PRESONUS BLUETUBE DP User manual

USERS MANUAL
?2004, PreSonus Audio Electronics, Incorporated.
All rights reserved.

2
PreSonus Limited Warranty
PreSonus Audio Electronics Inc. warrants this product to be free of defects in material and
workmanship for a period of one year from the date of original retail purchase. This warranty is
enforceable only by the original retail purchaser. To be protected by this warranty, the
purchaser must complete and return the enclosed warranty card within 14 days of purchase.
During the warranty period PreSonus shall, at its sole and absolute option, either repair or
replace, free of charge, any product that proves to be defective on inspection by PreSonus or its
authorizedservicerepresentative. To obtain warranty service, the purchaser must first call or
write PreSonus at the address and telephone number printed below to obtain a Return
Authorization Number and instructions of where to return the unit for service. All inquiries must
be accompanied by a description of the problem. All authorized returns must be sent to the
PreSonus repair facility postage prepaid, insured and properly packaged. PreSonus reserves
the right to update any unit returned for repair. PreSonus reserves the right to change or
improve the design of the product at any time without prior notice. This warranty does not cover
claims for damage due to abuse, neglect, alteration or attempted repair by unauthorized
personnel, and is limited to failures arising during normal use that are due to defects in material
or workmanship in the product. Any implied warranties, including implied warranties of
merchantability and fitness for a particular purpose, are limited in duration to the length of this
limited warranty. Some states do not allow limitations on how long an implied warranty lasts, so
the above limitation may not apply to you. In no event will PreSonus be liable for incidental,
consequential or other damages resulting from the breach of any express or implied warranty,
including, among other things, damage to property, damage based on inconvenience or on loss
of use of the product, and, to the extent permitted by law, damages for personal injury. Some
states do not allow the exclusion of limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you. This warranty gives you specific legal rights,
and you may also have other rights, which vary from state to state. This warranty only applies to
products sold and used in the United States of America. For warranty information in all other
countries please refer to your local distributor.
PreSonus Audio Electronics, Inc.
7257 Florida Blvd.
Baton Rouge, LA 70806
[phone]
?2004, PreSonus Audio Electronics, Incorporated. All rights reserved.

3
1Overview
1.1 Introduction
1.2 Features
2 Controls & Connections
2.1 Front Panel Basic Layout
2.2 Preamplifier Section
2.3 Back Panel Basic Layout
3Operation
3.1 Dynamic Microphones
3.2 Phantom Powered Microphones
3.3 Instrument Input
3.4 Some Thoughts on Vacuum Tubes
4Technical
4.1 Specifications

4
1.1INTRODUCTION
Thank you for purchasing the PreSonus BLUETUBE DP two
channel Dual Path mic/instrument preamplifier. This preamp was
designed using state of the art components to deliver crystal clear
audio for an infinite period of time. We believe the BLUETUBE DP
to be an exceptional sounding unit and an exceptional value.
Please contact us at 1-800-750-0323 with your questions or
comments regarding this product. PreSonus Audio Electronics is
committed to constant product improvement and believes the best
way to accomplish this task is by listening to the experts on our
gear, our valued customers. We appreciate the support you have
shown us through the purchase of this product.
Please pay close attention to how you connect your BLUETUBE
DP to your system. Improper grounding or bad cables are the most
common cause of noise problems found in studio or live sound
systems. We urge you to scan this manual before hooking up your
BLUETUBE DP to familiarize yourself with its features and various
applications.
Good luck and enjoy your BLUETUBE DP!
1.2 FEATURES
The following is a summary of your BLUETUBE DP’s features:
?Dual Path Gain Stage.Each channel of your
BLUETUBE DP contains both a solid state preamp
stage and a vacuum tube preamp stage, allowing for
solid state and tube operation. The use of discrete
components in the preamp stage ensures ultra low

