PRG V676 User manual

SOFTWARE VERSION 3.6
WWW.PRG.COM
V676®CONTROL CONSOLE
INSTALLATION & OPERATION MANUAL

AutoPar®, Bad Boy®, Best Boy 4000®, PRG Series 400®, MBOX®, MBOX Extreme®, OHM™, Super Node™, V476®, V676®, Virtuoso®, Virtuoso®
DX, Virtuoso®DX2, and VL6C+™ are trademarks of Production Resource Group, LLC, registered in the U.S. and other countries.
Mac®, QuickTime® and FireWire® are registered trademarks of Apple Computer, Inc.
All other brand names which may be mentioned in this manual are trademarks or registered trademarks of their respective companies.
This manual is for informational use only and is subject to change without notice. Please check www.prg.com for the latest version.
PRG assumes no responsibility or liability for any claims resulting from errors or inaccuracies that may appear in this manual.
V676® Control Console Installation & Operation Manual
Version as of: March 22, 2013
PRG part number: 02.9824.0002
Production Resource Group, LLC
Dallas Office
8617 Ambassador Row, Suite 120
Dallas, Texas 75247
www.prg.com
V676® Control Console Installation & Operation Manual
©2013 Production Resource Group, LLC. All Rights Reserved.

V676®CONTROL CONSOLE INSTALLATION & OPERATION MANUAL I
FOREWORD
End User Software License
PLEASE READ THIS DOCUMENT CAREFULLY BEFORE ACTIVATING, COPYING, INSTALLING, OR USING THIS
SOFTWARE PROVIDED BY PRODUCTION RESOURCE GROUP, LLC. BY ACTIVATING, COPYING, INSTALLING, OR
USING THIS SOFTWARE, YOU ARE AGREEING TO BE BOUND BY THE TERMS OF THIS LICENSE. IF YOU DO NOT
AGREE TO THE TERMS OF THIS LICENSE, DO NOT ACTIVATE, COPY, INSTALL, OR USE THIS SOFTWARE AND
PROMPTLY RETURN IT FOR A REFUND.
1) License. Production Resource Group, LLC. ("PRG") hereby grants you a limited license to install and use the Vx76
software and related documentation (collectively, the "Software") solely with the console sold in conjunction with
the Software. PRG retains all right, title and interest to the Software which is protected by various proprietary
rights, including but not limited to copyrights, trade secrets, or patents ("Proprietary Rights"). No license, right or
interest in any trademark, trade name or service mark of PRG or any third party is granted under this License.
2) No Implied License. You acknowledge that this License in no way shall be construed to provide an implied
license to use, modify or improve any of PRG’s patented technology, copyrights, trade secrets, trademarks, and/
or other Proprietary Rights.
3) Restrictions. The Software contains proprietary information that is possibly protected by a combination of patent,
copyright, trade secret, and/or other Proprietary Rights, and constitutes valuable property of PRG. You
acknowledge that the Software is disclosed in circumstances of confidence and only for use by you under the
terms and conditions of this License and that you do not acquire any rights of ownership or title in the Software.
You may not attempt to create or derive source codes by disassembly, reverse engineering or any other method,
or otherwise reduce the Software to a human-perceivable form. You may not modify or translate any part of the
Software. You may not use, disclose, distribute, make or have made any copies of the Software, in whole or in
part, without the prior written authorization of PRG. You agree to make reasonable efforts to notify and inform
your employees or agents having access to the Software of your limitations, duties and obligations regarding non-
disclosure and copying of the Software. The Software shall be used only by you, your employees or your
authorized agents. You agree to provide notice to PRG immediately after learning of or having reason to suspect
a breach of any of the restrictions set forth in this License.
4) Termination. This License is effective until terminated. You may terminate this License at any time by destroying
the Software, and all copies thereof. This License will terminate immediately without notice from PRG if you fail to
comply with any provision of this License. Upon termination, you must destroy the Software and all copies
thereof.
5) Export Control Requirements. This License, and any technical information supplied during the term of this
License, is made subject to any restrictions concerning the export of products or technical data from the United
States of America which may be imposed upon PRG or you from time to time by the Government of the United
States of America. Furthermore, you agree that at no time, either during the term of this License or thereafter, will
you knowingly export, directly or indirectly, any United States source technical data acquired from PRG under this
License or any direct products of that technical data to any country for which the U.S. Government or any agency
thereof at the time of export requires an export license or other governmental approval, without first obtaining that
license or approval when required by applicable United States law.
6) Limited Warranty. PRG warrants the media on which the Software is recorded to be free from defects in materials
and workmanship under normal use for a period of ninety (90) days from the date of purchase as evidenced by a
copy of your receipt. PRG’s entire liability and your exclusive remedy will be replacement of a media that does
not meet PRG’s limited warranty and is returned at your expense, along with a copy of your receipt, to PRG
customer support or to PRG’s authorized representative. If replacement of the media is not reasonably practical
or commercially reasonable as determined solely in the discretion of PRG, PRG will refund the purchase price as
evidenced by a purchase receipt. PRG will have no responsibility to replace media damaged by accident, abuse
or misapplication. EXCEPT FOR THE FOREGOING, THE SOFTWARE AND RELATED DOCUMENTATION ARE
PROVIDED "AS IS," WITHOUT ADDITIONAL WARRANTY OF ANY KIND, AND PRG EXPRESSLY DISCLAIMS ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF DESIGN, MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR TITLE, ANY

