Pro-Form 1800 Interactive Trainer Treadmill User manual

Serial Number Decal
Model No. DTL21140
Serial No.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
QUESTIONS?
If you have questions, or if there
are missing or damaged parts,
we will guarantee complete sat-
isfaction through direct assis-
tance from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
Customer Hot Line will provide
immediate assistance, free of
charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!

TABLE OF CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
OPERATION AND ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
HOW TO FOLD AND MOVE THE TREADMILL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
CONDITIONING GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
PART IDENTIFICATION CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
Note: An EXPLODED DRAWING is attached in the center of this manual.
1. It is the responsibility of the owner to ensure
that all users of this treadmill are adequately
informed of all warnings and precautions.
2. Use the treadmill only as described.
3. Place the treadmill on a level surface, with at
least eight feet of clearance behind it and two
feet on each side. Do not place the treadmill
on any surface that blocks air openings. To
protect the floor or carpet from damage, place
a mat under the treadmill.
4. Keep the treadmill indoors, away from mois-
ture and dust. Do not put the treadmill in a
garage or covered patio, or near water.
5. Do not operate the treadmill where aerosol
products are used or where oxygen is being
administered.
6. Keep children under the age of 12 and pets
away from the treadmill at all times.
7. The treadmill should be used only by persons
weighing 300 pounds or less.
8. Never allow more than one person on the
treadmill at a time.
9. Wear appropriate exercise clothes when
using the treadmill. Do not wear loose clothes
that could become caught in the treadmill.
Athletic support clothes are recommended for
both men and women. Always wear athletic
shoes. Never use the treadmill with bare feet,
wearing only stockings, or in sandals.
10. When connecting the power cord (see page 8),
plug the power cord into a surge suppressor
(not included) and plug the surge suppressor
into a grounded circuit capable of carrying 15
or more amps. No other appliance should be on
the same circuit. Do not use an extension cord.
11. Use only a single-outlet surge suppressor that
meets all of the specifications described on
page 8. To purchase a surge suppressor, see
your local PROFORM dealer or call 1-800-806-
3651 and order part number 146148.
12. Failure to use a properly functioning surge
suppressor could result in damage to the con-
trol system of the treadmill. If the control sys-
tem is damaged, the walking belt may change
speed or stop unexpectedly, which may result
in a fall and serious injury.
13. Keep the power cord and the surge suppres-
sor away from heated surfaces.
14. Never move the walking belt while the power
is turned off. Do not operate the treadmill if
the power cord or plug is damaged, or if the
treadmill is not working properly. (See BE-
FORE YOU BEGIN on page 4 if the treadmill is
not working properly.)
WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the
following important precautions and information before operating the treadmill.
IMPORTANT PRECAUTIONS
2

The decals shown have been placed on your treadmill. If a
decal is missing, or if it is not legible, please call our
Customer Service Department, toll-free, to order a free re-
placement decal (see the front cover of this manual). Apply
the decal in the location shown. Note: The decals are not
shown at actual size.
15. Never start the treadmill while you are stand-
ing on the walking belt. Always hold the
handrails while using the treadmill.
16. The treadmill is capable of high speeds.
Adjust the speed in small increments to
avoid sudden jumps in speed.
17. Never leave the treadmill unattended while it
is running. Always remove the key, unplug
the power cord and move the reset/off circuit
breaker to the off position when the treadmill
is not in use. (See the drawing on page 4 for
the location of the circuit breaker.)
18. Do not attempt to raise, lower, or move the
treadmill until it is properly assembled. (See
ASSEMBLY on page 5, and HOW TO FOLD
AND MOVE THE TREADMILL on page 21.)
You must be able to safely lift 45 pounds (20
kg) to raise, lower, or move the treadmill.
19. When folding or moving the treadmill, make
sure that the storage latch is fully closed.
20. When using iFIT.com CDs and videos, an
electronic “chirping” sound will alert you
when the speed of the treadmill is about to
change. Always listen for the “chirp” and be
prepared for speed changes. In some in-
stances, the speed may change before the
personal trainer describes the change.
21. When using iFIT.com CDs and videos, you
can manually override the speed setting at
any time by pressing the speed buttons.
However, when the next “chirp” is heard, the
speed will change to the next setting for the
CD or video program.
22. Remove iFIT.com CDs and videos from your
CD player or VCR when you are not using
them.
23. Inspect and properly tighten all parts of the
treadmill regularly.
24. Never insert any object into any opening.
25. DANGER: Always unplug the power
cord immediately after use, before cleaning the
treadmill, and before performing the mainte-
nance and adjustment procedures described in
this manual. Never remove the motor hood un-
less instructed to do so by an authorized ser-
vice representative. Servicing other than the
procedures in this manual should be performed
by an authorized service representative only.
26. This treadmill is intended for in-home use
only. Do not use this treadmill in a commer-
cial, rental, or institutional setting.
SAVE THESE INSTRUCTIONS
WARNING: Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
3