5
noise performance and wide dynamic control. This gives
the BLUETUBE DP the ability to boost your signal
without increasing unwanted background noise.
?Phantom Power. Each channel of your BLUETUBE
DP has 48V phantom power available. When the
phantom power switch is engaged on either channel,
power is supplied at a constant rate to that channel. This
assures optimum performance of your condenser
microphone(s) and that the signal will be free of
distortion due to insufficient power.
?PolarityReversal.A polarity reversal switch is provided
on each channel. This switch enables the user to invert
the polarity of a microphone if phase cancellation is
noticed when using identical microphones in close
proximity to one another. The polarity reversal switch
also can compensate for different XLR connector hook-
ups where pin connections have been inverted.
?-20dB Pad. A -20dB pad is available on each channel
for reducing the in-coming signal level. This pad
provides a more manageable signal from high output
devices giving the operator greater control over the in-
coming signal and a much reduced chance of over-
driving the input and thereby avoiding distortion.
?80Hz Filter. A rumble filter is available to eliminate low
frequency noise. This lets you greatly reduce
background noise such as air conditioners or wind noise
with the flick of a switch without effecting the desired
frequencies.
?Mic/Instrument Input. Each channel of the BLUETUBE
DP has a separate Neutrik Combo?XLR / ¼ inch
connector is provided on the back of the chassis for
signal input from microphone XLR or instrument ¼ inch

6
input.
?Tube Drive. The BLUETUBE DP provides a Tube Drive
potentiometer on each channel for controlling the
amount of saturation produced by the 12AX7 vacuum
tube. Greater levels of tube saturation give the signal
greater warmth and a richer sound. This works equally
well on mics and instruments.

7
2.1 FRONT PANEL BASIC LAYOUT
The front panel of theBLUETUBE DP has analog VU meters for channel
1 and 2 to the far left and far right respectively, which measure the input
level.VU stands for ‘volume unit’, which is an averagemeasurement of
the input signal level. This means that not all transients will be displayed
by the VU meter.
Bothpreampchannelscontain:
?+48V Switch
?Polarity Reversal Switch
?-20dB Pad
?80Hz Filter
?Gain Control (0 to 54dB)
?Tube Drive Control (0 to100%)
2.2 PREAMPLIFIER SECTION

8
Phantom Poweris available to each channel input of the BLUETUBE
DP.The 48 volts is supplied by way of the XLR connector for condenser
mics and any other devices requiring continuous power through the XLR
input. This power is supplied at a constant level allowing use of both
inputssimultaneously.
PIN 1 GND
PIN 2 +48v
PIN 3 +48v
XLR connector wiring for Phantom Power
Polarity Reversal Switch. This allows the user to invert the polarity of
the XLR connector by switching pins two and three. The inversion of the
pins of the XLR connector may be necessary to alter the audio phase of
two like microphones to compensate for phase cancellation. It may be
required that the wiring of a cable’s XLR connector be switched to
successfully utilize Phantom power.
-20dB Pad. This provides -20 decibels of attenuation with the push of a
button. This is a very useful feature for rapidly reducing the level coming
into the BLUETUBE DP and thus preventing the input signal from over-
modulating (distorting) the input. This may occur due to high output level
from a microphone or line device. Padding the input serves to provide
increased “headroom” for the operator.
Gain. This control governs the amount of boost to the signal being
processed by the preamplifier. Dynamic mics and instruments without
pre-amps will normally require more gain than condenser mics and
instruments that have a built-in preamp (care should be taken with
instruments having their own built-in preamp not to overdrive the input of
the BLUETUBE DP). If you should require more signal out of the pre-
amp for a hotter recording level or to drive an input of some down
stream device harder, cranking up the gain should provide all the

9
signal that you’ll need.
TubeDrive. The BLUETUBE DP Tube Drive control increases the
amount of saturation produced by the 12AX7 vacuum tube. The Tube
Drive can be turned on or off, and the effect achieved by this procedure
can be subtle to extreme, depending on the setting being used. A
“warming up” of the sound can be noticed with lower Tube Drive settings.
This desirable effect is especially good for microphones and electric bass
guitar, resulting in a warmer, “rounder” sound. An overdriven signal can
be achieved by significantly raising the level of the Tube Drive control.
This overdriven tube effect is extremely useful in creating vintage guitar
sounds and great for use with harmonicas for that authentic “Blues harp”
sound. The limits on the possibilities of the Tube Drive control are up to
you, your application,and your imagination. Experiment!

