PowerSmith MAGLITHION MLMS12C User manual

A MLMS12C
COMPACT ORBITAL SANDER
Operator’s Manual
WARNING: To reduce the risk of injury, user must read and understand
this operator's manual before operating this tool.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
BATTERIES AND CHARGERS SOLD SEPARATELY

2
English
GENERAL SAFETY RULES
WARNING:
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth defects or
other reproductive harm. Some examples of these chemicals are:
• leadfromlead-basedpaints,
• crystallinesilicafrombricksandcementandothermasonryproducts,and
• arsenicandchromiumfromchemicallytreatedlumber.
Your risk from these exposures varies, depending on how often you do this type
of work. To reduce your exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such as those dust masks that
are specially designed to filter out microscopic particles.
WARNING: READ AND UNDERSTAND ALL WARNINGS, CAUTIONS AND
OPERATING INSTRUCTIONS BEFORE USING THIS EQUIPMENT. Failure to follow
all instructions listed below may result in electric shock, fire and/or serious
personal injury.
SAVE THESE INSTRUCTIONS
WORK AREA SAFETY:
• Keep your work area clean and well lit. Cluttered benches and dark areas invite
accidents.
• Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Power tools create sparks which may ignite the
dust or fumes.
• Keep bystanders, children, and visitors away while operating a
power tool.Distractions can cause you to lose control.
ELECTRICAL SAFETY
•Powertoolplugsmustmatchtheoutlet.Never modify the plug in any way. Do
not use any adapter plugs in any earthed (grounded) power tools. Double insulated tools are
equipped with a polarized plug (one blade is wider than the other). This plug will fit in a polarized
outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not
fit, contact a qualified electrician to install a polarized outlet. Do not change the plug in any way.
Double insulation eliminates the need for the three wire grounded power cord and grounded
power supply system.
•Donotexposepowertoolstorainorwetconditions.Water entering a
power tool will increase the risk of electric shock.
•Avoidbodycontactwithearthedorgroundedsurfacessuchas
pipes, radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is grounded.

3
English
•Donotabusethecord.Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged cords increase the
risk of electric shock.
•Whenoperatingapowertooloutside,useanextensioncordsuitable
for outdoor use. These cords are rated for outdoor use and reduce the risk of electric
shock.
•DonotuseAConlyratedtoolswithaDCpowersupply.While the tool may
appear to work. The electrical components of the AC rated tool are likely to fail and rate a hazard
to the operator.
PERSONAL SAFETY
•Stayalert,watch what you are doing and use common sense when operating a power tool.
Do not use tool while tired or under the influence of drugs, alcohol, or medication. A moment of
inattention while operating power tools may result in serious personal injury.
•Usesafetyequipment.Always wear eye protection. Safety equipment such as dust
mask,non-skidsafetyshoes,hardhat,orhearingprotectionforappropriateconditionswillreduce
personal injuries.
•Dressproperly.Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewelry or long hair can be caught in moving parts. Air
vents may cover moving parts and should be avoided.
•Avoidaccidentalstarting.Ensure the switch is in the off position before plugging in.
Carrying power tool with your finger on the switch or plugging in power tools that have the switch
on invites accidents.
•Removeanyadjustingkeysorwrenchesbeforeturningthepower
tool on. A wrench or key that is left attached to a rotating part of the tool may result in
personal injury.
•Donotoverreach.Maintain proper footing and balance at all times. Loss of balance can
cause an injury in an unexpected situation.
•Ifdevicesareprovidedforconnectionofdustextractionand
collection facilities, ensure these are connected and properly used.
Use of these devices can reduce dust related hazards.
•Donotusealadderorunstablesupport.Stable footing on a solid surface
enables better control of the tool in unexpected situations.
•Keeptoolhandlesdry,cleanandfreefromoilandgrease.Slippery
handles cannot safely control the tool.
TOOL USE AND CARE
•Securetheworkpiece.Use clamp or other practical way to hold the work piece to a
stable platform. Holding the work piece by hand or against your body is unstable and may lead to
loss of control.
•Donotforcethepowertool.The tool will perform the job better and safer at the feed
rate for which it is designed. Forcing the tool could possibly damage the tool and may result in
personal injury.