Thank you for selecting the revolutionary PROFORM®
1800 treadmill. The PROFORM 1800 treadmill com-
bines advanced technology with innovative design to
help you get the most from your exercise program in
the convenience and privacy of your home. And when
you’re not exercising, the unique PROFORM 1800
treadmill can be folded up, requiring less than half the
floor space of other treadmills.
For your benefit, read this manual carefully before
using the treadmill. If you have questions after read-
ing this manual, please call our Customer Service
Department toll-free at 1-800-999-3756, Monday
through Friday, 6 a.m. until 6 p.m. Mountain Time (ex-
cluding holidays). To help us assist you, please note
the product model number and serial number before
calling. The model number of the treadmill is
DTL21140. The serial number can be found on a decal
attached to the treadmill (see the front cover of this
manual for the location).
Before reading further, please review the drawing
below and familiarize yourself with the labeled parts.
BEFORE YOU BEGIN
4
Handrail
Upright
Storage Latch
Accessory Tray
Fan
Key/Clip
Reset/Off
Circuit Breaker
Walking Belt
Cushioned Walking Platform
for maximum exercise comfort
Foot Rail
Power Cord
RIGHT SIDE
Rear Roller
Adjustment Bolts
Console
CD Player
CD Holder
BACK

ASSEMBLY
Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not
dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is
coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the
top of the walking belt or the shipping carton. This is a normal condition and does not affect treadmill perfor-
mance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild,
non-abrasive cleaner.
Assembly requires the included allen wrenches and your own phillips screwdriver
and wire cutters .
1. Make sure that the power cord is unplugged.
To identify small parts, use the PART IDENTIFICA-
TION CHART on page 27.
With the help of a second person, carefully raise the
Upright Base (97) to the position shown. Insert one of
the Extension Legs (92) into the Upright Base. (Note: It
may be helpful to tip the Upright Base forward as you in-
sert the Extension Leg.) Make sure that the Warning
Decal (91) is in the indicated location.
Insert the other Extension Leg (not shown) in the same
way.
5
2. With the help of a second person, carefully tip the
Upright Base (97) down as shown. (Note: It may be help-
ful to place your foot on one of the Extension Legs [92]
as you tip the Uprights.) Make sure that the Extension
Legs remain in the Uprights.
Attach each Extension Leg (92) with two Extension Leg
Bolts (96) and two 1/4” Washers (39) as shown. Thread
a Leveling Foot (95) into each side of the Upright Base
(97); do not thread the Leveling Feet fully into the
Upright Base.
Attach the two Base Pads (99) to the Upright Base (97)
in the locations shown with two 1” Tek Screws (40).
With the help of a second person, raise the Upright Base
(97) to the vertical position.
96
40
40
99
99
39
96
92
95
95
96
92
96
97
39
39
97
2
92
97
91
1

5. Set the Console Base (101) on the Uprights (80, 84). Be
careful not to pinch the Wires (not shown) in the
Uprights. Attach the Console Base to each Upright with
two Console Bolts (76) and two Internal Star Washers
(77); start all four Console Bolts before tightening any of
them.
Make sure that the Left and Right Trays (109, 111) are
pressed into the Console Base (101).
76 77
101
76
77
111 109
80
84
5
6
77
3. Attach the Latch Assembly (82) to the Left Upright (84)
with the two Latch Screws (56). Start both Latch Screws
before tightening either of them. Note: The Latch Screws
may be preattached to the Left Upright.
56
84
82
3
4. See step 6 and locate the four Upright Bolts (86). Loosen
the Upright Bolts two to three turns.
See drawing 4c. With the help of a second person, hold
the Console Base (101) near the Uprights (80, 84). Look
under the Console Base and locate the wires on the
sides of the Console Base. Make sure that the wires are
not routed through the openings for the Trays (109,
111). Drawing 4a shows the correct route for the wires;
drawing 4b shows an incorrect route.
See drawing 4c. Cut the plastic ties holding the Wire
Harness (74) and the pulse wire in the Uprights (80, 84).
Connect the Wire Harness and the pulse wire to the
wires on the sides of the Console Base (101). Make sure
to connect the connectors properly (see the inset
drawings). IF THE CONNECTORS ARE NOT CON-
NECTED PROPERLY, THE CONSOLE MAY BE DAM-
AGED WHEN THE POWER IS TURNED ON. The con-
nectors should slide together easily and snap into
place. If the connectors do not slide together easily and
snap into place, turn one connector and try again. Insert
the excess Wire Harness and pulse wire up into the
Console Base.
Press the Right and Left Top Endcaps (75, 81) into the
Uprights (80, 84) as shown.
101
111 109
80
75 81
84
4a 4b
4c
Correct Incorrect
Pulse
Wire
74

If you purchase the optional chest pulse sensor (see
page 20), follow the steps below to install the receiver
included with the chest pulse sensor.
1. Make sure that the power cord is unplugged. Remove
the indicated Screw (108) and the Access Door (122).
2. Remove the paper from the adhesive pad on the back of
the receiver (A). Hold the receiver so the small cylin-
der is near the lower edge of the receiver and facing
the Console (107) as shown. Firmly press the receiver
onto the indicated corner of the Access Door (122).
Connect the wire on the receiver to the indicated wire ex-
tending from the Console.
3. Make sure that no wires are pinched. Reattach the
Access Door (122) with the Screw (108). Note: The wires
included with the receiver may be discarded.
8. Make sure that all parts are properly tightened before you use the treadmill. Note: Extra hardware may
be included. Keep the included allen wrenches in a secure place. The large allen wrench is used to adjust the
walking belt (see page 23). To protect the floor or carpet, place a mat under the treadmill.
85
80
84
85
6. Press a CD Holder (85) into each side of the Upright Base
(97).
If the Wheels (not shown) are touching the floor, or if the
treadmill rocks slightly, see HOW TO LEVEL THE
TREADMILL on page 20.
If you wish to adjust the height of the Uprights (80,
84), go to step 7. If the Uprights are at the desired
height, tighten the four Upright Bolts (86) and go to step 8.
7. Note: The Uprights (80, 84) can be attached at three dif-
ferent heights. The Uprights are preattached in the mid-
dle position. Adjusting the Uprights requires two persons.
While a second person holds the Console Base (101) and
the Uprights (80, 84), loosen the four Upright Bolts (86).
Then, remove the two Upright Bolts and Upright Star
Washers (127) from the Right Upright (80). Raise or lower
the Right Upright to the desired height, being careful not
to damage the Wire Harness (74). If the Upright Spacer
(79) falls, press it back onto the Upright Base (97).
Loosely thread the two Upright Bolts and Upright Star
Washers back into the Right Upright and the Upright Base.
Adjust the Left Upright (84) in the same way. (Note:
There are no wires in the Left Upright.) Make sure that
both Uprights are at the same height. Lift the
Walking Platform (13) and make sure it is centered
between the Uprights. Retighten all four Upright Bolts
(86).
79
101
86
13
127
86
127
74
80
84
97
97
86
86
7
A
107
122 Cylinder
108
7
79
97
6
Wire
Wire