II V676®CONTROL CONSOLE INSTALLATION & OPERATION MANUAL
WARRANTIES ARISING FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE, OR ANY
WARRANTIES OF NON-INFRINGEMENT OF ANY THIRD PARTY'S PATENT(S), TRADE SECRET(S),
COPYRIGHT(S) OR OTHER INTELLECTUAL PROPERTY RIGHTS. PRG DOES NOT WARRANT THAT THE
FUNCTIONS CONTAINED IN THE SOFTWARE WILL MEET YOUR REQUIREMENTS, OR THAT THE OPERATION
OF THE SOFTWARE WILL BE UNINTERRUPTED OR ERROR-FREE, OR THAT DEFECTS IN THE SOFTWARE
WILL BE CORRECTED. FURTHERMORE, PRG DOES NOT WARRANT OR MAKE ANY REPRESENTATIONS
REGARDING THE USE OR THE RESULTS OF THE USE OF THE SOFTWARE OR RELATED DOCUMENTATION IN
TERMS OF THEIR CORRECTNESS, ACCURACY, RELIABILITY, OR OTHERWISE. NO ORAL OR WRITTEN
INFORMATION OR ADVICE GIVEN BY PRG OR ITS AUTHORIZED REPRESENTATIVE SHALL CREATE ANY
WARRANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY. SHOULD THE SOFTWARE PROVE
DEFECTIVE, YOU (AND NOT PRG OR ITS AUTHORIZED REPRESENTATIVE) ASSUME THE ENTIRE COST OF
ALL NECESSARY SERVICING, REPAIR OR CORRECTION. SOME STATES DO NOT ALLOW EXCLUSION OF
IMPLIED WARRANTIES, SO THE ABOVE EXCLUSION MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
7) Limitation Of Liability. UNDER NO CIRCUMSTANCES, INCLUDING NEGLIGENCE, SHALL PRG BE LIABLE FOR
ANY LOST REVENUE OR PROFITS OR ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL
DAMAGES THAT RESULT FROM THE USE OR INABILITY TO USE THE SOFTWARE OR RELATED
DOCUMENTATION, EVEN IF PRG OR ITS AUTHORIZED REPRESENTATIVE HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. SOME STATES DO NOT ALLOW THE LIMITATION OR EXCLUSION OF
LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES SO THE ABOVE LIMITATION OR EXCLUSION
MAY NOT APPLY TO YOU. IN NO EVENT SHALL PRG’S TOTAL LIABILITY TO YOU FOR ALL DAMAGES,
LOSSES, AND CAUSES OF ACTION, WHETHER IN CONTRACT, TORT (INCLUDING NEGLIGENCE) OR
OTHERWISE, EXCEED THE AMOUNT PAID BY YOU FOR THE SOFTWARE.
8) Arbitration, Jurisdiction, and Venue. You agree that any action at law or in equity arising out of the License or
relating to this Software shall be resolved, individually, through biding arbitration using the then current rules of
the American Arbitration Association, in Dallas, Texas and the resulting decisions may be entered in any court with
proper jurisdiction. This means that if you have a grievance with us, you cannot take us to court, and you may not
join your action with any other party. You can address such grievances through arbitration only and you are
hereby consenting to do it in Dallas, Texas, using Texas' laws (without regard to Texas' conflicts of laws). You
agree that are properly subject to the jurisdiction of the courts of the State of Texas and waive any rights to
challenge personal jurisdiction.
9) Government Licensee. If you are acquiring the Software on behalf of any unit or agency of the United States
Government, the following provisions apply: (a) the Government acknowledges PRG’s representation that the
Software and its documentation were developed at private expense and no part of them is in the public domain;
(b) the Government acknowledges PRG’s representation that the Software is "Restricted Computer Software" as
that term is defined in Clause 52.227-19 of the Federal Acquisition Regulations ("FAR") and is "Commercial
Computer Software" as that term is defined in Subpart 227.471 of the Department of Defense Federal Acquisition
Regulation Supplement ("DFARS"). The Government agrees that: (i) if the Software is supplied to the Department
of Defense ("DoD"), the Software is classified as "Commercial Computer Software" and the Government is
acquiring only "limited rights" in the Software and its documentation as that term is defined in Clause 252.227-
7013(a)(13) of the DFARS, and (ii) if the Software is supplied to any unit or agency of the United States
Government other than DoD, the Government’s rights in the Software and its documentation will be as defined in
Clause 52.227-19(c)(2) of the FAR.
10) Indemnity. You agree to indemnify and hold harmless PRG, and its parents, subsidiaries, affiliates, officers,
directors, shareholders, employees and agents, from and against any costs, losses, liabilities and expenses,
including reasonable attorney’s fees, that PRG may suffer, incur, or be subjected to by reason of any claim by a
third party due to or arising out of your conduct, your use of the Software, any alleged breach of this License or
the representations and warranties herein, the alleged violation of the rights of any third party, or any alleged
infringement of the intellectual property rights of any third party, including but not limited to your use of any
content, trademarks, service marks, trade names or other intellectual property used in connection with the
Software. PRG reserves the right to control the exclusive defense of any matter otherwise subject to your
indemnification, which will not excuse your indemnity obligations.

