3-1
3. Disassembly and Reassemble
3. Disassembly and Reassembly
This section of the service manual describes the disassembly and reassembly procedures for the LED TV.
WARNING
This LED TV contains electrostatically sensitive devices. Use caution when handling these components.
3-1. Disassembly and Reassembly
CAUTION
Disconnect the LED TV from the power source before disassembly.1.
Follow these directions carefully; never use metal instruments to pry apart the cabinet.2.
If there is no additional coment, it is same for all inches.3.
Description Picture Description Note
1
Place TV face down on cushioned table.
2
Remove the ASSY COVER P-REAR.
Remove the Screw of ASSY COVER
P-REAR.
6003-001782
NOTE
Locking Part
Top : Each 6 point•
L/R : Each 3 point•
Bottom : Each 4 point•
3
Remove the the ASSY SPEAKER
P-FRONT (R/L).
Speakers Connector
ASSY SPEAKER P-FRONT (R/L)

3-2
3. Disassembly and Reassemble
Description Picture Description Note
4
Remove the Function Cable, LVDS Cable,
LED Cable.
Function Cable Connector
LVDS Cable Connector
5
Remove the SMPS Board and Main Board.
Gently lift up to release the lock.•
Use both hands to hold the board and•
slide UP to release the board.
Locking
6
Completed disassembly.
NOTE
Reassembly procedures are in the reverse order of disassembly procedures.

ANNEX. Exploded View & Part List [UE32K4100AWXXH CA01]
1-1. Exploded View
1-1-1. Parts List
No. Code No. Description & Specication Q’ty SA/SNA Remark
1 BN95-02691A PRODUCT LCD-CSOT; CY-FK032ANHV1V,K4100,Y1 1 SA
2 BN63-15595A COVER-TERMINAL SIDE; 32K5100,ABS,MOLD,HB, 1 SA
3 BN94-10869M ASSY PCB MAIN; 4series 1 SA
4 BN96-39802B ASSY BOARD P-FUNCTION TACT; K6200/K5500/K 1 SA
5 BN96-39966A ASSY SPEAKER P-FRONT; TV-SPK,K5100,6ohm,1 1 SA
6 BN96-39939L ASSY COVER P-REAR; 32K4100,PC+ABS,V-0,BK0 1 SA
7 BN95-02829A ASSY COVER STAND SMT-FRONT; K5300,32,SILV 1 SA
ANNEX-1
ANNEX. Exploded View & Part List

Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
UE32K4100AWXXH (CA01)
1 S001A BN90-08323C ASSY STAND;UK5500N 32 1 SNA
0.2 BN95-02829A ASSY COVER STAND SMT-FRONT;K5300,32,SILV 1 SA
..3 0204-007390 COATING;UVICHEM CVM92000(VOC) Matt(3),Ye 3 SNA
..3 BN02-00518A TAPE DOUBLE FACE;32K5300,ACRYL,T0.1,W8.5 4 SNA
..3 RF01 BN61-13237A FOOT-RUBBER;55K5100,Si,GRAY,T3.5,OD10, I 4 SNA
..3 BN63-15182B COVER-STAND TOP;32K5100,PC+ABS+GF20%,MOL 2 SNA
..3 BN63-15503B COVER-STAND TOP;32K5100,PC+ABS+GF20%,MOL 2 SNA
..3 BN68-05603A LABEL-E PASS;ART PAPER 90G,W/W 1 SNA
..3 BN69-14176A BAG ACCESSORY;32K5100,HDPE,T0.03,L250,W1 1 SNA
1 BN90-08342A ASSY W/I;UK4100,32" 1 SNA
0.2 BN81-08159Z A/S PART SET-ELEC W/I;LED TV ELEC spec-C 1 SNA
0.2 BN81-11259C A/S PART SET-MECH W/I;UK4100A,U32KA* 1 SNA
1 R001A BN90-08343H ASSY COVER REAR;UK4100,32" 1 SNA
0.2 SCREW 6003-001782 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 1 SA
0.2 R001A BN96-39939L ASSY COVER P-REAR;32K4100,PC+ABS,V-0,BK0 1 SA
..3 R001 BN63-15059G COVER-REAR;32K4100,PC+ABS,T2,V-0,BK0120, 1 SNA
...4 0103-010904 RESIN PC ABS;NH-1017SG/72317,Deep Blue B 900 SNA
..3 BN64-03565C INLAY-TERMINAL SIDE;40K5100,PET,T0.125,W 1 SNA
1 M0017 BN91-17439M ASSY CHASSIS;4series 1 SNA
0.2 M0014 BN94-10869M ASSY PCB MAIN;4series 1 SA
..3 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0 SNA
..3 T0066 BN62-00071A HEAT SINK-CERAMIC;UN46C7000WFXZA,A6063,W 1 SNA
..3 BN63-15595A COVER-TERMINAL SIDE;32K5100,ABS,MOLD,HB, 1 SA
...4 0103-010894 RESIN ABS;HF-0680U/72317,Indigo Black,BK 30 SNA
..3 BN97-10727M ASSY SMD-MAIN;4series 1 SNA
...4 0202-001830 SOLDER-CREAM;LFM-48W TM-HP,D20~38um,96.5 4 SNA