8
OPERATION AND ADJUSTMENT
THE PERFORMANT LUBETM WALKING BELT
Your treadmill features a walking belt coated with
PERFORMANT LUBETM, a high-performance lubricant.
IMPORTANT: Never apply silicone spray or other
substances to the walking belt or the walking plat-
form. Such substances will deteriorate the walking
belt and cause excessive wear.
HOW TO PLUG IN THE POWER CORD
Your treadmill, like any other type of sophisticated
electronic equipment, can be seriously damaged by
sudden voltage changes in your home’s power.
Voltage surges, spikes, and noise interference can
result from weather conditions or from other appliances
being turned on or off. To decrease the possibility of
your treadmill being damaged, always use a surge
suppressor with your treadmill (see drawing 1 at
the right). To purchase a surge suppressor, see
your local PROFORM dealer or call 1-800-806-3651
and order part number 146148.
Use only a single-outlet surge suppressor that is
UL 1449 listed as a transient voltage surge sup-
pressor (TVSS). The surge suppressor must have a
UL suppressed voltage rating of 400 volts or less
and a minimum surge dissipation of 450 joules.
The surge suppressor must be electrically rated
for 120 volts AC and 15 amps. There must be a
monitoring light on the surge suppressor to indi-
cate whether it is functioning properly. Failure to
use a properly functioning surge suppressor could
result in damage to the control system of the
treadmill. If the control system is damaged, the
walking belt may change speed or stop unexpect-
edly, which may result in a fall and serious injury.
This product must be grounded. If it should malfunc-
tion or break down, grounding provides a path of least
resistance for electric current to reduce the risk of elec-
tric shock. This product is equipped with a cord having
an equipment-grounding conductor and a grounding
plug. Plug the power cord into a surge suppressor,
and plug the surge suppressor into an appropriate
outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
Important: The treadmill is not compatible with
GFCI-equipped outlets.
This product is for use on a nominal 120-volt circuit,
and has a grounding plug that looks like the plug illus-
trated in drawing 1 below. A temporary adapter that
looks like the adapter illustrated in drawing 2 may be
used to connect the surge suppressor to a 2-pole
receptacle as shown in drawing 2 if a properly
grounded outlet is not available.
The temporary adapter should be used only until a
properly grounded outlet (drawing 1) can be installed
by a qualified electrician.
The green-colored rigid ear, lug, or the like extending
from the adapter must be connected to a permanent
ground such as a properly grounded outlet box cover.
Whenever the adapter is used it must be held in place
by a metal screw. Some 2-pole receptacle outlet box
covers are not grounded. Contact a qualified elec-
trician to determine if the outlet box cover is
grounded before using an adapter.
DANGER: Improper connection
of the equipment-grounding conductor can
result in an increased risk of electric shock.
Check with a qualified electrician or service-
man if you are in doubt as to whether the
product is properly grounded. Do not modify
the plug provided with the product—if it will
not fit the outlet, have a proper outlet
installed by a qualified electrician.
1
2
Grounded Outlet Box
Grounded Outlet Box
Grounding Plug
Surge Suppressor
Surge Suppressor
Grounding Pin
Adapter
Lug
Metal Screw
Grounded Outlet
Grounding Pin

9
FEATURES OF THE CONSOLE
The treadmill console offers an impressive array of
features that help you get the most from your workouts.
When the manual mode of the console is selected, the
speed and incline of the treadmill can be changed with
a touch of a button. As you exercise, the console will
display instant exercise feedback. You can even mea-
sure your heart rate using the handgrip pulse sensor or
the optional chest pulse sensor (see page 20).
In addition, the console offers six preset workout pro-
grams. Each program automatically controls the speed
and incline of the treadmill as it guides you through an
effective workout. Two pulse programs are also offered.
Each program automatically adjusts the speed and in-
cline of the treadmill to keep your heart rate within a tar-
get range while you exercise.
The console also features iFIT.com interactive technol-
ogy. Having iFIT.com technology is like having a per-
sonal trainer in your home. Using the built-in CD player,
you can play special iFIT.com CD programs. IFIT.com
CD programs automatically control the speed and in-
cline of the treadmill as a personal trainer guides you
through every step of your workout. High-energy music
provides added motivation. To purchase iFIT.com
CDs, call toll-free 1-800-735-0768.
Using the included audio cable, you can also connect
the treadmill to your VCR and TV and play iFIT.com
video programs. iFIT.com video programs offer the
same benefits as iFIT.com CD programs, and allow
you to enjoy breathtaking scenery while you exercise.
To purchase iFIT.com videocassettes, call toll-free
1-800-735-0768.
You can also connect the treadmill to your home com-
puter, go to our Web site at www.iFIT.com, and access
programs directly from our Web site. Visit
www.iFIT.com for more information.
To use the manual mode of the console, follow the
steps beginning on page 10. To use preset programs,
see page 12. To use heart rate programs, see page
13. To use iFIT.com CD programs, see page 15. To
use iFIT.com video programs, see page 18. To use
iFIT.com programs directly from our Web site, see
page 19.
Note: If there are thin sheets of clear
plastic on the console, remove them.
Clip
Key

