Primal Vantage Fiels & Stream HEH00774 Instruction Manual

SAFETY MUST BE YOUR FIRST PRIORITY WITH THIS PRODUCT
• Always Wear a Safety Harness with this Product
• Practice Using at Ground Level
• Weight Limit: 300 lbs.
• Tree Size: 9”-18” diameter
MODEL: HEH00774
OUTPOST XL 17’ LADDER TREESTAND
Instruction and Safety Manual
Every year serious injury and death can occur from hunting related accidents. To ensure your safety, please COMPLETELY read
and follow this safety manual and ALL warning labels BEFORE assembling, installing or utilizing this product.
DO NOT USE THIS PRODUCT BEFORE FULLY UNDERSTANDING ALL SAFETY WARNINGS AND INSTRUCTIONS. IF YOU HAVE
QUESTIONS, ARE UNSURE ABOUT ANY INFORMATION OR NEED ADDITIONAL INFORMATION CONCERNING YOUR PRODUCT,
CONTACT OUR CUSTOMER SERVICE DEPARTMENT AT1-866-972-6168 OR VISIT PRIMALVANTAGE.COM/FIELD-STREAM. KEEP
AND MAINTAIN THIS SAFETY AND INSTRUCTION MANUAL IN A SAFE LOCATION FOR FUTURE REFERENCE.
The Field & Stream trademark is owned by American Sports Licensing Inc., and is not associated with Field & Stream Licenses
Company, LLC or Field & Stream Magazine.
W A R N I N G
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120

Treestand Safety Warnings
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168 primalvantage.com/field-stream
©2019 (rev. 1/19)
Please read the following instruction manual and warnings labels completely before utilizing this product. Failure to understand and execute the instructions
and warnings may result in serious injury or death. In the event of an accident, have a plan for rescue, including the use of devices that may be easily
reached while suspended.
ALWAYS read and understand all warnings and instructions. Watch the enclosed DVD in it’s entirety before doing anything with this product including
assembly, installation etc. before each use of this product. Failure to read and understand all warnings and instructions and DVD material may result in
serious injury or death. Contact a Customer Service Representative with any questions you may have.
NEVER exceed total weight limit of 300 lbs. DO NOT use if your combined weight with all of your hunting gear and any accessories exceeds 300 lbs. Use of
tree stand over the weight limit may result in serious injury or death.
DO NOT use this tree stand while under the influence of alcohol, medication or any illegal substances. Use of tree stand while under the influence of any of
these substances may result in serious injury or death.
NEVER use this treestand during inclement weather. DO NOT use tree stand during thunderstorms, snowstorms, hurricanes, tornadoes or any other weather
conditions that include (but not limited to) lightning, icy conditions, or high winds that could create slippery or dangerous situations. End your hunt and return
to the ground if inclement weather conditions arise.
NEVER use treestand If you are feeling ill, nauseous, dizzy or if you have a prior condition that could cause a problem. i.e., heart condition, joints that lock-up
spinal fusions, etc., or if you are not well rested and alert. Physical ailments can reduce your ability to safely install, utilize, and remove your treestand. Please
consult a physician prior to use.
NEVER use this tree stand if you have a history of health problems such as (but not limited to) heart problems, back problems, high blood pressure, impaired
vision, equilibrium impairments, are afraid of heights, have been advised by a doctor or physician not to climb. If you are not physically fit, well rested, and
alert, or if you have any other physical or mental condition that would impair your ability to properly use this treestand.
NEVER use this tree stand on a tree that is dead, leaning, diseased, loose barked or on a utility pole as the tree may fall, break, or uproot and may result in
