POWERSYS ERT-200S User manual

Feeder Remote terminal Unit
ERT-200S Manual
www.powersys.kr

2
Load Break Switch Control
ERT-200S
CONTENT
1. Product Introduction ..............................................................................................................6
1.1. Introduction RTU...............................................................................................................................6
1.2. Features...............................................................................................................................................7
2. Technical Specification ...........................................................................................................9
2.1. Control General Specification.........................................................................................................9
2.2. Environment Condition..................................................................................................................10
2.3. FRTU TECHNICAL SPECIFICATION ...............................................................................................11
2.4. Digital Process.................................................................................................................................11
2.4.1. Digital Signal Controller (DSCs) ..................................................................................................................................... 11
2.4.2. Analog/Digital Conversion................................................................................................................................................ 12
2.4.3. Function..................................................................................................................................................................................... 12
2.5. Function Block Diagram ................................................................................................................13
2.6. Fault Detect and Sectionalizing Functions.................................................................................14
2.7. Power System Measurements ......................................................................................................16
2.8. System Setting.................................................................................................................................17
2.9. Communications .............................................................................................................................18
2.10. Event Record.................................................................................................................................21
2.10.1. Event Record ........................................................................................................................................................................... 21
3. Physical Description..............................................................................................................23
4. Input/output Connector.......................................................................................................24
4.1. Modem Power supply Input.........................................................................................................25
4.2. Current Input ...................................................................................................................................25
4.3. Voltage Input ...................................................................................................................................25

3
Load Break Switch Control
ERT-200S
4.4. Remote Communication Port.......................................................................................................25
4.5. Digital Input /Output.....................................................................................................................26
4.6. DOOR Port........................................................................................................................................26
4.7. AUX. DI/DO......................................................................................................................................26
4.8. Motor Output Port .........................................................................................................................26
4.9. Power Supply Input (AC Input)....................................................................................................26
4.10. Battery Port ..................................................................................................................................27
4.11. Main Power Switch......................................................................................................................27
4.12. ETHERNET Connector .................................................................................................................27
5. Operator Control Panel ........................................................................................................28
5.1. Description .......................................................................................................................................28
5.2. Construction.....................................................................................................................................32
5.2.1. Operation.................................................................................................................................................................................. 32
5.2.2. Menu Control.......................................................................................................................................................................... 33
5.2.3. Other Control.......................................................................................................................................................................... 33
5.2.4. Fault Indication....................................................................................................................................................................... 34
5.2.5. Line Status Indication ....................................................................................................................................................... 34
5.2.6. SECTION Status...................................................................................................................................................................... 35
5.2.7. System Status.......................................................................................................................................................................... 35
5.2.8. AC/HANDLE LOCKED/GAS LOW/Battery Status ..................................................................................................... 36
5.2.9. CONSOL Port .......................................................................................................................................................................... 36
5.3. Operation Manual (LCD instruction)...........................................................................................37
5.3.1. LCD Screen............................................................................................................................................................................... 37
5.3.2. Control button........................................................................................................................................................................ 37
5.3.3. Menu structure tree............................................................................................................................................................. 38
5.4. LCD Menu Use.................................................................................................................................39
5.4.1. Initial Screen............................................................................................................................................................................ 39
5.4.2. Main Menu............................................................................................................................................................................... 40
5.4.3. Setting Menu .......................................................................................................................................................................... 41
6. Fault Indication ......................................................................................................................43
6.1. Fault Indication................................................................................................................................43

