PQI Cool Drive U339S User manual

USB Flash Drive
Rev. A.0 Sep 2006
Cool Drive U339S
BB03-xxx7 Series
BB03-xxx8 Series

USB Flash Drive
Rev. A.0 Sep 2006
Table of Contents
1. Introduction to Cool Drive ……...……....................................................................................... 1
2. Main Features Overview …………..……….....................……...……………………………..…… 1
3. Hardware Specification ………………………………………..….………….……………………… 1
3.1 USB Interface ………………………………………………….….........……………………………… 1
3.2 NAND Flash Interface …………………………………..………………........………..………………. 1
3.3 OS Support …………………………………………………………….........………………………… 1
3.4 Product Capacity ……………………………………………………..….......…………..……………. 1
4. Block Diagram ........................................................................................................................... 2
5. Absolute Maximum Ratings ..................................................................................................... 2
6. DC Characteristics .................................................................................................................... 3
7. Recommended Operating Conditions ..................................................................................... 3
8. Pin Assignments ....................................................................................................................... 3
9. Physical Specifications ............................................................................................................. 4

USB Flash Drive
Rev. A.0 Sep 2006
Revision History
Revision Date History Remark
A.0 09/08 ‘06 New Creation
Important!! Please make sure the driver matches the part number on your pen drive before you download.
Software AP System Requirements. One of following operation systems: Windows 98/98SE/Windows ME/Windows 2000/Windows XP
The advertised memory capacity of this device represents unformatted capacity. Please note that once formatted and due to variations in flash
module block limitations, the functional storage space will be lower than the advertised capacity.
“PQI reserves the right to make changes without notification when fit, form, function, quality and reliability are not affected. The data sheets do
not constitute contract documents and should not be considered part of the specification for purposes of any warranty.”

USB Flash Drive
Rev. A.0 1/4 Sep 2006
1. Introduction to U339S
The U339S gives you portability and security to offer you a peace of mind. Compact futuristic design in metallic casing.
The PQI Cool Drive U339S also comes with USB Notebook – Personal File Manager software which is design for data
security and easy management of your personal data.
2. Main Features Overview
♦Compact metallic casing with futuristic design
♦Trendy colors with metallic casing
♦Mobile USB flash drive, USB 2.0 compatible
♦Hot swappable, USB Plug & Play compatible
♦LED indicator with three modes: Busy, waiting, and off
♦Multimedia and data storage
♦Built-in personal customizable software (USB Notebook Professional)
3. Product Specification
USB Interface High-speed USB 2.0 interface; backward compatible with USB 1.1
NAND Flash Interface Integrated ECC circuits for 4-bit error correction
OS Support No drive is required for Windows ME, 2000,XP or Mac OS 9.x
Environment
Operating 0℃to 65℃
Temperature
Non-Operating -20℃to 75℃
Operating 0.2G
Vibration
Non-Operating 15G
Operating 150G
Shock resistant
Non-Operating 1000G
Configuration
Capacity 128MBytes ~ 2GBytes
Reliability
MTBF(@25℃) 1,000,000 hours
Power Requirement
Voltage DC 3.3/5V ± 10%
Power Consumption
Read <100mA
Write <120mA
Standby <100mA
Un-configuration <100mA
Suspend <0.5mA

USB Flash Drive
Rev. A.0 2/4 Sep 2006
4. Block Diagram
5. Absolute Maximum Ratings
Symbol Parameter Min Max Unit
Tstorage Storage Temperature -20 75 ℃
Ta Ambient Operating Temperature 0 65 ℃
Vcc3 3.3V Supply Voltage -0.3 3.6 V
Vcc18 1.8V Supply Voltage -0.3 2 V
Vin3.3 3.3V Buffer Input Voltage -0.3 3.6 V
Vin3/5 3.3V/5V Buffer Input Voltage -0.3 5 V
Vin1.8 1.8V Buffer Input Voltage -0.3 2 V
8051 Micro
Controller
Data /
Address
Bus
USB 2.0
Interface
USB2.0
USB1.1
Host
PLL, REG
Program ROM
Program RAM
DMA Flash
Control
Logic
EDC/
ECC
DATA RAM
CLK
PWR_GOOD
PWR_RST
Flash
Memory
USB2.0 or
1.1 Port

USB Flash Drive
Rev. A.0 3/4 Sep 2006
6. DC Characteristics
Symbol Parameter Min. Typical Max. Units
VDD Supply voltage for VCC3 or VCC3A 3.0 3.3 3.6 V
VDD18
Regulator output voltage for VCC or
VCCA
1.62 1.8 1.98 V
VIL Input Low Voltage -0.5 0.8 V
VIH Input High Voltage 2.0 V
VOL Output Low Voltage (IOL=4mA) 0.4 V
VOH Output High Voltage (IOH=4mA) 2.4 V
CIN Input pin capacitance 10 pF
IDD Supply current 50 mA
ISUS Suspend current (D+1.5KΩ) 300 uA
7. Recommended Operating Conditions
Symbol Parameter Min. Typical Max. Units
VCC33 Power Supply Voltage 3.0 3.3 3.3 V
VIN Input Voltage 0 Vcc Vcc + 0.3 V
VCC25 Internal Power Support 2.25 2.50 2.75 V
8. Pin Assignments
Pin No. Pin Name Function
1 VCC USB power input
2 USB D- USB differential signal
3 USB D+ The pairs are used to transmit Data/Address/Command
4 VSS Ground
Pin 1
Pin 2 Pin 3
Pin 4

USB Flash Drive
Rev. A.0 4/4 Sep 2006
9. Physical Specifications
9.1 Dimensions:
9.1.1 Height: 68.05mm
9.1.2 Width: 18.50mm
9.1.3 Depth: 8.99mm
9.1.4 Weight: 12.6g ± 1g
9.2 Outline of top view