...4 DS01A 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 2 SA
...4 DS01A 0401-001166 DIODE-SWITCHING;BAV20WS-V,150V,250mA,SOD 2 SA
...4 DR01A 0402-002006 DIODE-RECTIFIER;SBR6100CTL,100V,6A,TO-25 1 SA
...4 0403-001411 DIODE-ZENER;BZT52-B5V6S,5.49~5.73V,200mW 1 SA
...4 0404-001307 DIODE-SCHOTTKY;SSC54,40V,5000mA,DO-214AB 1 SA
...4 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 2 SA
...4 0406-001200 DIODE-TVS;RClamp0504F,6V,1MAV,TP 1 SA
...4 0406-001635 DIODE-TVS;SMF5.0A,6.4V,6.7V,7V,200MAV,20 5 SA
...4 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 7 SC
...4 0505-002560 FET-SILICON;AO6415,P,20V,-3.3A,0.15ohm,1 3 SA
...4 0505-003224 FET-SILICON;AO6405,P,30V,-5A,0.052ohm,2W 1 SA
...4 0505-003397 FET-SILICON;2N7002K,N,60V,0.38A,1.19ohm, 6 SA
...4 0505-003620 FET-SILICON;AOD4286,N,100V,14A,55.5mohm, 1 SA
...4 0801-003603 IC-CMOS LOGIC;MC74LCX244MN2TWG,Octal buf 1 SA
...4 0801-003604 IC-CMOS LOGIC;NL17SZ17DFT2G,SC-70,5P,TP, 2 SA
...4 1001-001998 IC-ANALOG MULTIPLEX;NX3DV221GM,USB switc 1 SA
...4 1103-001487 IC-EEPROM;AT24C256C-SSHL-T,256Kbit,32Kx8 1 SA
ANNEX-2
ANNEX. Exploded View & Part List
2-1. Electrical Parts List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 1201-003690 IC-AUDIO AMP;TAS5747PHPR,QFP,48P,DUAL,PL 1 SA
...4 1203-004363 IC-VOL. DETECTOR;SOT-23,3Z30,2.9x1.6mm,P 1 SA
...4 1203-006017 IC-VOL. DETECTOR;RT9824GJ8,TSOT23,8P,2.9 1 SA
...4 1203-008030 IC-DC/DC CONVERTER;TPS54531DDA,SO PowerP 1 SA
...4 1203-008103 IC-POSI.FIXED REG.;S-13A1D15-E800,HSOP,8 1 SNA
...4 1203-008104 IC-POSI.FIXED REG.;S-13A1D18-E800,HSOP,8 1 SNA
...4 1203-008105 IC-POSI.FIXED REG.;S-13A1D33-E800,HSOP,8 1 SNA
...4 1203-008728 IC-BACKLIGHT DRIVER;BD9413F,SOP,18P,11.2 1 SA
...4 1203-008734 IC-DC/DC CONVERTER;RT6214,TSOT-23,6,3x1. 3 SA
...4 1204-003665 IC-VIDEO PROCESS;SENK17,LFBGA,562P,21x21 1 SA
...4 1204-003698 IC-TUNER;SI2190-B30-ZM8,QFN,28P,4X4mm,PL 1 SA
...4 1205-004447 IC-SWITCH;TPS2051CDBVR,SOT23-5,5P,3x1.65 1 SA
...4 1205-005551 IC-SWITCH;ET20161,SOT23-5,5P,2.926x2.8mm 1 SA
...4 1405-001271 VARISTOR;35V,20VDC,5A,1.0x0.5mm,TP,100V, 11 SA
...4 2007-000060 R-CHIP;100Kohm,1%,1/10W,TP,1608 1 SNA
...4 2007-000067 R-CHIP;15Kohm,1%,1/10W,TP,1608 1 SNA
...4 2007-000137 R-CHIP;2Kohm,5%,1/16W,TP,1005 9 SNA
...4 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 31 SA
...4 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 49 SNA
...4 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 43 SA
...4 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 10 SNA
...4 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 5 SNA
...4 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 5 SNA
...4 2007-000168 R-CHIP;470Kohm,5%,1/16W,TP,1005 1 SA
...4 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 SNA
...4 2007-000172 R-CHIP;10ohm,5%,1/16W,TP,1005 2 SNA
...4 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 12 SNA
...4 2007-000231 R-CHIP;1.3Kohm,1%,1/10W,TP,1608 1 SA
...4 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
...4 2007-000343 R-CHIP;120ohm,1%,1/10W,TP,1608 1 SA
...4 2007-000475 R-CHIP;1Mohm,1%,1/10W,TP,1608 1 SA
...4 2007-000592 R-CHIP;22ohm,1%,1/4W,TP,3216 1 SA
...4 2007-000691 R-CHIP;3.3Mohm,5%,1/10W,TP,1608 1 SA
...4 2007-000775 R-CHIP;33Kohm,5%,1/16W,TP,1005 1 SNA
...4 2007-000879 R-CHIP;4.7ohm,1%,1/10W,TP,1608 1 SA
...4 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 4 SNA
...4 2007-001168 R-CHIP;75ohm,5%,1/4W,TP,3216 1 SA
...4 2007-001288 R-CHIP;18ohm,5%,1/16W,TP,1005 4 SA
...4 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 11 SNA
...4 2007-001323 R-CHIP;3Kohm,5%,1/16W,TP,1005 1 SA