4
Load Break Switch Control
ERT-200S
6.2. Cold load PickUp.............................................................................................................................46
6.3. Operation of Inrush........................................................................................................................47
6.4. SEF (Sensitive Earth Fault) Detection..........................................................................................47
6.5. Role of the Sectionalizer(Auto Sectionalizing) .........................................................................48
6.6. Phase Loss Detection .....................................................................................................................49
6.7. Phase Sync. Check...........................................................................................................................49
7. Operation Setting..................................................................................................................50
7.1. Operation Setting ...........................................................................................................................50
7.1.1. Phase Fault Setting............................................................................................................................................................... 50
7.1.2. Ground Fault Setting ........................................................................................................................................................... 53
7.1.3. Inrush Detect Setting .......................................................................................................................................................... 55
7.1.4. FI Reset Time Setting .......................................................................................................................................................... 56
7.1.5. Line Open Setting................................................................................................................................................................. 57
7.1.6. Sync. Check Setting.............................................................................................................................................................. 58
7.1.7. Sectionalize Setting.............................................................................................................................................................. 59
7.1.8. SEF Setting ............................................................................................................................................................................... 60
7.1.9. Under Frequency Setting .................................................................................................................................................. 61
7.1.10. Over Frequency Setting ..................................................................................................................................................... 62
7.1.11. Under Voltage Setting ........................................................................................................................................................ 63
7.1.12. Over Voltage Setting ........................................................................................................................................................... 64
7.2. System Config Menu......................................................................................................................66
7.2.1. I/O Config................................................................................................................................................................................. 66
7.2.2. Communication Config ...................................................................................................................................................... 71
7.2.3. Modem Control Setting..................................................................................................................................................... 72
7.2.4. TCP Control.............................................................................................................................................................................. 73
7.2.5. DNP Parameter Setting ...................................................................................................................................................... 74
7.2.6. IEC Parameter Setting ......................................................................................................................................................... 77
7.2.7. IEC 101 Parameter Setting................................................................................................................................................ 80
7.2.8. IEC 104 Parameter Setting................................................................................................................................................ 82
7.2.9. Event ........................................................................................................................................................................................... 83
7.2.10. Time............................................................................................................................................................................................. 84
8. Display Menu .........................................................................................................................85
8.1. Monitoring and Metering .............................................................................................................86

5
Load Break Switch Control
ERT-200S
8.2. Status view .......................................................................................................................................90
8.3. Counter view....................................................................................................................................91
8.4. Alarm View.......................................................................................................................................91
This menu displays controller Fault detection....................................................................................91
8.5. System Information........................................................................................................................92
9. Event (Event Log) ..................................................................................................................93
Appendix 1. Drawings....................................................................................................................96
1) Enclosure (Control Cabinet)..........................................................................................................96

6
Load Break Switch Control
ERT-200S
1.Product Introduction
1.1.Introduction RTU
ERT-200S is embedded in Distribution Automation SF6 gas insulated load break switch (Pole
mount) control box. It receives measurement information (3 phases current & voltages) and
status information from Switch, and meters current and voltage, detects FI, Line cut, Live
line/Dead line, Unbalance,Sectionalizeroptimizedfor remote control and automation systems.
ERT-200Smonitors not only electric qualityof distribution line but also, provides Section
operation in case of fault occurring and minimize its fault area.
All events occurring in the distribution line, are saved and provides fault analysis. With using
DNP3.0 Protocol, provides monitored status to SCADA for switch operation. Not only DNP3.0
Protocol, other communication protocols can be provided by user’s request.
As well as, controlling a switch by receiving Control Signal from SCADA, provides Distribution
Automation and minimize a fault area.

7
Load Break Switch Control
ERT-200S
1.2.Features
Measurements
Magnitude and phase angle of voltages & currents
Sequence components of 3-Phase voltages & currents
True RMS of voltages & currents
Active, reactive and apparent power for each phase and
3-phase
Energy(4-quadrant metering)
Displacement Power Factor
Frequency
Phase difference between source-side and load-side
voltage
Ground Fault
SEF
Inrush Detect
Sync. Check
Sectionalize
Control
•Manual LBS Open/Close at local or remote
operator Place,
Battery Test
Interlocking
•Gas low
•Handle lock
•Operator place
•Control lock
•Sync. Fail
•Live Load
Protection
Fault Detection (Phase and Earth Fault)
SEF(Sensitive Earth Fault) Detection
Cold Load protection(Pickup Adjustment)
Magnetizing Inrush Restraints
Open Line Detection
Phase Sync. Fail Detection

8
Load Break Switch Control
ERT-200S
Status
Monitoring
Switch Open/Closed/Select
Mechanical Locked
Gas Pressure Low
External AC Power
LBS Door Open
Battery Low
Local/Remote
Fault Indication
Open Line Detection
Event Record
•Event recording with time stamp
F.I Event / I/O Event / System Event / Control Event
/ Measure Event(Demand Current &
Power, Daily Max Current & Power)
•Waveform Recording
Storage:8 Fault Waveforms of 10 cycles.
Sampling ratio : 32 Sample/Cycle * 10 Cycles
Counter
•Restart(Boot Count)
•Switch Open Count
•All Fault Count
•Ch A, Ch B, Ch C, Ch N Fault
Communication
Port1 : Panel Serial Port (Maintenance Port : Modbus)
Port2 : Serial Port (DNP3.0, IEC60870-5-101Protocol)
Port3 : TCP Port (IEC60870-5-104, DNP/TCP)
-RJ-45 2Port (Option)