4
English
•Usethecorrectpowertoolforthejob.Don’t force the tool or attachment to do a
job for which it is not designed.
•Donotusetoolifswitchdoesnotturnitonoroff.Any tool that cannot be
controlled with the switch is dangerous and must be repaired or replaced by an authorized service
center.
•Turnpowertooloff,anddisconnecttheplugfrom the power source and/or
battery pack from the power tool before making any adjustments, changing the accessories, or
storing the tools. Such preventive safety measures reduce the risk of an accidental start up which
may cause personal injury.
•Storeidletoolsoutofreachofchildrenandotherinexperienced
persons. It is dangerous in the hand of untrained users.
•Maintainpowertoolswithcare.Check for proper alignment and binding of moving
parts, component breaks, and any other conditions that may affect the tool’s operation. A guard
or any other part that is damaged must be properly repaired or replaced by an authorized service
center to avoid risk of personal injury.
•Userecommendedaccessories.Using accessories and attachments not
recommended by the manufacturer or intended for use on this type tool may cause damage to
the tool or result in personal injury to the user. Consult the operator’s manual for recommended
accessories.
•Keepcuttingtoolssharpandclean.Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
•Feedtheworkpieceinthecorrectdirectionandspeed.Feed the work
piece into a blade, cutter, or abrasive surface against the direction of the cutting tool’s direction of
rotation only. Incorrectly feeding the work piece in the same direction may cause the work piece to
be thrown out at high speed.
•Neverleavethetoolrunningunattended,turnthepoweroff.Do not
leave the tool until it comes to a complete stop.
•Neverstartthepowertoolwhenanyrotatingcomponentisin
contact with the work piece.
BATTERY TOOL USE AND CARE
• Ensure the switch trigger is in the off position before inserting
battery pack. Inserting the battery pack into power tools that have the switch on invites
accidents.
• Recharge only with the charger specified by the manufacturer. A
charger that is suitable for one type of battery pack may create a risk of fire when used with
another battery pack.
• Use battery tools only with specified battery pack. Use of any other battery
packs may create a risk of injury and fire.
• Avoid storing battery pack in a container with other metal objects
such as nails, coins, clips, keys, screws, or other small metal objects that can make a connection
from one terminal to another. Always protect the battery terminals when battery pack is not being
used. Connecting the battery terminals together may cause burns or a fire.

5
English
• Under abusive conditions, liquid may be ejected from the battery.
Avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the battery may cause irritation or burns.
• Battery tools do not need to be plugged into an electrical outlet,
therefore, they are always in operation condition. Be aware of possible hazards when not using
your battery tool or when changing accessories. Following this rule will reduce the risk of electric
shock, fire or personal injury.
WARNING: USE OF THIS TOOL CAN GENERATE AND DISBURSE DUST OR
OTHER AIRBORNE PARTICLES, INCLUDING WOOD DUST, CRYSTALLINE SILICA
DUST AND ASBESTOS. Direct particles away from face and body. Always operate
tool in a well-ventilated area and provide for proper dust removal. Use dust
collection system wherever possible. Exposure to the dust may cause serious and
permanent respiratory or other injury, including silicosis (a serious lung disease),
cancer, and death. Avoid breathing the dust, and avoid prolonged contact with
the dust. Allowing dust to get into your mouth or eyes, or lay on your skin may
promote absorption of harmful material. Always use properly fitting NIOSH/OSHA
approved respiratory protection appropriate for dust exposure, and wash exposed
areas with soap and water.
SERVICE
• Have Your Power Tool Serviced by a qualified repair person using
only identical replacement parts. This will ensure that the safety of the power tool
is maintained.
WARNING: READ AND UNDERSTAND ALL WARNINGS, CAUTIONS AND
OPERATING INSTRUCTIONS BEFORE USING THIS EQUIPMENT. Failure to follow
all instructions listed below may result in electric shock, fire and/or serious
personal injury.
SAVE THESE INSTRUCTIONS

6
English
SPECIFIC SAFETY RULES FOR YOUR CORDLESS ORBITAL
SANDER
WARNING: DO NOT let comfort or familiarity with this tool (gained from
repeated use) replace strict adherence to safety rules. If you use this tool unsafely
or incorrectly, you can suffer serious personal injury!
•BeAwarethatthistoolisalwaysinanoperatingcondition, because it
does not have to be plugged into an electric outlet.
•Alwaysholdthetoolrmlyinyourhandsbeforeswitchingthetool
“ON”. The reaction to the torque of the motor as it accelerates to full speed may cause the tool
to twist.
•Weareyeandhearingprotection.Always use safety glasses with side shields.
Unless otherwise specified, everyday glasses provide only limited impact resistance, they are not
safety glasses. Use only certified safety equipment; eye protection equipment should comply with
ANSI z87.1 standards. Protective hearing equipment should comply with ANSI s3.19 standards.
•Protectyourlungs. Wear a face or dust mask if the operation is dusty. Following this rule
will reduce the risk of personal injury.
•Alwaysdisconnectbatterypackfromtoolor place the switch in the locked or
off position before any assembly, adjustments or changing accessories. Following this instruction
will reduce the risk of serious personal injury.
•Useonlyaccessoriesratedforthespeedrecommendedonthetool
warning label or higher. Some accessories running at speeds greater than rated can fly
apart and cause personal injury.
•Donotplacebatterytoolsortheirbatteriesnearreorheat.This will
reduce the risk of explosion and possibly personal injury.
•Neveruseabatterywhichhasbeendroppedorreceivedasharp
blow. A damaged battery is subject to explosion. Properly dispose of a dropped or damaged
battery immediately.
•Usedesignatedbatterypack(PowerSmithMagLithion™-Model
MLAB12)andcharger(PowerSmith™MagLithion-ModelMLACH12)
for this tool. Use of any other batteries may result in a risk of fire.
WARNING: Read and understand safety and operating instructions of
designated battery and charger before using this tool. This manual contains
important safety and operating instruction for battery charger.
SAVE THESE INSTRUCTIONS

