Premium PRM32PT800 User manual
Setup Wizard
7
Media 8
Input 10
10
11
12
17
17
19
Advance
MAXHUB share
Remote controller 26
19
User manual is for models :
PRM32PT800 - PRM43PT820 - PRM50PT850 - PRM55PT860 - PRM65PT860 -
PRM75PT860 - PRM86PT860
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety, If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at Plugs, convenience
receptacles, and the point where they exit from the apparatus.
11) Only use attachments /accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold
with the apparatus. When a cart is used caution when moving the cart/apparatus combination to
avoid injury
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
Caution:
14) To reduce the risk of fire or electric shock, do not expose this apparatus to rain or
moisture.
15) Themains plug is used as disconnect device, the disconnect device shallremain readily operable.
16) The socket-out shall be installed near the equipment and shall be easily accessible.
17) This product should never be placed in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.
18) The apparatus shall not be exposed to dripping or splashing and that no objects filled with
liquid, such as vases, shall be placed on the apparatus.
19) Do not place any sources of danger on the apparatus (e.g. liquid filled objects, lighted candles).
20) Wall or Ceiling Mounting - The appliance should be mounted to a wall or ceiling only as
recommended by the manufacturer.
21) Never place the monitor remote control or batteries near naked flames or
other heat sources, including direct sunlight. To prevent the spread of fire,
keep candles or other flames away from the monitor remote control and
batteries at all times.
22) The USB terminal should be loaded with 0.5 A under normal operation.
These servicing instructions are for use by qualified service personnel only. To reduce the risk
of electric shock does not perform any servicing other than that contained in the operating
instructions. unless you are qualified to do so.
23) The battery shall not be exposed to excessive heat such as sunshine, fire or the like.
24) This equipment is a Class II or double insulated electrical appliance. It has been
designed in such a way that it does not require a safety connection to electrical earth
25) The maximum using environment temperature is 45 degrees. The Maximum using altitude is
2000 meters
26) Do not touch or be close the RJ45, HDMI, USB terminals, and prevent electro static
discharge to disturb these terminals while in LAN operation mode, or it will cause the TV to stop
working or abnormal status.
6FUHHQEXWWRQVPD\YDU\DFFRUGLQJWRWKHPRGHO
higher
Optical
An optical digital audio connection
is used to send digital audio signals
ATV- DTV C/T/T2
DTV S/S2
it
a
come
it
T
S
T
6HWXS:L]DUG
The system setting will appear when you open the TV on
the first time Please set according to the on-screen guide
Press OK button to start the setup
Please follow the on-screen instructions to set up Bluetooth
(Only supported when Bluetooth function is selected).
.3UHVV ▼ / ▲ button to select the language
Press ◄ / ► button to choose the country.
Press ◄ / ► button to select Set Password
Press ◄ / ► button to select Set your TV network
Press ◄ / ► button to select Connect the TV assistant
Press ◄ / ► button to select TV viewing guide.
Press ▼ / ▲ button to choose the way you watch TV
programs or source: Home page/TV/AV1/AV2/
YPBPR/HDMI1/HDMI2/HDMI3/VGA.
(for system lock and system recovery)
Home page
Network
Press ◄ / ► button to select Network
Time
Press ◄ / ► button to select Time
Get the current time and date automatically.
Auto Attach
Time Zone
Daylight Saving
Time Edit
Date Format
24 Hours
Sleep Timer
Set the current time ]RQH
Set the daylight saving Auto/On/Off
Set the current time
Set the current date
Select the 12 hours or 24 hours
Set the sleep timer as Off / 15min / 30min /
45min / 60min/90min/120 min/240min
Screen saver time
7
Press ▼ / ▲ button to select . ome page in S etup Wizard
or press ◄ / ► button toselect Home in the
menu of ATV/DTV input .
Press ▼ / ▲ / ◄ / ► button to select Movie/ TV/
6XJJHVWHG$SS/FAV APP/MUSIC
You can choose the3URJUDPV you want onthe home page
SETTINGS
Press ▼ / ▲ / ◄ / ► button to select OTHERS .