...4 2007-002749 R-CHIP;3.3ohm,5%,1/4W,TP,3216 2 SNA
...4 2007-002906 R-CHIP;200Kohm,1%,1/10W,TP,1608 2 SA
...4 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 12 SNA
...4 2007-007135 R-CHIP;18Kohm,1%,1/16W,TP,1005 2 SNA
...4 2007-007136 R-CHIP;4.7Kohm,1%,1/16W,TP,1005 1 SNA
...4 2007-007139 R-CHIP;47Kohm,1%,1/16W,TP,1005,T0.35 1 SA
...4 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 5 SNA
ANNEX-3
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 12 SNA
...4 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 2 SNA
...4 2007-007308 R-CHIP;33Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007309 R-CHIP;12Kohm,1%,1/16W,TP,1005,T0.35 6 SA
...4 2007-007311 R-CHIP;22Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-007316 R-CHIP;3.3Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 13 SNA
...4 2007-007334 R-CHIP;200Kohm,1%,1/16W,TP,1005 7 SNA
...4 2007-007382 R-CHIP;20Mohm,5%,1/10W,TP,1608 1 SNA
...4 2007-007405 R-CHIP;560ohm,1%,1/16W,TP,1005 2 SA
...4 2007-007517 R-CHIP;240ohm,1%,1/16W,TP,1005 1 SNA
...4 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 2 SA
...4 2007-008035 R-CHIP;160Kohm,1%,1/10W,TP,1608 1 SA
...4 2007-008136 R-CHIP;36Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-008167 R-CHIP;120Kohm,1%,1/16W,TP,1005 2 SC
...4 2007-008263 R-CHIP;3Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-008269 R-CHIP;51Kohm,1%,1/16W,TP,1005 2 SNA
...4 2007-008485 R-CHIP;22ohm,1%,1/16W,TP,1005 2 SC
...4 2007-008517 R-CHIP;240Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-008720 R-CHIP;4.7ohm,1%,1/4W,TP,3216 3 SNA
...4 2007-008779 R-CHIP;0ohm,1%,1/16W,TP,1005 1 SA
...4 2007-009234 R-CHIP;0.47ohm,1%,1/4W,TP,3216 4 SNA
...4 2007-009753 R-CHIP;52.3Kohm,1%,1/16W,TP,1005 1 SA
...4 2011-000686 R-NETWORK;56ohm,5%,1/16W,L,CHIP,8P,TP,3. 2 SA
...4 2011-001261 R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,2. 2 SA
...4 2011-001264 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,2. 4 SNA
...4 2011-001344 R-NETWORK;100ohm,5%,1/16W,L,CHIP,8P,TP,2 2 SA
...4 2011-001345 R-NETWORK;10Kohm,5%,1/16W,L,CHIP,8P,TP,2 2 SA
...4 2011-001396 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP, 1 SA
...4 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1.0x1.0 1 SA
...4 AD480 2203-000138 C-CER,CHIP;1.5nF,10%,50V,X7R,TP,1005 1 SNA
...4 AD480 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,TP,1005 4 SA
...4 AD480 2203-000311 C-CER,CHIP;0.12nF,5%,50V,C0G,TP,1005 1 SA
...4 AD480 2203-000359 C-CER,CHIP;0.15nF,5%,50V,C0G,TP,1005,0.5 4 SA
...4 AD480 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 8 SA
...4 AD480 2203-000466 C-CER,CHIP;0.001nF,0.25pF,50V,C0G,TP,100 2 SA
...4 AD480 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1005 2 SA
...4 AD480 2203-000585 C-CER,CHIP;0.22nF,10%,50V,X7R,TP,1005 1 SA
...4 AD480 2203-000627 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1005 3 SNA
...4 AD480 2203-000679 C-CER,CHIP;0.027nF,5%,50V,C0G,TP,1005 1 SNA
...4 AD480 2203-000714 C-CER,CHIP;3.3nF,10%,50V,X7R,TP,1005 2 SA
...4 AD480 2203-000726 C-CER,CHIP;3.9nF,10%,50V,X7R,TP,1608 3 SA
...4 AD480 2203-000812 C-CER,CHIP;0.033nF,5%,50V,C0G,TP,1005 3 SA
...4 AD480 2203-000854 C-CER,CHIP;0.039nF,5%,50V,C0G,TP,1005 2 SA
...4 AD480 2203-000940 C-CER,CHIP;0.47nF,10%,50V,X7R,TP,1005 4 SA
...4 AD480 2203-000995 C-CER,CHIP;0.047nF,5%,50V,C0G,TP,1005 1 SA
...4 AD480 2203-001124 C-CER,CHIP;0.68nF,10%,50V,X7R,TP,1005 1 SNA
ANNEX-4
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 AD480 2203-001412 C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005 5 SNA