3
2
1
4
7
English
SPECIFICATIONS:
•Model: MLMS12C
•Motor: 12V DC
•No Load Speed: 10,000 RPM
•Orbit Diameter: 1/16" (1.6mm)
•Includes: Sander, Sandpaper assortment (1)80 grit ,(1)120 grit and (1)240 grit.
COMPACT ORBITAL SANDER
1. ON/OFF Switch
2. Hook and Loop Quick Attaching Pad
3. Air Vents
4. Rubberized Palm Grip
Unpacking and Content
Contents in Package:
Description QTY
Sander 1
Sandpaper 3
Manual & Other Instruction 1

8
English
OPERATION
WARNING: To reduce the risk of serious personal injuries, read and follow
all important safety warning and instructions before using this tool.
WARNING: Always disconnect battery pack from tool or place the switch
in the locked or off position before any assembly, adjustments or changing
accessories.
ATTACHING SANDPAPER, SCRUBBING PAD (NOT INCLUDED) AND
POLISHING PAD (NOT INCLUDED)
The sander comes with a Hook and Loop Quick attaching pad. Align the pointed tip and rounded edge
of this sandpaper or a pad with the pointed tip and rounded edge of the Hook and Loop pad. Carefully
press the fuzzy side of the sandpaper against the pad as tightly as possible.
NOTE:Sandpaper can be reused for the life of the sanding abrasive. It is
recommended that you keep the sandpaper backing pad clean to provide for the
best adhesion. Clean occasionally by brushing backing sandpaper lightly with a
small brush.
To remove sandpapers and pads, simply pull the used sandpaper off the Hook & Loop base
and attach the desired sandpaper by pressing it onto the base of the sander.
SWITCH ACTION
CAUTION: Before insertion of battery pack, always check to see that the tool is
switched off.
The switch can be locked in "ON" position for ease of operator comfort during extended use. Apply
caution when locking tool in "ON" position and maintain a firm grasp on the tool. Your sander is equipped
withaexibleplasticbootthatcoversthe"ON/OFF"switch;thisisreferredtoasa"dust-protected
switch". It is not uncommon for sanders to collect large amounts of airborne sawdust in the switch area,
which,ifnotclearedout,maycausetheswitchtobecomenon-functional.Thedustprotectedswitch,on
the other hand, can not accumulate dust in the switch area.
To start the sander, press down the "I" (ON) side of the switch.
To stop the tool, press down the "O" (OFF) side of the switch.
OPERATING
WARNING: Read and understand safety and operating instructions of
designated battery and charger before using this tool. This manual contains
important safety and operating instruction for the battery charger.
•Insertthebatterypack.
• Securetheworkpiecebyclamporotherdevicetopreventitfrommovingunderthesander.
• Graspsandertightlyinfrontandawayfromyou;keepitclearoftheworkpiece.Turnonsanderand
let motor build to its maximum speed. Slowly lower the sander onto the work piece. Move the sander
slowly across the work piece using small circular motions.

9
English
Do not force the tool. Let it do the work. Light pressure is all that is required for sanding, polishing
and scrubbing. Excessive pressure will slow the motor, rapidly wear sandpaper, reduce sander speed
and produce inferior results. Any finish or resin on wood may soften from frictional heat. Do not sand on
one spot for too long, as sander may remove too much material, making your surface uneven.
Extensive periods of sanding may tend to overheat the motor. If it this occurs, turn
sander off and wait until sandpaper comes to a complete stop, then remove it from the work piece,
remove the battery pack and let it cool down before using it again.
CAUTION:To avoid damaging the motor from overheating, be careful not to let
your hand cover the air vents.
For detail sanding such as corners and crevices, use the tip of the sanding pad with small
back and forth motions.

10
English
IMPORTANT SAFETY INSTRUCTIONS FOR
CHARGER & BATTERY OPERATION
NOTE: Battery and Charger Sold Separately.
BATTERY CHARGER
•SaveTheseInstructions.This manual contains important safety and operating instruction
for your battery charger.
•BeforeUsingthebatteryCharger,read all instructions and cautionary markings on (1)
Battery Charger, (2) Battery , and (3) Product using battery.
•Anextensioncordshouldnotbeusedunlessabsolutelynecessary.Use
of improper extension cord could result in a risk of fire and electric shock. If extension cord must be
used. Make sure:
a) The pins on plug of extension cord are the same number size, and shape as
those of plug on charger.
b) That extension cord is properly wired and in good electrical condition.
c) That wire size is at least as large as the one specified in the table below:
Cord Length (Feet) 25 ft. 50 ft. 100 ft.
Cord Size (AWG) 16 16 16
NOTE: AWG=American Wire Gauge
•Useonlythechargerwhich accompanied your product or direct replacements as listed in this
manual. Do not substitute any other charger.
•Donotrechargebatteryindamporwetenvironments.Do not expose battery
pack to water or rain.
•Donotoperatechargerwithdamagedcordorplug.Replace immediately.
•Donotoperatechargerifithasreceivedasharpblow, been dropped or
otherwise damaged in any way. Take it to a qualified serviceman.
•Donotdisassemblechargerorbatterypack.Take it to a qualified serviceman
when service or repair is required. Incorrect reassembly may result in a risk of electric shock or fire.
•Donotchargebatterypackwhen temperature is below 50 degrees F (10 degrees C) or
above 104 degrees F (40 degrees C). Store tool and battery pack in a location where temperature will
not exceed 122 degrees F (50 degree C). This is important to prevent serious damage to the battery
cells.
•Placechargeronatnon-ammablesurfaceand away from flammable materials
whenre-chargingthebatterypack.
•Toreduceriskofelectricshock,unplug charger from outlet before attempting any
maintenance or cleaning.
•Ifoperatingtimehasbecomeexcessivelyshorter,stop operating immediately. It
may result in a risk of overheating, possible burns and even an explosion.
•Batteryleakagemayoccurunder extreme usage or temperature conditions. Avoid contact
with skin and eyes. If liquid comes in contact with your skin, wash immediately with soap and water.
If liquid gets into your eyes, wash them out with clear water for at least 10 minutes, and then seek
medical attention right away.