serious injury or death.
NEVER rely on a branch for support.
NEVER jump or bounce on the treestand’s platform or ladder sections to seat it to the tree.
NEVER transport any of your equipment with yourself while ascending or descending the tree. You will need to have two hands free during ascending and
descending for safety. Use a haul line to pull up your firearm (unloaded, chamber opened with safety lock engaged, barrel facing towards the ground), bows,
arrows, knives or any other equipment to your tree stand once you have reached your desired hunting height. ONLY pull up hunting equipment after the tree
stand has been secured to the tree and after you and your harness have been secured to the tree. Prior to descending, lower your equipment on the opposite
side of the tree from which you are climbing. Make sure that the unloaded firearm’s safety lock is engaged and the gun barrel is pointing towards the ground.
DO NOT carry the stand when ascending or descending the tree. Use a haul line to raise and lower your stand.
ALWAYS hunt with a plan and a buddy. Before you leave home, let others know your exact location, when you plan to return and who is with you.
ALWAYS carry emergency signal devices such as a cell phone, walkie-talkie, whistle, signal flare, PLD (personal location device) and flashlight with you at all
times and within reach even while you are suspended in your harness. Watch for changing weather conditions. In the event of an accident, remain calm and
seek help immediately.
ALWAYS inspect the tree stand and the Fall Arrest System (FAS) (Harness) for signs of wear or damage BEFORE each use. Also inspect to ensure that nuts
and bolts are secure. Pay special attention to the harness and straps, guaranteeing that nothing has been frayed or severed. Destroy all products that cannot
be repaired by the manufacturer. Contact a Customer Service Representative for replacement parts. The Fall Arrest System MUST be discarded and
replaced after a fall has occurred.
NEVER modify your treestand in any way by making repairs, replacing parts, or altering adding or attaching anything to it except if explicitly authorized in
writing by the manufacturer. Improper installation or adjustment may cause serious injury or death. Remove all contents from box. Inspect for any damaged
or missing parts. If any parts are missing or damaged, you must only use certified replacement parts. Using any other replacement parts will
void product warranty. THERE ARE NO EXTRA PARTS. All parts MUST be used to ensure the safety of you and your stand. If you think parts are missing or
damaged, STOP IMMEDIATELY and contact our Customer Service Department. Using the tree stand with missing or damaged parts may result in serious
injury or death. Contact a Customer Service Representative if you have any missing, damaged or extra parts.
PRACTICE installing, adjusting and using hang-on treestands at ground level prior to using it at an elevated position.
ALWAYS keep instructions (written and video) in a safe place and review before each use. It is the responsibility of the treestand owner to furnish the
complete instructions to anyone who borrows or purchases the treestand from you.
NEVER use this treestand for any use other than hunting. Our treestands are designed for hunters to wear a Full Body Harness. If you are not completely
comfortable and confident with your ability to safely install, ascend, hunt and descend using a Full Body Safety Harness and this treestand, DO NOT
PROCEED.
NEVER use this treestand for trimming trees.
NEVER fall asleep in your stand as you may fall out resulting in serious injury or death.
ALWAYS be sure to retighten all bolts BEFORE each new use of treestand.
ALWAYS have a minimum of three people present when installing or removing this treestand.