9
Load Break Switch Control
ERT-200S
2.Technical Specification
This section details the technical specifications of the Load Break Switch (LBS) and Control System.
Provide to detail setting values of timing, current, voltage and other measurement accuracy is given
2.1.Control General Specification
Maintenance interval
5 years
Auxiliary supply voltage (LV AC mains supply)
As Ordered +10 -20%
Required auxiliary supply rating
50 VA, 120VA
Battery
2 x 12V 12Ah
Battery replacement interval
5 years
Earthing
10mm earth stud
Modem
Modem may be fitted by the manufacturer or by the utility, for remote communications.
Space, power and data interfaces are provided within the control cubicle.
Modem Power Supply Voltage (set by user)
24V DC
Modem Power Supply Continuous Current
1A
Modem Power Supply Max Current
3A for 30 sec with 20% duty
cycle
Modem Interface
RS232
Auxiliary Power supply(Internal Power)
Supply from an external AC Source
110V or 240V
Battery Charging /Control Power Transformer
-Motor Power –30VAC to 30VDC
-Battery Charging/Control Power –15VAC to
15VDC
30VAC to 30VDC
Main Power –16VAC
-Battery Charging Power: 27VDC
-Control Power : 24VDC
16VAC to 27VDC
-SMPS

10
Load Break Switch Control
ERT-200S
2.2.Environment Condition
Environmental condition
Altitude
<2,000m
Wind Speed
40m/s
Dielectric Strength
CT Input, VT Input, Control Power Input, Fiber-
optic insulation Input and Relay output
AC 60㎐, 2㎸/1 minute
Impulse Voltage
IEEE C62.45 (1992) , 6㎸(1.2×50㎲), 3㎄(8×20㎲) of
Relay System for Radio Electromagnetic Interference
Transceiver.
Surge Withstand Capability
Protection relay and Relay system protection purpose
IEEE C37.90.1 - 1989 IEEE SWC test (3 ㎸Vibration1 ㎒
to 1.5 ㎒, 5 ㎸fast saturation 1.2×50 ㎲)
IEEE C37.90.2 - 1987 IEEE Test, Test use standard, relay
system for Radio Electromagnetic
Interface that comes from Transceiver,10 V/m(150㎒
and 450㎒, 5 W transmitter 10㎝)
Vibration Test
IEC 255-21-1-1988 Electric Relay, Part 21: Metering
relay and protection device vibration, impact, crash
and earthquake test, Section One - Vibration tests
(sinusoidal), Class 2
IEC 255-21-1-1988 Electrical relays, Part 21 : Vibration,
shock, bump, and seismic tests on measuring relays
and protection equipment, Section One - Vibration
tests (sinusoidal), Class 2
Control Operating
Temperature
Operation range : -25℃∼+70℃ (-13℉∼+158℉)
LCD : -20℃∼+70℃(-4℉∼+158℉) Standard

11
Load Break Switch Control
ERT-200S
2.3.FRTU TECHNICAL SPECIFICATION
FRTU Technical Specification
Frequency
50 / 60 Hz System
Power Input
AC Voltage Power : 16Vac/32Vac
Power Output
Modem : DC 24V Max : 1A
Current Transformer Input
(CT: Current rate)
Current Input IA,IB,IC,IN,ZCT (Max : 13A)
Burden : Below than 0.5VA
Capacitor Voltage Divider
Inputs(CVD)
Input Rang : 2~6Vac
4Vrms at rated Phase Voltages
Burden : Below than 0.01VA
Output Contacts
Open/Close Operate Output : 240Vac 16A, 30Vdc 16A
Aux DO 1~4 : 250Vac3A, 30Vdc 3A
Input
Input 8 channel
Dry Contact Input Type
2.4.Digital Process
2.4.1.Digital Signal Controller(DSCs)
DSP Processor Feature
High-Performance 32-Bit CPU
•TMS320F283X 32-Bit core
•FPU : 150MHz
•Six-Channel DMA Controller (for ADC, McBSP, –
Up to 2 CAN Modules
•ePWM, XINTF, and SARAM)
•Harvard Bus Architecture –Up to 9 16-Bit
Timers
•Fast Interrupt Response and Processing (6 for
ePWMs and 3 XINTCTRs)
•Unified Memory Programming Model
•DMA 6CH
•On-Chip Memory : F28335, F28235: –One
Inter-Integrated-Circuit (I2C) Bus
•256K x 16 Flash, 34K x 16 SARAM
•Up to 6 Event Capture Inputs
•Up to 2 Quadrature Encoder Interfaces