BATTERY PACK
CHARGER GREEN LIGHT
RED LIGHT
11
English
•Donotattempttouseastep-uptransformer,an engine generator or DC power
receptacle.
•Donotshortthebatterypack.Do not touch the terminal with any conductive material.
Avoid storing battery pack in a container with other metal objects such as nails, coins, etc. Always
protect the battery terminals when battery pack is not used.
•Donotchargebatterypackinsideaboxorcontainerofanykind.The
battery must be placed in a well ventilated area during charging.
•Donotallowanythingtocoverorclogthechargervents.
•Donotincineratethebatterypackevenif it is severely damaged or is completely worn
out. The battery pack can explode in a fire.
•DisconnectChargerfromthepowersourcewhennotinuse.This will reduce
the risk to electric shock or damage to the charger if metal pieces should fall into the opening. It also
will help prevent damage to the charger during a power surge.
WARNING: Abatteryshortcancausealargecurrentow,overheating,
possible burns and even a breakdown.
WARNING: 120 volts are present at charging terminals, do not probe with
conductive objects. Electric shock or electrocution may result. Do not allow any
liquid to get inside charger. Electric shock may result.
OPERATION
NOTE:Always Check that the power supply corresponds to the voltage on the
ratings plate on your charger.
CHARGING WITH THE DIAGNOSTIC CHARGER
NOTE: Newly purchased batteries are not fully charged and must be charged
before using in your cordless tool(s).
1. Plug the battery charger into the proper AC voltage source. A steady GREEN light will illuminate
indicating charger is connected to a proper power source.
2. Insert the battery pack so that the ribs on the battery pack slide into the grooves on the battery charger.
Insert the battery pack fully into the charger.
3. When the battery pack is inserted, the GREEN charging light will flash indicating the charger has started
the charging cycle. A steady GREEN light indicates the battery is completely charged and should be
removed from the charger.

12
English
4. "A steady RED light after inserting the battery" indicates the battery is too warm to be charged. Once
the battery has cooled, the RED light will go off and the flashing GREEN light will illuminate indicating
the charge cycle has begun.
5. "A RED Light Flashing after inserting the battery" indicates that (1) battery pack has a bad
connection with charger, press the battery into the charging slot a little more to make sure the battery
is fully engaged with charger. OR (2) the battery is defective and needs to be replaced. Please
dispose of the defective battery in the method explained in this manual.
6. After charging, unplug the charger from the power source.
Tips for extending Battery life: Do not store batteries completely discharged. Charge them fully
before storing.
WARNING: Always be sure that the tool is switched off before insertion or
removal of the battery pack.
INSTALLING OR REMOVING BATTERY PACK
• To remove the battery pack, withdraw it from the tool while depressing the tabs on
both sides of the pack.
• To insert the battery pack, align the ribs on the top of the battery with the grooves in the
housing and slide it into place. Always insert it all the way until it locks in place with a little click.
Lightly pull on the battery pack to ensure it is locked into place and will not accidentally fall out of the
drill, causing an injury.
• Do not use force when inserting the battery pack. If the battery does not slide in
easily, it is not being inserted correctly.
IMPORTANT BATTERY INFORMATION: DISPOSING THE BATTERY PACK
• YourbatteriesareLITHIUM-IONrechargeablebatteries.CertainLocal,Stateand  
Federal laws prohibit disposal of these batteries in ordinary trash.
• Consultyourlocalwasteauthoritiesforyourdisposal/recyclingoptions.
• MoreinformationregardingbatterydisposalinU.S.andCanadaisavailableat;
 http://www.rbrc.org/index.html,orbycalling1-800-822-8837(1-800-8BATTERY).
TWO-YEAR WARRANTY
This product is warranted free from defects in material and workmanship for 2 years after date of
purchase. This limited warranty does not cover normal wear and tear or damage from neglect or accident.
The original purchaser is covered by this warranty and it is not transferable. Prior to returning your tool to
storelocationofpurchase,pleasecallToll-FreeHelpLineforpossiblesolutions.THIS PRODUCT IS NOT
WARRANTED IF USED FOR INDUSTRIAL OR COMMERCIAL PURPOSES.
TOLL-FREE HELP LINE
ForquestionsaboutthisoranyotherPowerSmithMagLithion™product,pleasecallToll-Free:
888-552-8665. Or visit our website: www.maglithion.com
©Richpower Industries, Inc. All Rights reserved
Richpower Industries, Inc.
736 Hampton Road
Williamston, SC 29697 Printed in China, on recycled paper

