PRETUL SICI-7-1/4P User manual

CAUTION Read this manual thoroughly
before using the tool.
INGLÉS
ESPAÑOL
Manual
Circular
Saw
SICI-7-1/4P
ModelCode
SICI-7-1/4P
Applies for:
27098
Power Disc
1.6 Hp 7-1/4”

2
SICI-7-1/4P
ENGLISH
CAUTION
Contents
Keep this manual for future references.
The illustrations in this manual are for reference
only. They might be different from the real tool.
To gain the best performance of
the tool, prolong the duty life,
make the Warranty valid if
necessary, and to avoid hazards
of fatal injuries please read and
understand this Manual before
using the tool.
Technical Data
Power Requirements
General power tool safety warnings
Safety warnings for circular saws
Parts
Start Up
Maintenance
Notes
Authorized Service Centers
Warranty Policy
3
3
4
5
8
9
10
12
13
14

3
SICI-7-1/4P
27098
7-1/4”
Clase II
60 Hz
Circular Saw
16 AWG X 2C with 221 °F insulation temperature.
20 minutes’ work per 10 minutes’ rest.
Maximum 1 hour and 30 minutes daily.
9.4 A
1.6 Hp
Code
Description
Disc
Voltage
Frequency
Current
Power
5 000 RPM
Speed
Work Cycle
Conductors
Insulation IP20
IP Grade
Power Cord Grips used in this product: Type “Y”.
Tool Build Quality: Reinforced insulation
Thermal insulation on motor winding: Class E
127 V
ENGLISH
Power Requirements
WARNING
WARNING Avoid the risk of electric shock or severe injury. When the power cable gets damaged
it should only be replaced by the manufacturer or at a Authorized Service Center.
The build quality of the electric insulation is altered if spills or liquid gets into the tool while in use.
Do not expose to rain, liquids and/or dampness.
Before gaining access to the terminals all power sources should be disconnected.
Technical Data
Tools with double insulation and reinforced insulation are
equipped with a polarized plug (one prong is wider than the other). This plug will
only fit in the right way into a polarized outlet. If the plug cannot be introduced into
the outlet, reverse the plug. If it still doesn’t fit, call a qualified electrician to install
for you a polarized outlet. Do not alter the plug in any way. Both insulation types
eliminate the need of both a grounded third power cord with three prongs or a
grounded power connection.
When using an extension cable, verify the gauge is enough for
the power that your product needs. A lower gauge cable will cause voltage drop in the line, resulting in power loss and
overheating. The following table shows the right size to use depending on cable’s length and the ampere capability shown in
the tool’s nameplate. When in doubt use the next higher gauge.
WARNING
WARNING
from 0 A and up to 10 A
from 10 A and up to 13 A
from 13 A and up to 15 A
from 15 A and up to 20 A
18 AWG(*)
16 AWG
14 AWG
8 AWG
16 AWG
14 AWG
12 AWG
6 AWG
3 (one grounded)
from 6’ to 49’ | higher than 49’
Ampere
Capacity Number of Conductors Extension gauge
WARNING When operating power tools outdoors, use a grounded
extension cable labeled “For Outdoors Use”. These extensions are specially designed for
operating outdoors and reduce the risk of electric shock.

4ENGLISH
Work area
Keep your work area clean, and well lit.
Cluttered and dark areas may cause accidents.
Never use the tool in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust.
Sparks generated by power tools may ignite the flammable material.
Keep children and bystanders at a safe distance while operating
the tool.
Distractions may cause loosing control.
Electrical Safety
The tool plug must match the power outlet. Never modify
the plug in any way. Do not use any adapter plugs with
grounded power tools.
Modified plugs and different power outlets increase the risk of electric shock.
Avoid body contact with grounded surfaces, such as pipes,
radiators, electric ranges and refrigerators.
The risk of electric shock increases if your body is grounded.
Do not expose the tool to rain or wet conditions.
Water entering into the tool increases the risk of electric shock.
Do not force the cord. Never use the cord to carry, lift or unplug
the tool. Keep the cord away from heat, oil, sharp edges or
moving parts.
Damaged or entangled cords increase the risk of electric shock.
When operating a tool outdoors, use an extension cord suitable
for outdoor use.
Using an adequate outdoor extension cord reduces the risk of electric shock.
If operating the tool in a damp location cannot be avoided, use
a ground fault circuit interrupter (GFCI) protected supply.
Using a GFCI reduces the risk of electric shock.
Personal safety
Stay alert, watch what you are doing and use common sense
when operating a tool. Do not use a power tool while you are
tired or under the influence of drugs, alcohol or medication.
A moment of distraction while operating the tool may result in personal injury.
Use personal protective equipment. Always wear eye
protection.
Protective equipment such as safety glasses, anti-dust mask, non-skid shoes,
hard hats and hearing protection used in the right conditions significantly
reduce personal injury.
Prevent unintentional starting up. Ensure the switch is in the
“OFF” position before connecting into the power source and /
or battery as well as when carrying the tool.
Transporting power tools with the finger on the switch or connecting power
tools with the switch in the “ON” position may cause accidents.
Remove any wrench or vice before turning the power tool on.
Wrenches or vices left attached to rotating parts of the tool may result in personal
injury.
Do not overreach. Keep proper footing and balance at all times.
This enables a better control on the tool during unexpected situations.
Dress properly. Do not wear loose clothing or jewelry. Keep
hair, clothes and gloves away from the moving parts.
Loose clothes or long hair may get caught in moving parts.
If you have dust extraction and recollection devices connected
onto the tool, inspect their connections and use them correctly.
Using these devices reduce dust-related risks.
Power Tools Use and Care
Do not force the tool. Use the adequate tool for your
application.
The correct tool delivers a better and safer job at the rate for which it was designed.
Do not use the tool if the switch is not working properly.
Any power tool that cannot be turned ON or OFF is dangerous and should be
repaired before operating.
Disconnect the tool from the power source and / or battery
before making any adjustments, changing accessories or
storing.
These measures reduce the risk of accidentally starting the tool.
Store tools out of the reach of children. Do not allow persons
that are not familiar with the tool or its instructions to
operate the tool.
Power tools are dangerous in the hands of untrained users.
Service the tool. Check the mobile parts are not misaligned or
stuck. There should not be broken parts or other conditions
that may affect its operation. Repair any damage before
using the tool.
Most accidents are caused due to poor maintenance to the tools.
Keep the cutting accessories sharp and clean.
Cutting accessories in good working conditions are less likely to bind and are
easier to control.
Use the tool, components and accessories in accordance with
these instructions and the projected way to use it for the type of
tool when in adequate working conditions.
Using the tool for applications different from those it was designed for, could
result in a hazardous situation.
Service
Repair the tool in a Authorized Service Center
using only identical spare parts.
This will ensure that the safety of the power tool is maintained.
General power tool
safety warnings
WARNING! Read carefully all safety warnings and instructions listed below. Failure to comply with any of
these warnings may result in electric shock, fire and / or severe damage. Save all warnings and instructions for
future references.
This tool is in compliance with
the Official Mexican Standard
(NOM - Norma Oficial Mexicana).