Treestand Safety Warnings
NEVER remove any safety warning
stickers from this product.
DO NOT use this ladderstand under the influence of alcohol,
drugs, or medication. Using ladderstand under the influence
of alcohol, drugs, or medication may result in serious injury or
death.
NEVER use ladderstand if you have dizzy spells, a heart
problem, are afraid of heights, have been advised by a doctor
or other health care provider not to climb, or have any
condition that would impair your ability to climb up or down or
use treestand as it could result in serious injury or death.
NEVER remove or deface ladderstand warning labels.
Replacement labels can be obtained from the address below.
NEVER make any alterations or modifications to the ladder
stand.Doing so may result in serious injury or death and will
void all warranties.
NEVER stand on treestand seat or armrests. Standing on any
of these parts may cause the treestand to break or fail resulting
in serious injury or death.
NEVER use treestand in a tree that is dead, diseased, leaning,
or on wet or uneven ground as the tree may fall, break, or
uproot and may result in serious injury or death.
NEVER use ladderstand during inclement weather. DO NOT
use treestand during thunderstorms or any other weather
conditions including (but not limited to) lightning, freezing rain,
high wind that could create slippery or dangerous conditions.
DO NOT use this ladderstand without reading and following all
warnings and instructions before each use. Failure to do so
may result in serious injury or death.
DO NOT exceed the ladderstand's 300 lbs. weight limit, which
includes your body weight as well as the weight of your clothes
and gear. Exceeding the ladderstand's weight limit may cause
the treestand to break or fail resulting in serious injury or death.
ALWAYS wear a Full Body Harness while using this ladder
stand. Failure to wear a full body harness while using
this ladderstand may result in serious injury or death.
ALWAYS inspect your ladderstand before each use. DO NOT
use if parts are missing, worn, or damaged.
SAMPLE
Safety must be your first priority
during the use of this product.
W A R N I N GW A R N I N G
Customer Service Department 1-866-972-6168 primalvantage.com/field-stream
©2019 (rev. 1/19)
NEVER adjust your stand while in use. Practice the attachment of this treestand at ground level before using in a hunting environment. ALWAYS ensure that
you and your treestand are safely secured to a healthy tree. Your tree stand MUST be attached tightly to the tree and secured in place. If the stand is not
secure, it may shift while in use, resulting in serious injury or death.
The Installation Cross Straps and Stabilizer Bar(s) MUST be properly installed before each use of the treestand.
ALWAYS inspect every ladder section connection every time you use the stand before you leave the ground. If ladder sections are separating, with the help of
at least two other people, lower the stand to the ground, make adjustments, and reinstall.
ALWAYS check the ground below the tree stand to make sure it is firm and level. Sloping ground or uneven terrain (one side of a rock or root) can cause your
tree stand to tilt or shift.
ALWAYS maintain three points of contact when climbing the tree stand. (Two feet and one hand or one foot and two hands.)
ALWAYS lean forward as you climb and attach your harness to the tree before securing the platform to the tree and stepping onto the platform.
DO NOT leave your treestand outside since weather or animals may cause damage. Tree growth can also cause stress and damage straps and buckles. It
must be stored inside, free of moisture, when not in use.
NEVER wear jewelry or loose fitting clothing, which can cause hazardous conditions. Clothing may be caught in your equipment and cause you to fall. You
must always wear non-slip or rubber boots. Shoelaces must be tucked into your boots. Rings and necklaces MUST NOT be worn.
NEVER use this treestand with a second person. The treestand is designed for use by ONE person.
NEVER let children use this treestand without adult supervision. This treestand is not a toy. No one under the age of 18 should attempt to use this product
without direct adult supervision.
DO NOT use tree stand if any nuts or bolts or parts are loose, bent, or crooked.
ALWAYS know your physical limitations. Don’t take chances. If you start thinking about how high you are, don’t go any higher. Instead, choose a minimum
height that will allow for safe, effective and comfortable hunting.
ALWAYS lean forward towards the tree as you climb and attach your harness to the tree BEFORE securing the platform to the tree and stepping onto the
platform. NEVER lean out from the treestand for any reason.
ALWAYS wear a Fall Arrest System (FAS) (Harness) consisting of a full body safety harness after leaving the ground. A Full Body Harness that meets
TMA/ASTM standards MUST always be connected to yourself and the tree during ascending, hunting and descending. Single safety belts and chest harnesses
are no longer allowed and should NEVER be used. If you are not wearing a Full Body Harness properly attached to the tree, that is protecting you from a fall,
DO NOT leave the ground. Failure to wear your Full Body Harness may result in serious injury or death. Be aware that falls can occur at anytime after leaving
the ground.
ALWAYS read and understand the manufacturer’s Warnings, expiration date (if applicable) and instructions on how to use and how to properly adjust the
harness. Practice the use of a full body safety harness at ground level in the presence of a responsible adult to experience the feeling of hanging suspended
before using in a hunting environment. Failure to follow harness instructions may result in not being able to return to the stand and being suspended in a
harness after a fall, or serious injury or possibly death. If the hunting location is unknown by anyone and communication efforts are unsuccessful, you MUST
have a personal plan for rescue/escape because prolonged suspension in a harness may be fatal. It is important to exercise the legs by pushing against the
tree or doing other forms of continuous leg exercises to avoid blood pooling while being suspended. Hunters with varying degrees of physical fitness may
require different plans to recover/escape the effects of prolonged suspension. Have a personal plan and practice it in the presence of a responsible adult before
leaving the ground. No one escape/rescue plan will work for every hunter on every tree in every circumstance. Only you can determine the best
recovery/escape plan for your situation before leaving the ground.
ALWAYS have a suspension relief device on your person and readily accessible while using a harness. These devices allow the user to relieve the load on the
lower extremities if suspended in a harness and help maintain circulation in the legs, mitigate suspension trauma (blood pooling) or allow descent to the
ground. Several optional products/systems are available that offer self-recovery or self-extraction from a fall when suspended in a harness. Some systems
automatically descend the user while others allow user control. One of these products/systems can be considered for use as an additional safety precaution
against prolonged suspension and suspension trauma, Be sure to follow the manufacturers’ instructions on the safe use of these products/systems.
Hunt from the ground when self-recovery escape is absent. There is time to make a correct decision on what action to take if a fall occurs while wearing a full
body harness. It is important to remember “DO NOT PANIC.” Remain calm and implement your practiced rescue, relief and recovery plan.
NEVER allow the tether strap to get under your chin or around our neck. The length of the harness tether MUST be minimized at all times. It should be
adjusted so that it is above the head with no slack (snug) in the sitting position and you should have the minimum amount of slack possible when climbing.