A MLMS12C
PONCEUSE ORBITALE COMPACTE
Manuel de l’opérateur
AVERTISSEMENT : Pour réduire le risque de blessure, l’utilisateur doit lire et
doit comprendre ce manuel de l’opérateur avant de fonctionner cet outil.
CONSERVER CE MANUEL POUR FUTURE RÉFÉRENCE
BATTERIES ET CHARGEURS VENDU SÉPARÉMENT

14
Français
RÈGLES GÉNÉRALES DE SÉCURITÉ
AVERTISSEMENT:
Certaines poussières produites par des appareils électriques de ponçage, sciage,
meulage, perçage et autres travaux de construction contiennent des produits
chimiques connus pour causer cancer, anomalies congénitales et autres atteintes à
la reproduction. Voici quelques exemples de ces produits nocifs :
• plombdespeinturesauplomb,
• silicecristallinedesbriquesetdubétonetd’autresmatériauxdeconstruction,
• arsenicetchromedeboisd’œuvretraitéchimiquement.
Votre risque en cas d’exposition varie, selon la fréquence d’exécution de ce type
de tâches. Pour réduire votre exposition à ces produits : travaillez dans une zone
bien ventilée en portant un équipement de sécurité approuvé, tel que masque à
poussières spécialement conçu pour filtrer les particules microscopiques.
AVERTISSEMENT: LISEZ ET ASSIMILEZ TOUS LES AVERTISSEMENTS,
MISES EN GARDE ET INSTRUCTIONS D’UTILISATION AVANT DE VOUS SERVIR
DE CET ÉQUIPEMENT. Sinon vous risquez commotion électrique, début
d’incendie et/ou blessures corporelles.
CONSERVEZ CES INSTRUCTIONS
LIEU DE TRAVAIL:
• Gardez propre la zone de travail. Leszonesetétablisendésordreattirentles
accidents.
•Nepasutiliserd’outilsélectriquesdansdesatmosphèresexplosives,
parexempleenprésencedeliquidés,gazoupoussièresinammables.Lesoutilsélectriques
produisentdesétincellesrisquantd’enammerlespoussièresouvapeurs.
•Garderlesbadauds,enfantsetvisiteursàl’écartpendantl’utilisation
d’un outil électrique. Les distractions peuvent causer une perdre le contrôle.
SÉCURITÉ ÉLECTRIQUE
• La puissance des bouchons outil doit correspondre à la prise
électrique. Ne jamais modifier la prise en aucune façon. Ne pas utiliser d'adaptateur de
bouchonsdanstoutelaterre(laterre)lesoutilsélectriques.Lesoutilsàdoubleisolationsontéquipés
d’unechepolarisée(unebrocheestpluslargequel’autre)..Cettechenepeutêtrebranchée
suruneprisepolariséequedansunseulsens.Silachenepeutpasêtreinséréedanslaprise,
l’inverser.Sivousnepouveztoujourspasêtrel’insérer,faireinstalleruneprisepolariséeparun
électricienqualié.Nepasmodierlache,dequelquefaçonquecesoit.Ladoubleisolation
éliminelebesoindecordond’alimentationàtroislsetd’uncircuitsecteurmisàlaterre.
•NEPASexposerlesoutilsélectriquesàlapluieoul’humidité. La
pénétrationd’eaudanscesoutilsaccroîtlerisquedechocélectrique.
•Évitertoutcontactducorpsavecdessurfacesmisesàlaterre,telles
quetuyaux,radiateurs,cuisinièresetréfrigérateurs.Lerisquédechocélectriqueestaccrulorsquele
corpsestmisàlaterre.