5
ENGLISH
Kickback
Kickback is the sudden and strong movement the tool
experiences outwards from the work piece that can lead
the operator to lose control or even cause him injuries.
Usually this happens when the cutting disc is stuck into
the piece or due to an inefficient operation. To avoid
kickback the following caution measures should be used:
• When the cut-off wheel gets jammed or caught in the
workpiece by the saw cut, the cut-off wheel stops and
consequently the reaction of the motor quickly directs the
tool towards the operator.
• Use perfectly maintained cutting discs. Double-check
discs are properly mounted. Badly mounted, bent,
damaged discs or with worn or dull teeth have a tendency
to get stuck into the material causing kickback.
•Maintain a firm grip on the tool, keeping your body and
arms so that you can resist kickback forces.
• Kickback can cause the saw to jump backward, but
kickback forces can be controlled by the operator if proper
precautions are taken.
• When operating the tool, hold it firmly setting one hand
on the handle and the other hand on the auxiliary handle.
Always use both hands. Keep good balance and footing to
be able to resist the force of possible kickback.
• To make cuts align the disc with the cut axle and wait for
the disc to reach its highest speed before starting to cut.
Do not try to cut setting the disc teeth on top of the work
piece. It could cause kickback.
• To restart working inside the cut, center the disc into the
cut and double-check the discs are not buried into the
material.
• If the cut-off wheel jams, it may advance upward or
produce kickback while restarting the saw operation.
• Support long workpieces to minimize the risk of binding
and kickback.
• If while operating the tool you notice the disc is bending
or the cut is interrupted, release the switch and hold the
tool inside the work piece until the disc comes to a
complete stop. Do not try to remove the disc while still
moving. This could cause kickback.
• To minimize the risk of having the disc stuck and cause
kickback, before cutting a wood piece remove all the nails.
Damp, warped wood or chipboard needs special attention
during the cut. When using large wood planks use supports
close to both sides of the cutting line to avoid the plank to
warp, close the cut and trap the disc. Wood resin and gum
hardened on the disc make the saw run slow. Use resin and
gum remover, hot water or kerosene to remove buildup.
DO NOT use gasoline.
• Use extreme care when making a pocket cut on wall or
blind spots. The disc may get into contact with hidden
objects and cause kickback.
• While operating the tool, do not set your hand or body
aligned with the cut axis, because if kickback sets there is a
severe injury hazard.
• Before starting a cut, the levers to adjust cutting depth
and bevel should be tight and secured. If they move
during the cut, they may cause the disc to bend and
cause kickback. Setting excessive cutting depth increases
the load on the unit and the disc might bend inside the
cut. It also increases the possibility that the cut closes and
increases the available area on top of the cutting disc.
• Do not use dull or damaged cut-off wheels.
• Dull or improperly installed cut-off wheels result in a
narrow cutting gap that causes excessive friction,
deformation of the cut-off wheels and kickback.
General measures
• Move away your hands from the
cutting area and the cutting disc. To prevent from
accidental injury and loosing control, firmly hold the tool
with both hands by the handle and the auxiliary handle.
Do not put your hand under the workpiece. The guard
cannot protect the operator if the cutting wheel reaches
the bottom of the workpiece.
• The accidental contact with a
rotating cutting disc may cause severe personal injury.
• NEVER hold the work piece to cut with
your hands or on top of your leg. Hold the work piece
adequately to avoid your body making contact with the
cutting disc, and to prevent the disc from bending or
loosing control of the tool or the work piece.
• Do not try to remove debris material
when the disc is running.
• Remember that the guards do not
protect you from the moving disc below the work piece.
Therefore never squat or try to put your hand below the
work piece when the machine is running.
WARNING
WARNING
DANGER
DANGER
DANGER
Safety warnings for
circular saws