Press ◄ / ► button to select the SETTINGS , and press OK
button to enter the System Setting. Press ◄ / ► button to
select Network/Image&Sound/Time/Commen/System Info/
.Accounts
Press ▼ / ▲ button to select Auto Attach/Time Zone/
Daylight /Saving Time Edit/Date Format/24Hours/Screen
saver time /Sleep Timer
Set the screen saver time as Off / 1min /
2min / 5min
Bluetooth
Press ▼ / ▲ button to select Bluetooth
Common
Press ◄ / ► button to select Common.
Set the current display language.The
default language is English
Set the remote controller input method.
Set the Wallpaper.
Recovery system to original state.
Language
Input Method
WallPaper
System Recovery
The device name Set the device name.
Media
Play List
Press ▼ / ▲ button to select Play List and press OK button to
.display all available videos
Play Mode
Press ▼ / ▲ button to select Play Mode and press OK button
to select.(Options: Repeat All/Auto exit/Repeat One/Random/
Play List) Aspect Ratio
.Press ▼ / ▲ button to select Aspect Ratio
Audio Track
Press▼ / ▲ button to select Audio Track and press
OK .button to select
8
Press ▼ / ▲ button to select Language/Input Method/
/Wallpaper /System Recovery./The device name
Press ▼ / ▲ / ◄ / ► button to select Multimedia in OTHERS
on the Home page or press MEDIA button on the remote,and
. press OK button to enter enter the Media Center
.Press ◄ / ► button to select All/Video/Audio/Image
Video
Press ▼ / ▲ button to select Video or All,and press
▼ / ▲ /◄ / ► button to select Movies.
Press M enu button to display the setting options on the
.left side
6\VWHP,QIR
3UHVVŻŹEXWWRQWRWRVHOHFW6\VWHP,QIR
Subtitle Track
Press ▼ / ▲ button to select Subtitle Track and press OK
.button to select close
Encoding Standard
Press ▼ / ▲ button to select Encoding Standard and
press OK button to select ISO/WINDOW
Region Language
Press ▼ / ▲ button to select Region Language and press OK
button to select .(Optional: Default/West Euro/Center Euro/
Baltic/Cyrillic/Arabic/Greek/Hebrew/Turkey/Thai/Vietnamese/
Chinese)
Character Set
Press ▼ / ▲ button to select Character Set and press OK
(button to select.(Optional:Default/GBK/ISO/WINDOWS
External Subtitles
Press ▼ / ▲ button to select External Subtitles and press OK
.button to select
Play List
Press ▼ / ▲ button to select Play List and press OK button to
display all available Audio.
Play Mode
Press ▼ / ▲ button to select Play Mode and press OK button
to select.(Options: Repeat All/Auto exit/Repeat One /Random/
Play List )
Play List
Play Slide
Interval Time
Aspect ratio
Rotate
Set as wallpaper
Playable picture list display .
You can choose to start the slide
show
Select slide show interval
(Optional:3/5/8/12Sec)
Set the aspect ratio. (Optional:
Auto/Full screen/Zoom Out/Original/
Zoom1/Zoom2)
/ Set the rotate. (Optional: Default
Rotate Right/Rotate left)
Set the current play picture as
wallpaper.
9
Audio
Press ▼ / ▲ button to select Audio or All
press ▼ / ▲ /◄ / ► button to select Music
Press ▼ / ▲ button to select Image or All,and press ▼ / ▲ /◄ /
.► button to select Pictures
+'5
3UHVV▼ ▲ EXWWRQ WR VHOHFW +'5 DQG SUHVV 2. EXWWRQ
WR V
HOHFW2Q2II
Input
Press ▼ / ▲ /◄ / ► button to select More under the
³:,6'206+$5(´RQWKH+RPHSDJH
TV Setting
Press MENU button to enter the main menu.
Press ◄ / ► button to select the Picture.
Press OK button to enter the sub-menu.
