MC15 MSR Setting Utility Manual
1. Starting
Click the “Connect to MSR”, the utility will communicate with the MSR to detect
the Firmware version, and lead to the corresponding setting screen.
This document is for the MSR of Firmware Version 2.01.
The setting screen for Version 2.01 is shown below.

2. MSR Setting
LanguageSettings Select the language
TransmitSentinels Select whether to output the Track Sentinels
BeepafterGoodRead Select whether to beep when good read
MSR Error Beep Select whether to beep when card error
LRCOutput Select whether to output the Track LRC
MSRDataOutputDelay Define the time delay between characters
MSRTrack1DataOutput Select whether to output the Track 1 data
MSRTrack2DataOutput Select whether to output the Track 2 data
MSRTrack3DataOutput Select whether to output the Track 3 data
MSR Pre/Postamble Output Format Select the Preamble/Postamble output format
MSRDataOutputWay Select the MSR data output way

Explanation
1. MSR Track Data Format
<Start Sentinels> <Data> <End Sentinels> <LRC>
Transmit Sentinels selects whether to output the Start Sentinels and End Sentinels.
LRC Output selects whether to output the LRC.
2. MSR Data
<MSRDataPreamble> (Item1)
<Track 1 Preamble> <Track 1 Data> <Track 1 Postamble> (Item2)
<Track 2 Preamble> <Track 2 Data> <Track 2 Postamble> (Item3)
<Track 2 Preamble> <Track 3 Data> <Track 3 Postamble> (Item4)
<MSRDataPostamble> (Item5)
MSR Track 1 Data Output selects whether to output Item2
MSR Track 2 Data Output selects whether to output Item3
MSR Track 3 Data Output selects whether to output Item4
MSR Pre/Postamble Output Format selects the format of Item1 and Item5
MSR Data Output Way selects the output format of all the Items
3. MSR Data Output Format
Suppose each data is composed of the Make code and Break code (Scan code),
MSR Data Output Way selects whether to output both of them, Make code only or
Break code only.
If the MSR Pre/Postamble Output Format is defined to be Send as Scancode,
the code of the Preamble and Postamble will be defined by the user.

3. MSR Advanced Settings
The MSR Advanced Settings is to define the Preamble and Postamble.
There are two options, Character and Scan code (code set 2).
If the MSR Pre/Postamble Output Format is defined to be Send as Character,
the MSR Advanced Settings screen will be,

Click the Edit next to the setting to define the Preamble and Postamble character.
Key in the character, or select the special key below.
The maximum character can be defined is eight.

If the MSR Pre/Postamble Output Format is defined to be Send as Scancode,
the MSR Advanced Settings screen will be,
Define the scan code (Code Set 2) in Hex format.
Click Previous to back to the previous screen.

4. Default Selection
Select the default type to reset the MSR configuration.
5. Read Device
It is to read back the configuration from the MSR device.
6. Program Device
It is to program the MSR device, so that the configuration will be saved into the
device. Note that the configuration will not take effect unless it is programmed to the
MSR device.

7. Open MSR Configuration File
Open a file saved before.
8. Save MSR Configuration as
The MSR configuration can be saved as a “*.DAT” file.

9. Read MSR Firmware Version
The firmware version will be shown on the top.