...4 AD480 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,TP,1005 13 SNA
...4 AD480 2203-002687 C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1005 4 SA
...4 AD480 2203-003019 C-CER,CHIP;8.2nF,10%,50V,X7R,TP,1005 1 SNA
...4 AD480 2203-005083 C-CER,CHIP;220nF,10%,50V,X7R,TP,1608,0.8 6 SA
...4 AD480 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 13 SNA
...4 AD480 2203-005659 C-CER,CHIP;0.18nF,5%,50V,NP0,TP,1005 1 SNA
...4 AD480 2203-005968 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1005,0.5 2 SNA
...4 AD480 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,TP,1005 75 SA
...4 AD480 2203-006126 C-CER,CHIP;47nF,10%,16V,X7R,TP,1005 12 SNA
...4 AD480 2203-006324 C-CER,CHIP;2200nF,10%,10V,X5R,TP,1608 2 SA
...4 AD480 2203-006348 C-CER,CHIP;1000nF,10%,25V,X5R,TP,1608,0. 5 SA
...4 AD480 2203-006474 C-CER,CHIP;22000nF,20%,6.3V,X5R,TP,2012 3 SA
...4 AD480 2203-006562 C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 11 SNA
...4 AD480 2203-006824 C-CER,CHIP;4700nF,10%,10V,X5R,TP,1608 2 SNA
...4 AD480 2203-006890 C-CER,CHIP;10000nF,20%,6.3V,X5R,TP,1608 24 SA
...4 AD480 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012,1 9 SNA
...4 AD480 2203-007240 C-CER,CHIP;22000nF,20%,6.3V,X5R,TP,1608( 8 SA
...4 AD480 2203-007269 C-CER,CHIP;22000nF,20%,10V,X5R,TP,2012(2 7 SA
...4 AD480 2203-007270 C-CER,CHIP;10000nF,10%,10V,X5R,TP,1608,0 7 SNA
...4 AD480 2203-007486 C-CER,CHIP;1000nF,10%,50V,X5R,TP,1608 1 SNA
...4 AD480 2203-008096 C-CER,CHIP;2200nF,10%,50V,X5R,TP,2012,1. 3 SA
...4 AD480 2203-008315 C-CER,CHIP;22000nF,20%,25V,X5R,TP,2012,T 9 SA
...4 AD480 2203-009740 C-CER,CHIP;1000nF,10%,100V,X7R,TP,3216,2 2 SA
...4 2402-001268 C-AL,SMD;100uF,20%,25V,WT,TP,8x6.3mm 1 SA
...4 2402-001276 C-AL,SMD;47uF,20%,35V,TP,6.6x6.6x5.8mm 1 SNA
...4 2703-000175 INDUCTOR-SMD;270nH,10%,1608,0.8Ohm,50mA, 4 SA
...4 2703-000213 INDUCTOR-SMD;470nH,10%,1.35Ohm,35mA,15,M 1 SA
...4 2703-001880 INDUCTOR-SMD;180nH,5%,1608,0.8T,2.7Ohm,2 1 SA
...4 2703-001938 INDUCTOR-SMD;56nH,5%,1005,1.5Ohm,200mA,1 3 SA
...4 2703-003149 INDUCTOR-SMD;2.2uH,20%,0.055Ohm,3000mA,W 1 SA
...4 2703-003790 INDUCTOR-SMD;4.7uH,20%,8080,0.025Ohm,450 3 SA
...4 2703-003930 INDUCTOR-SMD;4.7uH,20%,0.072Ohm,2450mA,W 4 SA
...4 2703-004575 INDUCTOR-SMD;22uH,20%,8.5T,0.058Ohm,5500 1 SNA
...4 2801-003773 CRYSTAL-SMD;12MHz,30ppm,28-AAN,20pF,50Oh 1 SA
...4 2801-004813 CRYSTAL-SMD;24MHz,50ppm,8pF,100ohm,TP 1 SA
...4 3301-000314 BEAD-SMD;120ohm,1608,TP,120ohm/100MHz 1 SNA
...4 3301-001364 BEAD-SMD;1000ohm,1608,TP,1085ohm/108MHz, 5 SNA
...4 3301-002039 BEAD-SMD;26ohm,1608,TP 22 SA
...4 3301-002315 BEAD-SMD;120ohm,3216,TP 1 SNA
...4 3601-001374 FUSE-SURFACE MOUNT;32V,5A,FAST-ACTING,PL 2 SA
...4 3701-001967 CONNECTOR-HDMI;19P,A,FEMALE,AU,0.5mm,BLK 2 SA
...4 3707-001106 CONNECTOR-OPTICAL;STRAIGHT,SPDIF,2.5PI 1 SA
...4 3708-001150 CONNECTOR-FPC/FFC/PIC;30P,1mm,SMD-A,SN,Z 1 SA
...4 3709-001782 CONNECTOR-CARD SLOT;68P,1.27mm,ANGLE,AU, 1 SA
...4 3711-007776 CONNECTOR-HEADER;BOX,8P,1R,1.25mm,SMD-A, 1 SA
...4 EH01 3711-008131 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,AN 1 SA
ANNEX-5
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 EH01 3711-008690 HEADER-BOARD TO CABLE;BOX,8P,1R,2.5mm,AN 1 SA
...4 3722-003322 JACK-DC POWER;4P,4PI,SN/PB,BLK,12.4x10.8 1 SA
...4 3722-003457 JACK-USB;4P/1C,NI,BLK,ANGLE,A,2.0,13.1x1 1 SA
...4 JACK PIN 3722-003546 JACK-PIN;5P,NI/SN,BLU/GRN/RED/WHT/YEL,SM 1 SA
...4 BN27-00094A COIL;CMI-SC0703-271K,270nH,10%,-,13ts짹1 1 SA
...4 BN37-00013A CONNECTOR-TUNER SHIELD;CPJ-AS-907A,1A,15 1 SA
...4 BN41-02527A PCB-MAIN;NT16L,FR-4,4L,1.2T,141x192mm,1, 1 SNA
