Pressalit AutoClose User manual

seats for your senses
www.pressalit.com
AutoClose®by Pressalit
Page
2-15
Instruction manual AutoClose®by Pressalit
GB

2
Congratulations on your new AutoClose® toilet seat.
Please read this instruction manual carefully before use and keep it
in a safe place for later reference.
Make sure that the seat fits your toilet.
Check toilet pan on www.pressalitseats.com under ”See what seats fit your toilet”.
Before use
Cleaning
1
If you follow these simple rules, your toilet
seat will stay beautiful for many years:
• Onlyuseregularsoapandwater.
• Neverusespiritsorahandshowerto
clean the console tube.
• Donotleavetheseatdamp-alwaysdry
it with a cloth after cleaning.
• Pleasedonotusetoiletcleanerorany
abrasive,causticorchlorinebased
cleaners as this can result in damage
or flash rust. The toilet seat should be
removeduntilthetoiletcleanerhasbeen
flushed away.

3
GB Page
Before use .................................................................................................... 2
Cleaning ....................................................................................................... 2
Contents ...................................................................................................... 3
Use ...............................................................................................................
4
The AutoClose® function .............................................................................. 4
Extended opening ....................................................................................... 5
Manual closing ............................................................................................. 5
Descriptionofquick-release ....................................................................... 6
Mounting instructions, bottom mounted hinge ........................................... 6-7
Mounting instructions, top mounted hinge ................................................. 7
Battery change indicator .............................................................................
8
Replacing the batteries ............................................................................... 8-11
Troubleshooting ........................................................................................... 12-15
Enclosed key .......................................................................................... Backside
Contents
Guarantee
Pressalit offers a 10-year product guarantee
for AutoClose® oilet seats
excluding electronic components, which are
guaranteed for two years.
Registered design
Patent Pending
Maximum load 240 kg
CE

4
Get to know your toilet seat:
All Pressalit toilet seats are made from solid
colour ingrained duroplast.
Theseatsarescratch-resistantandhavea
smooth easy-to-clean surface.
Functions:
Pressalit AutoClose®seats features a
number of practical functions.
AutoClose®:
The seat and lid close automatically using a
sensor.
Soft close:
Theseatandlidlowersoftlyandlandquietly
on the pan when released.
Quick-release:
Theseatcanbecompletelyremovedfor
easy cleaning.
The toilet seat features an automatic
closing mechanism that ensures that the
seat closes by itself after use. A sensor
located behind the console tube panel
continually registers whether a user is
present. As long as it registers the user,
the seat/lid will remain open. When it
no longer registers anyone, the seat/lid
will automatically close after approx. 15
seconds. The lid will always remain open
foraminimumof1½minutes.Duetothe
sensor, please allow a free distance of at
least 120 cm in front of the toilet.
Use
Min.
... +
1.30
Min. Sec.
0.15
Min. Sec.
3
AutoClose®function
2

5
CLICK!
6
Manual closing
Extended opening
If you want the seat/lid to stay open for a
longer period in connection with cleaning
etc., simply open seat and/or lid and step
outside out of the sensor’s range.
IfyouwanttodeactivatetheAutoClose®
function or if the batteries are dead, the lid
can be closed manually. When the lid is
pushed downwards, you will hear a click. This
is normal. When the lid is fully opened again,
the AutoClose® functionwillbereactivated.
x10
5.00
Min. Sec.
4
5
After about 15 seconds, the sensor will flash
10timesinquicksuccessiontoshowthe
extendedopeningmodehasbeenactivated.

6
Itiseasytoremovetheseatwithquick-
release in order to thoroughly clean the
toilet pan and seat.
Raise the seat to an angle of approx. 15
degrees, push the buttons at the sides
and lift off the seat.
Remount the seat by pressing the buttons
andplacingtheseatovertheconsoletube.
Release the buttons.
Openandclosetheseatandliduntilthe
buttons click into place.
Mounting instructions,
bottom mounted hinge.
15°
Description of quick-release
7
CLICK!
8
Insert bushings
 Note:Usethewhitebushingsiftheyt.
 Ifnot,leavethemoutandmountthetting
without bushings.
If top mounted go to picture 13 .
Sign Art
Modern Art
9
10
Mount the console tube as shown in picture
10.