10
HOW TO TURN ON THE POWER
Plug in the power cord (see page 8).
Locate the reset/off
circuit breaker near
the power cord. Make
sure that the circuit
breaker is in the reset
position.
Stand on the foot rails of the treadmill. Find the clip
attached to the key (see the drawing on page 9)
and slide the clip onto the waistband of your
clothes. Next, route the cord attached to the clip
under the handgrip pulse sensor, and insert the
key into the console. After a moment, the displays
and various indicators will light. Test the clip by
carefully taking a few steps backward until the
key is pulled from the console. If the key is not
pulled from the console, adjust the position of
the clip.
HOW TO USE THE MANUAL MODE
Insert the key fully into the console.
See HOW TO TURN ON THE POWER above.
Select the manual mode.
When the key is in-
serted, the manual
mode will be selected.
To reselect the manual
mode, press the
Program Select button
repeatedly until a track
appears in the matrix. Make sure that the indicator
on the iFIT.com button is not lit.
Start the walking belt.
To start the walking belt, press the Start button,
the Speed increase button, or one of the twelve
Quick Start buttons.
If the Start button or the
Speed increase button
is pressed, the walking
belt will begin to move
at 1 mph. As you exer-
cise, change the speed
of the walking belt as desired by pressing the
Speed increase and decrease buttons. Each time
a button is pressed, the speed setting will change
by 0.1 mph; if a button is held down, the speed
setting will change in increments of 0.5 mph.
If one of the Quick Start buttons is pressed, the
walking belt will gradually increase in speed until it
reaches the selected speed setting. Note: The
console can display speed and distance in ei-
ther miles or kilometers. For simplicity, all in-
structions in this section refer to miles.
To stop the walking belt, press the Stop button.
The Time/Pace display will begin to flash. To
restart the walking belt, press the Start button, the
Speed increase button, or one of the twelve Quick
Start buttons.
Note: The first time the treadmill is used, observe
the alignment of the walking belt, and align the
walking belt if necessary (see page 23).
Change the incline of the treadmill as desired.
To change the incline of
the treadmill, press the
Incline decrease and in-
crease buttons. Each
time a button is pressed,
the incline will change by
0.5%. To change the incline setting quickly, press
the Quick Incline buttons.
Follow your progress with the matrix and the
displays.
The matrix—When the
manual mode or the
iFIT.com mode is se-
lected, the matrix will
display a 1/4-mile track.
As you exercise, the in-
dicators around the track
will light, one at a time, until the entire track is lit.
The track will then darken and begin to light again.
Speed display—This
display shows the speed
of the walking belt. Note:
When the KM/H indica-
tor is lit, the console will
display speed and dis-
tance in kilometers; when the KM/H indicator is
not lit, the console will display speed and distance
in miles.
5
4
3
2
1
3
2
1
Reset
Position

11
To change the unit of
measurement, first hold
down the Stop button
while inserting the key
into the console. An “E”
for English miles or an
“M” for metric kilometers will appear in the Speed
display. Press the Speed increase button to
change the unit of measurement. When the de-
sired unit of measurement is selected, remove the
key.
Calories/Pulse
display—This display
shows the approximate
numbers of calories and
fat calories you have
burned (see FAT BURN-
ING on page 24). The
display will change from one number to the other
every few seconds. The display will also show
your heart rate when you use the handgrip pulse
sensor or the optional chest pulse sensor.
Distance/Incline dis-
play—This display
shows the distance that
you have walked or run
and the incline level of
the treadmill. The display
will change from one number to the other every
few seconds. Note: Each time the incline changes,
the display will show the incline setting for several
seconds.
Time/Pace display—
When the manual mode
or the iFIT.com mode is
selected, this display will
show the elapsed time
and your current pace
(pace is measured in minutes per mile). The dis-
play will change from one number to the other
every few seconds. When a preset program or a
heart rate program is selected, the display will
show the time remaining in the program rather
than the elapsed time.
To reset the displays, press the Stop button, re-
move the key, and then reinsert the key.
Measure your heart rate if desired.
You can measure your heart rate using either the
handgrip pulse sensor or the optional chest pulse
sensor.
To use the hand-
grip pulse sen-
sor, first make
sure that your
hands are clean.
Next, stand on
the foot rails
and place your
hands on the
metal contacts on the handgrip pulse sensor. Your
palms should be resting on the upper contacts
and your fingers should be touching the lower
contacts. Avoid moving your hands. When your
pulse is detected, two dashes (– –) will appear in
the Calories/Pulse display, and then your heart
rate will be shown. For the most accurate heart
rate reading, continue to hold the contacts for
about 15 seconds.
Turn on the fan if desired.
To turn on the fan, press the button below the fan.
To turn on the fan at high speed, press the button
a second time. To turn off the fan, press the but-
ton a third time. Note: A few minutes after the
walking belt is stopped, the fan will automatically
turn off.
When you are finished exercising, remove the
key from the console.
Step onto the foot rails, press the Stop button, and
adjust the incline of the treadmill to the lowest
setting. The incline must be at the lowest setting
when the treadmill is folded to the storage posi-
tion or the treadmill will be damaged. Next, re-
move the key from the console and put it in a se-
cure place. Note: If the displays and various indi-
cators on the console remain lit after the key is
removed, the console is in the “demo” mode.
See page 20 and turn off the demo mode.
When you are finished using the treadmill, move
the reset/off circuit breaker switch near the power
cord to the off position and unplug the power cord.
8
7
6
Contacts