V676®CONTROL CONSOLE INSTALLATION & OPERATION MANUAL III
11) Complete Agreement. This License constitutes the entire agreement between the parties with respect to the use
of the Software and supersedes all prior or contemporaneous understandings or agreements, written or oral,
regarding such subject matter.
12) Miscellaneous. If any provision of this License shall be unlawful, void, or for any reason unenforceable, then that
provision shall be deemed severable (or reformable, if necessary), and shall not affect the validity and
enforceability of any remaining provisions. Alternatively, such provision may also be modified to the extent
necessary for its validity.
13) Transfer. This License may be transferred to another party provided the other party reads and agrees to accept
the terms and conditions of this License and you notify PRG of the transfer in writing.
Warranty/Repairs
PRG warrants its products for 1 year from the date of shipment, unless otherwise noted on the face hereof in
accordance with the following:
1) PRG warrants its products against defects in workmanship and materials, under normal use, for a period of one
year from the time of delivery to the Customer. During this period, if any product is found to be defective or fails to
operate in accordance with PRG’s published specifications for the product in effect as of the date of shipment,
PRG will repair or replace the product, subject to the terms of this limited warranty. The warranty will be null and
void under the following conditions: (a) improper or inadequate maintenance; (b) unauthorized modifications or
misuse; (c) operations outside of environmental specifications for the product.
2) This Warranty does not cover any product or product part damaged by or subject to accident, negligence,
alteration, abuse or misuse, or any accessories or parts not supplied by PRG. This Warranty shall not apply to any
damage to any product, or product part caused by or due to an act of God, any catastrophe resulting from
earthquake, fire, flood, explosion or any other cause beyond the control of PRG. This warranty does not cover
“consumable” parts such as fuses, lamps, color media or components which may be warranted directly to the
Customer by the original manufacturer. PRG’s warranty does not extend to items not manufactured by PRG.
Freight terms on warranty repairs are FOB PRG factory in Dallas Texas or other PRG designated repair facility.
Collect shipments or freight allowances will not be accepted.
3) PRG’s sole responsibility under this warranty shall be to repair or replace at PRG’s option such parts as shall be
determined to be defective on PRG’s inspection. Such repairs may be performed with re-worked or refurbished
parts. PRG will not assume any responsibility for any labor expended or materials used to repair any equipment
without PRG’s prior written authorization. NO OTHER WARRANTY, EXPRESS OR IMPLIED, APPLIES TO THE
PRODUCT, INCLUDING BUT NOT LIMITED TO WARRANTY OF QUALITY, FITNESS FOR A PARTICULAR
PURPOSE OR MERCHANTABILITY. PRG SHALL NOT BE RESPONSIBLE FOR ANY INCIDENTAL, SPECIAL,
GENERAL OR CONSEQUENTIAL DAMAGES, DAMAGES TO PROPERTY, DAMAGES FOR LOSS OF USE, TIME,
PROFITS OR INCOME, OR ANY OTHER DAMAGES.
4) The Customer’s obligations during the warranty period under this warranty are to notify PRG of any suspected
defect and to return the goods prepaid to PRG at PRG’s depot in Dallas, Texas or authorized service center. In the
event the defect is not covered under the warranty, as determined by PRG at its reasonable discretion, PRG will
charge for the parts, materials and labor at rates as in effect from time to time.
5) (a) THIS WARRANTY IS CONTINGENT ON THE CUSTOMER’S FULL AND TIMELY COMPLIANCE WITH THE
TERMS OF USE AND PAYMENT SET FORTH HEREIN.
(b) This written warranty is intended as a complete and exclusive statement of the terms thereof. Prior dealings or
trade usage shall not be relevant to modify, explain or vary this warranty.
(c) To obtain warranty service contact Jan Pestinger at [phone], jpestin[email protected] or via mail at
Production Resource Group, 8617 Ambassador Row, Suite 120, Dallas, Texas 75247.
6) For sales outside of North America, the relevant PRG repair location shall be listed on the face of your invoice.