15
Français
•NEPASmaltraiterlecordond’alimentation.Ne jamais utiliser le cordon
d’alimentationpourtransporterl’outiletnejamaisdébranchercedernierentirantsurlecordon.
Garderlecordonàl’écartdelachaleur,del’huile,desobjetstranchantsetdespiècesen
mouvement.Remplacerimmédiatementtoutcordonendommagé.Uncordonendommagéaccroîtle
risqued’électrocution.
•Lorsquel'exploitationd'unpouvoirendehorsdesoutils, l'utilisation d'une
rallongeélectriquepouruneutilisationextérieure.Cescordonssontprévuspouruneutilisationà
l'extérieuretderéduirelerisquedechocélectrique.
•NEPASutiliserl'ACnotéeslesoutilsd'unealimentationencourant
continu. Mêmesil'outilsemblefonctionner,lescomposantsélectriquesdel'ACnotéesoutilsont
susceptiblesd'échoueretd'accroîtrelerisquepourl'opérateur.
SÉCURITÉ PERSONNELLE
• Rester attentif, prêter attention au travail et faire prévue de bon sens
lors de l’utilisation de tout outil électrique. Nepasutilisercetoutilenétatde
fatigueousousl’inuencedel’alcool,dedroguesoudemédicaments.Unmomentd’inattention
pendantl’utilisationd’unoutilélectriquepeutentraînerdesblessuresgraves
•Utiliserl’équipementdesécurité.Toujoursporteruneprotection
oculaire. Suivantlesconditions,leportd’unmasqueltrant,dechaussuresdesécurité,d’un
casqueoud’uneprotectionauditiveestrecommandé.
•Portezunetenueappropriée.Neportezpasdevêtementsottants,gants,cravate,
bracelets,montredepoignetouautresbijouxquipeuventêtrehappéspardespiècesen
mouvement.Leportdechaussuresantidérapantesestrecommandé,ainsiqueleportd’une
couverture des cheveux s’ils sont longs..
•Évitezd'undémarrageaccidentel.S'assurer que le commutateur est en position
arrêtavantdebrancherpo.Detransportoutilavecledoigtsurl'interrupteuroudebrancherdes
outilsélectriquesquisontlecommutateurinviteaccidents.
•Enlevezlesclésetoutilsderéglageavantdemettreenmarche. Les
clés,clavettes,déchetsetautresdébrispeuventêtreprojetésàgrandevitesse,etainsicauserdes
graves blessures..
•NEtravaillezpasàboutdebras.Gardezunebonnepostureetunbonéquilibreen
permanence,undéséquilibrepeutamenervotrechutesurlamachineenaction,avecpossibilitéde
blessure.
•SIdispositifssontprévuspourlaconnexiond'extractiondes
poussières et des installations de collecte, d'assurerceux-cisontconnectés
etutiliséscorrectement.L'utilisationdecesappareilspeutréduirelesrisquesliésàlapoussière.
Nepasutiliserl’outilsuruneéchelleouunsupportinstable.Unebonnetenueetunbonéquilibre
permettentdemieuxcontrôlerl’outilencasdesituationimprévue.
•Maintenezl’outilsec,propreetsanshuileougraisse.Utilisez toujours un
chiffonproprepourlenettoyage.N’utilisezjamaisdeuidepourfreins,d’essence,deproduitsà
basedepétrole,nin’importequeltypedesolvantpournettoyerl’outil.
UTILISATION ET ENTRETIEN DE L’OUTIL
• Sécurisation de la pièce à travailler. Utilisezdesserre-jointsouunétaupour
maintenirlapiècetravailléequandc’estpossible.C’estplussûrquedeseservirdesaousesmains

16
Français
etpermetdegardersesdeuxmainslibrespouractionnerl’outil.Lapertedecontrôledelapièce
travailléepeutentraînerdesblessurescorporelles.
• NE forcez pas sur l’outil. L’outileffectueralatâchedefaçonmeilleureetplussûre
àlavitessedepénétrationpourlaquelleilaétéconçu.Forcersurl’outilpeutéventuellement
endommagerlamachineetentraînerdesblessures.
•Utilisezlebonoutilpourlatâche.Ne forcez pas sur l’outil ou accessoire pour
exécuterunetâchepourlaquelleiln’apasétéconçu.N’utilisezpasl’outilpourunenaliténon
prévuecarvousrisquezdesdégâtsmatérielset/oudesblessurescorporelles.
•N’utilisezpasl’outilsisoninterrupteurdemarche/arrêtfonctionne
mal. Faitesimmédiatementremplacerlesinterrupteursdéfectueuxparuncentrederéparations
agréé.
•Débrancherl’outilavantd’effectuerdesréglages, de changer d’accessoire
ouderangerl’outil.Cesmesuresdesécuritéréduisentlesrisquesdedémarrageaccidentelde
l’outil.
•Rangerlesoutilsnonutiliséshorsdeportéedesenfantsetdes
personnes n’ayant pas reçu de formation adéquate. Entre les mains de
personnesn’ayantpasreçudeformationadéquate,lesoutilssontdangereux.
•Entretenirsoigneusementlesoutils.Vérierqu’aucunepiècemobilen’estmal
alignée,grippéeoubriséeets’assurerqu’aucunautreproblèmenerisquéd’affecterlebon
fonctionnementdel’outil.Encasdedommages,faireréparerl’outilavantdel’utiliserdenouveau.
Denombreuxd’accidentssontcauséspardesoutilsmalentretenir.
•N’utilisezquedesaccessoiresrecommandés.L’utilisation d’accessoires et
équipementsannexesnonrecommandésparleconstructeurounonprévuspourêtreutiliséssur
cetyped’outilpeutcauserdesdégâtsmatérielset/oudesblessurescorporellespourl’utilisateur.
Consultezlemanueld’utilisationpourconnaîtrelesaccessoriesrecommandés.
•Maintenirdesoutilsdecoupenetteetpropre.Bien entretenu avec des outils
decoupedepointesontmoinssusceptiblesdelieretsontplusfacilesàcontrôler.
•Poussezlapièceàtravaillerdanslabonnedirectionàlabonne
vitesse. N’envoyezlapièceverslalamelecouteauoulasurfaceabrasive,selonlamachine,
queensensopposéàlarotationdel’outildecoupe.Unemauvaiseprésentationdelapiècedans
lemêmesensquelarotationdel’outildecoupefaitquelapièceestprojetéeàgrandevitesse.
•NEjamaislaisserl'outilenmarchesanssurveillance.Éteignez l'appareil. Ne
laissezpasl'outiljusqu'àcequ'ilarriveàunarrêtcomplet.
•NEdémarrezjamaisunoutilquanduncomposantrotatifestdéjàen
contact avec la pièce travail lée.
UTILISATION ET ENTRETIEN DES OUTILS À BATTERIE
• Veillez à ce que l’interrupteur soit dans la postion de fermeture avant
d’insérerlablocdebatterie.l’insertiond’unblocdebatteriedansunoutilélectroportatifdon’t
l’interrupeur est dans la position de marche est une invites aux accidents.
• Rechargez avec le chargeur spécifié par le fabricant. Un chargeur qui
convientàuntypedebatteriecréerunrisqued'incendielorsqu'ilestutiliséavecuneautre
batterie