6ENGLISH
Safety warnings for
circular saws
• Double-check retractable guard and
the spring are working properly before each time you use
the tool. If the guard is not moving freely or is not closing
instantly, service the machine.
• Do not bring the disc near your body
when carrying the tool. If it accidentally starts the
retractable guard may open and make contact with your
clothes.
• Operating the tools holding it by the
insulated parts prevents the user from getting and electrical
discharge if the disc makes contact with hidden cabling.
• ALWAYS keep the electric supply cord away from the
cutting area. The electric supply cord SHALL NEVER hang
on top of the work piece when making the cut.
• Wear always safety glasses with side
protection. If dust is produced wear also a
dust mask.
Retractable guard
Before each use double-check if the retractable guard and
the spring are working correctly. If the guard is not
moving freely or not closing instantaneously service them
before further operation with the tool.
The retractable guard could work slowly because of
damaged parts, gummy deposits or debris accumulation. To
prevent from this possibility clean regularly the insides of
both guards and the disc axis. Use kerosene or compressed
air. Before cleaning disconnect the machine and remove the
cutting discs.
The retractable guard can be opened manually. Make this
only when changing discs and when making cuts such as
cut marking or combined cut. Using the guard lever open
the retractable guard. As soon as the disc gets into the
material, release the lever. For any other type of cuts the
guard should operate automatically. Never leave the
retractable guard in the open position.
The retractable guard might bend due to a stroke or if it
falls. Before operating the tool, verify it moves freely in
every angle and cutting depths. The guard should not
touch the cutting disc or any other part of the tool.
Verify the retractable guard covers the
disc before setting the saw on a bench or on the floor. A
disc rotating due to inertia could cause the saw to move
backwards cutting whatever objects in its way. Verify the
disc stops moving after turning off the tool.
Operation of the bottom guard
• Check that the bottom guard closes properly before using
the saw. Do not operate the saw if the bottom guard does
not have free movement and instantaneous closing. Do not
hold or tie the bottom guard in its open position.
• If the saw accidentally falls, the bottom guard may bend.
Lift the bottom guard with the retractable handle making
sure that the guard moves freely and does not touch the
saw blade or any other workpiece at all angles and depths
of cut.
• Check the operation and condition of the bottom guard
spring. If the guard and spring do not operate properly,
have them serviced before use.
• The bottom guard may operate sluggishly due to damage
to its parts, sticky residue or chip buildup.
• The guard can be retracted manually only for special cuts
such as "deep cuts" and "complex cuts".
• Lift the lower guard and retract the guard with the
retractable handle and as soon as the cut-off wheel touches
the material, release the lower guard. For all other types of
cutting the guard can operate automatically.
Keep hands away from the cutting area
and the cut-off wheel. Keep your support hand on the
auxiliary handle or motor housing.
• If both hands are holding the saw, they cannot be cut by
the cut-off wheel.
• Do not place your hand under the workpiece.
• The guard cannot protect the operator if the cut-off wheel
reaches the bottom of the workpiece.
• Adjust the depth of the cut to the thickness of the
workpiece.
CAUTION
CAUTION
WARNING
WARNING
Verify the retractable guard covers the
disc before setting the saw on a bench or on the floor. A
disc rotating due to inertia could cause the saw to move
backwards cutting whatever objects in its way. Verify the
disc stops moving after turning off the tool.
Remember that the guards do not
protect you from the moving disc below the work piece.
Never squat or put your hand below the work piece when
the tool is running.
Never use flanges or bolts that are damaged or are not
suitable for the blade disc.
Flanges and bolts are specifically designed for the saw, for
optimum performance and safe operation.
• Do not use abrasive discs.
WARNING
WARNING
WARNING

Dust coming from some materials have chemical
substances known to cause cancer, birth and reproductive
defects. Some of these chemical substances are:
• Lead in lead-based paint.
• Crystalline silica in partitions and cement, and other
masonry products.
• Arsenic and Chromium in wood treated with chemical
substances.
• Asbestos
• The risk involved due to exposure to these substances
varies with the frequency this type of job is made. To
reduce being exposed to the chemicals work in
well-ventilated areas, use the adequate safety equipment,
such as dust-mask specifically designed to filter
microscopic particles.
Toxic materials
• Less than one full sprocket should be observed from the
bottom of the workpiece.
• Never hold the workpiece to be cut with your hands or on
your legs when cutting. Make sure the workpiece is on a
stable platform (table).
• It is important to have adequate support during work to
minimize exposure of the body, deformation of the cut-off
wheel or loss of control.
• Hold the tool by the insulated handles only, when
performing an operation where the tool may contact a
hidden wire or cut its own wire.
• Contact with a live wire can cause exposed metal parts of
the tool to become live parts with potential risk of electric
shock.
• When making a continuous straight cut, always use a
guide for making a straight cut.
• Doing so improves the quality of the cut and reduces the
possibility of cut-off wheel deformation.
• Always use cut-off wheels of the correct shape and size to
fit the shaft orifices.
• Cut-off wheels that do not match the saw shaft orifice will
move eccentrically, resulting in loss of control.
• Never use flanges or bolts that are damaged or unsuitable
for the saw blade.
• Flanges and bolts are designed specifically for the saw for
optimum performance and safe operation.
• Check the operation and condition of the bottom guard spring. If
the guard and spring do not operate properly, have them serviced
before use.
• The bottom guard may operate sluggishly due to damage to its
parts, sticky residue or chip buildup.
• The guard can be retracted manually only for special cuts such as
"deep cuts" and "complex cuts".
• Lift the lower guard and retract the guard with the retractable
handle and as soon as the cut-off wheel touches the material,
release the lower guard. For all other types of cutting the guard can
operate automatically.
• Always check that the bottom guard covers the cut-off wheel
before installing it on the work table or on the floor.
• A freely advancing, unguarded cut-off wheel can cause the saw to
advance, cutting everything in its path. Expect that it takes time for
the saw blade to come to a complete stop once the trigger is
released.
7
ENGLISH
Safety warnings for
circular saws

Retractable Guard
Control Lever
Cutting Guide
Adjusting Knob
Circular saw blade
tungsten PRETUL ST-7245P
7-1/4”
Base
Auxiliary
Handle
Auxiliary
Handle
Auxiliary
Handle
Motor
Housing
Fixed
Guard
Cutting Guide
Power
Cord
Cable
Protection
Retractable
Guard
Retractible
Guard
Cutting Angle
Adjustment Knob
Retracable
Guard
Outer Flange
Cutting Angle
Adjusting Knob
Cutting Depth
Blocking Lever
Switch
Axis
Blocking
Button
Axis
Blocking
Button
Switch
lock
Handle
Allen
key
Parts
Saw Dust Ejector.
Saw dust is blown through the
back and sideways, as far away
as possible from the operator.
The motor cooling air is ejected
through the housing and it also
helps ejecting saw dust.
The saw dust ejector can be
used attached to an external
suction unit.
Retractable Guard.
The retractable guard
opens automatically when
the blade gets inside the
work piece. When the cut
is finished, the retractable
guard is closed to cover
the blade.
Motor.
The saw has the power you
need. It cools down
through and extra-large fan.
The use may overheat the
motor! Allow the motor to
cool down setting the no
load speed.
8ENGLISH
Cutting
Depth Guide
Saw Dust
Ejector