...4 CB07 BN61-13312B BRACKET-PCB;55KS8000,SK5,T0.3,13.7,11.4, 4 SNA
...4 BN97-11149A ASSY MICOM-MAIN;T-NT16LDEUC,NT16L,1107-0 1 SNA
....5 1107-002459 IC-NAND FLASH;F59L1G81MA-25TIG2Y,1Gbit,1 1 SA
....5 BN46-00541B S/W MANUAL;T-NT16LDEUC,NLDVBEU2K,E-MANUA 1 SNA
....5 BN46-00546A S/W MICOM;T-NT16LDEUC,K4100/K4170/K5100/ 1 SNA
...4 BN97-11163A ASSY MICOM-SUB;T-NT16LDEUS,EU/AA,NT16L,1 1 SNA
....5 1107-002226 IC-NOR FLASH;W25Q40CLSSIP,4Mbit,SOIC,8P, 1 SA
..3 BN97-11280A ASSY DRM;NT16L/NT16M,BN46-00555A,UES60 & U 1 SNA
...4 BN46-00555A KEY CODE-CERTIFICATION;CI PLUS,NT16L,NT1 1 SNA
1 BN91-17889G ASSY SHIELD;UK4100,32" 1 SNA
0.2 BN02-00102B TAPE-FILAMENT;FILAMENT,#8917,T0.15,W25,L 0 SNA
0.2 BN39-02223E LEAD CONNECTOR-SUB ASSY;32K5100,UL21016, 1 SA
0.2 RF01 BN67-00364C FOOT-RUBBER;X13,RUBBER,GRAY,W10,L10,T6 1 SNA
0.2 LVDS BN96-26659Q FFC CABLE;UN32F4030AF,Fold,L325,30P 1 SA
0.2 BN96-39802B ASSY BOARD P-FUNCTION TACT;K6200/K5500/K 1 SA
0.2 BN96-39966A ASSY SPEAKER P-FRONT;TV-SPK,K5100,6ohm,1 1 SA
1 ACCE1 BN92-19466D ASSY ACCESSORY;4seres 1 SNA
0.2 P001A BN44-00886D DC VSS(A);A4819_KSML,19V,2.53A,100~240V, 1 SA
0.2 ACCE4 BN96-38835D ASSY ACCESSORY-MANUAL;UJ4F 1 SNA
..3 6902-001964 BAG PE;LDPE,BIOBASED,T0.03,W200,L300,TRP 1 SNA
..3 BN68-03548J LEAFLET-WARRANTY;comm,Samsung,17Lang,Mid 1 SNA
..3 BN68-04972E LEAFLET-REGULATORY GUIDE;ALL,SAMSUNG,W/W 1 SNA
..3 BN68-07346X MANUAL USERS;UK5100B,XH,ENG/POL/SLV/HUN/ 1 SNA
..3 BN68-07598A LEAFLET-FICHE;ALL,W/P,0 1 SNA
0.2 ACCE2 BN96-38839A ASSY ACCESSORY-CABLE;UJ4F 1 SNA
..3 3721-001283 PLUG-CONVERSION;2P,Ni,15,BLACK,17.5mm,EU 1 SA
..3 4301-000121 BATTERY-MN;1.5V,R03,10.5x44.5m,7.5g,AAA 2 SNA
..3 6902-001965 BAG PE;LDPE,BIOBASED,T0.05,W200,L300,TRP 1 SNA
..3 REMO2 AA59-00741A REMOCON-TV;2012 TV,Samsung,44KEY,3V,F502 1 SA
..3 BN68-02989A LABEL ETC;ALL,ALL,PAPER,W30,L65,WHITE,SE 2 SNA
1 BN92-20130C ASSY LABEL;4series 1 SNA
0.2 BN68-06708G LABEL-RATING;Monitor,WW,PP,T0.161,W93,L7 1 SNA
0.2 BN68-07350D LEAFLET-QUICK SETUP GUIDE;32" UK5100B/UK 1 SNA
0.2 BN68-07519A LABEL-ENERGY;ALL JORDAN,WW,PP,T0.135,W60 1 SNA
1 BN92-20131B ASSY LABEL POP;4series 1 SNA
0.2 BN68-07971H LABEL POP-HIGHLIGHT;32K4100,PET,T0.1,W90 1 SNA
1 BN92-20455V ASSY BOX;UK4100,32" 1 SNA
0.2 BH68-00662A LABEL BOX;ALL,ART PAPER,W60,L110,WHT,NO 1 SNA
0.2 BN68-05640A LABEL BOX;ALL,ART PAPER,W110,L130,EUROPE 1 SNA
0.2 BN69-13647E BOX UNIT;32K4100,CB,SW4,F1,L781,W122,H50 1 SNA
ANNEX-6
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
1 BN92-20456A ASSY P/MATERIAL;UK4100,32" 1 SNA
0.2 0203-006958 TAPE-OPP;OPP,T0.065,W75,L1500M,CLEAR,#31 2 SNA
0.2 6902-002501 BAG ROLL;HDPE/PE FOAM,T0.5*,W750,L300M,T 2 SNA
0.2 6922-000013 BAND;PP,W18,L2300/L2900,TRP 1 SNA
0.2 BN01-00039A SHEET-PROTECTION COVER;LB4C,PE,T0.08,W93 0 SNA
0.2 AS080 BN63-10787F SHEET-PROTECTION COVER;UE22ES5000,PE,T4, 1 SNA
0.2 BN69-13429A CUSHION-SET;32K4100,EPS,16.7g/l,WHT 1 SNA
..3 0103-005099 RESIN EPS;BASF303,Natural,Natural 181 SNA
0.2 BN69-14440A PALLET-WOODEN;32",WOOD,800,1200,H130,2-W 1 SNA
1 BN95-03212A PRODUCT LCD DP;DP,BN95-02691A,SEH ONLY 1 SA
0.2 BN92-20675A ASSY P/MATERIAL;CY-FK032ANEV1H,inhouse L 1 SNA
..3 BN69-13430B CUSHION-PANEL;32K4000,EPS,ESD,-,-,-,22.2 1 SNA
...4 0103-005099 RESIN EPS;BASF303,Natural,Natural 2387 SNA
0.2 BN95-02691A PRODUCT LCD-CSOT;CY-FK032ANHV1V,K4100,Y1 1 SA
..3 AS080 BN63-07229A SHEET-PROTECTION COVER;rose70",PET,T0.05 1 SNA
..3 BN68-05722A LABEL-E PASS;POLYPROPYLENE,NON-COATING 1 SNA
..3 BN74-00053E TAPE-PAPER;PAPER,3M2307,T0.14,W20,L50M,W 0 SNA
..3 BN90-08215A ASSY MISC-BLU;Y16,LCM 1 SNA
