Bed and breakfast type environments.
DO NOT use or store the appliance outdoors. Store and use the appliance only
indoors, or in any case, protected from weathering such as rain, direct radiation of
the sun and dust.
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall NOT
play with the appliance. Cleaning and user maintenance shall NOT be made by
children unless they are older than 8 and supervised. Keep the appliance and its
cable out of reach of children less than 8 years old.
Save these instructions.
store containers made of glass or canned items in the appliance;
store medicine or medical products in the appliance;
tamper with the refrigerant circuit in any way as this could damage the appliance
or release the refrigerant gas into the immediate surroundings. This refrigerant
gas (R600a - chemical name: isobutane) is currently the refrigerant gas of choice
in domestic and small commercial refrigerators due to its low environmental
impact and excellent thermodynamic performance. However, it is a hydrocarbon
and is flammable;
move the appliance by the door handle.
•
•
•
•
4

1.
2.
3.
4.
5.
6.
7.
8.
9.
Before and during installation, DO NOT subject this appliance to an inclination of
greater than 45° to the horizontal, so as to prevent damage to the compressor and
refrigeration system of the appliance.
Clean the inside of the appliance with water & detergent with a non-abrasive
sponge. Ensure that the appliance is completely dry before use and standing at an
upright position for at least 1 hour before switching on the appliance. This will
reduce the possibility of malfunction of the cooling system which may have been
incurred during transportation.
This appliance should be installed in an environment free from explosive &
flammable substances, away from direct sunlight and sources of heat, on a
horizontal, stable and heat-resistant surface.
The appliance shall NOT be placed on a surface, or in the vicinity of, objects which
can be damaged by heat such as wood, carpets or plastics. If the appliance is
operated on wooden furniture, use a protective pad to prevent damage to delicate
finishes.
Place the appliance at a proper distance from objects or surrounding walls making
sure that its functioning will not cause accidental damages. There should be at least
10 cm of free space from the back, left & right sides and at least 30 cm from the top
of the door to allow adequate air circulation to cool the compressor. Never put
things on top of the appliance.
Before powering the appliance make sure the rating (voltage and frequency)
corresponding to the grid and the socket is suitable for the plug of the appliance,
the wall socket is properly grounded and the power cable is undamaged. DO NOT
power the appliance using adapters and/or extension cables, external timers and/or
other remote control appliances.
Plug the power cable to the electric mains and switch it ON.
Upon switching on the appliance for the first time, turn the Temperature Control
Rotary Knob to 3. Check that the Indicator Light, Compressor and Ventilation Fan
are all working smoothly. After half an hour, the temperature inside the appliance
should already be cool, and gradually getting colder. Let the Compressor operate
for a period of at least 2 – 3 hours before placing food & drinks into the appliance.
If you need to switch the appliance off, make sure at least 5 minutes had elapsed
before switching the appliance back on in order to protect the compressor and the
refrigeration system.
HOW TO INSTALL
5

1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
The numbers 1 – 5 on the Temperature Control Rotary Knob are the temperature
grades, NOT degrees Celsius (°C) on the Temperature scale.
(note: the higher the number, the lower the thermostat and the colder the
temperature. The default temperature is 3~4.).
When food needs to be quickly frozen, turn the Temperature Control Rotary Knob
to 5. When the food has frozen, turn back the Temperature Control Rotary Knob to
between 3~4. Increasing the temperature from a higher value (colder) to a lower
one (hotter) should always be done in increments of 1 over several hours.
DO NOT turn the Temperature Control Rotary Knob from 5 to 1.
DO NOT leave the door of the appliance open for long periods of time or open the
door repeatedly within short periods of time to avoid significant increases in
temperature leading to the spoilage of food. This action, if repeated often, can
damage to the appliance and lead to the shortening of the life of the appliance.
DO NOT place or use any electrical appliances inside the appliance unless
recommended by the manufacturer.
Avoid storing containers made of glass or canned items, as they may break or
explode upon freezing.
Avoid storing medicine or medical products in the appliance.
If the appliance is to be left empty for a long period of time, switch it off, defrost,
clean, dry and leave the door open to prevent mould from developing within the
appliance.
Freezer Compartment
Place fresh and clean raw food, wrapped in airtight boxes or aluminium foil, as
quickly as possible to prevent degradation of food as much as possible and to
preserve the freshness, taste and nutrients in the food. It is advisable to place each
food item in a separate bag or container to avoid mixing of fluids prior to freezing.
DO NOT allow frozen food present in the freezer compartment to have direct
contact with food to be frozen.
DO NOT place fresh fruits and vegetables into the freezer compartment.
Refrigerator Compartment
Avoid putting large amounts of food into the appliance at the same time. Make sure
that there is ample space around each package of food item in order to ensure
adequate circulation of cold air.
Warm food should be allowed to cool down to room temperature before placing
them into the appliance.
In addition to emitting various smells, cooked food especially meat, fish & other
seafood, or pickled dishes, etc. may dry out when being placed in the refrigerator
compartment. As such, cooked food should be covered and sealed with clingfilm,
wrapped in aluminium foil, or stored in airtight containers.
Store raw meat and fish in suitable containers at the bottom of the refrigerator
compartment BELOW cooked food so that it is NOT in contact with or allowed to
drip onto other food.
HOW TO USE
6

