Acousti-Q
Tube Preamp/Blender for Acoustic Instruments
The Acousti-Q is the first affordable tube-based preamp/blender for acoustic instruments. The Acousti-Q is the perfect
solution to help acoustic musicians bring their personal style and sound to new heights! The Acousti-Q gives you the
choice to use a single (piezo pick-up) or dual (piezo pick-up & mini-internal microphones) source. With two sources, you
can blend the signals to achieve the perfect mix. Guitars, woodwinds, basses, brass instruments – virtually any acoustic
instrument can benefit from the warm tube sound of the Acousti-Q.
The Acousti-Q employs two dual-servo preamplifiers with separate gain controls for input, a phase switch, a 12-volt
phantom power supply to accommodate miniature, internal condenser microphones, a variable notch filter and sweepable
mid-band EQ, as well as low and high shelving EQ controls. The master output section gives you the ability to set two
separate volumes, one for normal volume, and the other, a boost, for solo playing.
Acousti-Q
FREQ
LEVEL
+/- 12dB
+12V
PHASE FREQ
LEVEL
+/- 12dB
BRILLIANCE
BASS LEVEL CUT/BOOST
PEDAL +/- 12dB
MUTE
INPUT
POWER
-42 -36 -30 -24 -18 -12 -6 -3 0 3 6 9 12 15 18 24
CUT/BOOSTOUTPUT LEVEL (dBu)
0
-12 +12
293
92 494
0
-12 +12
1k
250 5k
0
-12 +12
10
3(dB) 30
0
-80 +20
0
-12 +12
TIP GAIN
RING GAIN
NOTCH EQUALIZER MASTERTUBE PREAMP
TIP (CH 1)
RING (CH 2)
Tuner/Amp
ACOUSTI-Q
TUBE ACOUSTIC PREAMP/BLENDER
Created, Designed and Manufactured
by PreSonus Audio Electronics In The USA Footswitch -20dB Output Effects Loop Main Output
Tip = Output
Ring = Input
Sleeve = GND
Tip = Mute
Ring = Cut/Boost
Sleeve = GND
POWER
18 VAC

Call Today: 1-800-750-0323
Presonus Audio Electronics, Inc.
7257 Florida Blvd. | Baton Rouge, LA 70806
Phone: [phone] | Fax: [phone]
[email protected] | www.presonus.com
Input
TRS
Tip Impedance...............................................................................................................................10 Meg Ohms
Ring Impedance................................................................................10 Meg Ohms (Without +12V Phantom Power)...........................................................................................................
3.2k Ohms (With +12V Phantom Power)
Output
Main Output XLR...................................................................................................................51 Ohms (Balanced)
-20dB Tuner/Amp..............................................................................................................51 Ohms (Unbalanced)
Effects Loop
Tip = Output/Send ............................................................................................................51 Ohms (Unbalanced)
Ring = Input/Return.........................................................................................................50k Ohms (Unbalanced)
Sleeve = Ground
Footswitch
Tip = Mute
Ring = Cut/Boost
Sleeve = Ground
Panel Controls
+12V DC Phantom Power (Ring Only)
Phase Invert (Ring Only)
Tip Gain...............................................................................................................................................0 - 40dB
Ring Gain .............................................................................................................................................0 - 40dB
Notch (+/-12dB)................................................................................................................................92 - 494Hz
Equalizer (+/-12dB)........................................................................................................................250Hz - 5kHz
Bass .......................................................................................................................................................100Hz
Brilliance...................................................................................................................................................8kHz
Mute........................................................................................................................................Main Output Only
Master Level ................................................................................................................................-80dB - +20dB
Cut/Boost.............................................................................................................................................+/-12dB
Performance
THD+Noise .......................................................................................................................0.005% (0dBu output)..................................................................................................................................
0.05% (+10dBu output)...................................................................................................................................
0.3% (+20dBu output)
Signal To Noise........................................................................................................................................>90dB
Amplifier Type ...................................................................................................................................Dual Servo
Meters
LED...................................................................................................................................................-42 to Clip
Physical
Weight .....................................................................................................................................................7 lbs.
Dimensions ...............................................................................................................................8" x 4.5" x 1.75"
Mounting ..................................................................................Custom Rack Adapter or Universal Rack Tray Insert
Chassis .....................................................................................................................................................Steel
Panel.....................................................................................................................................Brushed Aluminum
Power Supply
Type .......................................................................................................................................................Linear
Input.....................................................................................................................................................18V AC
Power..................................................................................................................................................20 Watts
Transformer..........................................................................................................................External Wall Mount
Acousti-Q
Technicial Specifications
Acousti-Q