9
Start Up
ENGLISH
Cutting Angle Adjustment
1. Loosen the cutting depth blocking lever (C).
2. Having the base fixed, lift the housing until the blade is sticking out of the base to the desired depth. Use the depth
guide (D) as reference.
3. Tighten de cutting depth blocking lever to prevent the housing to move while cutting.
4. Cutting depth may de up to 64 mm
• Cutting depth shall be equal to the work piece thickness or to protrude out of the piece one tooth of the
blade maximum to prevent accidents.
• Connect the plug to the outlet.
• To unblock the switch (A) keep the switch lock (B)
pressed down.
The switch lock prevents from accidental start up.
• Press the switch (A) to start the disc rotation.
• To stop the disc release the switch (A).
The circular saw is a multipurpose tool to cut soft or hard wood, plywood, resopal covered materials, etc..
This tool is not designed to cut metal or masonry, cement or bricks.
• Loosen the cutting angle adjusting knobs (E).
• Fix the base and turn the housing until the blade is in the desired angle.
• Tighten the cutting angle adjustment knobs to prevent the housing to move while cutting.
• The tool can make cuts from 0° to 45°
E
Turning On
CAUTION
CAUTION
Adjusting the Cutting Depth
Base
C
D
A
B
• Use only cut-off wheels whose diameter is specified according to the marking.

10
Start Up
ENGLISH
Cutting Guide Adjustment
Blade Replacement
Maintenance
To keep the work piece width fixed when making cuts use the
cutting guide.
To adjust width, loosen the knob (A) and run the cutting guide
into the desired position.
Do not use abrasive discs.
Cutting Indicator
The front of the base has a cut line indicator for vertical and
bevel cuts. This indicator allows you to guide the saw along
the line drawn on the work material.
A
When the cutting discs wear out, replace them
immediately
The cutting discs’ size specified for this
tool are 7-1/4” Never use a cutting disc of different type or
size. Otherwise it can cause severe personal injury or
damage the tool permanently and making the warranty
void.
Never use damaged or incorrect washers or bolts for
discs. To get excellent and safe operation the washers and
bolts included are specially designed for this model of
tool.
Use cutting discs with an arbor hole of the right size and
shape. Otherwise the disc may start rotating eccentrically
causing loss of control.
1. Unplug the tool and adjust the cutting depth to the
lowest setting. (See page 8).
2. Open the retractile guard all the way (A) and keep it in
that position.
3. Place the wrench (F) on the allen screw (E) and hold
down the shaft lock button (D).
Turn the screw counterclockwise. The cutting wheel will
rotate at the same time as the
bolt, until the axle is fully locked when the locking button
fully engages.
4. Loosen and remove the screw, remove the washer (C)
and the disc. Release the spindle lock button.
5. Fit the new blade disc (B). Make sure that the direction
of the arrow printed on the disk matches that of the arrow
engraved on the tool guard.
6. Place washer (C) on disc and insert screw (E).
7. Press the spindle lock button again. Tighten the screw
with the wrench (F) clockwise, once the disc is secure,
release the spindle lock button.
WARNING
Only clean, sharp and perfectly set blades can
guarantee a good cut. Keep handy extra cutting
discs to have sharp blades always available
D
A
B
C
E
F
G

11
ENGLISH
Keep in mind to disconnect the tool before cleaning or
servicing.
Every component in the tool is an important part of the
insulating system and should only be serviced in a
Authorized Service Center.
When sending the tool to maintenance, ALWAYS ask for
original spare parts.
When cleaning the plastic parts of the tool, refrain from
using solvents. Most plastic materials are susceptible to
damage when commercial type solvents are applied.
Use a clean cloth or pressurized air to clean dirt, coal or
dust.
A DVERTENNEVER put the tool in contact with
brake oil, petroleum-based products, penetrating oils, etc.
Those products contain chemical substances that damage
or destroy plastic.
When using pressurized air to clean
particles ALWAYS wear safety glasses with side protection
or a face mask. If it expels too much dust, also wear an
anti-dust mask.
It is not advisable to use this tool for extensive work in
fiberglass materials, gypsum wallboard, plaster or stucco.
The particles are highly abrasive for any power tool
components. If using the tool with those materials, it is
very important to frequently blow pressurized air to
increase the useful life of the tool.
Maintenance
• Carbon brushes shall be checked periodically and
replaced always in a Authorized
Service Center when worn.
• After being replaced ask to inspect if the new carbon
brushes can move freely in the carbon brush housing. Ask
to turn ON tie tool 5 minutes to make even the contact
between the carbon brushes and the commuter.
• Use only original spare carbon
brushes specifically designed with the hardness and
resistance adequate for each type of motor. Carbon
brushes that are out of specification
may damage the motor.
• When replacing carbon brushes, always replace both.
Carbon Brush Replacement
WARNING
WARNING