IV V676®CONTROL CONSOLE INSTALLATION & OPERATION MANUAL
Compliance and Safety Notice
FCC
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference that may cause undesired operation.
It is extremely important to read ALL safety information and instructions provided in this manual and any
accompanying documentation before installing and operating the products described herein. Heed all cautions and
warnings during installation and use of this product.
Safety symbols used throughout this manual are as follows:
UNIVERSAL VOLTAGE RANGE: 100-240 VAC, 50/60 Hz, 10A Max
MAXIMUM AMBIENT TEMPERATURE: TA= 50° C
NOT FOR RESIDENTIAL USE
DRY LOCATIONS ONLY
WARNING! Hazard of electrical shock. Disconnect power before servicing. Service and maintenance should
be performed only by qualified personnel as determined by PRG. Refer to service manual before operating
or servicing.
WARNING! Power supply plug and/or power switch/circuit breaker shall remain readily operable.
WARNING! For personal safety, this equipment must be properly grounded.
Do not, under any circumstances, cut or remove the ground prong from the power cord.
The power cord of this equipment is provided with a 3-prong grounding plug which mates with a standard 3-
prong grounded wall outlet to minimize the possibility of electric shock hazard from this equipment.
Have the wall outlet and electrical circuit checked by a qualified electrician to ensure the outlet is properly
grounded. If the outlet is a standard 2-prong outlet, it is your personal responsibility and obligation to have it
replaced with a properly grounded 3-prong outlet.
Never unplug the equipment by pulling on the power cord. Always grip the plug firmly and pull it straight out
from the outlet. Do not use a cord that shows cracks or damage along its length or at either end.
Replacement cords may be ordered from PRG.
CAUTION advising of potential damage to product.
WARNING advising of potential injury or death to persons.
3077774