10
3UHVVŻŹ EXWWRQ WR VHOHFW 79$9$9<3%35+'0,
+'0,+'0,9*$2USUHVV0HQXEXWWRQ
SUHVVŻŹ EXWWRQWRVHOHFW6RXUFH
3UHVV▼ ▲ bXWWRQ WR VHOHFW the LQSXWVRXUFH\RX ZDQW
3UHVV 2. EXWWRQ to HQWHU. 3UHVV (;,7 EXWWRQ WR TXLt
3UHVV Ż /Ź EXWWRQ WR KLJKOLJKWWKHGHVLUHGPHQXLFRQDQG
SUHVV 2 . E XWWRQWR VHOHFW.( 2SWLRQDO+RPH6RXUFH3LFWXUH
(6RXQG &KDQQHO/ /RFN &RPPRQ/ $GYDQFH
3UHVV0(18EXWWRQWo enter the TV Setting
Picture Mode
Highlight the item and press OK button to enter the sub-menu,
that shows the picture mode you can choose. Press ◄ / ►
.button to select Standard/Dynamic/Vivid/Energy Saving/User
Standard
Dynamic
. Produces a standard image
Enhance the contrast ,color and clarity of the
screen, so that the picture in the
Vivid
Sport
User
. dynamic will balance the color
Enhance the contrat , color and clarity of
the .screen to make the color more vivid
Go to Sport mode
Select to customize picture settings.
Contrast/Brightness/Color/Sharpness
These terms are available only when "User" is selected in
Picture Mode
Adjust the contrast of the image.
Contrast
Brightness
Color
Sharpness
Adjust the brightness of the image.
Adjust the color intensity of the image.
Adjust the edge sharpness of the image.
Backlight
Press ▼ / ▲ button to select Backlight.
Press ◄ / ► button to adjust.
Noise Reduction
Set up options to eliminate the image noise intensity.
Press ▼ / ▲ button to select Noise Reduction
Press ◄ / ► button to select Off/Low/Middle/High/Auto.
Aspect Ratio
Press ▼ / ▲ button to select Aspect Ratio.
Press ◄ / ► button to select 16:9/4:3/Zoom1/Zoom2.
Color Temp
Adjust the overall color of the image.
Press ▼ / ▲ button to select Color Temp.
Press ◄ / ► button to select Cool/Normal/Warm.
Cool The picture is in favor of green-blue and less
.red
Normal
Warm
The whole color is in favor of light. The picture
.is more fresh and elegant
The picture does not in favor of any color.The
. color is moderate
The picture is in favor of red-green and less
blue to make the color
.more vivid and soft
More Settings
Press ▼ / ▲ button to select More Settings.
Press O1 button to enter the sub-menu.
'/&
Press ▼ / ▲ button to select DLC.
Press ◄ / ► button to select On/Off.
Sound
Press MENU button to enter the main menu.
Press ◄ / ► button to select the Sound.
Press OK button to enter the sub-menu.
Press ▼ / ▲ b utton t o select Picture M ode/Contrast/
Brightness/Color/Sharpness/Backlight/Noise Reduction/
. Aspect Ratio/Color Temp/More Settings
Press MENU or EXIT button to quit.
11
3UHVV▼ ▲ EXWWRQ WR VHOHFW & RQWUDVW%ULJKWQHVV&RORU
6KDUSQHVV. 3UHVVŻ Ź EXWWRQ W R DGMXVW
Press ▼ / ▲ button to select Sound Mode/Bass/Treble/
Balance/AVC/Multi-Taack Sound/More Settings
Press MENU or EXIT button to quit
Sound Mode
Press▼ / ▲ button to select Sound Mod.
Press ◄ / ► button to select Standard/Music/Movie/News/User
Standard
Music
Movie
News
Standard emit balanced sound under any
circumstances
Enhance the high pitch and reduce the bass.
Enhances treble and bass for a rich sound
experience
Enhance the voice
User Select to customize sound settings.
AVC
Press ▼ / ▲button to select AVC
Press ◄ / ► button .to select On/Off
Note:After open the"AVC", once the volume is set up, it can
keep the volume of the
speaker steady no matter what kind of difference
among the TV sound of each channel.
Mulit-Track Sound
Press ▼ / ▲ button to select Mulit-Track Sound.
Optional: NICAM stereo/Mono.
More Settings
Press▼ / ▲ button to select More Settings
Press OK button to enter the sub-menu
Digital Audio Output
Press ▼ / ▲ EXWWRQ to select Digital Audio Output
3UHVV◄ / ► button to select Off/PCM/RAW
SPDIF Delay
Press ▼ / ▲ button to select SPDIF Delay
Press ◄ / ►buttonWR select
Surround
Press ▼ / ▲ button to select Sorround
Press ◄ / ► button to select On/Off
Audio
Press ▼ / ▲ button to select Audio Only
Press OK button enter the sub-menu
Channel
Press MENU button to enter the main menu.