12
HOW TO USE PRESET PROGRAMS
Insert the key fully into the console.
See HOW TO TURN ON THE POWER on page
10.
Select one of the preset programs.
When the key
is inserted,
the manual
mode will be
selected. To
select a pre-
set program,
press the Program Select button repeatedly until
one of the six preset program indicators lights.
When a preset program is selected, the Speed
display will flash the maximum speed setting of
the program, and the Distance/Incline display will
flash the maximum incline setting, for six seconds.
The Time/Pace display will show how long the
program will last.
The matrix will show
the first seven speed
settings of the program.
Note: The profiles
below the matrix show
how the speed and in-
cline of the treadmill
will change during the programs.
Press the Start button or the Speed increase
button to start the program.
A moment after the button is pressed, the tread-
mill will automatically adjust to the first speed and
incline settings of the program. Hold the handrails
and begin walking.
Each program is divided into several time seg-
ments of different lengths. One speed setting and
one incline setting are programmed for each seg-
ment. Note: The same speed setting and/or in-
cline setting may be programmed for consecutive
segments.
The speed setting for the
first segment is shown in
the flashing Current
Segment column of the
matrix. (The incline set-
tings are not shown in
the matrix.) The speed
settings for the next
seven segments are
shown in the seven columns to the right.
When only three seconds remain in the first seg-
ment of the program, both the Current Segment
column and the column to the right will flash and a
series of tones will sound. In addition, if the speed
and/or incline of the treadmill is about to change,
the Speed display and/or the Distance/Incline dis-
play will flash to alert you. When the first segment
is completed, all speed settings will move one col-
umn to the left. The speed setting for the second
segment will then be shown in the flashing Current
Segment column and the treadmill will automati-
cally adjust to the speed and incline settings for
the second segment. Note: If all of the indicators in
the Current Segment column are lit after the speed
settings have moved to the left, the speed settings
will move downward so that only the highest indi-
cators appear in the matrix. If some of the indica-
tors in the Current Segment column are not lit
when the speed settings move to the left again, the
speed settings will move back up.
The program will continue in this way until the
speed setting for the last segment is shown in the
Current Segment column of the matrix and the
Time/Pace display counts down to zero. The walk-
ing belt will then slow to a stop.
If the speed or incline setting is too high or too low
at any time during the program, you can manually
override the setting by pressing the Speed or
Incline buttons. Every few times a Speed button is
pressed, an additional indicator will light or darken
in the Current Segment column. (If any of the
columns to the right of the Current Segment col-
umn have the same number of lit indicators as the
Current Segment column, an additional indicator
may light or darken in those columns as well.)
Note: When the next segment of the program
begins, the treadmill will automatically adjust
to the speed and incline settings for the next
segment.
3
2
1
Current Segment

13
To stop the program temporarily, press the Stop
button. The Time/Pace display will begin to flash.
To restart the program, press the Start button or
the Speed increase button. To end the program,
press the Stop button, remove the key, and then
reinsert the key.
Follow your progress with the displays.
See step 5 on page 10.
Measure your heart rate if desired.
See step 6 on page 11.
Turn on the fan if desired.
See step 7 on page 11.
When the program is finished, remove the key
from the console.
When the program has ended, make sure that
the incline of the treadmill is at the lowest set-
ting. Next, remove the key from the console and
put it in a safe place. Note: If the displays and
various indicators on the console remain lit
after the key is removed, the console is in the
“demo” mode. See page 20 and turn off the
demo mode.
When you are finished using the treadmill, move
the reset/off circuit breaker switch near the power
cord to the off position and unplug the power cord.
HOW TO USE HEART RATE PROGRAMS
Follow the steps below to use a heart rate program.
Note: You must wear the optional chest pulse sen-
sor (see page 20) to use a heart rate program.
Put on the chest pulse sensor.
See the instructions included with the optional
chest pulse sensor.
Insert the key fully into the console.
See HOW TO TURN ON THE POWER on page
10.
Select a heart rate program.
When the key
is inserted, the
manual mode
will be se-
lected. To se-
lect a heart
rate program,
press the Program Select button repeatedly until
one of the two heart rate program indicators lights.
The two profiles on the left side of the matrix show
how the target heart rate will change during the
programs. During heart rate program 1, your heart
rate will reach approximately 85% of your esti-
mated maximum heart rate; during heart rate pro-
gram 2, your heart rate will reach approximately
80% of your estimated maximum heart rate.
Note: Your estimated maximum heart rate is de-
termined by subtracting your age from 220. For
example, if you are 30 years old, your estimated
maximum heart rate is 190 beats per minute
(220 – 30 = 190).
3
2
1
7
6
5
4
CAUTION: If you have heart prob-
lems, or if you are over 60 years of age and
have been inactive, do not use the heart rate
programs. If you are taking medication regu-
larly, consult your physician to find whether the
medication will affect your exercise heart rate.