17
Français
• Utilisez uniquement des outils électriques conçus spécifié batterie.
L'utilisationd'autresbatteriescréerunrisquedeblessuresetd'incendie.
• Évitez de stocker la batterie dans un conteneur avec d'autres objets
métalliquestelsquedesclous,despiècesdemonnaie,pinces,clés,visouautrespetitsobjets
métalliquesquipeuventfaireuneconnexionàpartird'unterminalàunautre.Toujoursprotéger
lesbornesdelabatterielorsquelabatterien'estpasutilisée.Lecourt-circuitagedelabatteriedu
terminalsprovoquerdesbrûluresouunincendie.
• Dans des conditions abusives,duliquidepeutêtreéjectédelabatterie,évitertout
contact, si un contact accidentel se produit, rincer avec de l'eau, liquide Si les contacts des yeux,
deplus,chercherdel'aidemédicale.Liquideéjectédelabatteriepeutprovoqueruneirritationou
desbrûlures.
• Les outils fonctionnant sur batteries n’ayant pas besoin d’être
branchés sur une prise secteur;ilssonttoujoursenétatdefonctionnement.Tenir
compte des dangers possibles lorsque l’outil n’est pas en usage et lors du remplacement des
batteries.Lerespectdecetterègleréduiralesrisquesd’incendie,dechocélectriqueetde
blessures graves.
AVERTISSEMENT: L’UTILISATION DE CET OUTIL PEUT GÉNÉRER ET
BRASSER DE LA POUSSIÈRE ET D’AUTRES PARTICULES EN SUSPENSION DANS
L’AIR,COMMESCIURE,SILICECRISTALLINEETAMIANTE.Dirigezleotde
particules hors de votre visage et de votre corps. Faites toujours fonctionner l’outil
dans une zone bien ventilée, et veillez à une bonne évacuation de la poussière.
Utilisez un système de collecte de poussières dans la mesure du possible.
L’exposition aux poussières peut causer des troubles respiratoires ou autres
sérieux et permanents, incluant la silicose (une sérieuse affection des poumons),
le cancer et la mort. Évitez de respirer la poussière et évitez un contact prolongé
avec elle. Si vous laissez entrer la poussière dans votre bouche ou vos yeux, ou
se déposer sur votre peau, vous risquez de provoquer l’absorption de matières
dangereuses. Portez toujours une protection respiratoire approuvée NIOSH/OSHA
bien ajustée convenant à la protection contre les poussières, et lavez les surfaces
de peau exposées à l’eau et au savon.
SERVICE
•Demandezàvotreoutilélectriqueàêtredesservieparunepersonne
qualifiée en utilisant uniquementdespiècesidentiques.Celapermettrades'assurerque
lasécuritédel'outilélectriqueestmaintenue.
AVERTISSEMENT: LISEZ ET ASSIMILEZ TOUS LES AVERTISSEMENTS,
MISES EN GARDE ET INSTRUCTIONS D’UTILISATION AVANT DE VOUS SERVIR
DE CET ÉQUIPEMENT. Sinon vous risquez commotion électrique, début d’incendie
et/ou blessures corporelles.
CONSERVEZ CES INSTRUCTIONS

18
Français
RÈGLES DE SÉCURITÉ SPÉCIFIQUES POUR PONCEUSES
ORBITALE ALIMENTÉ PAR LA BATTERIES
AVERTISSEMENT: NE laissez PAS une fausse sécurité à la suite de
notions provoquées par tout confort et familiarité avec le produit (suite à des
utilisations répétées) remplacer la stricte application des règles de sécurité. Si
vous utilisez cet outil dangereusement et incorrectement, vous pouvez subir de
sérieuses blessures!
• Garder à l’esprit que cet outil est toujours prêt à fonctionner, parce qu’il
n’apasbesoind’êtrebranchésurunepriseélectrique.
• Toujourstenirl'outilfermementdansvosmainsavantdemettre
l'outilsurlaposition«ON».Laréactionaucoupledumoteurcarilaccélèreàpleine
vitesse peut causer de l'outil de tourner.
• Portez une protection des yeux et oreilles.Utiliseztoujoursdelunettesdesécurité
avecécranslatéraux.Saufsuraviscontraire,leslunettesdetouslesjoursneprésententqu’une
résistancelimitéeauximpacts,cenesontPASdeslunettesdeprotection.Utilisezunéquipementde
sécuritécertié.LaprotectionoculairedoitêtreconformeauxnormesANSIZ87.1.L’équipementde
protectiondel’auditiondoitêtreconformeauxnormesANSIS3.19.
• Protection respiratoire.Porterunmasquefacialouunmasqueanti-poussièresiletravail
produitdelapoussière.Lerespectdecetterègleréduiralesrisquesdeblessuresgraves.
• Toujours débrancher bloc de batterie de l'outil ou du lieu de la interrupteur dans
lapositionverrouilléeouARRÊTavantd'effectuertoutlemontage,deréglagesoudechanger
d'accessoires.Suiteàcetteinstructionderéduirelerisquedeblessuregrave.
• Utiliser uniquement les accessoires prévuspourlavitesserecommandéesur
l'étiquetteoul'outild'alerteplusélevé.Certainsaccessoiresfonctionnantàunevitessenominale
supérieureàl'exceptionpeutvoleretcauserdesblessures.
• Ne pas placer les outils électriques sans fil ou leurs batteriesàproximité
deammesoud’unesourcedechaleur.Ceciréduiralesrisquesd’explosionetdeblessures.
• Ne jamais utiliser une batterie qui a été endommagée ousoumiseàun
chocviolent.Unebatterieendommagéerisqued’exploser.Éliminerimmédiatementtoutebatterie.
• Utilisez désigné bloc de batteries (PowerSmithMagLithion™-Modèle:
MLAB12)etlechargeur(PowerSmithMaglithion™-Modèle:MLACH12) pour
cetoutil.L'utilisationd'autresbatteriespeutrésultatunrisqued'incendie.
AVERTISSEMENT: Lire et comprendre les instructions de sécurité
etdefonctionnementdelabatterieetlechargeurdésignéavantd'utilisercet
outil. Ce manuel contient d’importantes instructions relatives à la sécurité et au
fonctionnement du chargeur de batteries.
CONSERVEZ CES INSTRUCTIONS