Notes
12 ENGLISH

13
ENGLISH
Authorized Service Centers
In the event of any problem contacting a Authorized Service Center, please see our webpage
www.truper.com to get an updated list, or call our toll-free numbers 800 690-6990 or 800 018-7873 to get
information about the nearest Service Center.
AGUASCALIENTES
BAJA
CALIFORNIA
BAJA
CALIFORNIA SUR
CAMPECHE
CHIAPAS
CHIHUAHUA
CIUDAD DE
MÉXICO
COAHUILA
COLIMA
DURANGO
ESTADO DE
MÉXICO
GUANAJUATO
GUERRERO
HIDALGO
JALISCO
MICHOACÁN
DE TODO PARA LA CONSTRUCCIÓN
GRAL. BARRAGÁN #1201, COL. GREMIAL, C.P. 20030,
AGUASCALIENTES, AGS. TEL.: [phone]
SUCURSAL TIJUANA
AV. LA ENCANTADA, LOTE #5, PARQUE INDUSTRIAL EL
FLORIDO II, C.P 22244, TIJUANA, B.C.
TEL.: [phone]
FIX FERRETERÍAS
FELIPE ÁNGELES ESQ. RUIZ CORTÍNEZ S/N, COL. PUEBLO
NUEVO, C.P. 23670, CD. CONSTITUCIÓN, B.C.S.
TEL.: [phone]
TORNILLERÍA Y FERRETERÍA AAA
AV. ÁLVARO OBREGÓN #324, COL. ESPERANZA
C.P. 24080 CAMPECHE, CAMP. TEL.: [phone]
FIX FERRETERÍAS
AV. CENTRAL SUR #27, COL. CENTRO, C.P. 30700,
TAPACHULA, CHIS. TEL.: [phone]
SUCURSAL CHIHUAHUA
AV. SILVESTRE TERRAZAS #128-11, PARQUE INDUSTRIAL
BAFAR, CARRETERA MÉXICO CUAUHTÉMOC, C.P. 31415,
CHIHUAHUA, CHIH. TEL. [phone]
FIX FERRETERÍAS
EL MONSTRUO DE CORREGIDORA, CORREGIDORA # 22,
COL. CENTRO, C.P. 06060, CUAUHTÉMOC, CDMX.
TEL: [phone]
SUCURSAL TORREÓN
CALLE METAL MECÁNICA #280, PARQUE INDUSTRIAL
ORIENTE, C.P. 27278, TORREÓN, COAH.
TEL.: [phone]
BOMBAS Y MOTORES BYMTESA DE MANZANILLO
BLVD. MIGUEL DE LA MADRID #190, COL. 16 DE
SEPTIEMBRE, C.P. 28239, MANZANILLO, COL.
TEL.: [phone]
TORNILLOS ÁGUILA, S.A. DE C.V.
MAZURIO #200, COL. LUIS ECHEVERRÍA, DURANGO,
DGO.TEL.: [phone]
SUCURSAL CENTRO JILOTEPEC
PARQUE INDUSTRIAL # 1, COL. PARQUE INDUSTRIAL
JILOTEPEC, JILOTEPEC, EDO. DE MÉX. C.P. 54257
TEL: [phone] EXT. 5728 Y 5102
CÍA. FERRETERA NUEVO MUNDO S.A. DE C.V.
AV. MÉXICO - JAPÓN #225, CD. INDUSTRIAL, C.P. 38010,
CELAYA, GTO. TEL.: [phone] / 79 / 80 / 88
CENTRO DE SERVICIO ECLIPSE
CALLE PRINCIPAL MZ.1 LT. 1, COL. SANTA FE, C.P. 39010,
CHILPANCINGO, GRO. TEL.: [phone]
FERREPRECIOS S.A. DE C.V.
LIBERTAD ORIENTE #304 LOCAL 30, INTERIOR DE PASAJE
ROBLEDO, COL. CENTRO, C.P. 43600, TULANCINGO,
HGO. TEL.: [phone]
SUCURSAL GUADALAJARA
AV. ADOLFO B. HORN # 6800, COL: SANTA CRUZ DEL
VALLE, C.P.: 45655, TLAJOMULCO DE ZUÑIGA, JAL.
TEL.: [phone] AL 90
FIX FERRETERÍAS
AV. PASEO DE LA REPÚBLICA #3140-A, COL.
EX-HACIENDA DE LA HUERTA, C.P. 58050, MORELIA,
MICH. TEL.: [phone]
FIX FERRETERÍAS
CAPITÁN ANZURES #95, ESQ. JOSÉ PERDIZ, COL.
CENTRO, C.P. 62740, CUAUTLA, MOR.
TEL.: [phone]
HERRAMIENTAS DE TEPIC
MAZATLAN #117, COL. CENTRO, C.P. 63000, TEPIC, NAY.
TEL.: [phone]
SUCURSAL MONTERREY
CARRETERA LAREDO #300, 1B MONTERREY PARKS,
COLONIA PUERTA DE ANÁHUAC, C.P. 66052, ESCOBEDO,
NUEVO LEÓN, TEL.: [phone]
FIX FERRETERÍAS
AV. 20 DE NOVIEMBRE #910, COL. CENTRO, C.P. 68300,
TUXTEPEC, OAX. TEL.: [phone]
SUCURSAL PUEBLA
AV PERIFÉRICO #2-A, SAN LORENZO ALMECATLA,
C.P. 72710, CUAUTLACINGO, PUE.
TEL.: [phone] / 84 / 85 / 86
ARU HERRAMIENTAS S.A DE C.V.
AV. PUERTO DE VERACRUZ #110, COL. RANCHO DE
ENMEDIO, C.P. 76842, SAN JUAN DEL RÍO, QRO.
TEL.: [phone]
FIX FERRETERÍAS
CARRETERA FEDERAL MZ. 46 LT. 3 LOCAL 2, COL EJIDAL,
C.P. 77710 PLAYA DEL CARMEN, Q.R.
TEL.: [phone]
FIX FERRETERÍAS
AV. UNIVERSIDAD #1850, COL. EL PASEO, C.P. 78320,
SAN LUIS POTOSÍ, S.L.P. TEL.: [phone]
SUCURSAL CULIACÁN
AV. JESÚS KUMATE SUR #4301, COL. HACIENDA DE LA
MORA, C.P. 80143, CULIACÁN, SIN.
TEL.: [phone]
FIX FERRETERÍAS
CALLE 5 DE FEBRERO #517, SUR LT. 25 MZ. 10, COL.
CENTRO, C.P. 85000, CD. OBREGÓN, SON.
TEL.: [phone]
SUCURSAL VILLAHERMOSA
CALLE HELIO LOTES 1, 2 Y 3 MZ. #1, COL. INDUSTRIAL,
2A ETAPA, C.P. 86010, VILLAHERMOSA, TAB.
TEL.: [phone]
VM ORINGS Y REFACCIONES
CALLE ROSITA #527 ENTRE 20 DE NOVIEMBRE Y GRAL.
RODRÍGUEZ, FRACC. REYNOSA, C.P. 88780, REYNOSA,
TAMS. TEL.: [phone]
SERVICIOS Y HERRAMIENTAS INDUSTRIALES
PABLO SIDAR #132, COL . BARRIO DE SAN BARTOLOMÉ,
C.P. 90970, SAN PABLO DEL MONTE, TLAX.
TEL.: [phone]
LA CASA DISTRIBUIDORA TRUPER
BLVD. PRIMAVERA. ESQ. HORTENSIA S/N, COL.
PRIMAVERA C.P. 93308, POZA RICA, VER.
TEL.: [phone]
SUCURSAL MÉRIDA
CALLE 33 #600 Y 602, LOCALIDAD ITZINCAB Y MULSAY,
MPIO. UMÁN, C.P. 97390, MÉRIDA, YUC.
TEL.: [phone]
MORELOS
NAYARIT
NUEVO LEÓN
OAXACA
PUEBLA
QUERÉTARO
QUINTANA ROO
SAN LUIS
POTOSÍ
SINALOA
SONORA
TABASCO
TAMAULIPAS
TLAXCALA
VERACRUZ
YUCATÁN