Choosing A Safe Tree
Proper Care And Maintenance:
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168 primalvantage.com/field-stream
©2019 (rev. 1/19)
• ALWAYS thoroughly inspect the tree before installing your product. DO NOT install your TREE/LADDER STAND onto any dead or unsafe tree, telephone or
utility pole, structural column, or man-made structure. Doing so may result in serious injury or death.
• ALWAYS select the proper tree for use with your TREE/LADDER STAND. Select a live straight tree that fits within size limits recommended (minimum tree
diameter must be no less than 9 inches and maximum of 18 inches.). DO NOT rely on a branch for support.
• DO NOT select a tree in the dark or choose a tree in close proximity to a fence. You must not have any stumps or rocks beneath your tree.
• NEVER use TREE/LADDER STAND on a tree that is dead, diseased , leaning or on wet and uneven ground as the tree may fall, break or uproot.
• Your tree must not be wet, icy or slippery or on wet, swampy, or loose ground that allows the tree to be unstable. Check the ground under TREE/LADDER
STAND to ensure it is firm and level.
• Be sure you have a level stand platform. Your tree must not lean or have any irregular shape.
• Tree must not have any loose or scaly bark or excessive vines, nails, screws, or any other sharp objects protruding that may sever webbing on product. Any
surrounding trees must not lean or have dead limbs that may fall onto you or your product.
• NEVER HURRY!! HURRYING CAUSES ACCIDENTS!! While climbing a TREE/LADDER STAND, make slow, even movements no more than ten to twelve
inches at a time. Make sure you have proper contact with tree and/or TREE/LADDER STAND every time you move. On ladder tree stand, ALWAYS maintain
three points of contact with each step up the ladder and ALWAYS lean forward as you climb.
Several treestands are equipped with a footrest, armrests and/or shooting rail. Neither the footrest, armrests nor the shooting rail have been designed
to support a user’s weight. Under NO circumstances should you place more than fifteen (15) pounds of weight on these structures. Doing so will put
the user in serious risk of injury or death.
• Inspection for defects (damage, rot, corrosion, cracks, freezing, excessive heat, etc.) before every use is required. Do not use if damage is detected
or suspected.
• We recommend replacing all hardware/cables/nuts/bolts/clips on your tree stand every two (2) years or sooner if inspection finds it necessary. Use
only Primal Vantage approved replacement straps and parts. Use of any other straps or parts, will be viewed as a modification to the product. Any
modification will void the warranties and relieve Primal Vantage from all liabilities. Failure to follow these instructions may result in serious injury or
death.
• DO NOT overtighten the hardware. DO NOT use a socket wrench. This can lead to structural damage and may negatively affect the performance of
your stand. Failure to follow these instructions may result in serious injury or death.
• All photos are taken from the front view unless otherwise noted.
• In most cases, bolts come with two nylon washers. One washer will be placed against the bolt head the other washer will be placed against the nut.

