Prince Hanger PHUS-0062 User manual

1 2
IMPORTANT- Read Before Assembly COMPLETE PARTS LIST
Please follow these safety precautions in order to ensure proper installation
and to prevent any bodily injuries and structural failures.
Please note that this unit includes poles and rods that are made out of steel, which can
cause bodily injuries and/or damages to the oor if dropped or held in an improper
manner during assembly. Example
Assemble the xtures (shelf brackets, rod brackets, etc.)
at least 4 in. away from the ceiling mount for
rm support.
Ceiling
4 inch
1. This unit is designed for use by keeping the poles
xed to the oor and the ceiling. Therefore, it is not
safe for children to climb or hang on the unit.
Children should be under adult supervision at all
times to prevent any injuries.
2. Overloading the unit might cause it to become
unstable and either tip or collapse, which may cause
serious bodily injury and/or damage to personal
possessions.
3. In order to prevent any accidental collapses due to improper care, install the unit,
so that it is slightly tilted towards the wall, not perpendicular to the oor.
4. We recommend that you frequently examine the unit for any loose bolts or wobbling.
5. The curtains should be hand washed. They are not machine-washable.
Please note
The unit may collapse if it is not securely xed to the oor or if it is installed to a weak
part of the ceiling.
Dierentiating Between the Poles
The upper poles are thinner than the lower poles.
(Make sure the upper poles attach to the ceiling mount and lower poles to the oor
mount during installation.)
Before
Assembly
Lowering the pole by loosening the set
screw without holding onto the pole
may be dangerous. Please hold the upper
pole with one hand and loosen the set
screw with the other when lowering the
pole.
Before installing the pole, tighten the set screw to the manual
fastening device a couple of times. (Note: Installing the pole with
the set screw too tight can damage the pole.)
Push the upper pole to the ceiling to set it upright and fasten it
by tightening the set screw completely.
(If the screw bolt is not tightened carefully, it can damage the
screw and aect its abilities to fasten the device.
Before tightening the set screw After tightening the set screw a couple of times
Set Screw
Manual
Fastening
Device
Upper Pole
Lower
Pole
Set Screw
Before Disassembly
Product Components *Check your inventory before beginning installation.
Safety Bolt (Located behind the shelf bracket)
Tighten gently by hand after installing the rods
Ceiling Mounts (2)
Upper & Lower Poles
(2 Sets)
Upper Pole
(1.1 in.)
Lower Pole
(1.26 in.)
Manual Fastening Device
Floor Mounts (2)
Curtain Rod Brackets (2)
Curtain Rods (1)
Wedges (2)-1.1/1.26 in.
Tie Bolts (2)
(Left-1) (Right-1)
Free Gift
Hanger Retriever (1)
Hanger Rods (2)
Rod Brackets (4)
Rubber Rings (4)
Set Screws (2)
Curtain (1)

3 4
ASSEMBLY INSTRUCTIONS (POLE) INSTALLATION (POLE)
Pole 2Pole 1
Extend the upper pole about
20 in. before assembling the
parts in order, as shown in the
diagram.
Extend the upper pole about
20 in. before assembling the
parts in order, as shown in the
diagram.
Rod Bracket
Used to support rods.
Please assemble the
bracket so that it is
U-shaped.
.79 in. ~1.18 in.
To Install the Poles,
Wall
Explanation
At the desired location, hold the lower pole with one hand and the upper pole with
the other and push it up to the ceiling so that the pole is xed upright to both the
ceiling and the oor. (Make sure the pole is xed securely on the ceiling by pushing
the pole up as far as you can (which can extend up to 1 1/6 in. due to the spring
mechanism in the ceiling mount)
After installing the pole, tighten the safety bolt behind the one-touch fastening
device by hand for safer use of the unit.
Install the unit, so that it
is slightly tilted towards
the wall, not strictly
perpendicular to the
oor.
Ceiling
Floor
Assemble the parts to the upper and lower poles in order, as shown in the diagram.
Upper Pole
(Thinner Pole)
Lower Pole
(Thicker Pole)
Upper Pole
(Thinner Pole)
Lower Pole
(Thicker Pole)
Ceiling Mount
Rod Bracket
Rubber Ring
Rod Bracket
Rubber Ring
Ceiling Mount
Rod Bracket
Rubber Ring
Rod Bracket
Rubber Ring
Manual Fastening Device Manual Fastening Device
Floor Mount Floor Mount
The rubber ring helps keep the xtures in place and should be inserted underneath all of the xtures.
(The rubber rings inserted underneath the xtures are not visible after installation.)
The pole extends about
3/4 in. to 1 1/6 in. due to
the spring.
Safety Bolt
(Tighten gently by hand.)
Install the poles after the
lower pole is securely
attached to the oor mount.
Upper PoleLower Pole
Attach the curtain rod bracket
after installing the pole. Refer
to Page 6 for more information.
Attach the curtain rod bracket
after installing the pole. Refer
to Page 6 for more information.

5 6
INSTALLATION (CURTAINS)
INSTALLATION (POLE & OTHER FIXTURES)
To install poles and other xtures,
Set the poles upright and distance them apart to the desired width of the unit.
After keeping the rod brackets level, t the rods into the rod bracket as shown
in the diagram.
Adjust the height of the rod brackets to the desired height using rubber rings
and then gently tighten the safety bolt in the back by hand.
1
2
3
*Refer to Page 6 for instructions on how to hang curtains.
Insert the hanger rod into
the rod bracket.
Adjust the height of the
rod bracket and then
tighten the safety bolt to
keep it xed.
Safety Bolt
Rod
Rod Brackets
*Product Dimensions:
Width: 47in.
Height: 67 in.~ 99.6in.
Depth : 13.8 in.
After mounting the
curtain rod onto the
rod bracket, tighten
the safety bolt.
Curtain Rod Bracket
Identify the curtain
rings on the top
edge of the curtain.
Thread the curtain
rings through the
curtain rod and put
the rod into the
brackets.
Curtain Ring
Arrange curtains evenly.
Keeping the curtain rod brackets level, attach them to the
upper poles. Tighten the tie bolt on the other side of the
nut. (The nut is only on one side of the bracket.)
Left
Left Right
Hanger Rod Rod Bracket
Manual Fastening Device
Pole 2
Pole 1
39.3 in.
To Hang Curtains
*Important: Please insert the wedge.
Wedge
curtain rod bracket
*Tighten the tie bolt on the other side of the nut.
Left Side: With the Nut Right Side: Without the Nut
Make sure both safety bolts are facing the ground.
Installing Curtain Rod Brackets (1)
Installing Curtain Rod Brackets (2) Finished Product
Curtain rod
Safety Bolt
Curtain Rod
