Prem-I-Air EH0154 User manual

EH0154
2 kW Fan Heater
2 Heat settings
2 Positions: Letterbox or upright
Adjustable thermostat
Built-in carrying handle
Safety overload cut-out
Safety tilt-switch
Page 1

IMPORTANT
Installer and Users please note:
These instructions should be read carefully and left with the
user of the product for future reference.
OPERATION
Place the EH0154 on a firm flat surface. It can be used either
upright or in the "letterbox" orientation as shown on the front
cover.
Plug the mains lead into a 13 Amp mains socket.
If connecting via an extension lead, make sure that the lead
is rated at 13 Amps or more, and that it is fully unwound.
Switch the appliance on at the mains socket.
Use the rotary power control switches on the top to select the
required operation:
• O = OFF
• Fan symbol = cool air only
• 1 = Low Heat (1kW)
• 2 = High heat (2 kW)
Unplug the appliance from the mains when not in use.
USING THE THERMOSTAT
The thermostat can be use to regulate the room temperature.
Turn the rotary switch to the high heat position, and rotate
the temperature control fully clockwise.
The appliance will then operate at maximum output. When
the desired temperature is reached, rotate the temperature
control anticlockwise until a click is heard. The appliance will
then switch on and off to keep the room at the desired
temperature.
Either the low or high heat setting can be used.
Page 2

PRODUCT SAFETY
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not
play with the appliance
• Place the appliance on a firm flat surface.
• Ensure that there is at least 300mm (1') between the sides
of the appliance and any flammable materials
• Ensure that there is at least 900mm (3') from the top of the
appliance and any flammable materials.
• Do not place on soft surfaces.
• Do not cover. This symbol shown on the casing of
the appliance means that the appliance should not be
covered.
• Do not use outdoors.
• Do not use in the immediate surroundings of a bath, a
shower or a swimming pool.
• Do not use in bathrooms, or in wet locations.
• Do not place the mains lead beneath a carpet or rug.
• Do not use the appliance in locations where paint, petrol or
other flammable liquids are used or stored.
• Do not use the appliance without the feet attached.
• Do not locate the appliance immediately below a socket
outlet
Page 3

PAT TESTING
When used in an office environment, this product must be
safety-tested yearly by a qualified electrician (PAT Tested) in
order to comply with the Electricity at Work Regulations.
We recommend that it is PAT tested regularly when used in a
domestic environment.
GENERAL SAFETY REQUIREMENTS
Domestic wiring must be tested periodically by a qualified
electrician at least once every 10 years or at every change of
occupancy. For office and retail premises, and buildings such
as village halls, the wiring must be inspected at least once
every 5 years.
It is recommended that all building be fitted with smoke
alarms (it is mandatory for new buildings).
MAINTENANCE
Before cleaning, turn the appliance off, and disconnect from
the mains supply. The appliance may then be cleaned using
a damp cloth with a drop of washing-up liquid to remove any
dust or dirt from the case. Do no use stronger detergents or
solvents as these may damage the plastic.
Using a dry 1" (25 mm) paint-brush, remove any dust from
the grilles.
Page 4

If the mains lead is damaged, it must be replaced by the
manufacturer or and authorised service centre. If the mains
plug needs to be replaced, proceed as follows:
• Connect the brown wire to the
terminal labelled "L".
• Connect the blue wire to the
terminal labelled "N".
• Connect the green/yellow wire
to the terminal labelled with the
earth symbol or "E".
• Make sure that the cord-grip is
positioned correctly (over the
outer sheath of the cable) and it fully tightened.
OPERATING COSTS
At time of going to press, the average cost of electricity is
£0.11 per unit (kilowatt-hour). The amount you are being
charged will be shown on your electricity bill.
At this cost, the appliance will cost £0.11 per hour to run on
the "low heat " setting, or £0.22 per hour to run on the "high
heat" setting, with the thermostat set to its maximum.
If the thermostat is used to regulate the temperature the
operating costs will be lower, depending on the room
temperature.
Page 5

FAULT-FINDING
If the appliance is not operating, proceed as follows:
Check that the mains plug is firmly in the socket, and that the
socket is switched ON.
Check that at least one of the power control switches is
switched ON.
The appliance also has a overload protection device to
prevent overheating. If this operates, disconnect the
appliance from the mains supply, and remove any objects on
or adjacent to the appliance that could have caused the
overheating. Wait 10 minutes, and reconnect to the mains
supply.
If the appliance still does not function, or the overload
protection device operates again, consult an authorised
service agent.
The appliance is also fitted with a tip-over switch which will
disconnect the power if if falls over. If it does not operate,
make sure that it is standing upright.
DISPOSAL AND RECYCLING
You must not dispose of this appliance with domestic
household waste.
Most local authorities have specific collection system for
appliances and disposal is free of charge to the end-user.
When replacing an existing appliance with a similar new
appliance your retailer may take the old appliance for
disposal.
Page 6

TECHNICAL SPECIFICATION
Dimensions: 250×230×130 mm
Weight: 1 kg
Power supply: 230 V ~
Power consumption: 2000 W
Operating current: 8.7 A
SERVICE WARRANTY
Prem-i-Air guarantees the product free from defects in
materials and workmanship for a period of two years.
Should this appliance be operated under conditions other
than those recommended, at voltages other than the voltage
indicated on the appliance, or any attempts made to service
or modify the appliance, then the warranty will be rendered
void.
The product you buy may sometimes differ slightly from
illustrations. This warranty is in addition to, and does not
affect, your statutory rights.
If you have any problems with this product, please call our
Help Desk on [phone].
Prem-i-Air Appliances Ltd.,
Lancots Lane, Sutton,
St. Helens, Merseyside.
WA9 3EX
website: www.prem-i-air.com