14
During heart rate pro-
grams, the matrix will
show a graphic that
represents your heart
rate. Each time a heart-
beat is detected, an ad-
ditional peak will ap-
pear.
Enter your age and a maximum speed setting.
When a heart rate pro-
gram is selected, the
word “AGE” and the
current age setting will
flash in the Calories/
Pulse display. If you
have already entered
your age, simply press the Enter Age button. If
you have not entered your age, press the increase
and decrease buttons beside the Enter Age button
to enter your age. Then, press the Enter Age
button.
After you have entered
your age, the letters
“SPd” and the maxi-
mum speed setting of
the program will flash in
the Calories/Pulse dis-
play. If desired, press
the increase and decrease buttons beside the
Enter Age button to adjust the maximum speed
setting. When the desired setting is shown, press
the Enter Age button.
Press the Start button or the Speed increase
button to start the program.
A moment after the button is pressed, the tread-
mill will automatically adjust to the first speed and
incline settings of the program. Hold the handrails
and begin walking.
Each heart rate program is divided into several time
segments of different lengths. One target heart rate
is programmed for each segment.
During each segment, the console will regularly
compare your heart rate to the current target heart
rate. If your heart rate is too far below or above
the target heart rate, the speed of the treadmill will
automatically increase or decrease to bring your
heart rate closer to the target heart rate. If the
speed reaches the maximum speed setting of the
program (see step 4 at the left) and your heart
rate is still too far below the current target heart
rate, the incline of the treadmill will also increase
to bring your heart rate closer to the target heart
rate.
During the last three seconds of each segment, a
series of tones will sound and the Speed display
and the Distance/Incline display will flash.
The program will continue until no time remains in
the program. The walking belt will then slow to a
stop.
If the speed or incline setting is too high or too low
at any time during the program, you can adjust the
setting with the Speed or Incline buttons. However,
each time the console compares your heart rate to
the current target heart rate, the speed and/or in-
cline of the treadmill may automatically change to
bring your heart rate closer to the target heart
rate.
If your pulse is not detected during the program,
the letters “PLS” will flash in the Calories/
Pulse display and the speed and incline of the
treadmill may automatically decrease until your
pulse is detected. If this occurs, see the instruc-
tions included with the optional chest pulse sensor.
To stop the program at any time, press the Stop
button. Heart rate programs cannot be stopped
temporarily and then restarted. To use a heart rate
program again, reselect the program and start it at
the beginning.
Follow your progress with the displays.
See step 5 on page 10.
Turn on the fans if desired.
See step 7 on page 11.
When the program is finished, remove the key
from the console.
See step 7 on page 13.
8
7
6
5
4

HOW TO USE IFIT.COM CD PROGRAMS
When you use an iFIT.com CD program, a certified
personal trainer will guide you through your workout as
the program interactively controls the speed and in-
cline of the treadmill. Note: To purchase iFIT.com
CDs, call toll-free 1-800-735-0768.
Follow the steps below to use an iFIT.com CD program.
Insert the key into the console.
See HOW TO TURN ON THE POWER on page 10.
Select the iFIT.com mode.
When the key
is inserted,
the manual
mode will be
selected. To
use iFIT.com
CDs, press
the Interactive Trainer button. The iFIT.com indica-
tor will light.
Insert an iFIT.com CD into the CD player.
To open the
CD player,
press the lid
of the CD
player in the
indicated loca-
tion. Carefully
insert an
iFIT.com CD
into the CD
player and close the lid.
Press the Play/Pause button to start the
program.
To start the CD pro-
gram, press the Play/
Pause button beside
the CD player. A mo-
ment after the button is
pressed, your personal
trainer will begin guiding you through your workout.
Simply follow your personal trainer’s instructions.
Note: If the Time/Pace display is flashing, press
the Start button or the Speed increase button on
the console. The treadmill will not respond to a
CD program while the Time/Pace display is flash-
ing.
During the CD program, an electronic “chirping”
sound will alert you when the speed and/or incline
of the treadmill is about to change. CAUTION:
Always listen for the “chirp” and be prepared
for speed and/or incline changes. In some in-
stances, the speed and/or incline may change
before the personal trainer describes the
change.
If the speed or incline settings are too high or too
low, you can manually override the settings at any
time by pressing the Speed or Incline buttons on
the console. However, when the next “chirp” is
heard, the speed and/or incline will change to
the next settings of the CD program.
To stop the program at
any time, press the Stop
button on the console
and then press the
Play/Pause button be-
side the CD player. The
Time/Pace display will begin to flash. To restart
the program, press the Play/Pause button and
then press the Start button or the Speed increase
button on the console. After a moment, the walk-
ing belt will begin to move at 1 mph. When the
next “chirp” is heard, the speed and incline
will change to the next settings of the CD pro-
gram.
When the CD program is
completed, the walking
belt will slow to a stop
and the Time/Pace dis-
play will begin to flash.
Note: To select a differ-
ent program on the CD, press the Skip/Search
button beside the CD player.
Note: If the speed or incline of the treadmill
does not change when a “chirp” is heard, make
sure that the iFIT.com indicator is lit and that
the Time/Pace display is not flashing. If the
Time/Pace display is flashing, press the Start
button or the Speed increase button on the
console.
Adjust the volume if desired.
To adjust the volume,
press the Volume but-
tons beside the CD
player.
5
4
3
2
1
Skip/
Search
15
Play/
Pause
Play/
Pause
Volume