...4 BN39-02225A LEAD CONNECTOR-BLU;32K4000,UL21016,3P,10 1 SNA
...4 HDP01 BN61-08161A HOLDER-PCB;Direct-LED,PC,MOLD,white,V-2 2 SNA
....5 0103-009493 RESIN PC;LH-1070W,W92853,WT0107,V-0 2 SNA
...4 BN61-13643A OPTICAL SHEET-REFLECTOR;16Y_K5100_32 inc 1 SNA
...4 BN61-13680A FRAME-MIDDLE TOP;32K4100,TPV,HB,BK0008,M 1 SNA
...4 BN61-13681A FRAME-MIDDLE BOTTOM;32K4100,TPV,HB,BK000 1 SNA
...4 BN61-13682A FRAME-MIDDLE LEFT;32K4100,TPV,HB,BK0008, 1 SNA
...4 BN61-13761A FRAME-MIDDLE RIGHT;32K4100,TPV,HB,BK0008 1 SNA
....5 0103-010669 RESIN TPE;5402PV/5409H,Black,BK0008,HB,T 110 SNA
...4 BN61-13958A OPTICAL SHEET-COMPLEX;16Y_K4100_32INCH_O 1 SNA
...4 BN96-39779A ASSY LED BAR P;K4100 32inch HD CSOT,ALUM 1 SNA
...4 BN96-40505G ASSY CHASSIS REAR P;32K4100,PC+ABS+ED20% 1 SNA
....5 SCREW 6003-000115 SCREW-TAPTYPE;BH,+,B,M3,L6,ZPC(BLK),SWRC 3 SA
....5 BN96-40505F ASSY CHASSIS REAR P;32K4100,PC+ABS+ED20% 1 SNA
.....6 SCREW 6003-000115 SCREW-TAPTYPE;BH,+,B,M3,L6,ZPC(BLK),SWRC 8 SA
.....6 T0073 AA63-01617A GASKET-EMI;50Q71,Conductive Fabric,T1.0, 2 SNA
.....6 BN02-00102B TAPE-FILAMENT;FILAMENT,#8917,T0.15,W25,L 0 SNA
.....6 BN02-00435B TAPE PET;K5300,PET,T1.3,W12,L40,WHITE 2 SNA
.....6 BN39-02183A LEAD CONNECTOR-BLU;32K5000,UL21016,8P,80 1 SNA
.....6 BN61-04692A ADHESIVE-AA;SHEET,CLEAR,C043 0 SNA
.....6 BN61-05915A TAPE DOUBLE FACE;65LB650,ACRYL FOAM,T1.1 0 SNA
.....6 CB07 BN61-13726A BRACKET-PCB;32K5100,EGI-SECC,T0.6,NATURA 1 SNA
......7 BN01-00394A STEEL;32K5100,EGI-SECC,L275,0.6,510,AG 1 SNA
......7 CB20 BN61-13521A BRACKET-WALL;32K5500,CR-SPCC,T1.2,L10.5, 4 SNA
.....6 AB285 BN61-14143A BRACKET-REAR;32K5300,EGI-SECC,T1,NATURAL 1 SNA
.....6 BN61-14255A HOLDER-SHEET;32K5300,ABS,MOLD,WT0034,HB, 1 SNA
.....6 BN61-14263A FRAME-CHASSIS REAR BOTTOM LEFT;32K4100,P 1 SNA
.....6 BN61-14264A FRAME-CHASSIS REAR BOTTOM RIGHT;32K4100, 1 SNA
......7 0103-009493 RESIN PC;LH-1070W,W92853,WT0107,V-0 8 SNA
ANNEX-7
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
.....6 BN61-14335A BRACKET-STAND LEFT;32K5300,SK5,T0.5,NATU 1 SNA
.....6 BN61-14336A BRACKET-STAND RIGHT;32K5300,SK5,T0.5,NAT 1 SNA
.....6 BN63-16049A GASKET-EMI;GASKET,FABRIC,T3.3,W45,L10,Gr 2 SNA
.....6 BN63-16106A SHEET-PS;32K5300,PS,T1,W6,L170,GRAY,RIGH 1 SNA
.....6 BN63-16107A SHEET-PS;32K5300,PS,T1,W6,L170,GRAY,LEFT 1 SNA
.....6 CC04 BN64-03508A CHASSIS-REAR;32K4100,PC+ABS+ED20%,V-1,MO 1 SNA
......7 0103-010844 RESIN PC ABS;CM20G/BK90070,Deep Blue Bla 2050 SNA
......7 CCM1 BN63-02183D SHEET-PROTECTION COVER;Rhcm,PE,T0.04,W68 2 SNA
.....6 BN74-00053E TAPE-PAPER;PAPER,3M2307,T0.14,W20,L50M,W 0 SNA
....5 BN96-40920A ASSY BRACKET P-LED PCB;32K5300,EGI-SECC, 1 SNA
.....6 BN61-13250A BRACKET-LED PCB;32K5100,EGI-SECC,T0.6,NA 1 SNA
.....6 BN61-14256A HOLDER-SHEET;32K5300,ABS,MOLD,WT0034,HB, 1 SNA
..3 BN96-30110B ASSY OPEN CELL;ST3151A04-8,16:9,32inch 6 1 SNA
...4 BN81-11242A A/S-IC DRIVER SOURCE;ST3151A04-8,3302100 1 SNA
...4 BN81-11243A A/S-IC DRIVER GATE;ST3151A04-8,330110000 1 SNA
...4 BN81-11244A A/S-POLARIZER CF;ST3151A04-7,31305061000 1 SNA
...4 BN81-11245A A/S-POLARIZER TFT;ST3151A04-7,3130506000 1 SNA
...4 BN81-12726A A/S-ASSY PCB SOURCE;A/S-ASSY PCB-SOURCE, 1 SNA
..3 BN96-40415A ASSY CHASSIS FRONT P;32K4100,PC+ABS,BLK, 1 SA
...4 BN60-00715D SPACER-CONDUCTIVE;LCM MNT 28,CONDUCTIVE 4 SNA
...4 BN60-00930C SPACER-CONDUCTIVE;Y14 NNB/VNB 32",CONDUC 1 SNA
...4 BN60-00930D SPACER-CONDUCTIVE;Y14 NNB/VNB 32",CONDUC 2 SNA
...4 BN60-01060Z SPACER-CONDUCTIVE;32J4004, CSOT,CONDUCTI 1 SNA
...4 BN63-07556G SHEET-PROTECTION COVER;TOC,PO,T0.7,W70,L 1 SNA