Press ◄ / ► button to select Channel.
Press OK button to enter the sub-menu.
ATV
Press ▼ / ▲ button to select Country/Antenna Type/Scan/
Channel List. Press MENU or EXIT button to quit
12
Bass
Adjust the low frequency sounds .
Press▼ / ▲ button to select Bass.
Press ◄ / ► b utton to adjust.
Treble
Adjust t he high frequency sounds .
Press ▼ / ▲ button to select Treble
Press ◄ / ► button to adjust
Blance
. Balanced left and right channels
Press ▼ / ▲ button to select Balance
Press ◄ / ► button to adjust
Country
Press ▼ / ▲ button to select Country
Press OK button .to enter to select country
Antenna Type
Press ▼ / ▲ button to select Antenna Type
Press ◄ / ► button to enter to select Air/Cable/Satellite
Scan
Press ▼ / ▲ button to select Scan
Press OK button to enter the sub-menu .
Press ▼ / ▲ button to select Search Type/Auto Scan/
Analog Manual Scan/Digital Manual Scan
Auto Scan
Automatic search can search for effective program
channel automatically .
Press ▼ / ▲ button to select Auto Scan
then press▼ / ▲ button to select LCN / Start Scan
LCN
Press ▼ / ▲ button to select LCN
Press ◄ / ► button to select On/Off
Start Scan
Press ▼ / ▲ button to select Start Scan
Press ◄ / ► button to start auto scan
Analog Manual Scan
Analog manual search can search for effective simulation
.program channel manually
Press ▼ / ▲button to select Analog Manual Scan , and
press OK button toenter the sub-menu.
Press EXIT or MENU button to quit
13
Search Type
Press ▼ / ▲ button to select Search Type
then press ◄ / ► button to select ATV+DTV/ATV/DTV
Channel
Press ▼ / ▲ button to select Channel
Press ◄ / ► button to select the channel number
Color System
Press ▼ / ▲ button to select Color System
Press ◄ / ► button to select PAL/SECAM/NTSC/Auto
Sound System
press ▼ / ▲ button to select Sound System
Press ◄ / ► button to select DK/BG/I/L/M/N Frequency
Press ▼ / ▲ button to select Frequency
Press ◄ / ► button to adjust
Digital Manual Scan
Digital manual search can search for effective simulation
program channel manually
Press ▼ / ▲ button to select Digital Manual Scan
press OK button to enter the sub-menu
Press EXIT or MENU button to quit
Channel List
View all of the existing program.
Press ▼ /▲ button to select Channel List
Press OK button to enter the sub-menu
DTV
Press ▼ / ▲ button to select Country/Antenna Type/Scan
Signal Information/CI Card/Audio Language/Subitle Channel
List/EPG
Press MENU or EXIT button to quit
Country
Press ▼ / ▲ button to select Country
Press OK button to .enter to select country
Antenna Type
Press ▼/▲ button to select Antenna Type
Press ◄ / ► button to select Air/Cable/Satellite
Scan
Press ▼ / ▲ button to select Scan.
Press OK button to enter the sub-menu
Press ▼ / ▲ button to select Search Type/AutoScan/Analog
Munual Scan /Digital Manual Scan
Auto Scan
Automatic search can search for effective program channel
automatically
Press ▼ / ▲ button to select Auto Scan, then press OK button
to start auto search. If you want to stop searching
press EXIT or MENU button to stop searching
14
Press ▼ / ▲ b utton to select All/ Favorite/ATV/DTV /
Radio /Encrypt /HD /Free /Data
All
Press ▼ / ▲ b utton t o select All
Press M ENU button to edit the program
Optional: Favorite/Rename /Delete/Skip .
If the program is selected as an analog signal, the
program can be renamed
Favorite
Press ▼ / ▲ button to select Favorite
Press button to edit the favorite Channel
(Optional : Top/Delete / Skip)
ATV/DTV/Radio/Encrypt/HD/Free/Data are type of
program
Press ▼ /▲ button to select Search Type
then press◄ / ► button to select ATV+DTV/ATV/DTV
Analog Manual Scan
Analog manual search can search for effective simulation
program channel manually
Press ▼ / ▲ button to select Analog Manual Scan , and
press OK button to enter the sub-menu.