V676®CONTROL CONSOLE INSTALLATION & OPERATION MANUAL V
ATTENTION! Pour votre sécurité, cet appareil doit être correctement mis à la terre.
Il ne faut en aucun cas couper ou enlever la broche de terre du cordon d'alimentation.
Le cordon d'alimentation de cet appareil est fourni avec une fiche à 3 broches qui s'accouple avec un
standard à 3 broches mise à la terre prise murale afin de minimiser le risque de choc électrique de cet
équipement.
Faites vérifier la prise murale et le circuit électrique par un électricien qualifié pour assurer la prise est
correctement mise à la terre. Si la prise est un standard 2 broches prise, il est de votre responsabilité et
l'obligation de la faire remplacer par une prise à 3 broches prise.
Ne jamais débrancher l'appareil en tirant sur le cordon d'alimentation. Toujours saisir fermement la fiche et
tirez-le tout droit hors de la prise. Ne pas utiliser un cordon qui présente des fissures ou des dommages sur
toute sa longueur ou aux extrémités. Cordons de rechange peuvent être commandées auprès PRG.
Revision History
This manual has been revised as follows:
Version Release Date Notes
BASIC March 22, 2013 Initial release.

VI V676®CONTROL CONSOLE INSTALLATION & OPERATION MANUAL
Notes

V676®CONTROL CONSOLE INSTALLATION & OPERATION MANUAL VII
TABLE OF CONTENTS
Introduction
About This Manual ................................................................................................................................................... 1
Additional Documentation........................................................................................................................................ 1
Training Videos ......................................................................................................................................................... 1
Customer Service..................................................................................................................................................... 1
Text Conventions and Icons ..................................................................................................................................... 2
Product Overview
Features.................................................................................................................................................................... 3
Included Items .......................................................................................................................................................... 4
Optional Items .......................................................................................................................................................... 4
Monitors and Channel Select Panel................................................................................................................... 4
DMX Processing Module ................................................................................................................................... 4
Desk Layout.............................................................................................................................................................. 5
Console Front and Rear Panels................................................................................................................................ 6
Installation
Unpack and Setup Procedure.................................................................................................................................. 7
Display Setup ......................................................................................................................................................... 12
Using Standard DVI Monitors................................................................................................................................. 12
Basic Operation
About Vx76 Software.............................................................................................................................................. 13
Power Up Console and Launch Vx76 Application ................................................................................................. 13
Restart Front Panel................................................................................................................................................. 13
Restart Vx76 Application........................................................................................................................................ 14
Power Down Console............................................................................................................................................. 14
Touchscreen Operation .......................................................................................................................................... 15
LED Indicators ........................................................................................................................................................ 16
Setting Preferences
Brightness Level ..................................................................................................................................................... 18
For Front Panel and Monitors .......................................................................................................................... 18
For Keyboard ................................................................................................................................................... 18
Technical Specifications
V676 Control Console ............................................................................................................................................ 19

VIII V676®CONTROL CONSOLE INSTALLATION & OPERATION MANUAL
Notes

V676®CONTROL CONSOLE INSTALLATION & OPERATION MANUAL 1
INTRODUCTION
About This Manual
This manual provides necessary information regarding product safety, installation, and operation for the following
equipment:
+ V676® Control Console (20.9824.0001)
This manual applies to the hardware (console) only. For complete software operating instructions, refer to the
following manual:
+ Vx76 Software User Manual (02.9814.0001.xx)
Familiarizing yourself with this information will help you get the most out of your lighting system.
WARNING: It is important to read ALL accompanying safety and installation instructions to avoid damage to
the product and potential injury to yourself or others.
Additional Documentation
For more information, refer to the following PRG manuals:
+ Vx76 Software User Manual (02.9814.0001.xx)
+ PRG Lighting Systems Networking Guide (02.3004.1000.0)
+ PRG Node Plus User Manual (02.9801.0301)
+ PRG Super Node™ User Manual (02.9821.0001)
Training Videos
Console Training Videos are available on the PRG website. For a list of videos, refer to the following webpage:
+ http://www.prg.com/console-training-videos/
Customer Service
For technical assistance, contact the PRG International Service Center or contact your nearest PRG office. Contact
information for all PRG office locations can be found on our website at: www.prg.com
PRG Dallas (International Service)
8617 Ambassador Row, Suite 120
Dallas, Texas 75247 USA
Phone: [phone]
Fax: [phone]
Service Fax: [phone]
Service Email: [e-mail]
For additional resources and documentation, please visit our website at: www.prg.com