Left Handle Rail (1)
Yoke (2)
Shooting Rail Cover (1)
Foot Platform (1)
Tree Brace (1)
Tree Brace Support (1)
Right Handle Rail (1)
Backrest Support (2)
Installation
Cross Strap (2)
Shooting Rail
Knob (2)
Shooting Rail
Bracket (2)
Footrest (1)
Stabilizer Bar (1)
Stabilizer
Buckle (1)
Part # 1270
Part # 1045
Part # 1290B
8 M8 x 70mm Bolt....................
4 M6 x 45mm...........................
2 M8 x 90mm Bolt....................
w/Bushing
90
HARDWARE P/N 774H
70
Part # 1070S2 M6 x 70mm Bolt....................
w/Spacer
70
Part # 1255B
Part # 1255
2 M8 x 55mm Bolt....................
w/Bushing
55b
55
Part # 1240
2 M8 x 40mm Bolt....................
40
100 2 M6 x 100mm Bolt w/Spacer..
and Bushing
Part # 10100B
Part # 1050
2 M6 x 50mm Bolt....................
50
Part # 10252 M6 x 25mm Bolt....................
25
1 Top Ladder..........................
2 Ladder Section...................Part # DL-5719
Part # DL-5709
45
2 Platform Brace................... Part # DPB-620
1 Seat Platform (Complete)...
1 Foot Platform......................
1 Right Handle Rail................
1 Left Handle Rail..................
1 Shooting Rail......................
2 Armrest...............................
2 Shooting Rail Arm...............
1 Harness..............................
2 Ratchet Strap........................Part # RA-100
1 Shooting Rail Cover............
1 Tree Brace..........................
1 Footrest..............................
2 Shooting Rail Bracket............
Part # SRB-621
1 Spreader Bar......................Part # DSB-621
2 Installation Cross Strap.........Part # ICS-1000
2 Armrest Cover.....................
2 Backrest Support................
1 Tree Brace Support............
2 Yoke....................................
Part # 1615
4 M6 Quickclip..........................
Part # DRH-774
Part # DLH-774
Part # DYK-621
Part # DFP-621
Part # DFR-580
Part # DBS-621
Part # DTBS-580
Part # DTB-580
Part # DSP-621
Part # DAR-579
Part # DSRA-620
Part # DSR-620
Part # DARC-580
Part # DPSC-580
1 Seat Fabric Only...............Part # DSC-621
Part # 2018-FS
2 Shooting Rail Knob...............Part # SRK-100
1 Stabilizer Buckle Strap..........Part # DBA-100
Part # 1245w
1 M8 x 45mm Bolt w/Wingnut..
45w
1 Stabilizer Bar......................Part # DSB-600
Part # AK-1001 Adjustment Knob...................
2 M8 x 55mm Bolt....................
PARTS LIST
B
C
D
E
F
H
J
K
L
M
N
A
G
O
Q
R
S
T
U
P
V
X
Y
Z
• Always Wear a Safety Harness with this Product
• Practice Using at Ground Level
• Weight Limit: 300 lbs.
• Tree Size: 9”-18” diameter
MODEL: HEH00774
OUTPOST XL 17’ LADDER TREESTAND
Top Ladder
Section (1)
A
Ladder
Section (2)
B
Platform Brace (2)
C
(Holes on Sides)
D
E
F
G
H
Ratchet
Strap (2)
X
Adjustment
Knob (1)
Z
Y
VM6
Quickclip (4)
J
M
K
Spreader Bar (1)
Q
J
M
L
Armrest (2)
O
Seat Platform (1)
J
N
Shooting Rail Arm (2)
J
R
Shooting Rail (1)
J
S
JU
Armrest Cover (2)
J
T
P
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168 primalvantage.com/field-stream
©2019 (rev. 1/19)