14 www.truper.com
03-2022
ENGLISH
Warranty
policy
1
YEAR
27098
Stamp of the business. Date of purchase:
Code
SICI-7-1/4P
Model Brand
This product is guaranteed for 1 year. To make the warranty valid or purchase parts and components you must
present the product in Corregidora 22, Col. Centro, Alc. Cuauhtémoc, CDMX C.P. 06060 or at the
establishment where you purchased it, or at any Truper®Service Center listed in the annex to the warranty
policy and/or in www.truper.com . Transportation costs resulting from compliance of this warranty will be
covered by
For questions or comments, call 800-690-6990. Made in China. Imported by Truper S.A. de C.V. Parque
Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257
Warranty policy

14 ESPAÑOL www.truper.com
03-2022
Póliza de Garantía
1
AÑO
27098
Sello del establecimiento comercial. Fecha de compra:
Código
SICI-7-1/4P
Modelo Marca
Este producto está garantizado por 1 año. Para hacer válida la garantía o adquirir piezas y componentes deberá
presentar el producto en Corregidora 22, Col. Centro, Alc. Cuauhtémoc, CDMX C.P. 06060 o en el
establecimiento donde lo compró, o en algún Centro de Servicio Truper®de los enlistados en el anexo de la
póliza de garantía y/o en www.truper.com . Los gastos de transportación que resulten para su cumplimiento
serán cubiertos por
Para dudas o comentarios, llame al 800-690-6990. Hecho en China. Importado por Truper S.A. de C.V. Parque
Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257