...4 AS080 BN63-07556Y SHEET-PROTECTION COVER;Y13 SF-LED,PO,T0. 2 SNA
...4 BN63-16054A GASKET-EMI;GASKET,FABRIC,T8,W23,L10,Gray 2 SNA
...4 BN63-16066A SHEET-THERMAL;32K5300,Al,T0.5,W10,L570,B 1 SNA
...4 AC155 BN64-03507A CHASSIS-FRONT;32K4100,PC+ABS,V-0,MOLD,BK 1 SNA
....5 0103-010904 RESIN PC ABS;NH-1017SG/72317,Deep Blue B 200 SNA
ANNEX-8
ANNEX. Exploded View & Part List

Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as
electrical shock.
1-1-1. Warnings
WARNING
For continued safety, do not attempt to modify the circuit board.
Disconnect the AC power and DC power jack before servicing.
1-1-2. Servicing the LED TV
When servicing the LED TV, Disconnect the AC line cord from the AC outlet.1.
It is essential that service technicians have an accurate voltage meter available at all times. Check the calibration of this2.
meter periodically.
1-1-3. Fire and Shock Hazard
Before returning the monitor to the user, perform the following safety checks:
Inspect each lead dress to make certain that the leads are not pinched or that hardware is not lodged between the1.
chassis and other metal parts in the monitor.
Inspect all protective devices such as nonmetallic control knobs, insulating materials, cabinet backs, adjustment and2.
compartment covers or shields, isolation resistorcapacitor networks, mechanical insulators, etc.
Leakage Current Hot Check:3.
DEVICE
UNDER
TEST
(READING SHOULD)
NOT BE ABOVE 0.5mA LEAKAGE
CURRENT
TESTER
TEST ALL
EXPOSED METAL
SURFACES
2-WIRE CORD
ALSO TEST WITH
PLUG REVERSED
(USING AC ADAPTER
PLUG AS REQUIRED)
EARTH
GROUND
WARNING
Do not use an isolation transformer during this test.
Use a leakage current tester or a metering system that complies with American National Standards
Institute (ANSI C101.1, Leakage Current for Appliances), and Underwriters Laboratories (UL
Publication UL1410, 59.7).
With the unit completely reassembled, plug the AC line cord directly into a 120V AC outlet. With the unit’s AC switch rst 4.
in the ON position and then OFF, measure the current between a known earth ground (metal water pipe, conduit, etc.)
and all exposed metal parts, including: metal cabinets, screwheads and control shafts.
The current measured should not exceed 0.5 milliamp.
Reverse the power-plug prongs in the AC outlet and repeat the test.
1-1
1. Precautions
1. Precautions
1-1. Safety Precautions

1-2
1. Precautions
1-1-4. Product Safety Notices
Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from visual
inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage,
wattage, etc. Parts that have special safety characteristics are identied by on schematics and parts lists. A substitute
replacement that does not have the same safety characteristics as the recommended replacement part might create
shock, re and/or other hazards. Product safety is under review continuously and new instructions are issued whenever
appropriate.

WARNING
An electrolytic capacitor installed with the wrong polarity might explode.
CAUTION
Before servicing units covered by this service manual, read and follow the Safety Precautions section of
this manual.
NOTE
If unforeseen circumstances create conict between the following servicing precautions and any of the
safety precautions, always follow the safety precautions.
1-2-1. General Servicing Precautions
Always unplug the unit’s AC power cord from the AC power source and disconnect the DC Power Jack before1.
attempting to: (a) remove or reinstall any component or assembly, (b) disconnect PCB plugs or connectors, (c) connect
a test component in parallel with an electrolytic capacitor.