16
Follow your progress with the track and the
displays.
See step 5 on page 10.
Measure your heart rate if desired.
See step 6 on page 11.
Turn on the fans if desired.
See step 7 on page 11.
When the program is completed, remove the
key.
See step 7 on page 13.
CAUTION: Always remove iFIT.com CDs from
the CD player when you are finished using
them.
HOW TO PLAY MUSIC CDS
If desired, you can play your own music CDs in the CD
player. Before playing music CDs, select the manual
mode of the console (see HOW TO USE THE MAN-
UAL MODE on page 10). Note: Due to the nature of
CD players, the ability of the player to read a CD-
RW disk while a user is running vigorously on the
treadmill may be affected by factors such as the
condition of the CD-RW and the quality of the
burner used to create the CD-RW.
You can also use your own headphones with the CD
player. Headphones with foam ear cushions are rec-
ommended to minimize the chances of static electricity
shock. Plug your headphones into the jack below the
fan. Secure the headphone wire to your clothing to
keep the wire out of your way.
9
8
7
6

17
HOW TO CONNECT THE TREADMILL TO
YOUR VCR OR COMPUTER
HOW TO CONNECT THE TREADMILL TO YOUR
VCR
Note: If your VCR has an unused AUDIO OUT jack,
see instruction A below. If the AUDIO OUT jack is
being used, see instruction B. If you have a TV
with a built-in VCR, see instruction B.
A. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the included adapter.
Plug the adapter into the AUDIO OUT jack on your
VCR.
B. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the included adapter.
Plug the adapter into an RCA Y-adapter (available
at electronics stores). Next, remove the wire that is
currently plugged into the AUDIO OUT jack on your
VCR and plug the wire into the unused side of the
Y-adapter. Plug the Y-adapter into the AUDIO OUT
jack on your VCR.
HOW TO CONNECT THE TREADMILL TO YOUR
COMPUTER
Note: If your computer has a 3.5mm LINE OUT jack,
see instruction A. If your computer has only a
PHONES jack, see instruction B.
A. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the LINE OUT jack on
your computer.
B. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into a 3.5mm Y-adapter
(available at electronics stores). Plug the Y-adapter
into the PHONES jack on your computer. Plug your
headphones or speakers into the other side of the
Y-adapter.
AUDIO OUT
RIGHT
LEFT
VIDEO AUDIO
ANT.IN
RF OUT
IN
OUT
CH
34
C
Audio
Cable Adapter
A
VIDEO AUDIO
ANT.IN
RF OUT
IN
OUT
CH
34
Audio
Cable Adapter
B
Wire removed from
AUDIO OUT jack
RCA Y-adapter
LINE OUT
Audio
Cable
A
PHONES
Audio
Cable
B
3.5mm
Y-adapter
Headphones/Speakers

18
HOW TO USE IFIT.COM VIDEO PROGRAMS
To use iFIT.com videocassettes, the treadmill must be
connected to your VCR. See HOW TO CONNECT
THE TREADMILL TO YOUR VCR on page 17. Note:
To purchase iFIT.com videocassettes, call toll-free
1-800-735-0768.
Follow the steps below to use an iFIT.com video
program.
Insert the key into the console.
See HOW TO TURN ON THE POWER on page 10.
Select the iFIT.com mode.
When the key
is inserted,
the manual
mode will be
selected. To
use iFIT.com
videocas-
settes, press the iFIT.com button. The iFIT.com
indicator will light.
Insert the iFIT.com videocassette.
Insert the videocassette into your VCR.
Press the PLAY button on your VCR.
A moment after the button is pressed, your per-
sonal trainer will begin guiding you through your
workout. Simply follow your personal trainer’s
instructions. Note: If the Time/Pace display is
flashing, press the Start button or the Speed in-
crease button on the console. The treadmill will
not respond to a video program while the
Time/Pace display is flashing.
During the video program, an electronic “chirping”
sound will alert you when the speed and/or incline
of the treadmill is about to change. CAUTION:
Always listen for the “chirp” and be prepared
for speed and/or incline changes. In some in-
stances, the speed and/or incline may change
before the personal trainer describes the
change.
If the speed or incline settings are too high or too
low, you can manually override the settings at any
time by pressing the Speed or Incline buttons on
the console. However, when the next “chirp” is
heard, the speed and/or incline will change to
the next settings of the video program.
To stop the walking belt at any time, press the
Stop button on the console. The Time/Pace dis-
play will begin to flash. To restart the program,
press the Start button or the Speed increase but-
ton. After a moment, the walking belt will begin to
move at 1 mph. When the next “chirp” is heard,
the speed and incline will change to the next
settings of the video program.
When the video program is completed, the walking
belt will stop and the Time/Pace display will begin
to flash. Note: To use another video program,
press the Stop button or remove the key and go to
step 1 on this page.
Note: If the speed or incline of the treadmill
does not change when a “chirp” is heard:
• Make sure that the iFIT.com indicator is lit and
that the Time/Pace display is not flashing. If
the Time/Pace display is flashing, press the
Start button or the Speed increase button on
the console.
• Adjust the volume of your VCR. If the volume
is too high or too low, the console may not
detect the program signals.
• Make sure that the audio cable is properly
connected, that it is fully plugged in, and that
it is not wrapped around a power cord.
Follow your progress with the track and the
displays.
See step 5 on page 10.
Measure your heart rate if desired.
See step 6 on page 11.
Turn on the fans if desired.
See step 7 on page 11.
When the program is completed remove the
key.
See step 7 on page 13.
CAUTION: Always remove iFIT.com videocas-
settes from your VCR when you are finished
using them.
8
7
6
5
4
3
2
1