1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Turn the Temperature Control Rotary Knob to “OFF”, switch off the appliance and
unplug the socket from the electric mains before cleaning or conducting
maintenance. Open the doors of the appliance.
Wait until the interior of the appliance has completely warmed up, and the
compressor cooled down, before cleaning or performing any maintenance
operation.
If the interior of the appliance is covered with a layer of frost, defrosting needs to
be carried out. Not performing this action may lead to an increase in electricity
consumption and a lessening of the effects of refrigeration.
DO NOT use electrical devices (e.g. hairdryers, heaters, radiators, fans, etc. to melt
ice), mechanical devices (sharp knives, ice-picks, etc. to scrape ice), a direct flame or
by any other means to remove ice from the interior surfaces) when defrosting.
After defrosting, clean the interior of the appliance with a soft, damp cloth. If
necessary, you can use a cloth moistened with mild liquid detergent. DO NOT use
abrasive scouring pads or powders.
Wipe the exterior of the appliance using a soft, damp cloth or sponge. Remove
stubborn spots with a cloth moistened with mild liquid detergent. DO NOT use
abrasive scouring pads or powders.
DO NOT soak the appliance in water or other liquids, wash it under the tap, or let
any liquid flow into the internal casing of the appliance to prevent electric shock
After cleaning, dry every surface using a soft cloth before restarting the appliance.
Remove dust and grime from the Condenser to keep it in good working order.
Rubbing some talcum powder on the gasket of the Freezer Door may help prolong
its life.
HOW TO CLEAN
PROBLEM SOLVING
The plug of the appliance is not inserted into the power socket.
Insert the plug into the grounded power socket and switch it
on.
The circuit breaker tripped or the fuse is blown.
Check the household circuit breaker for any tripped wires.
Call for a qualified electrician.
The Temperature Control Rotary Knob was set at too high a
temperature.
Set the Temperature Control Rotary Knob to between 3~4.
The appliance
does not work
7

Check to see whether the Temperature Control Rotary Knob is
set to 4.
External environment may require a colder temperature
setting above 4, e.g. 5.
The Freezer’s Door or Refrigerator’s Door (or both) was not
closed properly or was opened too often.
The Freezer’s Door gasket or Refrigerator’s Door gasket (or both)
does not seal properly. Send to the authorised repair centre.
The appliance was not placed with clearances around it at
10 cm. There should be at least 10 cm of free space from the
back, left & right sides and at least 30 cm from the top of the
door to allow adequate air circulation to cool the compressor.
External environment is at a hotter temperature than normal.
A large amount of food has been added into the appliance.
The Freezer’s Door or Refrigerator’s Door (or both) was not
closed properly or was opened too often.
The Freezer’s Door gasket or Refrigerator’s Door gasket (or both)
does not seal properly. Send to the authorised repair centre.
The appliance was not placed with clearances around it at
10 cm. There should be at least 10 cm of free space from the
back, left & right sides and at least 30 cm from the top of the
door to allow adequate air circulation to cool the compressor.
The appliance may not be level. Check whether the appliance
is placed on a horizontal and stable surface.
The appliance is
not cold enough
The Compressor
turns on & off
frequently
The appliance
vibrates excessively
The rattling and gurgling sounds may have come from the flow
of refrigerant inside the appliance. This is normal.
Contraction of the interior walls may result in ‘popping’or
‘crackling’ noises.
The appliance may not be level. Check whether the appliance
is placed on a horizontal and stable surface.
The appliance
makes a lot of loud
noises
The appliance may not be level. Check whether the appliance
is placed on a horizontal and stable surface.
The Freezer’s Door gasket or Refrigerator’s Door gasket (or
both) is dirty or worn out. Clean the Freezer’s Door gasket or
Refrigerator’s Door gasket (or both) or replace Freezer’s Door
gasket or Refrigerator’s Door gasket (or both) at the authorised
repair centre.
The Freezer’s Door
or Refrigerator’s
Door will not close
properly
Switch off the appliance and unplug the power cable holding it
firmly with dry hands. Ensure that the light bulb is screwed
securely in the bulb holder. Plug the power cable and switch
the appliance on (make sure at least 5 minutes had elapsed
before switching the appliance back on in order to protect the
compressor and the refrigeration system).
If the bulb still fails, replace it with an‘E14 screw-cap type
15 Watt’ bulb.
The Light Bulb fails
8

The manufacturer provides warranty of 2 years, in accordance with the legislation of
the customer’s own country of residence, starting from the date on which the
appliance is sold to the end user. The warranty on the Compressor is 10 years, subject
to the same conditions as above.
The warranty covers defects in material and workmanship.
The repairs under warranty may only be carried out by an authorised service centre.
When making a claim under the warranty, the original bill of purchase (with purchase
date clearly indicated) must be submitted.
The warranty will not apply in cases of:
•
•
•
•
•
•
normal wear and tear
if the steps (as laid out in the section regarding Warnings) have not been observed
e.g. overloading of the appliance, use of non-approved accessories
if the appliance has not been properly maintained, if force has been used against it
or if it has been damaged in any other way
damage caused by non-observance of the user manual or non-compliance with the
installation instructions
errors or faults owing to defects in the distribution system
if the appliance has been repaired or modified or changed in any way or by any
person not properly authorised
WARRANTY
This appliance, along with all other electronic appliances, should, when it is no longer
capable of functioning, be disposed with the least possible environmental damage
according to the local regulations in your area. In most cases you can discard the
appliance at your local recycling center.
DISPOSAL: Do not dispose this appliance as unsorted municipal waste. Collection of
such waste separately for special treatment is necessary.
Risk of child or animal entrapment
Before you discard this appliance, please remove all doors and leave the shelves inside
so that children or animals may not easily get trapped inside.
ENVIRONMENTAL TIP
9

MODEL PPF136
VALID CAPACITY 136 Litre
REFRIGERANT R600a (48g)
PRODUCT DIMENSION 470 x 490 x 1265 mm
WEIGHT 37 kg
RATED POWER 160-260V ~ 50Hz
POWER 75W
SPECIFICATION
10