Some components are raised above the printed circuit board for safety. An insulation tube or tape is sometimes used.2.
The internal wiring is sometimes clamped to prevent contact with thermally hot components. Reinstall all such elements
to their original position.
After servicing, always check that the screws, components and wiring have been correctly reinstalled. Make sure that3.
the area around the serviced part has not been damaged.
Check the insulation between the blades of the AC plug and accessible conductive parts (examples: metal panels, input4.
terminals and earphone jacks).
Insulation Checking Procedure: Disconnect the power cord from the AC source and turn the power switch ON. Connect5.
an insulation resistance meter (500 V) to theblades of the AC plug. The insulation resistance between each blade of the
AC plug and accessible conductive parts (see above) should be greater than 1 megohm.
Always connect a test instrument’s ground lead to the instrument chassis ground before connecting the positive lead;6.
always remove the instrument’s ground lead last.
1-3
1. Precautions
1-2. Servicing Precautions

Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly
called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some eld-effect
transistors. The following techniques will reduce the incidence of component damage caused by static electricity.
Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your1.
body by touching a known earth ground. Alternatively, wear a discharging wrist-strap device. To avoid a shock hazard,
be sure to remove the wrist strap before applying power to the monitor.
After removing an ESD-equipped assembly, place it on a conductive surface such as aluminum foil to prevent2.
accumulation of an electrostatic charge.
Do not use freon-propelled chemicals. These can generate electrical charges sufcient to damage ESDs.3.
Use only a grounded-tip soldering iron to solder or desolder ESDs.4.
Use only an anti-static solder removal device. Some solder removal devices not classied as “anti-static” can generate 5.
electrical charges sufcient to damage ESDs.
Do not remove a replacement ESD from its protective package until you are ready to install it. Most replacement ESDs6.
are packaged with leads that are electrically shorted together by conductive foam, aluminum foil or other conductive
materials.
Immediately before removing the protective material from the leads of a replacement ESD, touch the protective material7.
to the chassis or circuit assembly into which the device will be installed.
CAUTION
Be sure no power is applied to the chassis or circuit and observe all other safety precautions.
Minimize body motions when handling unpackaged replacement ESDs. Motions such as brushing clothes together, or8.
lifting your foot from a carpeted oor can generate enough static electricity to damage an ESD.
1-4
1. Precautions
1-3. Static Electricity Precautions

For safety reasons, more than a people are required for carrying the product.1.
Keep the power cord away from any heat emitting devices, as a melted covering may cause re or electric shock.2.
Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature3.
may cause re.
Bend the external antenna cable when connecting it to the product. This is a measure to protect it from being exposed4.
to moisture. Otherwise, it may cause a re or electric shock.
Make sure to turn the power off and unplug the power cord from the outlet before repositioning the product. Also check5.
the antenna cable or the external connectors if they are fully unplugged. Damage to the cord may cause re or electric
shock.
Keep the antenna far away from any high-voltage cables and install it rmly. Contact with the highvoltage cable or the 6.
antenna falling over may cause re or electric shock.
When installing the product, leave enough space (0.4m) between the product and the wall for ventilation purposes.7.
A rise in temperature within the product may cause re.
If an equipment is provided with a replaceable battery, and if replacement by an incorrect type could result in an8.
explosion (for example, with some lithium batteries), the following applies:
CAUTION
Risk of explosion if battery is replaced by an incorrect type dispose of used batteries according to•
the instructions.
Do not dispose of batteries in a re.•
Do not short circuit, disassemble or overheat the batteries.•
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent•
type.
Do not be exposed to excessive heat such as sunshine, re or the like.•
1-5
1. Precautions
1-4. Installation Precautions

2-1
2. Product specications
2. Product Specications
2-1. Product information
Model UE32K4100AW
Front View
W
D
* W : Width H : High D : Depth
H
Detail View
Color Front : INDIGO BLACK, Stand : SILVER, Middle : INDIGO BLACK
Dimensions
(W x H x D) 32"
With Stand 728.7 x 521.7 x 185.3 mm
Without Stand 728.7 x 468.8 x 78.0 mm
Weight 32"
With Stand 4.8 kg
Without Stand 4.7 kg
Panel Type All Slim LED

2-2
2. Product specications
2-2. Product specication
2-2-1. Detailed Specications
NOTE
Design and specications are subject to change without prior notice.
Item UE32K4100AWXXH
General Information Product LED
Series 4
Country HUNGARY
Display Screen Size 32"
Resolution 1366 x 768
Ultra Black N/A
Quantum Dot Display N/A
Screen Curvature N/A
10 bit Support N/A
Video Picture Engine HyperReal
Motion Rate 50
PQI (Picture Quality Index) 100
HDR (High Dynamic Range) N/A
Dynamic Contrast Ratio Mega Contrast
Micro Dimming N/A
Precision Black (Local Dimming) N/A
Quantum Dot Color N/A
Active Crystal Color N/A
Wide Color Enhancer (Plus) Yes
PurColor N/A
Auto Depth Enhancer N/A
Contrast Enhancer N/A
Auto Motion Plus N/A
Film Mode Yes
Peak Illuminator N/A
Audio Dolby Digital Plus Yes
DTS Codec Yes
Sound Output (RMS) 10W+10W
Speaker Type 2CH(Full Range SPK)
Woofer N/A
Wallmount Sound Mode Yes
