Prime Power MIL DC/DC 24-24V 60A User manual

DC/DC
CONVERTER
24V-24V / 40A & 60A
GALVANIC ISOLATED

1
DCDC CONVERTER 24/24
Idavägen 11 SE-352 46 |[phone] |[e-mail]
CRITICAL INFORMATION
The technical data, information and illustrations have been carefully compiled and corresponds to the product status
at the time of printing this manual. The manufacturer reserves the right to improve or modify the product,
specifications and documentation at any time without prior notice, provided that it is not considered necessary for
technical reasons.
Descriptions have been prepared very carefully and in detail, yet it is never possible to completely rule out wrong.
Under no circumstances will the manufacturer be held responsible for errors or damages resulting from wrong use
or from misinterpretation.
The content of this documentation may not be copied, reproduced, translated or otherwise passed on to third
parties in any form without the express written consent of Primepower.
Warning!
Failure to follow these safety instructions could result in personal injury, property damage or impair the
function of the product.
Danger! High voltage!
Failure to follow this safety instruction can result in injury or death, or may damage or destroy the
product.
Important Information!
To avoid operator error, read this manual carefully before installing and using the product and follow
the appropriate instructions. Keep this manual near the product so that it can be referred to later.
This product is not intended for use by persons (including children) with reduced physical sensory or
mental capabilities, or lack of knowledge or experience, unless they have received instructions or
information on how to use the product by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the product.

2
DCDC CONVERTER 24/24
Idavägen 11 SE-352 46 |[phone] |[e-mail]
TABLE OF CONTENT
CRITICAL INFORMATION ................................................................................................................................................... 1
USER MANUAL .................................................................................................................................................................. 3
General.......................................................................................................................................................................... 3
Installation .................................................................................................................................................................... 3
STANDARDS....................................................................................................................................................................... 3
TECHNICAL SPECIFIKATION ............................................................................................................................................... 4
INCLUDED IN THE PACKAGE.............................................................................................................................................. 4
WARRANTY........................................................................................................................................................................ 5
Warranty claim.............................................................................................................................................................. 5

3
DCDC CONVERTER 24/24
Idavägen 11 SE-352 46 |[phone] |[e-mail]
USER MANUAL
•Read this instruction before the DC/DC is taken into use.
•Keep this manual within easy reach for the user of this DC/DC converter.
General
This product from Primepower is a high efficient, intelligent and very compact DC/DC charger with the latest switch
mode technology in power conversion. Suitable for all DC applications where a secured and stable 27,2 VDC voltage
is needed. The internal electronics controls input and output current and is both overload and short circuit
protected.
All electronics are potted with polyurethane which makes the unit completely waterproof and very shock resistant.
The unit has no LED indications on the outside of the unit for black-out purpose as well as no ON/OFF function
button. An external LED can be connected for Power ON indication.
As the unit acts like a stable power supply, the voltage will always be stable at 27,2V as long as the input voltage is
between 18-32VDC and the unit will always be able to provide the specified current.
Installation
Check that the correct input voltage range and output voltage range matches the installation and the parameters
mentioned on the DC/DC. The DC/DC enclosure is IP67, the internal electronics has a protective layer of lacquer. This
brings the DC/DC suitable for indoor mounting, outdoor mounting in vehicles, in boats or built into the current
machine.
DC-in & out connection according to VG95234.
STANDARDS
•MIL-STD 461 F, Army ground applications
•MIL-STD 1275D
•Vibration/shock according to IEC 60028-2-6
•Humidity IEC 68-2-30 100% non-condensing

4
DCDC CONVERTER 24/24
Idavägen 11 SE-352 46 |[phone] |[e-mail]
TECHNICAL SPECIFIKATION
MODELL
MIL DC/DC 24-24V 60A
MIL DC/DC 24-24V 40A
Article number
0060392
0060391
Input voltage
18-32 VDC
18-32 VDC
Output voltage
27,2 VDC
27,2 VDC
Output current
60A
40A
Ambient temperature
-46Co–+55Co
-46Co–+55Co
Efficiency
>95%
>95%
DC-in connection
Glenair CA3102E
Glenair CA3102E
DC-out connection
Glenair CA3102E
Glenair CA3102E
Encapsulation
IP67
IP67
Measurments (W x L x H)
160 x 144 x 101 mm
160 x 144 x 101 mm
Weight
2,5 Kg
2,3 Kg
INCLUDED IN THE PACKAGE
PRIMEPOWER DCDC MANUAL
PRIMEPOWER DCDC converter

5
DCDC CONVERTER 24/24
Idavägen 11 SE-352 46 |[phone] |[e-mail]
WARRANTY
Primepower warranty applies only to original purchaser within a period of 24 months from the date from
delivery.
Primepower guarantees that the product is in excellent condition upon delivery, unless comes full refund.
If the user has not conducted a proper installation or used the product incorrectly applies no warranty.
Warranty claim
To take advantage of warranty please contact your retailer.
Please have following information available:
Receipt
Model number
Product serial number
A brief description of the malfunction
WARNING!
Do not use this product without reading the entire manual! Incorrectly installed or use of the product
can sincerely damage the user, destroy the product or connected equipment. If the product is used the
wrong way, warranty may be void.