12
Load Break Switch Control
ERT-200S
•Serial Port Peripherals : 2 CAN / 3 SCI(UART) /
2 McBSP / 1 SPI / 1 I2C
2.4.2.Analog/Digital Conversion
ADC Feature
16 Bit A/D Converter
Anti-aliasing analog filter
One gain channel for each current input :
effective 16 bit resolution for current
measurements
2.4.3.Function
Self-Diagnostic
Watch dog Timer
Control Power System
RTC Self Check Logic
Memory Check Logic
ADC Converter Self Check Logic

13
Load Break Switch Control
ERT-200S
2.5.Function BlockDiagram

14
Load Break Switch Control
ERT-200S
2.6.Fault Detect and Sectionalizing Functions
Phase Fault Detection
Phase Fault Threshold Current Setting Range
(Pick up Current)
5 to 900A
Default : 400A / step : 1A
Definite Time for Fault to Persist Setting Range
(Detection Time)
0.01 to 10.0 sec
Default : 0.05s / step : 0.01s
Inrush Restraint
Yes/NoDefault : No
Cold Load Pickup
100 ~ 500%
Default : 200% / step : 10%
Cold Load Time
0.1to 180sec
Default : 0.2sec / step : 0.1sec
Direction Detection Enable
No Use/Use Default : Use
Direction Voltage Pickup
5 ~ 85 %
Default : 10% / Step : 1 %
Direction MTA
0 ~ 359 deg
Default : 0 deg / step : 1 deg
Ground Fault Detection
Earth Fault Threshold Current Setting Range
(Pick up Current)
5 to 900 A
Default : 60A / step : 1A
Definite Time for Fault to Persist Setting Range
(Detection Time)
0.01 to 10.0 sec
Default : 0.05s / step : 0.01s
Inrush Restraint
Yes/No
Default : No
Direction Detection Enable
No Use/Use Default : Use
Direction Voltage Pickup
5 ~ 85 %
Default : 10% / Step : 1 %
Direction MTA
0 ~ 359 deg
Default : 0 deg / step : 1 deg
Inrush Detection
2ndHarmonic Setting Range
5 ~ 50 %
Default : 20 % / step : 1%
Detection Time
0.02 ~ 1sec
Default : 0.02 / step : 0.01 sec
Inrush Time
0.1~180.0 sec
Default : 0.2 s step : 0.1 sec
Multiple
100 ~ 1000 %
Default : 200% / step : 10%
FI Reset Time

15
Load Break Switch Control
ERT-200S
FI Reset Time
1~180 s
Default : 20s / step : 1s
Line Open Detection
Live Line ON Voltage Setting Range
50 ~ 90 %
Default : 50% / step : 1%
Line OFF Voltage setting Range
35 –75%
Default : 50% / step : 1%
Detection Time setting Range
0.01 ~ 300 s
Default : 0.4s / step : 0.01s
Phase Sync. Check Set
Phase Difference Setting Range
5 ~ 60 deg
Default : 30deg / step : 1deg
Detection Time Setting Range
0.1 ~300 s
Default : 0.1s / step : 0.1s
Sectionalizer
Sectionalizer Mode Select
VIT / VT
Default : VIT
Faults to trip (Fault count)
1to 3
default : 2 / step : 1
Sequence reset time
20 ~ 240 s
Default : 30s / step : 1s
SEF(Sensitive Earth Fault) Detection
Sensitive Earth Fault Threshold Current Setting Range
(Pick up Current)
2 to 20 A
Default : 5A / step : 1A
Pick up Voltage Setting Range
10 ~ 80 V
Default : 30V / step : 1V
Angle Setting Range
0 ~ 90 deg
Default : 90deg / step : 1deg
Definite Time for Fault to Persist Setting Range
0.1 to 30.0 sec
Default : 0.1s / step : 0.1s
Inrush Restraint
Yes/No
Default : No
UFR (Under Frequency Relay)
Under Frequency Pickup Level
45.00 to 60.00 Hz
Default: 49.80Hz/step : 0.01Hz
Pick up Voltage Setting Range
50 ~ 85%
Default : 80% / step : 1%
Delay Time Setting Range
0.1 ~ 20.0 sec
Default : 1.0s / step : 0.1s