Press EXIT or MENU button to quit
Channel
Press ▼ / ▲ button to select Channel
Press ◄ / ► button to select . the channel number
Color System
Press ▼ / ▲ button to select Color System
Press ◄ / ► button to select PAL/SECAM/NTSC/Auto
Sound System
Press ▼ / ▲ button to select Sound System
Press ◄ / ► button to select DK/BG/I/L/M/N Frequency
Press ▼ / ▲ button to select Frequency
Press ◄ / ► button to adjust
Digital Manual Scan
Digital manual search can search for effective simulation
program channel manually.
Press ▼ / ▲ button to select Digital Manual Scan ,
and press OK button to enter the sub-menu
Press EXIT or MENU button to quit
Signal Information
Press ▼ / ▲ button to select Signal Information
Press OK button to enter
CI Card
Press ▼ / ▲ button to select CI Card to view the information of CI
card
15
Scan mode
Press ▼ / ▲ button to select Scan mode
Press ◄ / ► button to select Network/Quick/Full/Blind.
Modulation
Press ▼ / ▲ button to select Modulation
Press ◄ / ► button to select Auto/16QAM/32QAM/
64QAM/128QAM/256QAM
Network ID
Press ▼ / ▲ button to select Network ID
Frequency
Press ▼ / ▲ button to select Frequency
Symbol Rate
Press ▼ / ▲ button to select Symbol Rate
LCN
Press ▼ / ▲ button to select LCN
Press ◄ / ► button to select On/Off
Start Scan
Press ▼ / ▲ button to select Start Scan
Press ◄ / ► button to start auto scan
Audio Language
Press ▼ / ▲ button to select Audio Language
Press ENTER & ▼ /▲ button to select audio language
Subtitle
Press ▼ / ▲ button to select Subtitle
Press ENTER & ▼ /▲ button to select
Channel List
View all of the existing programs.
Press ▼ / ▲ button to select Channel List
Press OK button
Press ▼ / ▲ button to select All / Favorite/ ATV/ DTV/
Radio /Encrypt /HD/Free/Data
All
Press ▼ / ▲ button to select All.
Press MENU button to edit the program
Optional:Favorite/Rename/Delete/Skip
If the program is selected as an analog signal, the
program can be renamed
Favorite
Press ▼ / ▲ button to select Favorite
Press MENU button to edit the Favorite Channel
(Optional:Top/Delete/Skip)
ATV/DTV/Radio/Encrypt/HD/Free/Data are type of program
EPG
Press ▼ / ▲ button to select EPG
Press enter the sub-menu
ATV+DTV
The Country/Antenna Type/Signal Information/CI Card/Audio
Language/Subitle Channel List/EPG are the same as DTV
Scan
Press ▼ / ▲ button to select Scan
Press OK button to enter the sub-menu
Press ▼ / ▲ button to select Search Type/AutoScan/Analog
Munual Scan/Digital Manual Scan
Star Scan
Press ▼ / ▲ button to select Start Scan
Press ◄ / ► button to start auto scan
If you want to stop searching
press EXIT or MENU button to stop searching
then press ◄ / ► button to select (ATV+DTV/ATV/DTV)
Search Type
Press ▼ /▲ button to select Search Type
Channel List
View all of the existing program.
Press ▼ / ▲ button to select Channel List
Press OK button to enter the sub-menu
16
Lock
Press MENU button to enter the main menu
Press ◄ / ► button to select Lock
Press OK button to input password to enter the sub-menu
Default password is (1234)
Press ▼ / ▲ button to select Change Password / System
Lock/Key Lock/Parental Guidance
Change Password
Press ▼ / ▲ button to select Change Password
Press ENTER button to set Password
System Lock
Press ▼ / ▲ button to select System Lock
Press ◄ / ► button t o select On/Off
Key Lock
Press ▼ / ▲ button to select Key Lock
Press ◄ / ► button to select On/Off
Parental Guidance
Press ▼ / ▲ button to select Parental Guidance
Press ◄ / ► button to select Off/5~18
Common
Press MENU button to enter the main menu.
Press ◄ / ► button to select Common.
Press OK button to enter the sub-menu.
17
EPG
Press ▼ / ▲ button to select EPG
press MENU button to enter the sub menuu
This manual suits for next models
6
Table of contents