2V676®CONTROL CONSOLE INSTALLATION & OPERATION MANUAL
Text Conventions and Icons
The following button styles are used throughout this manual:
Note these equivalent buttons on the Mac keyboard and front panel command-line keypad:
[Button] Front panel "hard" button.
Example : Press [Cue] [1] [Enter] to recall Cue 1.
<Button> Optional desk button press.
Example : Press [Store] <Cue> [n] [Enter].
[Button 1 ] / [Button 2] Front Panel button combination sequence.
Press and hold Button 1 while pressing Button 2.
[Button/Button] Front Panel button double-click.
ButtonTouchscreen "soft" button.
Example : Press Plan Viewto open plan view.
Button
Software menu or window dialog button.
Example : Click OK.
Example : At Operation menu, select Luminaire Status.
ENTER Mac keyboard key.
Example : Hold down ALT on the Mac keyboard.
Shift
Option
Cmd
123
.0
Clear At EnterFull
789
Time
456 Sub
Rate
Link
+Thru -Loop
Force
Mark
Cue/
Delay/
Speed
Track
Back
Track/
Wait/
Trail
SneakLabel
Move
Delete Copy/
Sel Park/
PatchUndoRecall
Store Unpark
Update Grab
Help
Query/
Store
Block/
UnBlk
Revert
Manual/ Effect Set Seq
DynamGroup Step
Snap
BeamColorPreset
Macro Shot
Chan
Cue/
Stack
Board
Cue
WIN =
ALT =
SHIFT =
Mac
Keys

V676®CONTROL CONSOLE INSTALLATION & OPERATION MANUAL 3
PRODUCT OVERVIEW
Features
The V676 console is a lighting control desk capable of operating automated luminaires, conventional fixtures and
media servers. The console supports up to 702 universes when used with PRG Node Plus units.
Console Function Capacities:
+ Channels: 4,000 multiple parameter luminaires
+ Color Palettes: 1,000
+ Beam Palettes: 1,000
+ Presets: 1,000
+ Macros: 2,000
+ Effects: 1,000
+ Sets: 1,000
+ Sequences: 1,000
+ Dynamics: 500
+ System Snapshots: 1,000
+ Cue Snapshots: 10,000
+ Cues: 10,000
+ Stacks: 1,000
+ Submasters: 30
External Equipment:
+ Up to 2 external monitor displays
+ Channel Select Panel for fast and intuitive access to 2,000 luminaires
+ PRG Node Plus - provides up to 6 additional universes
+ PRG Super Node™ - provides up to 16 additional universes
+ PRG Series 400 Ethernet Switch - allows 2 or more consoles to be linked together
Outputs:
+ Fiber Optic: 1 - 702 universes possible
+ Ethernet: 1 - 702 universes possible
+ Art-Net/sACN: 16 universes *
+ DMX512: 8 universes *
Interfaces:
* These features are available with the optional DMX Processing Module. Refer to "DMX Processing Module" on page 4.
+ Copper and Fiber Optic Ethernet connections
for communications protocol
+ (8) 5-pin DMX512 Outputs *
+ (1) 5-pin DMX512 Input *
+ (1) Ethernet DMX Output *
+ (2) Mac USB Ports
+ (1) Auxiliary Mac Ethernet
+ (2) DVI-D Single Link
+ (3) Integrated Display Outputs
+ (2) IEC Convenience Outlets
+ SMPTE Time Code input
+ MIDI Time Code input
+ MIDI Show Control input and output
+ MIDI Notes input
+ External Trigger