16
Load Break Switch Control
ERT-200S
OFR (Over Frequency Relay)
Over Frequency Pickup Level
50.00 to 70.00 Hz
Default: 62.20Hz/step : 0.01Hz
Pick up Voltage Setting Range
50 ~ 85%
Default : 80% / step : 1%
Delay Time Setting Range
0.1 ~ 20.0 sec
Default : 1.0s / step : 0.1s
UVR (Under Voltage Relay)
Pick up Voltage Setting Range
50 ~ 90 %
Default : 80% / step : 1%
Delay Time Setting Range
0.1 ~ 20.0 sec
Default : 1.0s / step : 0.1s
OFR (OverVoltage Relay)
Pick up Voltage Setting Range
110 ~ 150 %
Default : 120% / step : 1%
Delay Time Setting Range
0.1 ~ 20.0 sec
Default : 1.0s / step : 0.1s
2.7.Power System Measurements
Current measurement
RMS(A) & Phase angle(°)
Ia, Ib, Ic, In
Sequence Component
I1, I2, I0
Reading Range
2 ~ 12,500 A
( External CT Ratio 1,000 : 1)
Accuracy
2~12,000A: ±1% or ±1A
Voltage Measurement
Sequence Component
Va, Vb, Vc, Vr, Vs, Vt [kV]
Voltage Measurement Range (RMS Phase to Earth)
V1s, V2s, V0s, V1L, V2L, V0L
0.38 to 26 kV
Voltage Measurement Resolution
±%1 or ±0.1kV
Phase angle difference(°)
∠Va - ∠Vr
Power Measurement
Active Power(kW)
Pa, Pb, Pc, P3p
Reactive Power(kVar)
Qa, Qb, Qc, Q3p
Apparent Power(kVA)
Sa, Sb, Sc, S3p
Accuracy
±1%
Power Factor Measurement
A phase, B Phase, C phase, 3Phase total
PFa,PFb, PFc, PF3
Power Measurement Range
0-100%
Accuracy
±2%

17
Load Break Switch Control
ERT-200S
Frequency Measurement
Reading range
10 ~ 100Hz
Accuracy
±0.1Hz
Energy measurement
Reading range
0 ~ 65565
Accuracy
±2%
Average Demand Current and Power
Configurable demand interval
15minutes
Ia, Ib, Ic, Pa, Pb, Pc, P3ph,
Daily max. currents and power are stored
2.8.System Setting
Config Menu
I/O Config
System Frequency
50 ~ 60 Hz / default : 50 Hz
System Type
3P4L~3P3L / default : 3P4L
Rated Voltage
3800 ~ 26000 V /
CT Ratio
100 ~ 2000 A / default : 1000 A
NCT Ratio
100 ~ 2000 A / default : 1000 A
CT Direction
FWD ~ REV / default : FWD
Interlock
1) Live Load(Volt Interlock)
: Yes –No / No
2) Sync Fail (Sync Interlock)
: Yes –No / No
3) Open Interlock : Yes –No / Yes
FI Reset
Auto –Manu / default : Manu
FI Clear Time
0~600 sec / default : 300sec
Pulse Set (Do Pulse)
1200 ~ 5000ms/
default : 1200ms(Motor)
Battery Test Time
1 ~ 100 h / default : 24h
Aux. DO Config
Options for users
DI Debounce Time
DI : 1~9999ms /default 20ms
AC Power : 1~60s / default : 20s
Ref Phase
A,B,C / default : A
Phase Rotation
ABC , ACB / default : ABC