13
ESPAÑOL
Centros de Servicio Autorizados
En caso de tener algún problema para contactar un Centro de Servicio Autorizado
consulte nuestra página www.truper.com donde obtendrá un listado actualizado, o llame al:
800 690-6990 ó800 018-7873 donde le informarán cuál es el Centro de Servicio más cercano.
AGUASCALIENTES
BAJA
CALIFORNIA
BAJA
CALIFORNIA SUR
CAMPECHE
CHIAPAS
CHIHUAHUA
CIUDAD DE
MÉXICO
COAHUILA
COLIMA
DURANGO
ESTADO DE
MÉXICO
GUANAJUATO
GUERRERO
HIDALGO
JALISCO
MICHOACÁN
MORELOS
NAYARIT
NUEVO LEÓN
OAXACA
PUEBLA
QUERÉTARO
QUINTANA ROO
SAN LUIS
POTOSÍ
SINALOA
SONORA
TABASCO
TAMAULIPAS
TLAXCALA
VERACRUZ
YUCATÁN
DE TODO PARA LA CONSTRUCCIÓN
GRAL. BARRAGÁN #1201, COL. GREMIAL, C.P. 20030,
AGUASCALIENTES, AGS. TEL.: [phone]
SUCURSAL TIJUANA
AV. LA ENCANTADA, LOTE #5, PARQUE INDUSTRIAL EL
FLORIDO II, C.P 22244, TIJUANA, B.C.
TEL.: [phone]
FIX FERRETERÍAS
FELIPE ÁNGELES ESQ. RUIZ CORTÍNEZ S/N, COL. PUEBLO
NUEVO, C.P. 23670, CD. CONSTITUCIÓN, B.C.S.
TEL.: [phone]
TORNILLERÍA Y FERRETERÍA AAA
AV. ÁLVARO OBREGÓN #324, COL. ESPERANZA
C.P. 24080 CAMPECHE, CAMP. TEL.: [phone]
FIX FERRETERÍAS
AV. CENTRAL SUR #27, COL. CENTRO, C.P. 30700,
TAPACHULA, CHIS. TEL.: [phone]
SUCURSAL CHIHUAHUA
AV. SILVESTRE TERRAZAS #128-11, PARQUE INDUSTRIAL
BAFAR, CARRETERA MÉXICO CUAUHTÉMOC, C.P. 31415,
CHIHUAHUA, CHIH. TEL. [phone]
FIX FERRETERÍAS
EL MONSTRUO DE CORREGIDORA, CORREGIDORA # 22,
COL. CENTRO, C.P. 06060, CUAUHTÉMOC, CDMX.
TEL: [phone]
SUCURSAL TORREÓN
CALLE METAL MECÁNICA #280, PARQUE INDUSTRIAL
ORIENTE, C.P. 27278, TORREÓN, COAH.
TEL.: [phone]
BOMBAS Y MOTORES BYMTESA DE MANZANILLO
BLVD. MIGUEL DE LA MADRID #190, COL. 16 DE
SEPTIEMBRE, C.P. 28239, MANZANILLO, COL.
TEL.: [phone]
TORNILLOS ÁGUILA, S.A. DE C.V.
MAZURIO #200, COL. LUIS ECHEVERRÍA, DURANGO,
DGO.TEL.: [phone]
SUCURSAL CENTRO JILOTEPEC
PARQUE INDUSTRIAL # 1, COL. PARQUE INDUSTRIAL
JILOTEPEC, JILOTEPEC, EDO. DE MÉX. C.P. 54257
TEL: [phone] EXT. 5728 Y 5102
CÍA. FERRETERA NUEVO MUNDO S.A. DE C.V.
AV. MÉXICO - JAPÓN #225, CD. INDUSTRIAL, C.P. 38010,
CELAYA, GTO. TEL.: [phone] / 79 / 80 / 88
CENTRO DE SERVICIO ECLIPSE
CALLE PRINCIPAL MZ.1 LT. 1, COL. SANTA FE, C.P. 39010,
CHILPANCINGO, GRO. TEL.: [phone]
FERREPRECIOS S.A. DE C.V.
LIBERTAD ORIENTE #304 LOCAL 30, INTERIOR DE PASAJE
ROBLEDO, COL. CENTRO, C.P. 43600, TULANCINGO,
HGO. TEL.: [phone]
SUCURSAL GUADALAJARA
AV. ADOLFO B. HORN # 6800, COL: SANTA CRUZ DEL
VALLE, C.P.: 45655, TLAJOMULCO DE ZUÑIGA, JAL.
TEL.: [phone] AL 90
FIX FERRETERÍAS
AV. PASEO DE LA REPÚBLICA #3140-A, COL.
EX-HACIENDA DE LA HUERTA, C.P. 58050, MORELIA,
MICH. TEL.: [phone]
FIX FERRETERÍAS
CAPITÁN ANZURES #95, ESQ. JOSÉ PERDIZ, COL.
CENTRO, C.P. 62740, CUAUTLA, MOR.
TEL.: [phone]
HERRAMIENTAS DE TEPIC
MAZATLAN #117, COL. CENTRO, C.P. 63000, TEPIC, NAY.
TEL.: [phone]
SUCURSAL MONTERREY
CARRETERA LAREDO #300, 1B MONTERREY PARKS,
COLONIA PUERTA DE ANÁHUAC, C.P. 66052, ESCOBEDO,
NUEVO LEÓN, TEL.: [phone]
FIX FERRETERÍAS
AV. 20 DE NOVIEMBRE #910, COL. CENTRO, C.P. 68300,
TUXTEPEC, OAX. TEL.: [phone]
SUCURSAL PUEBLA
AV PERIFÉRICO #2-A, SAN LORENZO ALMECATLA,
C.P. 72710, CUAUTLACINGO, PUE.
TEL.: [phone] / 84 / 85 / 86
ARU HERRAMIENTAS S.A DE C.V.
AV. PUERTO DE VERACRUZ #110, COL. RANCHO DE
ENMEDIO, C.P. 76842, SAN JUAN DEL RÍO, QRO.
TEL.: [phone]
FIX FERRETERÍAS
CARRETERA FEDERAL MZ. 46 LT. 3 LOCAL 2, COL EJIDAL,
C.P. 77710 PLAYA DEL CARMEN, Q.R.
TEL.: [phone]
FIX FERRETERÍAS
AV. UNIVERSIDAD #1850, COL. EL PASEO, C.P. 78320,
SAN LUIS POTOSÍ, S.L.P. TEL.: [phone]
SUCURSAL CULIACÁN
AV. JESÚS KUMATE SUR #4301, COL. HACIENDA DE LA
MORA, C.P. 80143, CULIACÁN, SIN.
TEL.: [phone]
FIX FERRETERÍAS
CALLE 5 DE FEBRERO #517, SUR LT. 25 MZ. 10, COL.
CENTRO, C.P. 85000, CD. OBREGÓN, SON.
TEL.: [phone]
SUCURSAL VILLAHERMOSA
CALLE HELIO LOTES 1, 2 Y 3 MZ. #1, COL. INDUSTRIAL,
2A ETAPA, C.P. 86010, VILLAHERMOSA, TAB.
TEL.: [phone]
VM ORINGS Y REFACCIONES
CALLE ROSITA #527 ENTRE 20 DE NOVIEMBRE Y GRAL.
RODRÍGUEZ, FRACC. REYNOSA, C.P. 88780, REYNOSA,
TAMS. TEL.: [phone]
SERVICIOS Y HERRAMIENTAS INDUSTRIALES
PABLO SIDAR #132, COL . BARRIO DE SAN BARTOLOMÉ,
C.P. 90970, SAN PABLO DEL MONTE, TLAX.
TEL.: [phone]
LA CASA DISTRIBUIDORA TRUPER
BLVD. PRIMAVERA. ESQ. HORTENSIA S/N, COL.
PRIMAVERA C.P. 93308, POZA RICA, VER.
TEL.: [phone]
SUCURSAL MÉRIDA
CALLE 33 #600 Y 602, LOCALIDAD ITZINCAB Y MULSAY,
MPIO. UMÁN, C.P. 97390, MÉRIDA, YUC.
TEL.: [phone]