4V676®CONTROL CONSOLE INSTALLATION & OPERATION MANUAL
Included Items
The V676 Console includes the following standard components:
Figure 1: V676 Components
Optional Items
Monitors and Channel Select Panel
External monitors and/or a Channel Select panel are available from PRG. These are optional items which do not affect
the function or capabilities of the console.
DMX Processing Module
An optional DMX Processing Module - with eight (8) 5-pin DMX512 Outputs, one (1) 5-pin DMX512 Input, and one (1)
Ethernet DMX Output - is also available from PRG. This option provides DMX and DMX-over-Ethernet capabilities
which may not be available on consoles without the DMX Processing Module installed.
1AC Power Cable
2Desk Lamp (2)
3Console Front Panel
2
1
3

V676®CONTROL CONSOLE INSTALLATION & OPERATION MANUAL 5
Desk Layout
The following illustration shows the major control areas of the V676 console.
Figure 2: V676 Front Panel Layout
Light
Pan
Flip High
Tilt
Last Next
Intensity
Full Mark
Out Zero
Open
Close 12
21
11
3
13
4
14
65
15 16 Func
Bank
19
9
7
17
8
18
10
20
Dynam
Frame
Shift Grid
Slow
Pan
3D
Effect
Color
Beam
1211
12
13
3
14
4
15 16
56
Func
Bank
19
9
17
7
18
8
20
10
Select
Control
Board
Back
Stop/
Go Bump Bump Bump
213
SoloSolo Solo
Go
Back
Go
Back
Go
Back
Step
Stop/
Step
Stop/ Step Stop/
Master
Grand
Black
Select
Out Load Load Load
RunRun Run
Select
Stop/
Bump
Back
Bump Bump
45
Solo Solo
Bump Bump
768
SoloSolo Solo
Go
Back
Go
Back
Step
Stop/ Step Stop/
Go
Back
Go
Back
Go
Step
Stop/
Step
Stop/ Step
Bump Bump
910
Solo Solo
Go
Back
Go
Back
Step
Stop/ Step Stop/
Load
Select
Load Load
Run Run
Select Select
Load Load
RunRun Run
SelectSelect
Load Load
Run Run
Select Select
1211
1
13
23
14
46
16
15
5
17
7
18
8
19 20
910
Func
Bank
Control
Rate
Shift
Option
Cmd
Move
Update
Sneak
Undo
Copy/
Delete
Label
Recall
Store
Sel
Effect
Preset
Group
Patch
Park/
Unpark
Dynam
Set
Step
Seq
Color
Macro
Beam
Snap
Shot
Chan
0. Clear
123
4
7
56
89
At Full
Time
+Thru -Link Loop
Enter
Sub
Rate
Grab
Force
Help
Query/
Mark
Cue/
Cue
Board
Dimmer
Cue/
Stack
Delay/
Speed
Block/
UnBlk
Track
Back
Track/
Wait/
Trail
Store
Manual/
Revert
Command Keypad -
Used to input various
command-line actions.
Central Touchscreen -
Displays command-line entries and
active cue numbers. Also used to
configure Timing, Filter, Patch, and
other console operations.
Grandmaster Fader / Blackout Button -
Used to master overall intensity output.
Submasters/Utility Touchscreen -
Displays system configuration
information and submaster settings.
Encoders / Buttons -
Six knobs and associated buttons
which can be mapped for control of
various luminaire parameters.
Palette (3) -
Used to store and recall Preset,
Color, Beam, Group, Macro,
Snapshot, Effect, Dynamic and
Stack settings.
Intensity Buttons -
Appliesanintensity
state to selected
luminaire(s).
Intensity Encoder -
Adjusts intensity level for
selected luminaire(s).
Board Control Buttons - Provides
a method to record events on the
console and play them back on
command.
Pan/Tilt Encoders -
Used to manually
control pan and tilt
functions of selected
luminaire(s).
Soft Function Buttons -
Used with the touchscreen
displays. Function will depend
on the current controls being
shown in the touchscreen.
Rate Encoder -
Used to speed up or slow down the
playback of events (cues or effects).
Submaster Faders -
Used for playback control.