10
2.3BACK PANEL BASIC LA YOUT
PIN 1 GND
PIN 2 High (+)
PIN 3 Low (-)
Cable Wiring Diagram for Input and Output XLR
The Output XLR Connector is servo balanced and operates at
+4dBu.
TIP High (+)
SLEEVE GND (-)
CableWiringDiagram for Input and Output ¼” TS Plug
TheOutput ¼” TS Connector is unbalanced and operates at
-10dBv.

11
3.1 DYNAMIC MICROPHO NES
Dynamic microphones are characterized by lower output levels. Hence,
more gain is needed to amplify a dynamic microphone to operating level.
Occasionally it is necessary to engage the –20dB pad to the microphone
to avoid distortion (e.g. when recording percussion). Do not use phantom
power when using dynamic microphones.
3.2 PHANTOM POWERED(CONDENSOR) MICROPHONES
Phantom powered microphones such as condenser microphones require
external power for the microphone to operate. These microphones
typically have much higher output than dynamic microphones. Use the –
20dBto avoid distortion while recording loud sources.
3.3 INSTRUMENT INPUT
The instrument input is designed to handle ¼” plugs from instruments
such as guitars and basses. This instrument input is an ultra high
impedance amplifier designed to allow the full audio potential of an
acoustic or electric instrument pickup to be realized. Care should be
taken not to overdrive the input with instrument preamplifiers.

12
3.4 SOME THOUGHTS ONVACUUM TUBES
The BLUETUBE DP comes supplied with a 12AX7 vacuum tube
that meets or exceeds the stated performance criteria for the unit.
We expect some owners of the BLUETUBE DP will try different
tubes to investigate the various performance possibilities they
might provide. Tube replacement can be easily accomplished by
first unplugging the unit from the electrical outlet and removing the
screws which attach the top to the chassis. The tube is mounted in
a transverse fashion and care should be taken to properly align the
pins on the tube to the corresponding holes in the receptacle.
Make sure the tube is completely seated in the receptacle and
replace the top of the unit before restoring power to it. Remember:
Tube life and performance are affected by how often a tube is used
and by how hard the tube is driven when in use. Signs of wear
may be exhibited by poor performance or by the tube becoming
“microphonic”. Periodic replacement of vacuum tubes is
recommended. The time between the suggested replacement
varies greatly with use. If you notice a deterioration in sound
quality then it’s time to change the tube.

4.1 TECHNICAL SPECIFICATIONS
BLUETUBE DP Technical Specifications:
Number of Channels Two
Performance
THD + Noise (Unweighted) 0.005%@0dBTubeDrive
10% @ 100% Tube Drive
Noise Floor -94dBu
Signal to Noise >90dB
Power Supply Rejection >98dB
Amplifier TypeDual Path
Input
Connectors Neutrik?Combo
Input Impedance, XLR 1.3k Ohms
Input Impedance, High Z ¼” 1Meg Ohms
Output
Output Impedance, XLR Balanced 51 Ohms
Output Impedance, ¼”TRS Unbalanced 51 Ohms
Panel Controls
Tube Drive 0% -100%
Gain 0dB to +54dB
Polarity Reversal
-20dB Pad
80Hz Filter
+48V Phantom Power
Metering
Backlit VU Meter -20dBu to +6dBu
Power Supply
Type Linear Supply
Input 16 VAC/1000mA
(The power supply that ships with the unit is for the country that it ships to.)
Power 16 WATTS
Physical
Weight 4lbs.
Size ½ U Rack
Dimensions 8” X 5” X 1.75”
Chassis Steel
Front Panel Brushed Aluminum
As a commitment to constant improvement, PreSonus, Inc. reserves the right to change any specification
stated herein at any time in the future without notification.
13
