Thank you for choosing
PPI
audio epuipment. Now, HANG ON!
PPI
products are engineered and manufactured to deliver a wild ride of
performance, sound quality, and reliability. This
PPI
product reflects our com-
mitment to offer you versatility and quality for years of incredible power and
listening enjoyment!
SERVICE
Do not attempt to service
PPI
products yourself. Performing exploratory
surgery on your audio equipment yourself will void the warranty. All parts of
your
PPI
gear have been built to our specifications. These parts are not made
available to any unauthorized
PPI
dealer nor are they for sale. Our goal is to
make sure that your
PPI
product will always perform as good as the day it
was purchased. Contact your authorized
PPI
dealer about obtaining any war-
ranty service through
PPI
. (See Warranty inside back cover.)
CAUTION!
The extended use of a high powered audio system may result in hearing loss
or damage. While
PPI
systems are capable of "Concert Level" volumes, they
are also designed for you to enjoy at more reasonable levels all of the cre-
ative expressions made by musicians. Please stay seated while driving and
observe all local sound ordinances.
Your new speakers incorporate some or all of the following features:
Woven Carbon Fiber Woofer Cones -
This rigid and light
material provides powerful bass and rich midrange without
distortion and cone breakup
Butyl Rubber Woofer Surrounds & Flat Spiders -
Provide low
distortion through the full range of speaker cone motion
Titanium Tweeter Domes -
Will not distort even when driven
with large amounts of power
Composite Tweeter Surrounds -
Eliminates ringing that can
occur with metal dome tweeters while controlling dome motion
Neodymium Tweeter Magnets -
Greater magnetic strength
in a smaller package with higher efficiency
Swivel Tweeter Mounts (not on PPI35.1&40.1) -
Allows you to
focus the accoustical energy for better imaging
Built-in Tweeter Crossover -
Protects and provides a simple
hookup to the tweeter
AcousticallyTransparent Speaker Grills -
Protects the speakers
without degrading the sound
Gold Plated Speaker Terminals -
Provides a corrosion free
high integrity connention
Professional Mounting Hardware, including Speaker Cable
Your coaxial system includes the following:
1 - pair of coaxial speakers
1 - pair of 2-piece speaker grilles with adhesive (not with PPI35.1)
1 - pair of stick-on logos for the grilles
1 - pair of 2-conductor speaker cable (20 feet each) with push-on
speaker terminals
8 mounting screws ( 4 mounting screws for the PPI35.1)
8 speed clips (4 speed clips for the PPI35.1)
1
2
PPI35.1
Woofer Size 3.5 in
Tweeter Size .75 in
Swivel Tweeter No
Maximum power handling 50 Watts
Nominal power handling 20 Watts
Frequency Response 150 - 20 kHz
Efficiency @ 1W/1M 86.75 dB
Xmax .18 mm
Woofer Voice Coil Diameter .75 in
Woofer Magnet Weight 5.35 oz
Impedance 4 ohms
Resonant Frequency 171.5 Hz
Voice Coil Resistance 3.32 ohms
Mounting Depth 1.69 in
Mounting Diameter 3.13 in
3
PPI40.1
Woofer Size 4 in
Tweeter Size .75 in
Swivel Tweeter Yes
Maximum power handling 80 Watts
Nominal power handling 40 Watts
Frequency Response 70 Hz - 22 kHz
Efficiency @ 1W/1M 90 dB
Xmax 1.5 mm
Woofer Voice Coil Diameter 1 in
Woofer Magnet Weight 8 oz
Impedance 4 ohms
Resonant Frequency 134 Hz
Voice Coil Resistance 3.8 ohms
Mounting Depth 1.87 in
Mounting Diameter 3.68 in