ALL PHOTOS TAKEN FROM FRONT VIEW UNLESS OTHER-
Assembly Instructions Page 1 Model: HEH00774
Outpost Xl 17’ Ladder Treestand
G
Bolt
Head
Washer Washer
Nut
Footrest
Bushing
H
90
J
90
90
H
G
Insert the bushing from 1-M8x90mm Bolt
into the front inside of Foot Platform H . Place
Footrest J between the bushings at the front of
Foot Platform H . Insert the bolt through the
footrest, through the Foot Platform, then place
the flat side of Yokes against the outside of the
Foot Platform. Make sure the sleeved end of
Yokes are facing up. (See Right Side Closeup)
1
1
Insert the bushing into the foot platform,
insert the bolt and one washer through the
footrest, then insert the bolt through the foot
platform, then through the yoke. Insert the
last washer onto the bolt and secure with
the nut.
45
45
EF
G
2
Insert Left Handle Rail F and Right Handle Rail E
over Yoke G . Insert 1-M6x45mm Bolt
on each side.
Make sure that the flat side of each Handle Rail is
facing towards the inside of the stand.
2
Right Side Closeup
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168 primalvantage.com/field-stream
©2019 (rev. 1/19)

Assembly Instructions Page 2
Attach the bottom of Backrest Support K to the brackets on the rear
of Foot Platform H using 1-M8x40mm Bolt on each side.
NOTE: The Top of Backrest Support will curve away from the
front of the stand.
Attach Backrest Support K to the second hole behind the bracket on
the inside of each Handle Rail E and F using 1-M8x70mm Bolt
on each side. Make sure the Top of Backrest Support curves away
from the front of the stand.
H
K
F
E
40
70
E
F
70 70
L
M
Attach Tree Brace M to the top of Handle Rails
E and F at the rear most holes using 1-M8x70
Bolt on each side.
Attach Tree Brace Support L to the top of
Handle Rails E and F at the holes just in front
of Tree Brace M using 1-M8x70mm Bolt
on each side.
K
H
F
E
70
70
40 40
40
70
70
70
3
3
4
4
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168 primalvantage.com/field-stream
©2019 (rev. 1/19)
Model: HEH00774
Outpost Xl 17’ Ladder Treestand

Assembly Instructions Page 3
Slide Backrest Fabric onto Backrest Supports K .
Attach Seat Platform N between brackets on
Handle Rails E and F using 2-M8x55mm Bolts
w/Bushings on each side.
Note: The Bushings will be placed between the
bracket and the Seat Frame.
55b
F
E
N
55b
55b
F
E
N
70
70
100
100
Attach Arm Rest Cover to each Armrest O .
Note where the holes are located on the armrests.
Slide Shooting Rail Bracket P onto each armrest.
Attach Shooting Rail Knob V to Shooting Rail
Bracket P .
NOTE: Shooting Rail Knob will be facing the
outside of the stand as the Assembled Shooting
Rail will rest on top of these knobs.
Attach the front of each Armrest O to Handle Rail E
and F with 1-M6x70mm Bolt w/Spacer on each
side. Place the Spacer between the Armrest and the
Handle Rail.
Attach the rear of each Armrest O to each Handle Rail
E and F . Place the Spacer between the Armrest and
the Handle Rail. Use 1-M6x100 Bolt w/ Spacer and
Bushing to hold the armrest in place for the next
step. But DO NOT tighten the bolt yet.
Hole for
M6x100mm Bolt
Hole for
M6x70mm Bolt w/Spacer
70
PO
Shooting
Rail Knob
N
Q
50
50
Turn Seat Platform over. Attach Spreader Bar Q to
the front of Seat Platform N using 1-M6x50mm
Bolt on each side.
5
5
6
6
7
7
8
8
BOTTOM
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168 primalvantage.com/field-stream
©2019 (rev. 1/19)
Model: HEH00774
Outpost Xl 17’ Ladder Treestand

Assembly Instructions Page 4
Insert both Shooting Rail Arms R into Shooting
Rail S .
Insert 1-M6x25mm Bolt through the
Shooting Rail and Shooting Rail Arms to secure.
Attach Shooting Rail Cover to assembled
Shooting Rail.
Attach assembled Shooting Rail to Armrests O
using the previously installed M6x100mm Bolt
w/Spacer and Bushing . Insert the bushing
between the Shooting Rail and the Armrests.
NOTE: Make sure that the Shooting Rail is curved
up.
Attach one Ratchet Strap X between Tree Brace
and Tree Brace Support .
Attach remaining Ratchet Strap to the rear of Foot
Platform
(See Ratchet Instructions).
Attach each Installation Strap Y just behind the
Ratchet Straps between Tree Brace and Tree Brace
Support. (See Installation Strap Instructions).
X
Y
M
L
H
Shooting
Rail Cover
S
R
25
25
R
100
100
V
9
9
10
10
11
11
SIDE VIEW REAR VIEW
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168 primalvantage.com/field-stream
©2019 (rev. 1/19)
Model: HEH00774
Outpost Xl 17’ Ladder Treestand

Assembly Instructions Page 5
Follow above steps to attach the bottom section to the middle section.
Insert Ladder Section B into the
sleeved end of Top Ladder Section A .
Close the quickclip to secure the
ladder sections together.
Insert 1 - M6 Quickclip through
the hole on each side of the
ladder section.
B
A
A
G
45
45
Attach Top Ladder Section A into Yokes G
using 1-M6x45mm Bolt on each side. Attach one end of Platform Brace C to the INSIDE of Foot
Platform H using 1-M8x55mm Bolt on each Side.
Attach oppostie end of Platform Brace C to the OUTSIDE to Top
Ladder Section A using 1-M8x70mm Bolt on each side.
55
55
70
H
C
A
55
70
17
15 16
15
16
17
18
13 14
13
14
Ladder Assembly
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168 primalvantage.com/field-stream
©2019 (rev. 1/19)
Model: HEH00774
Outpost Xl 17’ Ladder Treestand

