1 Introduction
Prime 911A4G is a rescue device with voice function.It works on LTE B2 / B4 / B12
network with superior receiving sensitivity. Based onthe embedded wireless tracking
protocol, Prime 911A4G can communicate with the backend server through LTE network,
and transfer emergency reports.
2 Product Overview
2.1 Appearance
Figure 1-1
2.2 Buttons Description
Button /12PIN Interface Description
KEY/interface Description
Energy query
Key
Query How much energy left.
SOS Key Press this key to dial a phone number through LTE network
Reset Key Press this key to shut down the device in abnormal condition

4
2.3 LED Description
To be added
Figure 1-2
There are 2LED lights in Prime 911A4G device, the description as
following.
Light Event State
Red LED Power on Steady light
charging Slow flash
Blue LED Power on Steady light
Network indicate Slow flash
3 Getting Started
3.1 Parts List
Name Picture Remark
Rescue device

5
charging Dock charging for the device
3.2 Battery Charging
The following items are suggestion for battery charge, please pay more attention.
The red LED of charging Dock will be steady light no matter rescue device is charging
or not.
Charging will last about 3 hours.
Note: If the Rescue device is firstly used, please make sure the battery is fully charged,
which will make the life of battery much longer.
3.3 Charging Dock
Charging Dock is a base with an AC Adapter.
The charging dock is used for device charging , which can be used for charging at any
time ( by end user)..
Figure 2-2

6
3.4 Power on/Power off
Figure 2-2
Power on:
Press the SOS key at least 3 seconds and release it to power on rescue device.
Power off:
Rescue device is auto power off and user can’t turn off the machine by itself.
4 Frequency
LTE:Band2、Band4、Band12
WIFI:2.4GHz
4.1 WIFI
The device role of WIFI could be Master and Slave.
When the device role is Master, the device will provide below services: the others devices
can read or use the above services after connecting devices, connect the designated
device to read the data or related information of the designated WIFI devices. After
reading the data, the server can be reported to the server by the corresponding message.

7
5 Trouble shooting and Safety info
5.1 Trouble shooting
5.2 Safety info
The following items are suggestion for safety use, please pay more attention.
Please do not disassemble the device by yourself.
Please do not put the device on the overheating or too humid place, avoid exposure
to direct sunlight. Too high temperature will damage the device or even cause the
battery explosion.
Please do not use the device on the airplane or near medical equipment.
Trouble Possible Reason Solution
Messages can’t be
reported to the
backend server by
Mobile network.
APN is wrong. Some
APN can not visit the
internet directly.
Ask the network operator for the right
APN.
The IP address or port of
the backend server is
wrong.
Make sure the IP address for the
backend server is an identified address
in the internet.
Unable to power off
ATW.
The function of power key
was disabled by
AT+GTFKS.
Enable the function of power key by
AT+GTFKS.
Battery can not be
charged
The battery has not been
used for too long time and
has been locked.
Using a external power source with 3.6V
to 4.2V DC power supply to active the
battery or apply for after sale help.
ATW can’t fix GPS
successfully.
The GPS signal is weak. Please move ATW to a place with open
sky.
It is better to let the top surface face to
the sky. (The same surface with
indication LED)

8