19
HOW TO USE PROGRAMS DIRECTLY FROM
OUR WEB SITE
To use programs from our Web site, the treadmill must
be connected to your home computer. See HOW TO
CONNECT THE TREADMILL TO YOUR COMPUTER
on page 17. In addition, you must have an internet
connection and an internet service provider. A list of
specific system requirements is found on our Web site.
Follow the steps below to use a program from our
Web site.
Insert the key into the console.
See HOW TO TURN ON THE POWER on page 10.
Select the iFIT.com mode.
When the key
is inserted, the
manual mode
will be se-
lected. To use
a program
from our Web
site, press the iFIT.com button. The iFIT.com indi-
cator will light.
Go to your computer and start an internet
connection.
Start your web browser, if necessary, and go to
our Web site at www.iFIT.com.
Follow the desired links on our Web site to se-
lect a program.
Read and follow the on-line instructions for using a
program.
Follow the on-line instructions to start the
program.
When you start the program, an on-screen count-
down will begin.
Return to the treadmill and stand on the foot
pads. Find the clip attached to the key and slide
the clip onto the waistband of your clothes.
When the on-screen countdown ends, the program
will begin and the walking belt will begin to move.
Hold the handrails, step onto the walking belt, and
begin walking. During the program, an electronic
“chirping” sound will alert you when the speed
and/or incline of the treadmill is about to change.
CAUTION: Always listen for the “chirp” and be
prepared for speed and/or incline changes.
If the speed or incline settings are too high or too
low, you can manually override the settings at any
time by pressing the Speed or Incline buttons on
the console. However, when the next “chirp” is
heard, the speed and/or incline will change to
the next settings of the program.
To stop the walking belt at any time, press the
Stop button on the console. The Time/Pace dis-
play will begin to flash. To restart the program,
press the Start button or the Speed increase but-
ton. After a moment, the walking belt will begin to
move at 1 mph. When the next “chirp” is heard,
the speed and incline will change to the next
settings of the program.
When the program is completed, the walking belt
will stop and the Time/Pace display will begin to
flash. Note: To use another program, press the
Stop button and go to step 5.
Note: If the speed or incline of the treadmill
does not change when a “chirp” is heard, make
sure that the iFIT.com indicator is lit and that
the Time/Pace display is not flashing. In addi-
tion, make sure that the audio cable is properly
connected, that it is fully plugged in, and that it
is not wrapped around a power cord.
Follow your progress with the track and the
displays.
See step 5 on page 10.
When the program has ended, remove the key.
See step 7 on page 13.
9
8
7
6
5
4
3
2
1

THE INFORMATION MODE/DEMO MODE
The console features an information mode that keeps
track of the total number of hours that the treadmill has
been operated and the total number of miles that the
walking belt has moved. The information mode also al-
lows you to switch the console from miles per hour to
kilometers per hour. In addition, the information mode
allows you to turn on and turn off the demo mode.
To select the information mode, hold down the Stop
button while inserting the key into the console. When
the information mode is selected, the following informa-
tion will be shown:
The Distance/Incline display
will show the total number of
miles (or kilometers) that the
walking belt has moved.
The Time/Pace display will
show the total number of
hours the treadmill has been
used.
An “E” for English miles or
an “M” for metric kilometers
will appear in the Speed dis-
play. Press the Speed in-
crease button to change the
unit of measurement.
IMPORTANT: The Calories/Pulse display should be
blank. If a “d” appears in the display, the console is in
the “demo” mode. This mode is intended to be used
only when a treadmill is displayed in a store. When the
console is in the demo mode, the power cord can be
plugged in, the key can be removed from the console,
and the displays and indicators on the console will au-
tomatically light in a preset sequence, although the
buttons on the console will not operate. If a “d” appears
in the Calories/Pulse display when the information
mode is selected, press the Speed decrease button
so the display is blank.
To exit the information mode, remove the key.
THE OPTIONAL CHEST PULSE SENSOR
An optional chest pulse
sensor features hands-
free operation and en-
ables you to use the con-
sole’s heart rate pro-
grams. To purchase a
chest pulse sensor, call
toll-free 1-800-734-2377.
HOW TO LEVEL THE TREADMILL
If the treadmill wheels
are touching the floor or
if the treadmill rocks
slightly, turn one or both
of the leveling feet
under the upright base
until the wheels are off
the floor and the rocking
motion is eliminated.
Note: If necessary, tip
the treadmill and use a
phillips screwdriver to
turn the leveling feet.
CHANGING THE ISOLATOR SPRINGS
The treadmill features Isolator Springs (6) that cushion
the walking platform. A pair of Gray Isolator Springs is
preinstalled on the treadmill. For a firmer walking plat-
form, the Gray Isolator Springs can be removed and
the included Blue Isolator Springs can be installed.
Fold the treadmill to the storage position (see page
21). Using an allen wrench, remove the two Isolator
Bracket Bolts (12) from one of the Isolator Brackets
(10). Remove the Gray Isolator Spring (6) from the
Isolator (7), and slide a Blue Isolator Spring onto the
Isolator. Insert the Isolator back into the circular chan-
nel in the Isolator Top Cap (5), and reattach the
Isolator Bracket with the Isolator Bracket Bolts; start
both Isolator Bracket Bolts before tightening either
of them.
Replace the other Gray Isolator Spring (6) in the same
way.
Leveling
Feet
Wheel
12
10 6
7
20