Installation Instructions Page 1
45w
45w
D
Adjustment
Knob
Slide the inner part of the Stabilizer Bar into the outer part.
Attach Stabilizer Bar D to the second rung of the Middle
Ladder Section with 1 - M8x45mm bolt and 1 wingnut.
Insert the Adjustment Knob in the Stabilizer bar at the proper
adjustment point to the tree.
1
Position bottom of stand 4-5 feet from base of tree.
1
2
One person will stand at the base of ladder with
his/her foot on the bottom rung while holding
installation straps. This will prevent tree stand from
sliding. Two people will stand at opposite ends of
tree stand, facing platform and slowly walk tree
stand upward using rungs of ladder.
2
3
As tree stand is being raised, the
person holding installation straps will
pull toward themselves to take up slack.
It will steady and ease the weight of
stand on the other two people. Continue
walking stand upward, until Tree
Connetion Brace is resting against the
tree.
3
4
4
NOTE: Drawings are for illustration purposes only and may not depict actual product.
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168 primalvantage.com/field-stream
©2019 (rev. 1/19)
Model: HEH00774
Outpost Xl 17’ Ladder Treestand

12 3 4
Cross Installation Straps behind tree.
Attach to the top rung of the bottom
ladder section.
(See Installation Strap Instructions)
Z
Installation Instructions Page 2
Move base of ladder toward or
away from tree slightly in order to
make Platform as parallel to the
ground as possible.
Apply your full weight to the first
step so it settles into the ground.
Buckle Instructions
Attach Buckle Strap Z just behind
the brace of the inner part of
Stabilizer Bar D by following the
Strap Installation below.
(See Strap Installation Below)
Position the Stabilizer Bar against
the tree and secure it by wrapping
the strap around the back of the
tree once and insert the strap into
the buckle.
(See Buckle Instructions Below)
5.
5
6.
6
7.
7
567
Detailed Stabilizer Strap Installation
Hold Strap as shown. Insert Strap through
looped end. Pull Strap to tighten. Use these same instructions
to attach the buckle.
1
2 34
Pull strap to desired length.
Press down on latch and
insert strap underneath
teeth as shown.
Pull slack to tighten.
Hold buckle as shown.
NOTE: Drawings are for illustration purposes only and may not depict actual product.
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168 primalvantage.com/field-stream
©2019 (rev. 1/19)
Model: HEH00774
Outpost Xl 17’ Ladder Treestand

Detailed Ratchet Strap Instructions
Stabilizer Bar and Installation Straps
MUST be secured prior to climbing
the Ladderstand. Failure to comply
may result in serious injury or death.
DO NOT climb ladder without Stabilizer
Bar installed. Serious injury or death
may occur if Stabilizer Bar and
Installation Straps are not installed.
9
8
9
Cautiously climb to the top of the treestand. Wrap
the strap of the ratchet around the back of the
tree once and thread through the ratchet.
(See Detailed Ratchet Instructions Below)
8
After the ladder stand has been secured to the
tree with the installation straps, and the
stabilizer bar has been securely attached to
the tree, continue to have two people hold the
ladder and climb cautiously up to the platform.
Once you reach the top, IMMEDIATELY
ATTACH YOUR SAFETY HARNESS TO THE
TREE. Keep the tether strap above your head.
Strap Installation
Ratchet handle back
and forth to tighten
strap. Ensure that the
ratchet wheel makes
at least one and a
half revolutions once
installed. DO NOT
allow the ratchet
wheel to over-fill and
contact the ratchet
mechanism of the
ratchet strap.
12 3 4 5 6
Open ratchet handle
flat and insert end of
strap through opening.
Pull Strap through
opening. Insert end of strap
through slot in ratchet
wheel.
To release tension, push
spring loaded retaining lock
and simultaneously pull
on strap.
After strap is tight,
close handle to
the locked position.
DO NOT sit on seat platform until
the Ratchet and Installation Straps
have been secured.
W A R N I N G
X
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168 primalvantage.com/field-stream
©2019 (rev. 1/19)
Model: HEH00774
Outpost Xl 17’ Ladder Treestand