18
Load Break Switch Control
ERT-200S
2.9.Communications
RS232C
9pin Signals
DCD(1), Rx(2), Tx(3), DTR(4), GND(5), DSR(6),
TRS(7), CTS(8), NC(9)
Speed(Baud rate)
1200,2400,4800,9600,19200,38400
Modem Control
CTS,DCD signal Timeout Configurable
RTS off-delay Configurable
DNP3.0 / DNP-TCP
Support DNP3.0 Subset Level 2
Class of each point is settable
Supports multi-frame transmission (multi-frame interval is configurable)
Enable/Disable unsolicited message class
Non-transmitted events are stored on non-volatile memory during communication
fail
Supports direct operate or select before operate (SBO) for control output
Supports report by exception for analog values Protocol frame monitor was built
in FRTU
IEC60870-5-101
Address size is configurable.
Two time tag formats are selectable. :24-bit or 56-bit
Single character for NACK is supported.
Cyclic update of measurements data.
Class assignable for each object type. ( single point, double points, measured point,
Set Points Command)
Supports report by exception for updating analog values
IEC60870-5-104
IEC 60870-5-104 (also known as IEC 870-5-104) is an international standard,
released in 2000 by the IEC (International Electrotechnical Commission). As can be
seen from the standard's full designation 'Network access for IEC 60870-5-101
using standard transport profiles', its application layer is based on IEC 60870-5-
101. IEC 60870-5-104 enables communication between control station and
substation via a standard TCP/IP network. The TCP protocol is used for connection-
oriented secure data transmission.

19
Load Break Switch Control
ERT-200S
Communication
Protocol Setting
Protocol Select
DNP, IEC60870-5-101, IEC60870-5-
104, DNP/TCP
Default : DNP
Modem Control
Comm. Speed
1200/2400/4800/9600/19200
Default : 9600pbs
Comm Line
2Wire/4Wire / Default : 2Wire
RTS Off Delay
10 ~ 500ms / Default : 10 ms
CTS TimeOut
1 ~ 255sec / default : 1 sec
DCD TimeOut
100 ~ 30,000ms / Default : 100 ms
TCP Control
IP Setting
Default : 192.168.010.009
Subnet Mask
Default : 255.255.255.0
GateWay
Default : 192.168.010.001
LAN Port Set
1-65534 / Default : 5000
LAN Card Select
1 ~ 2 Port / Default : 1 Port
DNP Parameter
D/L Retry
0~2 / default : 0
D/L Time Out
0 ~ 255 / default : 10s
D/L Confirm
Yes-No-Sometime /
default : Sometime
A/L retry
0 ~ 2 / default : 0
A/L Time Out
0 ~ 255 sec / default : 15 sec
InitUnsol
Yes –No / default : No
Unsol Class1
Enable/Disable / default : Disable
Unsol Class2
Enable/Disable / default : Disable
Unsol Class3
Enable/Disable / default : Disable
Unsol Delay
0 ~ 60 sec / default : 5 sec
SBO Time Out
1 ~ 255 sec / default: 15 sec
Master Address
0 ~ 65534 / default : 3
Slave Address
0 ~ 65534 / Default : 4
Frame Interval
100 ~ 5,000 ms / default : 100 ms
IEC Parameter
A/L Cycle PRD
0 ~ 60 / default : 1 sec
SBO TimeOut
1 ~ 255 / default : 15 sec
M_SP Cyclic
Enable/Disable / Default : Enable
M_DP Cyclic
Enable/Disable / Default : Enable
M_ME Cyclic
Enable/Disable / Default : Enable
M_SP Address
1-10000 / default : 100
C_SC Address
1-10000 / default : 200
M_DP Address
1-10000 / default : 300
C_CD Address
1-10000 / default : 400

20
Load Break Switch Control
ERT-200S
M_ME Address
1-10000 / default : 1000
C_SE Address
1-10000 / default : 2000
M_IT Address
1-10000 / default : 4000
IEC101
LINK Address
1-254 / Default : 1
ASDU Address
1-254 / Default : 1
Originator
0-255 / Default : 1
LINK Address Size
1-2 / Default : 1
ASDU Address Size
1-2 / Default : 1
IOA Address Size
1-3 / Default : 1
COTA Address Size
0-2 / Default : 2
Link Mode
Unbalance/Balance
/ Default: Unbalance
IEC104
T0 Off PRD
1 ~ 255 / default : 30 sec
T1 Ack PRD
1 ~ 255 / default : 15 sec
T2 S frame PRD
1 ~ 255 / default : 10 sec
T3 Test PRD
1 ~ 255 / default : 20 sec
Event
Set S/W Counter
S/W Count
0 ~ 65535 / default : 0
Clear Events
All Events are cleared
Yes / No
Clear Fault
All Faults are cleared
Yes / No
Time
Time Set
Setting Time
yy-mm-dd-hh-mm-ss
Pass Word
Pass Word Se
Setting Pass Word
****
Volt Calib
Volt. Adjust
In Voltage
3,800-30,000V