7
35
5-7°
!
Mount the seat by pressing the buttons and
 placingtheseatovertheconsoletube.
Release the buttons.
Openandclosetheseatandliduntilthe
buttons click into place.
15°
11
Mounting instructions,
top mounted hinge
46
5
79
8
13
2
10 1211
A
B
13
12
 Iftheseatandlidtendtofalloverinopen
position replace the plain rubber disc with
 oneortwooftheenclosedobliquewashers
in each side.
Pay attention to the
arrow’s direction.
Check that the distance between top of the
lid and wall is minimum 35 mm.
See the mounting instructions in picture 13.
 Iftheseatandlidtendtofalloverinopen
position replace the plain rubber disc with
 oneoftheenclosedobliquewashersineach
side (see picture 12).
When placing the washer under the hinge,
please be sure to make the arrow face down.
 Alsoseequickguide

8
When the lid is opened, the red diode in the
console tube panel flashes twice to indicate
if there is sufficient power.
When the diode no longer flashes it is time
to change the batteries.
You need to use 2 x AAA alkaline batteries
(IR3-1.5V ).
To change the batteries, see section on
battery replacement.
Used batteries should be disposed at
authorised collection sites.
x 2
Battery change indicator
14
-visitwww.pressalitseats.comfor
step-by-step instructions.
Lower seat and lid to horizontal position.
Raise the seat to an angle of 15
 degrees.Pressthetwobuttonsandremove
the seat.
Replacing the batteries
Use the key, which you will find on
the backside of this manual. Slide the key
through the oblong hole at the right end of
the console tube and turn the panel 90°.
15°
90°
Pull out the locking module using the key. 17
16
15

9
 Turnandremovethekey.
Insert the batteries with plus and minus
as shown in picture 19. You will need
2 x AAA alkaline batteries (lR3 1.5V). Use
high-qualitybatteriestoavoidchanging
thebatteriestoooften.Avoidchangingthe
batteriesoverthetoiletpanasyoumaydrop
the components.
19
18
Turn the black battery tube until you hear
a clicking sound or until it cannot be turned
any further.
CLICK
21
Check to see if the black tube can be
turned. If not - proceed to picture 21,
otherwise follow instructions in picture 20.
CLICK
20
If the ”teeth” in the two outer rings are not
engaged, please do the following:
Turn the outer ring in the direction of the
arrow so the line on the outer ring is flush
with the line on the inner ring and you hear a
clicking sound. The “teeth” will then lock into
place.
CLICK
22

10
Gently insert the module.
Turn and gently push until the module
slides in and the black ring disappears into
the tube.
Slide the key through the oblong hole at the
right end of the console tube and turn it 90°.
Turn the module until the red line is flush
with the stamped line on the console tube.
 Notethattheblackringmustnotbevisible
(see picture 24).
Press the locking module all the way in.
23
24
26
90°
STOP
25
27
Replacing the batteries

11
28
CLICK!
30
15°
29
Max. 5 min.
32
x2
31
 Turnandremovethekey.
 Saveitforanothertimeinthepocketonthe
backside of this manual.
Openandclosetheseatandliduntilthe
buttons click into place.
Press the two buttons and place the seat
 overtheconsoletube.Releasethebuttons.
After this test that the red diode in the
console tube panel flashes when the lid is
opened.
Step away from the toilet and test that the lid
closes after app. 5 minutes.