6V676®CONTROL CONSOLE INSTALLATION & OPERATION MANUAL
Console Front and Rear Panels
The following illustrations show the front and rear panels of the V676 console.
Note: The drawings in this manual show the optional DMX Processing Module installed, however, your particular
console may not have this hardware. Refer to "DMX Processing Module" on page 4 for more details.
Figure 3: V676 Console Front and Rear Panels
INPUT
POWER
LABEL
COMPLIENCE
LABEL DMX RDM
1DMXOut 2345678
DMX RDM DMX RDM DMX RDM DMX RDM DMX RDM DMX RDM DMX RDMDMX RDM
In
Link
Act
Link Act
C
o
n
s
o
l
e
Trigger
In Thru Out
Tx
Rx
InIn In
Out
Tx
Rx
Lk
System Comm MIDI SMPTE In Serial Data
AB
Displays Accessory
Aux Ethernet
Enable
Enable
1
2
USB100-240 VAC
Line/NeutLine
Power Button
10A Breaker Switch
(console power)
Desk Lamp
Connector
Desk Lamp
Connector
Power Cable Input
External Control Inputs
Standard Monitor
AccessoryEthernet & USB
Connectors
Display Connections
FRONT VIEW
REAR VIEW
Pull-Out Keyboard & Trackpad
Storage Drawer
Headset / Belt Pack Holder
Inputs
Convenience
Outlets
DMX Processing
Module
(OPTIONAL)

V676®CONTROL CONSOLE INSTALLATION & OPERATION MANUAL 7
INSTALLATION
Unpack and Setup Procedure
Step 1. Remove all components from shipping container (Figure 4).
Step 2. Place console on a sturdy table or other flat surface.
Figure 4: Unpacking the V676 Console Contents
AC Power Cable
Desk Lamp (2)
Console

8V676®CONTROL CONSOLE INSTALLATION & OPERATION MANUAL
Note: Monitors and/or Channel Select panel are optional. If these components are not included, skip to Step 6.
Note: The console supports up to two (2) external monitors (optional). This can be two PRG-provided monitors, two
user-provided monitors, or a combination of one each. In any case, only two external monitors should be installed.
Note: If DVI monitors are to be used instead of PRG-provided monitors, refer to "Display Setup" on page 12.
Step 3. At rear of console, install one support arm for each external monitor/panel, as shown in Detail B of Figure 5.
Step 4. Slide monitor/panel onto support arm quick-release connectors as shown in Detail A of Figure 5.
Figure 5: Installing Channel Select Panel and Monitors on V676 Console (Optional)
Support Arm (3)
Monitor (2)
Channel
DETAIL A
Select
DETAIL B
Quick-
Release
Support Arm
Bracket (2)
Support Arm
Bracket (2)

V676®CONTROL CONSOLE INSTALLATION & OPERATION MANUAL 9
CAUTION: Power supply plug and/or power switch/circuit breaker shall remain readily operable.
Step 5. Connect monitors and/or Channel Select panel to console, as required (Figure 6). Be sure to connect LEMO
connectors as shown.
Step 6. Connect AC Power Cable (supplied) from AC In connector at back of console to AC power source.
Figure 6: Connecting Components to V676 Console
Note: The console supports up to two (2)
external monitors (optional). This can be two
PRG-provided monitors, two user-provided
monitors, or a combination of one each. In
any case, only two external monitors should
be installed. Note that your particular set-up
may be different than what is shown here.

10 V676®CONTROL CONSOLE INSTALLATION & OPERATION MANUAL
Step 7. At rear of console, install desk lamps (Figure 7).
Figure 7: Installing Desk Lamps
INPUT
POWER
LABEL
COMPLIENCE
LABEL DMX RDM
1DMXOut 234 5678
DMX RDM DMX RDM DMX RDM DMX RDM DMX RDM DMX RDM DMX RDMDMX RDM
In
Link
Act
Link Act
C
o
n
s
o
l
e
Trigger
In Thru Out
Tx
Rx
InIn In
Out
Tx
Rx
Lk
System Comm MIDI SMPTE In Seri
AB
Accessory
Aux Ethernet
Enable
Enable
2
Line/NeutLine
Desk Lamp