3
2
1
4
19
Français
CARACTÉRISTIQUES:
•Modèle:   MLMS12C
•Moteur: 12V C.C.
•VitesseàVide:   10,000OPM
•DiamètreOrbital:  1,6mm(1/16po)
•Inclut: Ponceuse, un assortiment de papiers de verre: (1) grain 80,(1) grain 120, & (1) grain 240
PONCEUSE ORBITALE COMPACTE
1.InterrupteurMARCHE/ARRÊT
2. Coussinet À Boucles et Crochets
3.LesOuïesD’aération
4.GripCaoutchoutéDePalme
OUVERTURE DE L`EMBALLAGE ET CONTENU
Contenu de carton de pièces en vrac :
Description QUAN
Ponceuse 1
papiers de verre 3
Manueldel’opérateur   1

20
Français
CONSIGNES DE FONCTIONNEMENT
AVERTISSEMENT: Pour réduire le risque de graves blessures corporelles,
lisezetsuiveztouteslesinstructionsetavertissementsdesécuritéavantd'utiliser
cet outil.
AVERTISSEMENT: Toujoursdébrancherblocdebatteriedel'outiloudu
lieudelainterrupteurdanslapositionverrouilléeouàl'extérieuravantd'effectuer
toutlemontage,deréglagesoudechangerd'accessoires.
INSTALLATION DES PAPIER DE VERRE, ET DES TAMPONS À RÉCURER (NON
INCLUS) / À POLIR (NON INCLUS).
L'outilestlivréaveccrochetetbouclerapideattachéspad.Alignerlespointesetlesbordsarrondisde
lafeuilleabrasivesurceuxducoussinetàbouclesetcrochets.Pressersoigneusementlafaceàboucles
delafeuilleabrasive,demanièreàl’assujettirsolidement.
REMARQUE:Les papiers peuvent être réutilisées tant que l’abrasif n’est pas usé.
Il est recommandé de garder le revêtement à boucles de la papier de verre propre
pour assurer une adhérence maximum. Le nettoyer de temps en temps avec une
petite brose.
Pour changer de papier de verre et de tampons,ilsuftderetirerlapièceuséedepapiers
et la tampons ,et de la remplacer par une autre.
FONCTIONNEMENT DE L'INTERRUPTEUR
ATTENTION:Avantd'insérerlablocdebatterie,vériertoujoursquel'interrupteur
estenposition«OFF»(Arrêt).
L'interrupteurpeutêtreverrouilléenposition«ON»(MARCHE)pourleconfortdel'opérateurenpériode
prolongéed'utilisationdel'outil.Êtreprudentlorsduverrouillagedel'outilenposition«ON»(MARCHE)
etmaintenirunefermeprisesurl'outil.Laponceuseestéquipéed'unsabotenplastiquequicouvre
l'interrupteur«ON/OFF»(MARCHE-ARRÊT).Cetteprotectionpermetd'éviterquedelapoussièrene
s'accumuledanslazonedel'interrupteuretneprovoqueladéfaillancedeceponceuse.
Pour mettre la ponceuse EN MARCHE, appuyersurlesymbole«I»(ON/MARCHE)de
l'interrupteuràbascule.
Pour ARRÊTER la ponceuse, appuyersurlesymbole«O»(OFF/ARRÊT)del'interrupteurà
bascule.
FONCTIONNEMENT
AVERTISSEMENT: Lire et comprendre la sécurité et instructions
d'utilisationdelabatterieetlechargeurdésignéavantd'utilisercetoutil.Ce
manuel contient des instructions de sécurité importantes et de fonctionnement
pour chargeur de batterie.
•Insérezleblocdebatterie.
• Assujettirlapièceàponcerpourl’immobilisersouslaponceuse.