12
The seat falls down
and/or the lid stays
up.
- First check whether the seat fits the toilet pan. – see
www.pressalitseats.com and “What fits your toilet”
- The distance from the wall/cistern must be no more
than 14 cm. The distance ahead must be at least
120 cm.
- The seat must be 5-7 degrees further back than 90
degrees to lock into place when open.
- The seat could be mounted on a crooked toilet pan.
Use the enclosed oblique washers to adjust the an-
gle of the seat. See quick guide.
The damper does not
work after the seat has
been removed and
remounted.
- The QR pins are not engaged. Open and close
the seat/lid several times until both buttons have
snapped into place. (See seat when it has been
removed).
- If necessary, remove the seat from the toilet. Use
the battery changing key with the handle facing
forward and place it in the left side of the tube. You
can now turn the Y leg forward towards yourself.
The leg should be in the horizontal position after
troubleshooting. Then attach the seat to the toi-
let again in the same position as it was taken off.
We recommend 15 degrees.
At what angle is the
seat detached?
Place the seat/lid horizontally on the toilet. Lift the
seat off at a 15 degree angle while pressing in the
QR buttons on the side. Refasten by pressing in
the QR buttons, pressing the seat down over the
console at a 15 degree angle, and open/close the
seat/lid a couple of times until the QR buttons pop
out.
Troubleshooting

13
The damper does not
work after the seat has
been removed and
remounted.
A step in the instructions for replacing the batteries
was possible missed. Please follow the instruc-
tions on again, or find step-by-step instruction at
www.pressalit.com/autoclose.
The seat does not
close automatically.
- When the lid opens, the sensor no longer flashes
twice: The batteries need to be replaced.
- If the problem occurs after the batteries have been
replaced: Check if the batteries have been inserted
correctly or whether the batteries have any power.
Please use 2 x AAA alkaline batteries
- The seat has gone into extended open mode:
it closes after about five minutes.
- The seat was pressed too far back. Push the seat
forward to about 90 degrees upright.
- The user or something else is in front of the sensor
and in its range: 1.20 m.
The locking module
has fallen into the toilet
in connection with
battery replacement.
Remove the batteries. Allow the locking module to
dry until all moisture has evapourated. If the locking
device does not work, please contact Pressalit.
The “extended
opening” mechanism
is not working.
The sensor has detected a person and thinks it is a
normal toilet visit.
No flashing light. Reset the electronics by closing the lid for a
minimum of 5 seconds. If this does not work,
follow the instructions or visit the website
www.pressalitseats.com

14
What does two blinks
mean?
The batteries have enough power.
What does ten blinks
mean?
The seat has gone into extended open mode and
stays open for at least five minutes.
Are the rays from
the console tube
dangerous?
No more than the rays from your remote control.
What batteries are
required?
2 AAA (IR3 – 1.5V) high quality alkaline batteries.
Rechargeable batteries can also be used, but are
not recommended, as they typically lose power over
time.
Can the lid close while
you are sitting on the
toilet?
- No. The lid is open for a minimum of 90 seconds.
After this, it checks for movement every 15 seconds.
- If the lid falls down, it might be due to oblique
porcelain. Check the mounting instructions regarding
uneven washers.
- Tighten the fitting – if it is not sufficiently tight, the
seat/lid will have difficulty finding its centre of gravity
when open.
The key to replace the
batteries has been
lost.
A new key and instruction manual can be ordered at
www.pressalitseats.com
Troubleshooting

15
How do you clean the
console tube?
Clean it with the same agent as the rest of the
toilet seat, i.e. regular soapy water, not alcohol, WC
cleaner, etc. The console cannot be showered off.
Remove the seat before cleaning and do not leave it
wet. Also see ’Cleaning’.
Using the AutoClose®
seat, even though the
batteries are dead?
The seat can be closed manually. It makes
a click when the seat/lid are closed, which
is completely normal (the lock disengages).
The Soft Close-function still works.
The AutoClose® function reactivates following a
change of batteries.
How do you remove
the locking module
from the console
tube?
Using the key attached to the backside of this
manual. It is also possible to order an extra key from
Pressalit.
Why can’t the locking
module be pres-
sed into the console
again?
The gears must first fall correctly into place. Also see
’Replacing the batteries’
Seat/lid makes a loud
click sound when it
closes?
This is completely normal. The sound is a sign that
the seat/lid are being released for closing.
Seat/lid falls against
the wall?
- Make sure that the QR buttons are in place and
popped out.
- Use the diagonal washer if the porcelain is oblique.

Pressalit A/S
Pressalitvej 1
DK-8680 Ry
Tel. [phone]
Fax [phone]
[e-mail]
www.pressalitseats.com
A 3516 / 0 8 -11