Notas
12 ESPAÑOL

Recuerde desconectar la herramienta antes de limpiarla o
darle mantenimiento.
Todos los componentes de la herramienta son parte
importante del sistema de aislamiento y solamente se les
debe dar mantenimiento en un Centro de Servicio
Autorizado .
Cuando mande la herramienta a mantenimiento, pida
SIEMPRE refacciones originales .
Cuando limpie las partes de plástico, evite usar solventes.
La mayoría de los materiales plásticos son susceptibles a
dañarse con varios tipos de solventes comerciales.
Para limpiar suciedad, carbón o polvo use un trapo limpio
o aire a presión.
A DVERTENCIANUNCA se debe poner la
herramienta en contacto con aceite para frenos,
productos con base de petróleo, aceites penetrantes, etc.
Contienen substancias químicas que pueden dañar o
destruir el plástico.
Cuando use aire a presión para
limpiar partículas use SIEMPRE lentes de seguridad con
protectores laterales o careta, en caso de expulsar mucho
polvo, use también una mascarilla contra polvo.
No es recomendable que esta herramienta se use para
trabajos extensos en materiales de fibra de vidrio, cartón
de yeso, emplastecidos o yeso, ya que sus partículas son
altamente abrasivas para los componentes de cualquier
herramienta eléctrica. En caso de usar la herramienta en
alguno de esos materiales es muy importante que se
limpie frecuentemente con aire a presión para aumentar
la vida útil de la herramienta.
• Los carbones deben revisarse periódicamente, y ser
reemplazados siempre por un Centro de Servicio
Autorizado cuando se hayan
desgastado.
• Después de que hayan sido reemplazados, pida que se
inspeccione si los nuevos carbones pueden moverse
libremente en el porta-carbón y solicite que enciendan la
herramienta durante 5 minutos para emparejar el contacto
de los carbones y el conmutador.
• Sólo se deben de usar carbones de repuesto originales
, diseñados específicamente con la
dureza y la resistencia eléctrica adecuadas para cada tipo
de motor. Los carbones fuera de especificaciones pueden
dañar el motor.
• Cuando se haga el cambio de carbones siempre deben
reemplazarse los dos carbones.
Cambio de carbones
ADVERTENCIA
ADVERTENCIA
11
Mantenimiento
ESPAÑOL

Puesta en marcha
10 ESPAÑOL
Ajuste de la guía paralela de corte
Cambio del disco de corte
Mantenimiento
Para mantener fijo el ancho de la pieza de trabajo al realizar
los cortes utilice la guía de corte.
Para ajustar el ancho afloje la perilla (A) y recorra la guía de
corte a la posición deseada.
No utilizar discos abrasivos.
Indicador de corte
La parte de adelante de la base tiene un indicador de línea de
corte para cortes verticales y biselados. Este indicador le
permite guiar la sierra a lo largo de la línea trazada en el
material de trabajo.
A
Una vez que los discos de corte se desgasten deben
reemplazarse de inmediato.
Los discos de corte especificados para
esta herramienta son de 7-1/4” (18.5 cm). Nunca debe usar
otro tipo o medida de disco de corte. De lo contrario puede
ocasionar lesiones personales de gravedad o dañar la
herramienta invalidando su garantía.
Nunca utilice arandelas y pernos para disco dañados o que
no sean los correctos. Los pernos y arandelas incluidos están
diseñados especialmente para este modelo de herramienta,
para un funcionamiento excelente y brindar seguridad en su
operación.
Utilice discos de corte con orificios de la medida y forma
correcta para el eje. De lo contrario pueden girar con un
movimiento excéntrico provocando pérdida de control.
1. Desconecte la herramienta y ajuste la profundidad de corte
al mínimo (consulte la página 8).
2. Abra por completo la guarda retráctil (A) y manténgala en
esa posición.
3. Coloque la llave (F) en el tornillo allen (E) y mantenga
presionado el botón de bloqueo del eje (D).
Gire el tornillo en sentido contrario a las manecillas del reloj.
El disco de corte girará al mismo tiempo que el
perno, hasta que el eje sea totalmente bloqueado cuando el
botón de bloqueo calce por completo.
4. Afloje y retire el tornillo, retire la arandela (C) y el disco.
Suelte el botón de bloqueo del eje.
5. Coloque el disco de corte nuevo (B). Asegúrese que la
dirección de la flecha impresa en el disco coincida con la de
la flecha grabada en la guarda de la herramienta.
6. Coloque la arandela (C) en el disco e inserte el tornillo (E).
7. Presione de nuevo el botón de bloqueo del eje. Apriete el
tornillo con la llave(F) en el sentido de las manecillas del
reloj.Una vez que el disco esté asegurado,suelte el botón de
bloqueo del eje
ADVERTENCIA
D
Sólo discos limpios, afilados y bien instalados
pueden garantizar un buen corte. Tenga a la
mano discos de corte extra para tener discos
afilados siempre disponibles.
A
B
C
E
F
G

Ajuste de la profundidad de corte
Ajuste del ángulo de corte
E
1. Afloje la perilla de bloqueo de profundidad de corte (C).
2. Con la base fija, levante la carcasa hasta que el disco sobresalga de la base a la profundidad deseada. Utilice la guía de
profundidad (D) como referencia.
3. Apriete la perilla de bloqueo de profundidad de corte para evitar que la carcasa se mueva durante el corte.
4. La profundidad de corte puede ser de hasta 64 mm
• La profundidad de corte debe ser igual al grosor de la pieza de trabajo o sobresalir de esta la medida
de un diente del disco como máximo para evitar accidentes.
• Conecte la clavija al tomacorriente.
• Mantenga presionado el botón de bloqueo (B) para desbloquear
el interruptor (A).
El seguro del interruptor evita encendidos accidentales.
• Presione el interruptor (A) para que el disco comience a girar.
• Para detener el disco suelte el interruptor (A).
La sierra circular es una herramienta multiuso para cortar madera suave o dura, aglomerado, contrachapado, materiales
con cubierta de resopal, etc.
Esta herramienta no está diseñada para cortar metal, ni materiales de mampostería, cemento o ladrillo.
• Afloje las perillas de ajuste del ángulo de corte (E).
• Con la base fija, gire la carcasa hasta que el disco tenga el ángulo deseado.
• Apriete las perillas de ajuste del ángulo de corte para evitar que la carcasa se mueva durante el corte.
• La herramienta puede hacer cortes de 0° hasta 45°
Encendido
ATENCIÓN
ATENCIÓN
Base
C
D
A
B
9
Puesta en marcha
ESPAÑOL
• Utilizar sólo discos de corte cuyo diámetro se especifica de acuerdo con el marcado.