Installation Strap Instructions
DO NOT sit on seat platform until the Ratchet Strap and Installation Straps have been secured.
Insert end of strap
through the loop.
2
Place looped end of strap
under platform.
Slot 2 Slot 1
Place loose end of strap with clip,
under the top rung of the bottom
ladder section.
4
Insert the strap through Slot 1 on
the clip.
5
Insert the strap through the
Slot 2 with the teeth.
6
Pull strap to tighten.
Slide the buckles out to the sides
to create tension on the straps.
Pull to tighten. Repeat steps
1-8 to install the other
strap on the other side of the
platform.
1
678
45
23
7
8
1
2
3
W A R N I N G
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168 primalvantage.com/field-stream
©2019 (rev. 1/19)
Model: HEH00774
Outpost Xl 17’ Ladder Treestand

Ratchet Strap Instructions
Ratchet handle back
and forth to tighten
strap. Ensure that the
ratchet wheel makes
at least one and a
half revolutions once
installed. DO NOT
allow the ratchet
wheel to over-fill and
contact the ratchet
mechanism of the
ratchet strap.
Place looped end of Ratchet
under platform.
1
Place looped end of strap
under platform.
Insert Ratchet through loop.
2
Pull to tighten.
3
YOU MUST READ AND FOLLOW ALL INSTRUCTIONS PRIOR TO INSTALLATION
1
6
12 3 4 5 6
Open ratchet handle
flat and insert end of
strap through opening.
Pull Strap through
opening. Insert end of strap
through slot in ratchet
wheel.
To release tension, push
spring loaded retaining lock
and simultaneously pull
on strap.
After strap is tight,
close handle to
the locked position.
Detailed Ratchet Strap Instructions
4
Pull to tighten.
6
Insert strap through loop.
5
5
32
4
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168 primalvantage.com/field-stream
©2019 (rev. 1/19)
Model: HEH00774
Outpost Xl 17’ Ladder Treestand

DO NOT climb ladder without Stabilizer Bar and
Installation Straps installed. These MUST be
correctly installed prior to use. Serious injury or
death may occur if Stabilizer Bar and Installation
Straps are not installed.
W A R N I N G
ALWAYS read and understand all warnings and instructions
before each use of this product. Failure to read and
understand all warnings and instructions may result in
serious injury or death.
NEVER exceed weight limit of 300 lbs. DO NOT use if your
combined weight with all your hunting gear and any
accessories exceeds 300 lbs. Use of tree stand over the
weight limit may result in serious injury or death.
ALWAYS inspect the tree stand for signs of wear or
damage BEFORE each use. Also inspect to ensure that
nuts and bolts are secure and straps are not frayed, worn,
or broken.
ALWAYS wear a Fall Arrest System (FAS) after leaving the
ground. If you are not wearing an FAS that meets ASTM
standards, DO NOT leave the ground. Failure to wear an
FAS may result in serious injury or death.
DO NOT use this tree stand while under the influence of
alcohol, medication, or illegal substances. Use of tree stand
while under the influence of any of these substances may
result in serious injury or death.
NEVER use this tree stand if you have a history of health problems
such as (but not limited to) heart problems, back problems,
impaired vision, equilibrium impairments are afraid of heights or
have been advised by a doctor not to do any strenuous activity. If
you are feeling ill, nauseous, or dizzy DO NOT use this tree stand
or If you are not physically fit, well rested and alert. Physical
ailments can reduce your ability to safely install, utilize and remove
your tree stand.
NEVER use this tree stand during inclement weather such as (but
not limited to) thunderstorms, snowstorms, hurricanes, icy
conditions, or high winds that could create slippery or dangerous
situations.
NEVER use this tree stand on a dead, leaning, loose barked tree or
on a utility pole as the tree may fall, break, or uproot and may result
in serious injury or death.
DO NOT modify or alter your tree stand.
NEVER leave the ground without checking every ladder
section connection to ensure they are firmly connected. If
ladder sections are separating, with the help of at least two
other people, remove the tree stand from the tree, tighten
all connections and reinstall on the tree.
NEVER remove or deface warning labels.
Installation Straps, Ratchet Straps, Quickclips,
Tiedown Ropes and Stabilizer Bars MUST be installed
and secured prior to climbing tree stand. Failure to
comply may result in serious injury or death.
Failure to follow all warnings listed below could result in serious injury or death.
Manufactured in the year 2019 Primal Vantage Company Inc. 2407 W. Euclid Ave., Littleton, CO 80120 1-866-972-6168