4
PPI46.1
Woofer Size 4 x 6 in
Tweeter Size .75 in
Swivel Tweeter Yes
Maximum power handling 80 Watts
Nominal power handling 40 Watts
Frequency Response 70 Hz - 22 kHz
Efficiency @ 1W/1M 89 dB
Xmax 2 mm
Woofer Voice Coil Diameter 1 in
Woofer Magnet Weight 8 oz
Impedance 4 ohms
Resonant Frequency 100 Hz
Voice Coil Resistance 3.9 ohms
Mounting Depth 2.06 in
Mounting Diameter N/A
5
PPI52.1
Woofer Size 5.25 in
Tweeter Size .75 in
Swivel Tweeter Yes
Maximum power handling 90 Watts
Nominal power handling 45 Watts
Frequency Response 60 Hz - 22 kHz
Efficiency @ 1W/1M 88 dB
Xmax 2.5 mm
Woofer Voice Coil Diameter 1 in
Woofer Magnet Weight 10 oz
Impedance 4 ohms
Resonant Frequency 105 Hz
Voice Coil Resistance 3.9 ohms
Mounting Depth 2.37 in
Mounting Diameter 4.65 in
PPI57.1
Woofer Size 5 x 7 in
Tweeter Size .75 in
Swivel Tweeter Yes
Maximum power handling 90 Watts
Nominal power handling 45 Watts
Frequency Response 50 Hz - 22 kHz
Efficiency @ 1W/1M 91 dB
Xmax 2.5 mm
Woofer Voice Coil Diameter 1 in
Woofer Magnet Weight 10 oz
Impedance 4 ohms
Resonant Frequency 70 Hz
Voice Coil Resistance 3.8 ohms
Mounting Depth 2.37 in
Mounting Diameter N/A
6
7
PPI65.1
Woofer Size 6.5 in
Tweeter Size .75 in
Swivel Tweeter Yes
Maximum power handling 100 Watts
Nominal power handling 50 Watts
Frequency Response 40 Hz - 21 kHz
Efficiency @ 1W/1M 91 dB
Xmax 3 mm
Woofer Voice Coil Diameter 1 in
Woofer Magnet Weight 13 oz
Impedance 4 ohms
Resonant Frequency 65 Hz
Voice Coil Resistance 3.8 ohms
Mounting Depth 2.81 in
Mounting Diameter 5.62 in
8
PPI69.1
Woofer Size 6 x 9 in
Tweeter Size 1 in
Swivel Tweeter Yes
Maximum power handling 150 Watts
Nominal power handling 75 Watts
Frequency Response 50 Hz - 21 kHz
Efficiency @ 1W/1M 92 dB
Xmax 2 mm
Woofer Voice Coil Diameter 1.5 in
Woofer Magnet Weight 20 oz
Impedance 4 ohms
Resonant Frequency 50 Hz
Voice Coil Resistance 3.9 ohms
Mounting Depth 3.25 in
Mounting Diameter N/A
Route wires around any
obstructions such as pedals
and levers under the dash
Protect all wires from chaffing
by avoiding sharp turns and
using grommetts where they
pass through metal
When cutting into panels
inspect for any hazards such
as computers or wiring harnesses
The installation of your new
PPI
coaxial speakers should be relatively
simple; especially if you are replacing factory speakers of the same size.
However, if you are installing your speakers where there are not any
currently installed or if you are planning to install speakers larger than the
factory speakers, the process will be more difficult. If this is the case, we
strongly recommend a professional installation by your authorized
PPI
retailer.
Your
PPI
coaxials are shipped with all the hardware you should need for
proper installation. Although, as with most installations, you may not use
all of the pieces. We recommend that you keep everything including this
owners manual and the original packing in case you decide to move the
speakers into another vehicle that may require a different type of
installation.
Before starting the installation make sure the system is operating properly.
Test the balance, fader and volume controls to ensure your system is
functioning properly. If everything is fine, proceed with the installation;
otherwise, locate the problems and have them repaired.
Replace all screws and fastners
securely to avoid potential noise
or other mishaps
9
