Principal LED STREET WRAP Configuration guide

CUTTING AND CONNECTION
Installation Tools
1. Silicone Insert
2. Silicone End Cap
3. Silicone Glue
4. Pipe Cutter
Instructions for Cutting and Connection
1. Cut on the designated cut mark. 2. Clean cut end before next steps.
3. Install silicone insert after cut. 4. Apply silicone glue to silicone end
cap, making sure that the cut section
is completely sealed.
STREET WRAP™ FLEX SIDE-BEND
INSTALL INSTRUCTIONS

REV20200212
Mounting Accessories
Install Instructions
1. 8 ft. aluminum extrusion
2. 2” Aluminum Clip
3. Clear Clip
Notes: There are no pre-drilled holes in the aluminum extrusion, please drill holes accordingly to meet eld
requirements, using the appropriate screw.
Installation and Warning
Lighting Surface
Side-Bend only bends as shown above.
For specs visit: P-LED.com/product/families/street-wrap-ex
Do not twist or bend sharper than 90º.
STREET WRAP™ FLEX SIDE-BEND
INSTALL INSTRUCTIONS
